2ADLG-TGSTSimultaneous Interpretation System

Power switch Display is illuminated: System in ON / operational mode Press the power button to turn the TG-500ST on. When display is illuminated, it indicates system is ready to use. Press the power button again to turn the TG-500ST off. Headphone output 3.5mm jack with volume control for monitoring Menu button Easy to use menu navigation button AB-01UHF Antenna Booster maybe used to compensate for RF loss associated with long coaxial cable operation. But be careful to avoid overloading the RF signa Prepare a standard tripod, microphone stand or other ceiling mount bracket, and a sufficient length of terminated coaxial cable if using ANT-100WD. AB-01UHF When two separate/different audio sources are connected to AF input L( I )/R( II ) on the rear panel, adjust this knob to choose the source you like to transmit. OLED screen AF L( I )/R( II )balance control Turn the knob left or right to set the audio balance of the transmitted signal Turn the knob left increases the audible volume of the AF L ( I ) channel and Turn it right increases the audible volume of the AF R ( II ) channel AF input volume control Turn the knob to adjust volume. Knob fully counter-clockwise will MUTE the audio volume RF Input (1~4) LED Indicators When the stationary transmitter is powered on and its RF output is connected to the ACR4 input, the corresponding RF input LED on the front panel of the ACR4 will light in blue. UHF 500 - 937.5 MHZ 0dB+2.5dB 10dBm (10mW) < -50dBc 4 BNC (Female) 1 BNC (Female) 50Ω DC 12V, 1.2A 215(W) x 157(D) x 43(H) mm 682 g Black half-rack metal housing Frequency range Gain MAX input power Intermodulation attenuation RF input RF output Impedance Power Supply Dimension Weight Enclosure Power switch 12V DC, 1.2A Max Power Input ACR4 4port Antenna Combiner Specification ACR 4 Front Panel 5 1 2 3 2 1 467 Multiple-Channel Wireless Interpretation / Monitor System DC In 15V 1.6A 5V charger output / Engineering service interface for product maintain and software update Multiple transmitters network loop connection AF input sensitivity level switch (Aux / Line level switchable) The ACR 4 is a broadband 4 RF input port antenna combiner designed to connect up to four transmitters to create large multi-channel systems. It operates over an ultra-wide frequency range of 500 to 937.5 MHz with four BNC RF inputs, one BNC RF output and four RF input blue status indicator LEDs. A 50 ohm load connector is attached to each RF input for use with no antenna input to prevent unwanted radio interference noise. ACR 4 greatly improves the transmission quality, reduces intermodulation distortion and signal loss due to multipath interference. The ACR 4 is compatible with the Linkx wireless fixed transmitter TG-100ST/200ST/ 300ST/288ST/500ST. The ACR 4 features a black, rugged, half-rack metal enclosure. The optional rack mount bracket kit allows you to mount one or two ACR 4 combiners into the 1 RU space of any standard 19-inch equipment rack. If there is no signal coming at the input, be sure to connect the included 50 ohm load connector to the BNC socket to prevent unwanted radio interference noise. Note: Audio output / Loop out / Balanced, 6.3mm jack Left ( I ) & Right ( II ) Audio input / Balanced, XLR & 6.3 combo Left ( I ) & Right ( II ) RF Antenna output, BNC socket Related products Connect standard dipole antenna AN0510-5501BBN Connect Directional Log Antenna ANT100WD with Antenna Booster AB-01UHF enhances signal transmission. Ideal for increasing operation range and reducing reliability concern from outside interference ANT-100WD: Directional UHF log antenna AB-01UHF Antenna Booster TG-500T: portable transmitter TG-500R: portable receiver eTour Digital UHF tour guide system up to 4pcs of Stationary Transmitters with 1pc of ACR4 4port Antenna Combiner ACR 4 Stationary Transmitter TG-500ST TG-500ST TG-500ST RF IN 4RF IN 3RF IN 2RF IN 1 (BNC socket) TG-500ST 3 Rear Panel 8 9 111213 14 10 RF INRF OUT Only use the power adaptor supplied to ensure safe operation. Plug power supply into TG-500ST and power cable into AC wall socket. Connect the Power Adaptor Connect the Headphone Condition: Cable length exceeds 10 meters parameter setup Installation and Setup Prepare a standard tripod, microphone stand or other ceiling mount bracket, and a sufficient length of terminated coaxial cable if using ANT-100WD. Use the AB-01UHF antenna booster to compensate for signal loss during long coaxial cable operation Set the RF power setting on the stationary transmitter to the appropriate level (it is recommended to start from the "Low" level) to avoid RF signal overload. Briefly press the power button, the receiver switches on and the display illuminates. To avoid permanently damaging your ears with extremely loud volume, turn the volume knob of the headphone to fully counter-clockwise (the minimum sound level ) before wearing your headphone. 1. 2. 3. Connect the headphone with 3.5mm jack and monitor the contents Wear the headphone and gradually turn up to reach your desired volume Press the ON/OFF Button TG-500ST AB-01UHF Antenna Booster + ANT-100WD Directional Log-Periodic Antenna STEP 1STEP 2STEP 3 STEP 2 STEP 1

Connect either standard Dipole Antenna AN0510-5501BBN or optional Directional Log-Periodic Antenna ANT-100WD to the RF OUT on the rear panel of stationary transmitter Connect the Antenna Press the Menu button and the Navigation button simultaneously for 3seconds until LOCK icon appears. Lock and Unlock the Transmitter Repeat the same step to Unlock Adjust the "Lock Mode" There are 4 different lock options on the transmitter. Go to the main menu, select "Lock Mode" and then adjust the setting as needed: AN0510-5501BBN Dipole Antenna ANT-100WD Directional Log-Periodic Antennaa <10 m 6 7 STEP 1STEP 2 Condition: Cable length less than 10 meters Remember to set the RF power to "High" while using ANT-100WD Directional Log-Periodic Antenna parameter setup TG-500ST Prepare a standard tripod, microphone stand or other ceiling mount bracket, and a sufficient length of terminated coaxial cable if using ANT-100WD. 1. Connect audio sources to Left (input I ) or Right (input II) input jacks on the rear panel 2. Adjust to the proper input sensitivity level (Line or Aux level) 3. Turn the AF VOL knob to the desired audio level 4. Connect Audio Input Sources Make sure the AF balance cursor is positioned at the center or shift to the L ( I )/ R( II ) channel according to where input source is connected Interpreter 1 Interpreter 2 Interpreter 3 OUT OUT IN IN Presenter IN STEP 1 STEP 3STEP 4STEP 2 TG-500R The following daisy chaining example describes how the presenter's sound source will be connected to a series of transmitter devices and sent simultaneously to the left (I) channel input of all transmitters. Turn the AF control knob clockwise to shift the AF Balance cursor to the Right to wireless transmit interpreter's audio information. Daisy Chaining Same Audio Input Sources To Multiple Stationary Transmitters Note: Shift the AF Balance cursor to the Left will transmit presenter's voice.

TG-500ST Safety Precautions Features Checking the Supplied Items Antenna Option Application Diagrams and Options Tour Guide & Broadcasting Application Simultaneous Interpretation Application Overview of the Operating Panel Installation and Setup Connect the Power Adaptor Connect the Headphone Lock and Unlock the Transmitter Connect Audio Input Sources Daisy Chaining Same Audio Input Sources to Multiple Stationary Transmitters Connect the Antenna Multiple-Channel Wireless Interpretation / Monitor System Network Connection Control - string process technology for group coordination and assignments across multiple transmitters Menu and Display Illustrations Frequency Specification Manufacturer Declarations Contents Manufacturer Declarations 2 3 4 4 5 6 6 7 9 9 9 10 11 12 13 15 17 19 21 21 21 FCC Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: . Reorient or relocate the receiving antenna. . Increase the separation between the equipment and receiver. . Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. . Consult the dealer or an experienced radio/TV technician for help. FCC Caution: To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. (Example - use only shielded interface cables when connecting to computer or peripheral devices). FCC Radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. TG-500ST Digital UHF Simultaneous Interpretation Specification Safety Precautions UHF 500-952 MHz 400m (with Directi onal log Antenna) GFSK - 42kHz 16bit< 1% 32ms - > 80 dB 20Hz~17KHz < 1% -10 ~ 50°C Hi: 10mW Mid: 5mW Lo: 2.51mW 2, Combo XLR & 6.3mm jack; electronically Balanced; Aux -10dBV,Line +4dBu 2, 6.3mm jack 3.5mm jack OLED BNC type DC 15V / 1.6A 215(W) x 190(D) x 44(H) mm 516 g Carrier frequency range RF range (open field) Modulation Frequency preparation Audio sampling Latency Nominal / Peak deviation Dynamic range Frequency response THD at 1KHz Operating temperature RF output power AF input with level switch Loop output Headphone output Screen Antenna Jack Power Dimension Weight The eTour ST single channel stationary transmitter is used to transmit reliable and optimal audio quality to eTour portable receiver. System provides superior transmission coverage and comprehensive solution with abundances of key features; suitable for mid-to-large scale of simultaneous interpretations and stationary guided tours. eTour ST series stationary transmitter handles multiple inputs (i.e. microphones and auxiliary devices) with adjustable settings. The OLED screen displays group status, input volumes and rich details of operation parameter. TG-500ST is compatible with TG-500 portable tour guide system. Ideal for flexible usage in the venues; completely fulfills group guide essential needs. OLED high-resolution screen with easy control menu navigation. Two inputs accept a wide variety of audio sources, XLR & 6.3 combo connector with selectable Aux / Line signal level Controllable AF L(I) / AF R(II) output balance Assorted frequency ranges available eTour String Process Technology for group coordination and assignments across multiple transmitters Adjustable RF output power Headphone monitors transmitting contents Enhanced transmitting distance by utilizing the directional log antenna ANT-100WD Main menuExtended menu Input Adjustment First check the model number of the main system purchased. The accessories supplied may differ depending on the model and your request. Menu and Display Illustrations Checking the Supplied Items Group code RF Power Link Lock Mode Displayed Time Version Reaet All Exit Menu item Function of the menus Group adjustment RF power adjustment:High/Middle/Low When there is an interconnection of multiple transmitter,the master transmitter will search and loop through all the transmitters and show briefly total number of transmitters on the screen when completed. Select lock option: All, Menu+Power, Menu+AF Level, Menu When power supply is connected, the system operation condition will turn On, stay Off or remain the same as Previous condition Time to exit the menu and return to home screen Modle number and version of the device Return all the parameters to factory default settings Exit the menu and return to home screen Group code AF input sensitivity level indicator (Aux / Line) Left ( I ) & Right ( II ) Audio signal level meter with overload/peak hold function Audio output volume RF output level Network control Master/Slave indicator Headphone volume Lock mode icon Power-on Mode UHF Directional Log Antenna ANT-100 500-950 Mhz B E C H F D G A TG-500ST Ad…
