2ADM5-EP-0685S23 24HR TWS

Zeeva International Limited Suite 1007B, 10th Floor, Exchange Tower, 33 Wang Chiu Road, Kowloon Bay, Hong Kong Tel: +852-2868 0511 | Fax: +852-2524 1986 E-mail: [email protected] 3/ 09/2023 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Declaration letter We, Zeeva International Limited hereby declare that we have a product named as S23 24HR TWS ( FCC ID:2ADM5-EP-0685; Model No.: EP-0685)was tested by China Certification ICT Co., Ltd (Dongguan) ,which has left earbud and right earbud. We would like to declare that the product has two units which are electrically identical; except left earbud have one resistance without functional to distinguish left earbud and right earbud.We confirm that all information above is true, and we’ll be responsible for all the consequences. Please contact me if you have any question. Sincerely Yours, Signature: Printed Name: Kevin Tso Title: Engineering & Compliance Manager

Zeeva International Limited Suite 1007B, 10th Floor, Exchange Tower, 33 Wang Chiu Road,Kowloon Bay, Hong Kong Tel: +852-2868 0511 | Fax: +852-2524 1986 E-mail: [email protected] Date: 3/09/2023 To: FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 We, Zeeva International Limited hereby declare that： Product Name: S23 24HR TWS Model No.: EP-0685 FCC ID: 2ADM5-EP-0685 For BT Mode: BLE 1M/2M ; are disable by software For Below are activated: Bluetooth BDR(GFSK) , EDR(π/4‐DQPSK), EDR(8DPSK) Except for the manufacturer, the end user does not have any capability to modify/change the RF parameters. We acknowledge that it is the manufacturer’s responsibility to provide the radio configurations to ensure compliance with Commission’s rules. Sincerely Yours, Signature: Printed Name: Kevin Tso Tiltle: Engineering & Compliance Manager

CFR 47 §2.911(d)(5)(i) Attestation Letter QA-FR-1006-A RC 02-08-2023 Zeeva International Limited Suite 1007B, 10th Floor, Exchange Tower, 33 Wang Chiu Road, Kowloon Bay, Hong Kong Tel: +852-2868 0511 | Fax: +852-2524 1986 E-mail: [email protected] Attestation Letter Date: 3/09/2023 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(5)(i) Filing FCC ID: 2ADM5-EP-0685 Zeeva International Limited (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Signature: Contact Person: Kevin Tso Title: Engineering & Compliance Manager Company Name: Zeeva International Limited Address: Suite 1007B, 10th Floor, Exchange Tower, 33 Wang Chiu Road, Kowloon Bay Hong Kong

CFR 47 §2.911 (d)(5)(ii) Attestation Letter QA-FR-1007-A RC 02-08-2023 Zeeva International Limited Suite 1007B, 10th Floor, Exchange Tower, 33 Wang Chiu Road, Kowloon Bay, Hong Kong Tel: +852-2868 0511 | Fax: +852-2524 1986 E-mail: [email protected] Attestation Letter Date: 03/09/2023 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(5)(ii) Filing FCC ID: 2ADM5-EP-0685 Zeeva International Limited (“the applicant”) certifies that as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Signature: Contact Person: Kevin Tso Title: Engineering & Compliance Manager Company Name: Zeeva International Limited Address: Suite 1007B, 10th Floor, Exchange Tower, 33 Wang Chiu Road, Kowloon Bay Hong Kong

Zeeva International Limited Suite 1007B, 10th Floor, Exchange Tower, 33 Wang Chiu Road, Kowloon Bay, Hong Kong Tel: +852-2868 0511 | Fax: +852-2524 1986 E-mail: [email protected] FCC Authorization 03/09/2023 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We, Zeeva International Limited the undersigned, hereby authorize China Certification ICT Co., Ltd (Dongguan) to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by China Certification ICT Co., Ltd (Dongguan) on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Signature: Printed Name: Kevin Tso Title: Engineering & Compliance Manager QA-FR-170-B

Zeeva International Limited Suite 1007B, 10th Floor, Exchange Tower, 33 Wang Chiu Road,Kowloon Bay, Hong Kong Tel: +852-2868 0511 | Fax: +852-2524 1986 E-mail: [email protected] 03/09/2023 Product Similarity Declaration FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern, We, Zeeva International Limited hereby declare that we have a product named as S23 24HR TWS (Model No.: EP-0685) FCC ID: 2ADM5-EP-0685 was tested by China Certification ICT Co., Ltd (Dongguan) , meanwhile, for our marketing purpose, we would like to list a series products on reports and certificate, all the Products are identical schematics, except for the difference of color appearance. No other changes are made to them. We confirm that all information above is true, and we’ll be responsible for all the consequences. Please contact me if you have any question. Sincerely Yours, Signature: Printed Name: Kevin Tso Title: Engineering & Compliance Manager

Date The Ass o Acc for t FCC Refe The belo A. S to af B. T the p Co n Base sam FCC Sin c Sign Prin Titl e:3/09/2023 Zeeva Inte r ociated User ording to the the FCC ID t C ID to be pr erring to the FCC ID wi l ow: Side surface ( ffix thelabel Top cover (B printing of th nclusion： ed on the abo mll for enabli C ID to the U cerely Your nature: nted Name: e: Engineer rnational Lim r Manual and e FCC Regul to be moved rinted. above quot e ll be moved t (A): The cur on the surfac ): The plastic he FCC ID ac ove descripti ing the FCC User manual rs, Kevin Tso ing & Compli FC mited here b d base charge lation and Gu to the User’ e, as the devi to the last pa rvature shape ce of the earb c logo of the ccording to b ion of area A ID to be pri l and chargin iance Manage Zeeva Int Suite 100 Road, Ko Tel: +852 E-mail: e CC ID Cover by submits ju er. uidance (KD s manual if t ice is too sma age of user’s e of the silico buds. e top cover d below referen A to B, we co inted onto an ng case er ternational Lim 07B, 10th Floo owloon Bay, H 2-2868 0511 | ngineering@ z r Letter ustification fo DB Publicatio the device is all (FCC ID: manual and one sleeve ba does not prov nce picture. onclude that ny surface, W mited or, Exchange T Hong Kong Fax: +852-2 5 zeeva.com for placing th on 784748 D unquestiona : 2ADM5-EP charging cas ack cover is n vide enough the device i s We therefore Tower, 33 Wa 524 1986 he FCC ID in D01 v09r01) a ably too smal P-0685) to be se. The detai not flat, so it physical spa s unquestion request to m ang Chiu n the allows ll for the e printed. ls are as t’s hard ace to fit nably too move the

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS Port

Labe Lab e el: el location

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS Uncover Chip Left Chip Antenna Right Chip Antenna left earbud have one resistance without functional to distinguish left earbud and right earbud

Circuit Description Battery (DC 3.7V) provides energy for the Bluetooth chip (AD6983B); Crystal oscillator (24MHz) provides the clock signal for the Bluetooth chip. Bluetooth signals get through a matching circuit, and then transmitted to the space through the antenna (2402-2480MHz). When the product is connected, the product can in two-way communication with other Bluetooth Devices, and then the device’s Bluetooth module sends Bluetooth signals into space, the product receives the Bluetooth signal through an antenna, transmission to the Bluetooth chip via matching circuit. Modulation Technique: GFSK, π/4-DQPSK, 8DPSK

China Certification ICT Co., Ltd (Dongguan) Report No.: CR230204911-00 Page 57 of 57 5. RF EXPOSURE EVALUATION 5.1 Applicable Standard FCC § 15.247 (i) Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. See §1.1307(b)(1) of this chapter . 5.2 Procedure According to 447498 D04 Interim General RF Exposure Guidance v01, clause 2.1.2- 1-mW Test Exemption: Per §1.1307(b)(3)(i)(A), a single RF source is exempt RF device (from the requirement to show data demonstrating compliance to RF exposure limits, as previously mentioned) if the available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption applies to all operating configurations and exposure conditions, for the frequency range 100 kHz to 100 GHz, regardless of fixed, mobile, or portable device exposure conditions. This is a standalone exemption, and it cannot be applied in conjunction with any other test exemption. 5.3 Measurement Result Frequency (MHz) Conducted output power including Tune- up Tolerance (dBm) Antenna Gain (dBi) The Greater of Conducted Power or ERP 1-mW Test Exemption dBm mW 2402-2480 -11-2.9-110.08 Compliant Note: The Conducted Power includin g Tune-up Tolerance was declared by manufacturer. Result: Compliant. RF Exposure is exemption. ===== END OF REPORT =====

1 Product specification Quick Reference Antenna model information Antenna Type PCB Frequency 2.4-2.5GHz Ant. Port Input Pwr.(dBm) 0(Typ.BT class 2 output power) Tot.Rad.Pwr.(dBm) -5.8(Input pwr-loss pwr) Peak EIRP(dBm) -2.9 Directivity(dBi) 1(all direction antenna) Efficiency(dB) -5.8(26.03%) Gain(dBi) -2.9(Peak Gain XY-plane) Maximum Power(dBm) -2.9(XY-plane) Minimum Power(dBm) -7.9(XY-plane) Average Power(dBm) -4.5(XY-plane) Max/Min Ratio(dB) 5(XY-plane) Max/Avg Ratio(dB) 1.6(XY-plane) Min/Avg Ratio(dB) -3.4(XY-plane) Average Gain(dB) -4.5(Avg Gain XY-plane) Antenna module & Size Antenna Gain Gain Table Unit in dB@ 2.44GHz XY-plane XZ-plane YZ-plane Efficiency Peak Avg Peak Avg Peak Avg -2.9 -4.5 -3.7 -6.9 -2.9 -6.1 26.03% Antenna Model ZXD-F9 Manufacturer Shenzhen zhongxiangda technology co., ltd 11th Floor, Jianghao Science Park Business Center, Jihua Road, Bantian, Longgang District, Shenzhen City, Guangdong Province 2 3 3D radiation pattern diagram XY-plane 4 XZ-plane YZ-plane

TEST REPORT Applicant: Zeeva International Limited Address: Suite 1007B, 10th Floor, Exchange Tower, 33 Wang Chiu Road, Kowloon Bay, Hong Kong FCC ID: 2ADM5-EP-0685 Product Name: S23 24HR TWS Standard(s): 47 CFR Part 15, Subpart C(15.247) ANSI C63.10-2013 KDB 558074 D01 15.247 Meas Guidance v05r02 The above equipment has been tested and found compliant with the requirement of the relative standards by China Certification ICT Co., Ltd (Dongguan) Report Number: CR230204911-00 Date Of Issue: 2023/3/9 Reviewed By: Sun Zhong Title: Manager Test Laboratory: China Certification ICT Co., Ltd (Dongguan) No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China Tel: +86-769-82016888 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230204911-00 Page 2 of 57 Test Facility The Test site used by China Certification ICT Co., Ltd (Dongguan) to collect test data is located on the No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China. The lab has been recognized as the FCC accredited lab under the KDB 974614 D01 and is listed in the FCC Public Access Link (PAL) database, FCC Registration No. : 442868, the FCC Designation No. : CN1314. The lab has been recognized by Innovation, Science and Economic Development Canada to test to Canadian radio equipment requirements, the CAB identifier: CN0123. Declarations China Certification ICT Co., Ltd (Dongguan) is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with a triangle symbol “▲”. Customer model name, addresses, names, trademarks etc. are not considered data. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report cannot be reproduced except in full, without prior written approval of the Company. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report may contain data that are not covered by the accreditation scope and shall be marked with an asterisk “★”. China Certification ICT Co., Ltd (Dongguan) Report No.: CR230204911-00 Page 3 of 57 CONTENTS T EST FACILITY .......................................................................................................................................... 2 DECLARATIONS .......................................................................................................................................... 2 DOCUMENT REVISION HISTORY .......................................................................................... 5 1. GENERAL INFORMATION .................................................................................................... 6 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ....................................................... 6 1.2 DESCRIPTION OF TEST CONFIGURATION ........................................................................................... 7 1.2.1 EUT Operation Condition: ............................................................................................................................. 7 1.2.2 Support Equipment List and Details .............................................................................................................. 7 1.2.3 Support Cable List and Details ...................................................................................................................... 7 1.2.4 Block Diagram of Test Setup ......................................................................................................................... 7 1.3 MEASUREMENT UNCERTAINTY .......................................................................................................... 8 2. SUMMARY OF TEST RESULTS ............................................................................................ 9 3. REQUIREMENTS AND TEST PROCEDURES .................................................................. 10 3.1 AC LINE CONDUCTED EMISSIONS .................................................................................................... 10 3.1.1 Applicable Standard ..................................................................................................................................... 10 3.1.2 EUT Setup.................................................................................................................................................... 11 3.1.3 EMI Test Receiver Setup ............................................................................................................................. 11 3.1.4 Test Procedure ............................................................................................................................................. 12 3.1.5 Corrected Amplitude & Margin Calculation ................................................................................................ 12 3.2 RADIATION SPURIOUS EMISSIONS .................................................................................................... 13 3.2.1 Applicable Standard ..................................................................................................................................... 13 3.2.2 EUT Setup.................................................................................................................................................... 13 3.2.3 EMI Test Receiver & Spectrum Analyzer Setup ......................................................................................... 14 3.2.4 Test Procedure ............................................................................................................................................. 14 3.2.5 Corrected Amplitude & Margin Calculation ................................................................................................ 14 3.3 20 DB EMISSION BANDWIDTH ........................................................................................................... 15 3.3.1 Appl…

Text truncated - open the document above for the full version.

EXHIBIT D - TEST SETUP PHOTOGRAPHS Radiated Emission Below 1GHz View Left Radiated Emission Below 1GHz View Right Radiated Emission Above 1GHz View Left
