2ADM5-GH-1003TXDUAL WIRELESS GAM HS

INSTRUCTION MANUAL Congratulations, and thank you for choosing the Elite Wireless Gaming Headset. This manual will help you operate the Elite Wireless Gaming Headset, but firstly you should familiarize yourself with the Bluetooth functionality of your mobile phone or other devices before using the Elite Wireless Gaming Headset. To use your Bluetooth headset, you must first pair your headset with a mobile phone or other Bluetooth device. Once your Bluetooth headset is paired to a specific mobile phone, they will remain paired and automatically recognize each other whenever they are within range. 5. Product Specification 6. FAQ Turn on your phone and ensure the Bluetooth function is activated. Turn on the headset, enter the Bluetooth pairing mode. Search your Bluetooth devices on your phone by following the phone’s instructions. Refer to your phone’s user manual for more information. After a few seconds the phone will list the “GH-1003” as a discover device. Select it and follow your phone’s instructions to select this pairing. Your phone will confirm the pairing, and then press Yes/OK. Use the USB Type-C charging cable accessory provided with this headset. Connect the USB Type-C plug to the USB Type-C port on the headset positioned at in headset diagram on page 3. Connect the USB plug to a USB port on wall adapter to activate charging. For your safety, please always use an appropriate 5V input charger/Adapter to charge the product. DO NOT USE Quick Charging USB Adapter to charge the product, as it might damage the product. **Make sure to keep the headset charging for a minimum of 2 hours before initial use. USB PlugUSB Type-C Plug 5 Please follow the rules depicted in this manual closely to ensure your safety. Before using this Bluetooth headset, we would strongly encourage you to read through this user manual. Do not modify, repair or dismantle this Bluetooth headset. Doing so may result in fires, electric shocks, complete breakdown of this Bluetooth headset, etc. All are not covered under warranty. Be more wary of any edges, uneven surfaces, metal parts, accessories and its packaging so as to prevent any possible injury or damage. Do not use an diluent or volatile liquid to clean the Bluetooth headset. Do not use the Bluetooth headset in a hazardous location. 1 X Elite Wireless Gaming Headset **Left Side of the headset 1 X USB Type-C Charging Cable 1 X USB Adapter1 X Instruction Manual 1 X 3.5mm Audio Cable 4.2. Pairing to Mobile phone or other device Pairing to a phone and Entertainment: Plug the USB Adapter to the USB Port of a host device(Such as a computer). Press and hold the Mode Button for 3 seconds to switch to Adapter Mode. The Headset will be paired automatically in few seconds. 4.3. Pairing by USB Adapter (2.4 GHz) Use the 3.5mm Audio Cable provided by the headset, plug any end of the 3.5mm Audio Cable to the 3.5mm Audio Jack of the headset, and then plug the other end to an Audio device. Note: The buttons on the headset will be disabled when connected with the 3.5mm Audio Cable. 4.4. Connected with 3.5mm Audio Jack 4.5. Charging your headset 4.1. General Functions FCC ID: 2ADM5-GH-1003 (Bluetooth Mode) FCC ID: 2ADM5-GH-1003TX (USB Adapter) 7. FCC Statement8. Battery Statement 2. Packaging Contents3. Headset Diagram Desired ResultRequired Action Use a mobile phone with Bluetooth function or other Bluetooth devices to perform necessary pairing action. Press and hold the Mode Button for 3 seconds to switch to Bluetooth Mode. After pairing, LED indicator will turn in blue. Plug the USB Type-C to the USB Type-C port. When charging, the LED indicator turns red. After full charging, the LED indicator turns off. Answering a Call Press and hold the On / Off Button for 3 seconds. After turning on, the LED indicator flashes red/blue. Press and hold the On / Off Button for 3 seconds. Voice AssistantTriple press On / Off button. Press On / Off button to answer phone call, press On / Off button again to end call. Short press 2 times to reject call. Microphone Mute / Unmute Press Mode button once. (Only available in Bluetooth and Adapter Mode) Charging Turn off Pairing with Bluetooth Turn on & enter the pairing mode Press and hold the Mode Button for 3 seconds to switch between Bluetooth Mode and Adapter Mode. A prompt sound will be heard from the headset. Mode change 4. How to use1. Introduction Table of Contents 1 Introduction ······························· 2 Packaging Contents ···················· 3 Connection Diagram ··················· 4 How To Use ······························ 4.1 General Function ·················· 4.2 Pairing To Mobile Phone ········· 4.3 Pairing by USB Adapter (2.4GHz) ····························· 4.4 Connected with 3.5mm Audio Jack ·························· 4.5 Charging Your Headset ·········· 5 Product Specification ·················· 6 FAQ ········································ 7 FCC Statement ·························· 8 Battery Statement ······················ 1 2 3 4 5 6 6 7 8 8 9 10 -The input voltage to the product is 5V 1A. -In order to charge the product in safe manner and reliable conditions, please only adopt certified appropriate charger/ adapter for charging the product. -Only charge the product at ambient temperatures between 10 °C / 50 °F and 40 °C / 104 °F. - Do not heat above 70 °C / 158 °F, e.g. Do not expose to sunlight or throw into fire. -Switch off the product after use. -Please note that we won’t take any responsibility for any wrong operation (e.g. Voltage higher than 5V) as this may result in severe injury or loss of property, and we cannot control the operating process during the time the user using this product. -In extreme cases, abuse or misuse of Lithium battery pack can lead to explosion, heat generation, fire development or smoke development. Safety instructions for the lithium battery and charging the product Keep All Relevant Information For Future Reference 1. Why is there no power even when the headset is turned on ? Ans:…

Text truncated - open the document above for the full version.

ZeevaInternationalLimited Suite 1007B,10th Floor, ExchangeTower,33 Wang Chiu Road,KowloonBay, Hong Kong, China Date: [2024.05.27 ] FederalCommunicationsCommission Authorizationand EvaluationDivision 7435 OaklandMills Road Columbia, MD 21046 FCC ID :2ADM5-GH-1003TX FRN: 0024102113 US Agent –AttestationStatement/ Part 2.911(d)(7) [ZeevaInternationalLimited]certifies,that as of [202 4.0 5.27 ], we have designatedFCC US Agent,LLC to acceptserviceof processon our behalffor FCC ID :2ADM5-GH-1003TX [ZeevaInternationalLimited], acceptsto maintainan agent of serviceof processin the United Statesfor no less than one year after her the granteehas permanentlyterminatedall marketing and importationof the applicableequipmentwithin the U.S., or the conclusionof any Commissionrelatedadministrativeor judicialproeitceedinginvolvingthe equipment,whichever is later. FCC US Agent,LLC, acceptsas of the date of the filing of this application,the obligationof being the designatedagent for the purposeof acceptingserviceof processon behalfof [Zeeva InternationalLimited]for FCC ID :2ADM5-GH-1003TX DesignatedAgentInformation: CompanyName:FCC US Agent,LLC FRN: 0033402884 Address:3722 IllinoisAvenue,Saint Charles,IL, 60174,USA ContactPerson:Tim Payne Phone:708-571-3148 Email:[email protected] Sincerely, Company:[ZeevaInternationalLimited]DesignatedAgent:FCC US Agent,LLC CompanyRepresentative:[KevinTso]DesignatedAgentRepresentative:Tim Payne Signature:[Signature]Signature:

Rev1/26/2023 (ZeevaInternationalLimited) EurofinsElectricalandElectronicTestingNA,Inc. 914WestPatapscoAvenue Baltimore,MD21230 USA Date:2024.06.19 Ref:AttestationStatementsPart2.911(d)(5)(i)Filing FCCID：2ADM5-GH-1003TX [ZeevaInternationalLimited](“theapplicant”)certifiesthattheequipmentforwhichauthorizationis soughtisnot“covered”equipmentprohibitedfromreceivinganequipmentauthorizationpursuantto section2.903oftheFCCrules. Sincerely, (Applicantsignature) (KEVINTSO) Rev1/26/2023 (ZeevaInternationalLimited) EurofinsElectricalandElectronicTestingNA,Inc. 914WestPatapscoAvenue Baltimore,MD21230 USA Date:2024.06.19 Ref:AttestationStatementsPart2.911(d)(5)(ii)Filing FCCID：2ADM5-GH-1003TX [ZeevaInternationalLimited](“theapplicant”)certifiesthat,asofthedateofthefilingoftheapplication, theapplicantisnotidentifiedontheCoveredList(asaspecificallynamedentityoranyofitssubsidiaries oraffiliates)asanentityproducing“covered” equipment. Sincerely, (Applicantsignature) (KEVINTSO)

ZeevaInternationalLimited 2024.06.19 EurofinsElectricalandElectronicTestingNA,Inc. 914WestPatapscoAvenue Baltimore,MD21230 RE:CONFIDENTIALITYREQUESTFOR( ProductName：DUALWIRELESSGAMHS ModelNumber：GH-1003 FCCID：2ADM5-GH-1003TX Applicant:ZeevaInternationalLimited Address: Suite1007B,10thFloor,ExchangeTower,33 WangChiuRoad,KowloonBay,HongKong, China ) ToWhomItMayConcern: Thisletterservesasanofficialrequestforconfidentialityundersections0.457and0.459 ofCFR47.Wehaverequestedthatthe(BlockDiagram,Schematics,Operational Description)requiredtobesubmittedwiththisapplicationbepermanentlywithheld frompublicreview. SPECIFYREASONFORREQUEST(Theabovematerialscontaintradesecrets andproprietaryinformationnotcustomarilyreleasedtothepublic.Thepublic disclosureofthesematerialsmaybeharmfultotheapplicantandprovide unjustifiedbenefitstoitscompetitors.) Pleasecontactmeifthereisanyinformationyoumayneed. Sincerely, KEVINTSO Mustbesignedbytheapplicantcontactcitedastechnicalornon-technicalcontactonthe 731formprovidedtoEurofinsMETLabs,orbytheauthorizedagentifanappropriate authorizedagentletterhasbeenprovided.Letterssignedbytheapplicantshouldbe placedonapplicantletterhead.

ZeevaInternationalLimited 2024.06.19 EurofinsElectricalandElectronicTestingNA,Inc. 914WestPatapscoAvenue Baltimore,MD21230 RE:LETTEROFAGENTAUTHORIZATION ToWhomItMayConcern: We,theundersigned,herebyauthorizeSamLvatEMTEK(DONGGUAN)CO.,LTD.toacton ourbehalfinallmattersrelatingtoapplicationforequipmentauthorization,includingthesigning ofalldocumentsrelatingtothesematters. Wealsoherebycertifythatnopartytotheapplicationauthorizedhereunderissubjecttothe denialofbenefits,includingFCCbenefits,pursuanttoSection5301oftheAnti-DrugAbuseAct of1988,21U.S.C.853(a). Thisagreementexpiresoneyearfromthecurrentdate. Sincerely, KEVINTSO Mustbesignedbytheapplicantcontactcitedastechnicalornon-technicalcontactonthe 731formprovidedtoEurofinsMETLabs,orbytheauthorizedagentifanappropriate authorizedagentletterhasbeenprovided.Letterssignedbytheapplicantshouldbe placedonapplicantletterhead.

ReportNo.EDG2405130269E001Page1of3Ver.1.0 FCCID:2ADM5-GH-1003TX ReportNo.EDG2405130269E001Page2of3Ver.1.0 ReportNo.EDG2405130269E001Page3of3Ver.1.0

ReportNo.EDG2405130269E001Page1of2Ver.1.0 FCCID:2ADM5-GH-1003TX BTANT ReportNo.EDG2405130269E001Page2of2Ver.1.0

ReportNo.EDG2405130269E00102RPage1of7Ver.1.0 TESTREPORT ProductName：DUALWIRELESSGAMHS ModelNumber：GH-1003 FCCID：2ADM5-GH-1003TX Preparedfor:ZeevaInternationalLimited Address:Suite1007B,10thFloor,ExchangeTower,33WangChiu Road,KowloonBay,HongKong,China Preparedby:EMTEK(DONGGUAN)CO.,LTD. Address:-1&2/F.,Building2,ZoneA,ZhongdaMarineBiotechnology ResearchandDevelopmentBase,No.9,XinchengAvenue, SongshanhuHigh-technologyIndustrialDevelopmentZone, Dongguan,Guangdong,China TEL:+86-0769-22807078 FAX:+86-0769-22807079 ReportNumber:EDG2405130269E00102R Date(s)ofTests:May13,2024toMay26,2024 Dateofissue:May27,2024 $二维码$ ReportNo.EDG2405130269E00102RPage2of7Ver.1.0 TableofContents 1.TESTRESULTCERTIFICATION...............................................................................................................................................3 2.EUTSPECIFICATION.................................................................................................................................................................5 3.TESTREQUIREMENT................................................................................................................................................................6 4.MEASUREMENTRESULT.........................................................................................................................................................7 ReportNo.EDG2405130269E00102RPage3of7Ver.1.0 1.TESTRESULTCERTIFICATION Applicant:ZeevaInternationalLimited Address: Suite1007B,10thFloor,ExchangeTower,33WangChiuRoad,KowloonBay, HongKong,China Manufacturer:ZeevaInternationalLimited Address: Suite1007B,10thFloor,ExchangeTower,33WangChiuRoad,KowloonBay, HongKong,China EUT:DUALWIRELESSGAMHS ModelName:GH-1003 Trademark:N/A MeasurementProcedureUsed: APPLICABLESTANDARDS STANDARDTESTRESULT §15.247(i),§2.1093 PASS TheaboveequipmentwastestedbyEMTEK(DONGGUAN)CO.,LTD.Thetestdata,dataevaluation,test procedures,andequipmentconfigurationsshowninthisreportweremadeinaccordancewiththeprocedures giveninANSIC63.10(2013)andtheenergyemittedbythesampleEUTtestedasdescribedinthisreportisin compliancewiththerequirementsofFCCRulesFCC§15.247(i),§2.1093. Thetestresultsofthisreportrelateonlytothetestedsampleidentifiedinthisreport DateofTest:May13,2024toMay26,2024 Preparedby: WarrenDeng/Editor Reviewer: TimDong/Supervisor Approve&AuthorizedSigner: SamLv/Manager ReportNo.EDG2405130269E00102RPage4of7Ver.1.0 ModifiedHistory VersionReportNo.RevisionDateSummary EDG2405130269E00102R/OriginalReport ReportNo.EDG2405130269E00102RPage5of7Ver.1.0 2. EUTSpecification CharacteristicsDescription Product:DUALWIRELESSGAMHS ModelNumber:GH-1003 SKU:9157192,9157193 UPC:1922340373370,1922340373387 COLOR:BLACK,WHITE Sample:1# DataRate: 1MbpsforGFSKmodulation 2MbpsforGFSKmodulation Modulation: GFSK OperatingFrequency Range(s): 2402-2480MHz NumberofChannels: 40channels TransmitPowerMax: -7.76dBm(0.000167W) AntennaGain:-0.58dBi Powersupply:DC5VfromUSB Evaluationapplied:MPEEvaluation SAREvaluation ReportNo.EDG2405130269E00102RPage6of7Ver.1.0 3. TestRequirement SAREvaluation Accordingto447498D01V06,systemsoperatingundertheprovisionsofthissectionshallbeoperatedina mannerthatensuresthatthepublicisnotexposedtoradiofrequencyenergylevelinexcessofthe Commission’sguidelines. RoutineSARevaluationreferstothatspecificallyrequiredby§2.1093,usingmeasurementsorcomputer simulation.WhenroutineSARevaluationisnotrequired,portabletransmitterswithoutputpowergreaterthan theapplicablelowthresholdrequireSARevaluationtoqualityforTCBapproval. OneantennaisavailablefortheEUT.Theminimumseparationdistanceis5mm. ReportNo.EDG2405130269E00102RPage7of7Ver.1.0 4. MeasurementResult Antennagain:-0.58dBi Transmit Frequency (MHz) Mode Measured Power (dBm) Tune upPower (dBm) Maxtuneup power (dBm) Calculation Result 1-gSAR 2402 GFSK（1M） -8.01 -8±1-7 0.06183 2440GFSK（1M）-7.84 -7±1-6 0.07853 2480GFSK（1M）-7.76 -7±1-6 0.07913 2402GFSK（2M）-8.09 -8±1-7 0.06183 2440GFSK（2M）-7.87 -7±1-6 0.07853 2480GFSK（2M）-7.85 -7±1-6 0.07913 AccordingtoKDB447498D01V06,nostand-alonerequiredforBTantenna,andnosimultaneousSAR measurementisrequired. ***EndofReport***

ReportNo.EDG2405130269E00101RPage1of57Ver.1.0 $二维码$ TESTREPORT ProductName：DUALWIRELESSGAMHS ModelNumber：GH-1003 FCCID：2ADM5-GH-1003TX Preparedfor:ZeevaInternationalLimited Address:Suite1007B,10thFloor,ExchangeTower,33WangChiu Road,KowloonBay,HongKong,China Preparedby:EMTEK(DONGGUAN)CO.,LTD. Address:-1&2/F.,Building2,ZoneA,ZhongdaMarineBiotechnology ResearchandDevelopmentBase,No.9,XinchengAvenue, SongshanhuHigh-technologyIndustrialDevelopmentZone, Dongguan,Guangdong,China TEL:+86-0769-22807078 FAX:+86-0769-22807079 ReportNumber:EDG2405130269E00101R Date(s)ofTests:May13,2024toMay26,2024 Dateofissue:May27,2024 ReportNo.EDG2405130269E00101RPage2of57Ver.1.0 TableofContents 1TESTRESULTCERTIFICATION..................................................................................................................................3 2EUTTECHNICALDESCRIPTION................................................................................................................................5 3SUMMARYOFTESTRESULT.....................................................................................................................................6 4TESTMETHODOLOGY.................................................................................................................................................7 4.1GENERALDESCRIPTIONOFAPPLIEDSTANDARDS......................................................................................7 4.2MEASUREMENTEQUIPMENTUSED..................................................................................................................7 4.3DESCRIPTIONOFTESTMODES..........................................................................................................................8 5FACILITIESANDACCREDITATIONS........................................................................................................................9 5.1FACILITIES.............................................................................................................................................................9 5.2EQUIPMENT............................................................................................................................................................9 5.3LABORATORYACCREDITATIONSANDLISTINGS.........................................................................................9 6TESTSYSTEMUNCERTAINTY.................................................................................................................................10 7SETUPOFEQUIPMENTUNDERTEST.....................................................................................................................11 7.1RADIOFREQUENCYTESTSETUP1.................................................................................................................11 7.2RADIOFREQUENCYTESTSETUP2.................................................................................................................11 7.3BLOCKDIAGRAMCONFIGURATIONOFTESTSYSTEM.............................................................................14 7.4SUPPORTEQUIPMENT.......................................................................................................................................14 8TESTREQUIREMENTS...............................................................................................................................................15 8.1DTS6DBBANDWIDTH.......................................................................................................................................15 8.2DTS99%BANDWIDTH.......................................................................................................................................19 8.3MAXIMUMPEAKCONDUCTEDOUTPUTPOWER........................................................................................23 8.4MAXIMUMPOWERSPECTRALDENSITY.......................................................................................................27 8.5UNWANTEDEMISSIONSINNON-RESTRICTEDFREQUENCYBANDS.....................................................31 8.6RADIATEDSPURIOUSEMISSION.....................................................................................................................45 8.7CONDUCTEDEMISSIONSTEST........................................................................................................................53 8.8ANTENNAAPPLICATION...................................................................................................................................56 ReportNo.EDG2405130269E00101RPage3of57Ver.1.0 1TESTRESULTCERTIFICATION Applicant:ZeevaInternationalLimited Address: Suite1007B,10thFloor,ExchangeTower,33WangChiuRoad,KowloonBay, HongKong,China Manufacturer:ZeevaInternationalLimited Address: Suite1007B,10thFloor,ExchangeTower,33WangChiuRoad,KowloonBay, HongKong,China EUT:DUALWIRELESSGAMHS ModelName:GH-1003 Trademark:N/A MeasurementProcedureUsed: APPLICABLESTANDARDS STANDARDTESTRESULT FCC47CFRPart2,SubpartJ FCC47CFRPart15,SubpartC PASS ICRSS-GEN,Issue5(04-2018)+A1(03-2019)+A2(02-2021) ICRSS-247Issue3(08-2023) PASS TheaboveequipmentwastestedbyEMTEK(DONGGUAN)CO.,LTD.Thetestdata,dataevaluation, testprocedures,andequipmentconfigurationsshowninthisreportweremadeinaccordancewiththe proceduresgiveninANSIC63.10(2013)andtheenergyemittedbythesampleEUTtestedasdescribed inthisreportisincompliancewiththerequirementsofFCCRulesPart2,Part15.247,ICRSS-247Issue 3andICRSS-GEN,Issue5. Thetestresultsofthisreportrelateonlytothetestedsampleidentifiedinthisreport. DateofTest:May13,2024toMay26,2024 Preparedby: WarrenDeng/ Editor Reviewer: TimDong/Supervisor Approve&AuthorizedSigner: SamLv/Manager ReportNo.EDG2405130269E00101RPage4of57Ver.1.0 ModifiedHistory VersionReportNo.RevisionDateSummary EDG2405130269E00101R/OriginalReport ReportNo.EDG2405130269E00101RPage5of57Ver.1.0 2EUTTECHNICALDESCRIPTION Note:formoredetails,pleaserefertotheUser’smanualoftheEUT. Characteristics Description Product: DUALWIRELESSGAMHS ModelNumber: GH-1003 Samplenumber:1# SKU:91…

Text truncated - open the document above for the full version.

ReportNo.EDG2405130269E00101RPage31of57Ver.1.0 8.5UNWANTEDEMISSIONSINNON-RESTRICTEDFREQUENCYBANDS 8.5.1ApplicableStandard AccordingtoFCCPart15.247(d)andKDB558074D0115.247MeasGuidancev05r02 AccordingtoRSS-2475.5 8.5.2ConformanceLimit Inany100kHzbandwidthoutsidethefrequencybandinwhichthespreadspectrumordigitally modulatedintentionalradiatorisoperating,theradiofrequencypowerthatisproducedbytheintentional radiatorshallbeatleast20dBbelowthatinthe100kHzbandwidthwithinthebandthatcontainsthe highestlevelofthedesiredpower,basedoneitheranRFconductedoraradiatedmeasurement, providedthetransmitterdemonstratescompliancewiththepeakconductedpowerlimits.Ifthe transmittercomplieswiththeconductedpowerlimitsbasedontheuseofRMSaveragingoveratime interval,aspermittedunderparagraph(b)(3)ofthissection,theattenuationrequiredunderthis paragraphshallbe30dBinsteadof20dB. 8.5.3TestConfiguration Testaccordingtoclause7.1radiofrequencytestsetup1 8.5.4TestProcedure Thetransmitteroutput(antennaport)wasconnectedtothespectrumanalyzer Referencelevelmeasurement Establishareferencelevelbyusingthefollowingprocedure: SetinstrumentcenterfrequencytoDTSchannelcenterfrequency. Setthespanto=1.5timestheDTSbandwidth. SettheRBW=100kHz. SettheVBW≥3xRBW. SetDetector=peak. SetSweeptime=autocouple. SetTracemode=maxhold. Allowtracetofullystabilize. UsethepeakmarkerfunctiontodeterminethemaximumPSDlevel. NotethatthechannelfoundtocontainthemaximumPSDlevelcanbeusedtoestablishthereference level. Band-edgemeasurement Usethefollowingspectrumanalyzersettings: Span=wideenoughtocapturethepeakleveloftheemissionoperatingonthechannelclosesttothe band-edge,aswellasanymodulationproductswhichfalloutsideoftheauthorizedbandofoperation SetRBW1%ofthespan=100kHzSetVBW3xRBW SetSweep=autoSetDetectorfunction=peakSetTrace=maxhold Allowthetracetostabilize.Setthemarkerontheemissionatthebandedge,oronthehighest modulationproductoutsideoftheband,ifthislevelisgreaterthanthatatthebandedge.Enablethe marker-deltafunction,thenusethemarker-to-peakfunctiontomovethemarkertothepeakofthe in-bandemission.Themarker-deltavaluenowdisplayedmustcomplywiththelimitspecifiedinthis Section. Emissionlevelmeasurement Setthecenterfrequencyandspantoencompassfrequencyrangetobemeasured. SettheRBW=100kHz. SettheVBW=300kHz. SetDetector=peak Sweeptime=autocouple. Tracemode=maxhold. Allowtracetofullystabilize. ReportNo.EDG2405130269E00101RPage32of57Ver.1.0 Usethepeakmarkerfunctiontodeterminethemaximumamplitudelevel. Ensurethattheamplitudeofallunwantedemissionsoutsideoftheauthorizedfrequencyband(excluding restrictedfrequencybands)areattenuatedbyatleasttheminimumrequirements.Reportthethree highestemissionsrelativetothelimit. 8.5.5TestResults Temperature: 25 ̊C RelativeHumidity: 45  ATMPressure:1011mbar Note:N/A Bandedge TestModeAntennaChNameFrequency[MHz]RefLevel[dBm]Result[dBm]Limit[dBm]Verdict BLE_1MAnt1Low2402-9.16-48.27≤-29.16PASS BLE_1MAnt1High2480-9.01-48.62≤-29.01PASS BLE_2MAnt1Low2402-9.32-43.91≤-29.32PASS BLE_2MAnt1High2480-9.19-48.25≤-29.19PASS ReportNo.EDG2405130269E00101RPage33of57Ver.1.0 BLE_1M-Ant1-2402-PASS BLE_1M-Ant1-2480-PASS ReportNo.EDG2405130269E00101RPage34of57Ver.1.0 BLE_2M-Ant1-2402-PASS BLE_2M-Ant1-2480-PASS ReportNo.EDG2405130269E00101RPage35of57Ver.1.0 ConductedSpuriousEmission TestModeAntennaFrequency[MHz] FreqRange [MHz] RefLevel [dBm] Result[dBm]Limit[dBm]Verdict BLE_1MAnt124020~Reference-9.71-9.71---PASS BLE_1MAnt1240230~1000-9.71-61.98≤-29.71PASS BLE_1MAnt124021000~26500-9.71-50.27≤-29.71PASS BLE_1MAnt124400~Reference-8.99-8.99---PASS BLE_1MAnt1244030~1000-8.99-61.89≤-28.99PASS BLE_1MAnt124401000~26500-8.99-50.82≤-28.99PASS BLE_1MAnt124800~Reference-9.87-9.87---PASS BLE_1MAnt1248030~1000-9.87-61.18≤-29.87PASS BLE_1MAnt124801000~26500-9.87-51.14≤-29.87PASS BLE_2MAnt124020~Reference-9.30-9.30---PASS BLE_2MAnt1240230~1000-9.30-61.65≤-29.3PASS BLE_2MAnt124021000~26500-9.30-50.37≤-29.3PASS BLE_2MAnt124400~Reference-12.25-12.25---PASS BLE_2MAnt1244030~1000-12.25-61.04≤-32.25PASS BLE_2MAnt124401000~26500-12.25-50.06≤-32.25PASS BLE_2MAnt124800~Reference-9.11-9.11---PASS BLE_2MAnt1248030~1000-9.11-61.27≤-29.11PASS BLE_2MAnt124801000~26500-9.11-50.32≤-29.11PASS ReportNo.EDG2405130269E00101RPage36of57Ver.1.0 BLE_1M-Ant1-2402-0~Reference-PASS BLE_1M-Ant1-2402-30~1000-PASS ReportNo.EDG2405130269E00101RPage37of57Ver.1.0 BLE_1M-Ant1-2402-1000~26500-PASS BLE_1M-Ant1-2440-0~Reference-PASS ReportNo.EDG2405130269E00101RPage38of57Ver.1.0 BLE_1M-Ant1-2440-30~1000-PASS BLE_1M-Ant1-2440-1000~26500-PASS ReportNo.EDG2405130269E00101RPage39of57Ver.1.0 BLE_1M-Ant1-2480-0~Reference-PASS BLE_1M-Ant1-2480-30~1000-PASS ReportNo.EDG2405130269E00101RPage40of57Ver.1.0 BLE_1M-Ant1-2480-1000~26500-PASS BLE_2M-Ant1-2402-0~Reference-PASS ReportNo.EDG2405130269E00101RPage41of57Ver.1.0 BLE_2M-Ant1-2402-30~1000-PASS BLE_2M-Ant1-2402-1000~26500-PASS ReportNo.EDG2405130269E00101RPage42of57Ver.1.0 BLE_2M-Ant1-2440-0~Reference-PASS BLE_2M-Ant1-2440-30~1000-PASS ReportNo.EDG2405130269E00101RPage43of57Ver.1.0 BLE_2M-Ant1-2440-1000~26500-PASS BLE_2M-Ant1-2480-0~Reference-PASS ReportNo.EDG2405130269E00101RPage44of57Ver.1.0 BLE_2M-Ant1-2480-30~1000-PASS BLE_2M-Ant1-2480-1000~26500-PASS ReportNo.EDG2405130269E00101RPage45of57Ver.1.0 8.6RADIATEDSPURIOUSEMISSION 8.6.1ApplicableStandard AccordingtoFCCPart15.247(d),15.205,15.209andKDB558074D0115.247MeasGuidancev05r02 AccordingtoICRSS-GenandRSS-247 8.6.2ConformanceLimit AccordingtoFCCPart15.247(d):radiatedemissionswhichfallintherestrictedbands,asdefinedin §15.205(a),mustalsocomplywiththeradiatedemissionlimitsspecifiedin§15.209(a)(see§15.205(c)). AccordingtoFCCPart15.205,Restrictedbands MHzMHzMHzGHz 0.090-0.11016.42-16.423399.9-4104.5-5.15 10.495-0.50516.69475-16.69525608-6145.35-5.46 2.1735-2.190516.80425-16.80475960-12407.25-7.75 4.125-4.12825.5-25.671300-14278.025-8.5 4.17725-4.1777537.5-38.251435-1626.59.0-9.2 4.20725-4.2077573-74.61645.5-1646.59.3-9.5 6.215-6.21874.8-75.21660-171010.6-12.7 6.26775-6.26825123-1382200-230014.47-14.5 8.291-8.294149.9-150.052310-239015.…

Text truncated - open the document above for the full version.

Inverted F Antenna Specification Summary ITEMANT SPEC Model Name 2.4G ANT HorizontalVertical 2400MHz 2450MHz2500MHz2400MHz2450MHz2500MHz Center Frequency -1.26-0.76-0.58-5.25-2.46-1.86 MAX. Gain -0.58dB PolarizationHorizontal and Vertical Azimuth Beam Pattern Omni-directional Impedance50 Ohm Antenna Length 38.20mm Manufacture ZHUHAI JIELI TECHNOLOGY CO.,LTD Antenna Photo & Length (mm) Horizontal:2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -40 Scale: 5/div Gain(dB) Frequency (MHz) Max Min Avg 2400 -1.26174 -30.0801 -7.18716 2450 -0.765802 -36.5604 -7.48023 2500 -0.585582 -22.0315 -6.59127 Vertical:2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -30 Scale: 5/div Gain (dB) Frequency (MHz) MaxMinAvg 2400-5.2537-22.1424-12.4294 2450-2.4652-24.5837-10.4702 2500-1.86120-29.5214-9.20432 ANT Test Labs˖Attestation of Global Compliance Co., Ltd.
