2ADPCS650Wireless High Precision GNSS Positioning Terminal

User Guide for GNSS BOX ----------- S650/S660 1 1．SAFETY PRECAUTIONS .................................................................................................................................................... 2 2. HIGH PRECISION GNSS BOX S650 ..................................................................................................................................... 3 2.1 PROFILE ........................................................................................................................................................................................... 3 2.2 SPECIFICATIONS ............................................................................................................................................................................... 4 2.3 STANDARD LIST ............................................................................................................................................................................... 5 2.4PRINCIPLE OF HIGH PRECISION GNSS S650 ..................................................................................................................................... 5 2.4.1. Positioning principle .............................................................................................................................................................. 5 2.4.2 Advantages of GNSS BOX S650/S660 ..................................................................................................................................... 6 3. OPERATION (TAKE S650 FOR AN EXAMPLE) .................................................................................................................. 7 3.1 CHARGE ........................................................................................................................................................................................... 7 3.2 POWER ON/OFF .............................................................................................................................................................................. 8 3.3 BLUETOOTH CONNECTION ............................................................................................................................................................... 8 3.4 SATELLITE SIGNALS ......................................................................................................................................................................... 9 3.5 DATA C O M M U N I C AT I O N .................................................................................................................................................................... 9 4. SAFETY WARNINGS AND ATTENTIONS .......................................................................................................................... 10 4.1 SAFETY WARNINGS ........................................................................................................................................................................ 10 4.2 ATTENTIONS ................................................................................................................................................................................... 10 2 1．Safety precautions In order to use the product correctly and safely, please read the safety instructions below carefully before use. Please turn off the product where ban to use the product, or use the product may cause interference or danger. Please do not place the product or accessories in appliance with strong electromagnetic field. Do not use the product when driving a car in order to avoid interfering with safe driving. Please keep the product far away from the magnetic equipment; otherwise the radiation of the product may erase the information stored on the magnetic equipment. In the medical place, please comply with the relevant provisions or regulations. Near the medical equipment, please turn off the product. Please don’t use the product close to high temperature place, or near flammable gases( such as gas stations) Please close the product when boarding the plane, lest the wireless signal interfering plane control signals. Please place the product and accessories where children can't touch, avoid the children using the product without supervise. Close to high precision electronic equipment, please shut down the product, otherwise it may lead to electronic equipment failure. Please use the specified batteries and chargers, otherwise, may cause explosion. Without authorization, please don’t disassemble the product or the accessories, only authorized technician can repair the product. When using the product, please comply with the relevant laws and regulations, and respect others' privacy and legal rights. 3 2. High precision GNSS BOX S650 2.1 Profile Fig.1-S650 mainframe Fig.2 Power key Fig.3-Indicators Fig.4-miniUSB port 4 2.2 Specifications Configuration Parameters Options Support PDA Windows Mobile /CE √ Android √ WIN7\WIN8 √ IOS Development pending GNSS GPS L1，L2， with carrier phase smoothing √ GLONASS L1、L2 √ Compass B1、B2、B3（optional） √ support data format NMEA-0183，TSIP √ I/O protocol RTCM3、RTCA、CMR and so on √ Data updating rate 1Hz √ recapture time <1s √ Cold start <30s √ Positioning accuracy point positioning 2m √ External source accuracy 5cm √ SBAS 1m √ Static accuracy 3mm+1ppm √ Data communication Data interface MicroUSB √ Bluetooth Bluetooth V2.1 Class 2 support EDR √ Power supply Battery 3.6V,6200mAh √ removable 5400mAh lithium battery，3.6V √ Working time More than 10 hours typically √ Environment characteristic Operating temperature -20°C — +25°C √ Storage temperature -30°C — +25°C √ Quick-proof 1.5m natural fall to the ground √ IP IP67 √ Physics Measurement（cm） 10×10×3.5 √ Weight 305 g √ 5 2.3 Standard list Item No Name model name Quantity 1 S660/S650 receiver 1 2 MicroUSB data cable USB-2 1 3 S660/S650 holder TP-S650 1 4 S660/S650 Adapter PSAI10R-050Q1 5 Packaging box 1 2.4 Principle of High precision GNSS S650 …

Text truncated - open the document above for the full version.

FCC INFORMATION This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.

Guangzhou SOUTH Surveying & Mapping Instrument Co., Ltd. Authorization Letter Number: CF101 Version: V03 Date: 01-08-2011 We, (the approval holder) Company name Guangzhou SOUTH Surveying & Mapping Instrument Co., Ltd. Addresss Room 301 South Building, No.24-26 Keyun Road, Tian He District, City Guangzhou Country China declare that the following representative (agent): Name (person) Jams .zhang Function Manager Company name Shenzhen BCTC Technology Co., Ltd. Address A.Floor 3, 44 Building, Tanglang Industrial Park B, Taoyuan Street, Nanshan District, City Shenzhen, Country China is hereby authorized to apply and sign the following equipment for certification, registration or filing on our behalf: Product Description Wireless high precision GNSS positionning terminal Type or Model(s) S650, S660 Tradename or Brand(s) SOUTH We also authorize Teleconformity (Mr. M. Koop, Manager Certification, Address: Rietven 31, 7534NH Enschede, the Netherlands) to apply and sign this application for certification, registration or filing on our behalf (as representative agent or certifier). Attestation: City and Country: Date:Name: (this must be a person) Function:Signature: (or official company stamp) Shenzhen 2014.12.25 Shusheng Wen Vice General Manager

SHENZHEN Hitevision Technology Co., Ltd. FCC Declaration of Conformity Number: CF302 Version: V03 Date: 22-08-2011 A declaration of conformity can only be issued by a U.S. entity based on a test report from an accredited laboratory. Accredited laboratories are located in the US, or in a country where the FCC has signed an MRA with. For a full list of accredited laboratories recognized by the FCC, please go to the FCC website https://fjallfoss.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm and for Test Firm Type, select “Accredited”. Additional information on administrative requirements for Declaration of Conformity can be found in KDB Publication Number 349827 . We, (responsible party must be a legal entity registered within the U.S., see FCC rule part 2.909 (2), must a U.S. address, such as importer or local manufacturer) Company Name: Guangzhou SOUTH Surveying & Mapping Instrument Co., Ltd. Address: Room 301 South Building, No.24-26 Keyun Road, Tian He District, Postal/Zip: City: Shenzhen State/Province: Country: China Contact Person: Mr. Ms. Name: Shusheng Wen Function: Email: [email protected] Web: Phone: +86- 13922455286 Fax: +86-20- 22131299 declare for the equipment identified by: Product Description Wireless high precision GNSS positionning terminal Type or Model(s) S650, S660 Tradename or Brand(s) SOUTH that: (if the DoC test reports are available at this moment, please cross item a below) a). The following test reports, issued by an FCC accredited Laboratory, are subject to this declaration: Accredited Test Firm or Laboratory name: Test Report Number: Date of issue: (if no DoC test report is available at this moment, then if you agree with the statement made in item b below, please cross item b below) b). DoC testing is pending at this moment, but will execute and finish the required DoC testing in an FCC accredited Laboratory before marketing the device in the U.S. The following Accredited Test Firm will complete DoC testing: Accredited Test Firm or Laboratory name: HK Standards and Testing Centre (HKSTC) Add: 38/F, Office Tower, Convention Plaza, 1 Harbour Road, Wanchai, Hong Kong Attestation: In addition to our declaration above, we also will ensure to label the equipment with the FCC logo, the name of the manufacturer and model number, as required by the FCC rule part 15.19 . City and Country: Date:Name: (this must be a person) Function:Signature: (or official company stamp) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. DoC SHENZHEN Hitevision Technology Co., Ltd. FCC Declaration of Conformity Number: CF302 Version: V03 Date: 22-08-2011 Shenzhen 2014.12.25 Shusheng Wen Vice General Manager

Guangzhou SOUTH Surveying & Mapping Instrument Co., Ltd. FCC Confidentiality Request Number: CF303 Version: V02 Date:17-06-2011 To: Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name Guangzhou SOUTH Surveying & Mapping Instrument Co., Ltd. Address Room 301 South Building, No.24-26 Keyun Road, Tian He District, City Guangzhou Country China request for this certification filing under: Grantee Code Product Number FCC ID: 2ADPC S650 to maintain permanent confidentiality for the following documents submitted within this application: (please cross what is applicable, or add other documents, provide the file name and description) Exhibit Description X Operational Description Description of the circuit functions X Block Diagrams Details of device showing the frequency of all oscillators X Schematics Diagrams All circuitry of devices and component values Bill of Materials Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. The documents indicated as confidential above, are not publicly available elsewhere. Attestation: City and Country: Date: Name: (this must be a person) Function:Signature: (or official company stamp) Shenzhen 2014.12.25 Shusheng Wen Vice General Manager

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation.

FCC RADIO TEST REPORT FCC ID: 2ADPCS650 Product： Wireless high precision GNSS positionning terminal Trade Name： SOUTH Model Name： S650 Serial Model： S660 Report No.： BCTC-20141203281F Prepared for Guangzhou SOUTH Surveying & Mapping Instrument Co., Ltd. Room 301 South Building, No.24-26 Keyun Road, Tian He District, Guangzhou, China Prepared by Shenzhen BCTC Technology Co., Ltd. A.Floor 3, 44 Building, Tanglang Industrial Park B, Taoyuan Street, Nanshan District, Shenzhen, China Page 2 of 88 Report No.: BCTC-20141203281F TEST RESULT CERTIFICATION Applicant’s name ................. : Guangzhou SOUTH Surveying & Mapping Instrument Co., Ltd. Address ................................. : Room 301 South Building, No.24-26 Keyun Road, Tian He District, Guangzhou, China Manufacture's Name ............ : Guangzhou SOUTH Surveying & Mapping Instrument Co., Ltd. Address ................................. : Room 301 South Building, No.24-26 Keyun Road, Tian He District, Guangzhou, China Product description Product name ........................... : Wireless high precision GNSS positionning terminal Model and/or type reference : S650 Serial Model： S660 Standards ............................. : FCC Part15.247 Test procedure ..............................ANSI C63.4-2003 This device described above has been tested by BCTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date (s) of performance of tests ............. : 21 Nov. 2014 ~29 Nov. 2014 Date of Issue ........................................... : 01 Dec. 2014 Test Result ............................................... : Pass Testing Engineer : (Lynn Chen) Technical Manager : (Carlen Liu) Authorized Signatory : (Tommy Zhang) Page 3 of 88 Report No.: BCTC-20141203281F Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 9 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS (BELOW 30 MHZ) 21 3.2.7 TEST RESULTS (BETWEEN 30M – 1000 MHZ) 22 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 24 3.2.9 TEST RESULTS (RESTRICTED BANDS REQUIREMENTS) 42 4 . NUMBER OF HOPPING CHANNEL 54 4.1 APPLIED PROCEDURES / LIMIT 54 4.1.1 TEST PROCEDURE 54 4.1.2 DEVIATION FROM STANDARD 54 4.1.3 TEST SETUP 54 4.1.4 EUT OPERATION CONDITIONS 54 4.1.5 TEST RESULTS 55 5 . AVERAGE TIME OF OCCUPANCY 57 Page 4 of 88 Report No.: BCTC-20141203281F Table of Contents Page 5.1 APPLIED PROCEDURES / LIMIT 57 5.1.1 TEST PROCEDURE 57 5.1.2 DEVIATION FROM STANDARD 57 5.1.3 TEST SETUP 58 5.1.4 EUT OPERATION CONDITIONS 58 5.1.5 TEST RESULTS 59 6 . HOPPING CHANNEL SEPARATION MEASUREMENT 65 6.1 APPLIED PROCEDURES / LIMIT 65 6.1.1 TEST PROCEDURE 65 6.1.2 DEVIATION FROM STANDARD 65 6.1.3 TEST SETUP 65 6.1.4 EUT OPERATION CONDITIONS 65 6.1.5 TEST RESULTS 66 7 . BANDWIDTH TEST 72 7.1 APPLIED PROCEDURES / LIMIT 72 7.1.1 TEST PROCEDURE 72 7.1.2 DEVIATION FROM STANDARD 72 7.1.3 TEST SETUP 72 7.1.4 EUT OPERATION CONDITIONS 72 7.1.5 TEST RESULTS 73 8 . PEAK OUTPUT POWER TEST 79 8.1 APPLIED PROCEDURES / LIMIT 79 8.1.1 TEST PROCEDURE 79 8.1.2 DEVIATION FROM STANDARD 79 8.1.3 TEST SETUP 79 8.1.4 EUT OPERATION CONDITIONS 79 8.1.5 TEST RESULTS 80 9 . ANTENNA REQUIREMENT 86 9.1 STANDARD REQUIREMENT 86 9.2 EUT ANTENNA 86 10 . EUT TEST PHOTO 87 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 88 Report No.: BCTC-20141203281F 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(a)(1) Hopping Channel Separation PASS 15.247(b)(1) Peak Output Power PASS 15.247(c) Radiated Spurious Emission PASS 15.247(a)(iii) Number of Hopping Frequency PASS 15.247(a)(iii) Dwell Time PASS 15.247(a)(1) Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 88 Report No.: BCTC-20141203281F 1.1 TEST FACILITY BZT Testing Technology Co., Ltd. Add.:1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registered No.: 701733 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 88 Report No.: BCTC-20141203281F 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Wireless high precision GNSS positionning terminal Trade Name SOUTH Model Name S650 Serial Model S660 Model Difference These two models are the same, just have different in the shape and model name. Model S650 is square and model S660 is circl…

Text truncated - open the document above for the full version.

Page 87 of 88 Report No.: BCTC-20141203281F 10. EUT TEST PHOTO Radiated Measurement Photos Page 88 of 88 Report No.: BCTC-20141203281F Conducted Emission Photos
