2ADQJ-Y89359WiFi/BT Combo Module

1 Global IT Leader in Automotive BWR-Y89359 manual 1)Host Interface for Bluetooth: 4 Pins (BT_UART_TXD, BT_UART_RXD, BT_UART_CTS, BT_UART_RTS) 2)Audio Interface for Bluetooth: 4 Pins (BT_PCM_CLK, BT_PCM_SYNC, BT_PCM_IN, BT_PCM_OUT) 3)Host Interface for Wi- Fi: 6Pins (SDIO_CMD, SDIO_CLK, SDIO_DATA0, SDIO_DATA1, SDIO_DATA2, SDIO_DATA3) 4)Bluetooth/Wi-Fi On/Off and Reset: 2Pins (BT_REG_ON for Bluetooth, WIFI_REG_ON for Wi- Fi) 5)Controlled by Module to wake-up Host. (Optional) 6)External LPO 32.768KHz Clock. (Optional) 7)Host Interface for WIFI : P CIeor SDIO 1. BWR-Y89359 Information #. BWR-Y89359SMA is a WiFi/Bluetooth Combo Module #. Module type : 48 pin SMD type #. RoHS compliant #. This module has deployed part which ar e AEC-Q100 qualified 2. Configuration 2 Global IT Leader in Automotive BWR-Y89359 Manual 3. Specification 1) Operating temperature Range : -40 ~ +85°C 2) Power Voltage : 3.3V Top View VBAT (3.3V) VIO (3.3V) VIO_SDIO (1.8V) 1PCIE_CLK_P17WL_REG_ON33BT_UART_RTS_N 2PCIE_CLK_N18BT_REG_ON34BT_UART_CTS_N 3PCIE_TD_N19BT_PCM_CLK35BT_UART_RXD 4PCIE_TD_P20BT_PCM_SYNC36BT_UART_TXD 5SDIO_CLK21BT_PCM_IN37VIO 6SDIO_CMD22BT_PCM_OUT38SDIO_DIS 7SDIO_DATA323WL_ANT_CORE039PCIE_EN 8SDIO_DATA224GND40PCIE_PME_L 9SDIO_DATA125LPO41PCIE_PERST_N 10SDIO_DATA026GND42PCIE_CLKREQ 11SECI_IN27VER_VOLTAGE43PCIE_RD_P 12SECI_OUT28WL_HOST_WAKE_UP44PCIE_RD_N 13VBAT29GND45GND 14VBAT30GND46GND 15VIO_SDIO31WL_ANT_CORE147GND 16BT_ANT32SDIO_PAD48GND WLAN ANT BT ANT 3 Global IT Leader in Automotive BWR-Y89359 Manual 4. Module Integration Guide 1) Applicable FCC Rule CFR 47 Part 15.247, 15.407 2) Operational Condition The module is limited to OEM installation ONLY. The OEM integrator is responsible for ensuring that the end-user has no manual instruction to removeorinstall module. 3) Limited Module Procedure BWR-B89359SMA is limited Module. The module doesn't have its own power supply regulation. Therefore, the host product manufacturer must design the host product so that a constant voltage of 3.3V is applied to the module. 4) Trace antenna desings: N/A 4 Global IT Leader in Automotive BWR-Y89359 Manual 4. Module Integration Guide 5) RF Exposure consideration (CFR 47 Part 1, 1.1307(b), 1.1310) This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum 20 cm between the radiator and human body. 6) Antenna This modular has PCB pattern antenna. Any changes of antenna designs might require additional assessment. The Host antenna type shall be same type and antenna gain shall be less or equal to below information Antenna Gain Frequency (MHz)Antenna Gain (dBi) Bluetooth2 400 ~ 2 483.53.36 WLAN (2.4G)2 400 ~ 2 483.51.22 WLAN (5G) 5 150 ~ 5 2503.49 5 250 ~ 5 3503.98 5 470 ~ 5 7254.83 5 725 ~ 5 8502.30 5 Global IT Leader in Automotive BWR-Y89359 Manual 4. Module Integration Guide 7) Label and compliance information The end user manual shall include all required regulatory information/warningasshown in this manual. If the FCC identification number is not visible when the module isinstalledinside another device, then the outside of the device into which the module isinstalledmust also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains FCC ID : 2ADQJ-Y89359” any similar wording that expresses the same meaning may be used. 8) Information on test modes and additional testing requirements This modular was tested in standalone configuration. Integration of this modular into ahostequipment would require additional testing. 9) Additional testing, Part 15 Subpart B disclaimer The grantee should include a statement that the modular transmitter is only FCC authorized for the specific rule parts (i.e., FCC transmitter rules) listed on the grant, and that the host product manufacturer is responsible for compliance to any otherFCC rules that apply to the host not covered by the modular transmitter grant of certification. If the grantee markets their product as being Part 15 Subpart B compliant (when it also contains unintentional-radiator digital circuity), then the grantee shall provide a notice stating that the final host product still requires Part 15 Subpart B compliance testing with the modular transmitter installed. 6 Global IT Leader in Automotive BWR-Y89359 Manual 4. Module Integration Guide 10) ISED Statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence- exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference.(2) This device must acceptany interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) L'appareil ne doit pas produire de brouillage, et (2) L'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Please notice that if the IC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains IC : 28512-Y89359” any similar wording that expresses the same meaning may be used. L’étiquette d’homologation d’un module d’Innovation, Sciences et Développement économique Canada devra être posée sur le produit hôte à un endroit bien en vue, en tout temps. En l’absence d’étiquette, le produit hôte doit porter une étiquette sur laquelle figure le numéro d’homologation du module d’Innovation, Sciences et Développement économique Canada, précédé du mot « contient », ou d’une formulation similaire allant …

Text truncated - open the document above for the full version.

ESSYS CO.,LTD 55, Gaetbeol-ro, Yeonsu-gu, Incheon, Republic of Korea May 24, 2022 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: I, the undersigned, hereby authorize Lab Manager Hyunchae, You (or Jinhyoung, Cho) of SGS Korea Co., Ltd. and hereafter referred to as SGS Korea, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Lab Manager Hyunchae, You (or Jinhyoung, Cho) of SGS Korea Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing SGS Korea as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; ESSYS CO.,LTD 55, Gaetbeol-ro, Yeonsu-gu, Incheon, Republic of Korea i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely yours, Name / Title : Kim Sung Hoon / Research Engineer Company Name : ESSYS CO.,LTD

Applicant Declaration Applicant Declaration Rev: 0.0 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name ESSYS CO.,LTD Address 55, Gaetbeol-ro, Yeonsu-gu, Incheon, Republic of Korea Grantee Code 2ADQJ FCC ID 2ADQJ-Y89359 Authorized Contact Name Kim Sung Hoon Contact Email [email protected] Contact Phone 82-32-215-0923 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical r ules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveilla nce of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has r ead, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt- gst.nsf/eng/sf01130.html Applicant Signature: Date: May 24, 2022 Print Name: Kim Sung Hoon Title: Research Engineer *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

ESSYS CO.,LTD 55, Gaetbeol-ro, Yeonsu-gu, Incheon, Republic of Korea May 24, 2022 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 Request of Confidentiality for FCC ID : 2ADQJ-Y89359 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, ESSYS CO.,LTD hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give ESSYS CO.,LTD temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL LIST Permanent 1 Block Diagram 2 Operational Descriptions 3 Schematics 4 - Short-Te r m 5 External Photos 6 Internal Photos 7 Te s t-Setup Photos 8 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely yours, Name / Title : Kim Sung Hoon / Research Engineer Company Name : ESSYS CO.,LTD

Cover Letter-Modular Approval FCC ID: 2ADQJ-Y89359 Date: May 24, 2022 Gentlemen: There’s an BWR-Y89359SMA that would like to have your authorization as a modular approval. The specific product as below, BWR-Y89359SMA with its designed features and specified description, meets special requirements for limited modular approval on FCC KDB996369 by cross-reference list below. Company ESSYS CO.,LTD Model Name BWR-Y89359SMA Model Number -Y89359 FCC ID 2ADQJ-Y89359 Requirement of FCC KDB996369 Comply (Y/N） 1.The radio elements shall have the radio frequency circuitry shielded. Physical / discrete and tuning capacitors may be located external to the shield, but must be on the module assembly. Y The EUT provides the RF shielding. See EUT photo. 2.The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over- modulation. Y The EUT has its buffered modulation. Please see the Block Diagram. 3. The modular transmitter must have its own power supply regulation. N The EUT doesn’t have its own power supply regulation. The host product manufacturer must design the host product so that a constant voltage of DC 3.3V is applied to the module. 4.The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. Y The EUT meets the FCC antenna requirements; unique antenna connector and photo of antenna are shown in the internal photo. and, The module doesn't have an external Amp. 5. The modular transmitter must be tested in a stand‐alone configuration, i.e., the module must not be inside another device during testing. Y The EUT was tested with a test board, Please see test report and setup photo 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID : 2ADQJ- Y89359” or “Contains FCC ID : 2ADQJ-Y89359” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. Y Please see exhibition label sample for the FCC ID of this module. And also in the exhibition Users manual, there are instructions give to the OEM on how to label the end product. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. Y The EUT is compliant with all applicable FCC rules. Details instructions for maintaining compliance are give in the User Manual. 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). Y The EUT complies with RF exposure requirement. Thank you. Sincerely, By: Sung Hoon, Kim _ (Signature 1 ) (Print name) Title: Research Engineer On behalf of : ESSYS CO.,LTD (Company Name) Telephone: +82-10-8837-7721

External photos of EUT Top view of EUT Bottom view of EUT Side view of EUT

Since the device is too small and impracticable to label it with statement, labelling will be placed in the user manual. Label Information <engraved on shield can>

Model name: VT240S8AN Internal photos of EUT Model name: VT240S8AN Internal view of EUT Model name: VT240S8AN Top view of Main PCB Bottom view of Main PCB Model name: VT240S8AN View of Antenna & Module - with shield-can - without shield-can BT/WIFI Module Model name: VT240S8AN WIFI Antenna Bluetooth Antenna

SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003140 Page: 2 of 7 RTT7081-02(2020.10.05)(0)A4(210 mmQG297 mm) INDEX Table of ContentsPage 1. General Information --------------------------------------------------------------------------------3 2. RF Exposure Evaluation --------------------------------------------------------------------------5 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003140 Page: 3 of 7 RTT7081-02(2020.10.05)(0)A4(210 mmQG297 mm) 1.General Information 1.1. Testing Laboratory SGS Korea Co., Ltd. (Gunpo Laboratory) - 10-2, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - Designation number: KR0150 All SGS services are rendered in accordance with the applicable SGS conditions of service available on request and accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx. Telephone: +82 31 688 0901 FAX: +82 31 688 0921 1.2. Details of Applicant Applicant: ESSYS CO.,LTD Address: 55, Gaetbeol-ro, Yeonsu-gu, Incheon, Republic of Korea Contact Person : Sung-hoon, Kim Phone No.: +82 32 215 0923 1.3. Details of Manufacturer Company: Same as applicant Address: Same as applicant SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003140 Page: 4 of 7 RTT7081-02(2020.10.05)(0)A4(210 mmQG297 mm) 1.4. Description of EUT Kind of ProductWiFi/BT Combo Module Model Name BWR-Y89359SMA Variant Model Name- Power SupplyDC 3.3 V Frequency Range 2 402 ໬~ 2 480 ໬(Bluetooth) 2 412 ໬~ 2 462 ໬(11b/g/n_HT20) 5 180 ໬~ 5 240 ໬(Band 1: 11a/n_HT20, 11ac_VHT20) 5 190 ໬~ 5 230 ໬(Band 1: 11n_HT40, 11ac_VHT40) 5 210 ໬(Band 1: 11ac_VHT80) 5 260 ໬~ 5 320 ໬(Band 2A: 11a/n_HT20, 11ac_VHT20) 5 270 ໬~ 5 310 ໬(Band 2A: 11n_HT40, 11ac_VHT40) 5 290 ໬(Band 2A: 11ac_VHT80) 5 500 ໬~ 5 720໬(Band 2C: 11a/n_HT20, 11ac_VHT20) 5 510 ໬~ 5 710໬(Band 2C: 11n_HT40, 11ac_VHT40) 5 530 ໬~5690໬(Band 2C: 11ac_VHT80) 5 745 ໬~ 5 825 ໬(Band 3: 11a/n_HT20, 11ac_VHT20) 5 755 ໬~ 5 795 ໬(Band 3: 11n_HT40, 11ac_VHT40) 5 775 ໬(Band 3: 11ac_VHT80) Modulation Technique DSSS, OFDM, GFSK, ʌ'436.'36. Number of Channels 79 channels (Bluetooth) 11 channels (11b/g/n_HT20) 4 channels (Band 1: 11a/n_HT20, 11ac_VHT20) 2 channels (Band 1: 11n_HT40, 11ac_VHT40) 1 channel (Band 1: 11ac_VHT80) 4 channels (Band 2A: 11a/n_HT20, 11ac_VHT20) 2 channels (Band 2A: 11n_HT40, 11ac_VHT40) 1 channel (Band 2A: 11ac_VHT80) 9 channels (Band 2C: 11a/n_HT20, 11ac_VHT20) 4 channels (Band 2C: 11n_HT40, 11ac_VHT40) 2 channels (Band 2C: 11ac_VHT80) 5 channels (Band 3: 11a/n_HT20, 11ac_VHT20) 2 channels (Band 3: 11n_HT40, 11ac_VHT40) 1 channel (Band 3: 11ac_VHT80) Antenna TypePattern antenna Antenna Gain ଖ 2 400 ໬~ 2 483.5 ໬:3.36໒i (Bluetooth) 2 400 ໬~ 2 483.5໬:1.22໒i (WLAN 2.4 G) 5 150 ໬~ 5 250 ໬:3.49໒i(WLAN 5 G) 5 250 ໬~ 5 350 ໬:3.98໒i(WLAN 5 G) 5 470 ໬~ 5 725 ໬:4.83໒i(WLAN 5 G) 5 725 ໬~ 5 850 ໬:2.30໒i(WLAN 5 G) H/W Version 1.0 S/W Version 1.0 1.5. Test Report Revision RevisionReport NumberDate of IssueDescription 0F690501-RF-RTL0031402022.05.19Initial SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003140 Page: 5 of 7 RTT7081-02(2020.10.05)(0)A4(210 mmQG297 mm) 2. RF Exposure Evaluation 2.1. Environmental evaluation and exposure limit according to FCC CFR 47 part 1, 1.1307(b), 1.1310 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) 2.1.1. Friis transmission formula: Pd = (Pout*G)/(4*pi*R 2 ) Where Pd = power density in ໧/່ Pout = output power to antenna in ໧ G = gain of antenna in linear scale R = distance between observation point and center of the radiator in ໅ Pd the limit of MPE, 1໧/່. If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Frequency Range (໬໬) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (໧/່) Average Time (A) Limits for Occupational/Controlled Exposure 0.3-3.06141.63*(100)˺6 3.0-301842/f4.89/f*(900/f 2 )<6 30-30061.40.1631.0<6 300-1 500--f/300<6 1 500-100 000--5<6 (ii) Limits for General Population/Uncontrolled Exposure 0.3-1.346141.63*(100)<30 1.34-30824/f2.19/f*(180/f 2 )<30 30-30027.50.0730.2<30 300-1 500--f/1500<30 1 500-100 000--1.0<30 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003140 Page: 6 of 7 RTT7081-02(2020.10.05)(0)A4(210 mmQG297 mm) 2.1.2. Test Result of RF Exposure Evaluation Test Item 烉RF Exposure Evaluation Data Test Mode 烉Normal Operation 2.1.4. Output Power into Antenna & RF Exposure Evaluation Distance Bluetooth - Maximum tune up tolerance Frequency (໬໬) Maximum Average Target Power (໒m) Maximum Tune up (໒) Antenna Gain (໒i) Power Density at 20໅ (໧/່) Limits (໧/່) 2 400 ~ 2 483.5223.360.001 0831 WLAN (2.4G) - Maximum tune up tolerance Frequency (໬) Maximum Average Target Power (໒m) Maximum Tune up (໒) Antenna Gain (໒i) Power Density at 20໅ (໧/່) Limits (໧/່) 2 400 ~ 2 483.5421.22 0.001 049 1 WLAN (5G) - Maximum tune up tolerance Frequency (໬) Maximum Average Target Power (໒m) Maximum Tune up (໒) Antenna Gain (໒i) Power Density at 20໅ (໧/່) Limits (໧/່) 5 150 ~ 5 250 7 23.490.003 5301 5 250 ~ 5 350 7 23.980.003 9511 5 470 ~ 5 725 5 24.830.003 0321 5 725 ~ 5 850 2 22.300.000 8491 Note; - The power density Pd (6th column) at a distance of 20໅calculated from the friis transmission formula is far below the limit of 1 ໧/່. - This equipment complies with FCC radiation exposure limits set forth for an unco…

Text truncated - open the document above for the full version.

SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003139 Page: 2 of 17 RTT7081-02(2020.10.05)(0)A4(210 mmQ297 mm) INDEX Table of contents 1. General Information ---------------------------------------------------------------------------------------- 3 2. DFS (Dynamic Frequency Selection)------------------------------------------------------------------ 6 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003139 Page: 3 of 17 RTT7081-02(2020.10.05)(0)A4(210 mmQ297 mm) 1. General Information 1.1. Testing Laboratory SGS Korea Co., Ltd. (Gunpo Laboratory) - 10-2, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - Designation number: KR0150 All SGS services are rendered in accordance with the applicable SGS conditions of service available on request and accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx. Phone No.: +82 31 688 0901 Fax No.: +82 31 688 0921 1.2. Details of Applicant Applicant: ESSYS CO.,LTD Address: 55, Gaetbeol-ro, Yeonsu-gu, Incheon, Republic of Korea Contact Person : Sung-hoon, Kim Phone No.: +82 32 215 0923 1.3. Details of Manufacturer Company: Same as applicant Address: Same as applicant SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003139 Page: 4 of 17 RTT7081-02(2020.10.05)(0)A4(210 mmQ297 mm) 1.4. Description of EUT Kind of ProductWiFi/BT Combo Module Model NameBWR-Y89359SMA Variant Model Name- Serial NumberConducted Sample: C-001 Power SupplyDC 3.3 V Frequency Range 5 180 ໬~ 5 240 ໬(Band 1: 11a/n_HT20, 11ac_VHT20) 5 190 ໬~ 5 230 ໬(Band 1: 11n_HT40, 11ac_VHT40) 5 210 ໬(Band 1: 11ac_VHT80) 5 260 ໬~ 5 320 ໬(Band 2A: 11a/n_HT20, 11ac_VHT20) 5 270 ໬~ 5 310 ໬(Band 2A: 11n_HT40, 11ac_VHT40) 5 290 ໬(Band 2A: 11ac_VHT80) 5 500 ໬~ 5 720 ໬(Band 2C: 11a/n_HT20, 11ac_VHT20) 5 510 ໬~ 5 710 ໬(Band 2C: 11n_HT40, 11ac_VHT40) 5 530 ໬~ 5 690 ໬(Band 2C: 11ac_VHT80) 5 745 ໬~ 5 825 ໬(Band 3: 11a/n_HT20, 11ac_VHT20) 5 755 ໬~ 5 795 ໬(Band 3: 11n_HT40, 11ac_VHT40) 5 775 ໬(Band 3: 11ac_VHT80) Modulation Technique OFDM Number of Channels 4 channels (Band 1: 11a/n_HT20, 11ac_VHT20) 2 channels (Band 1: 11n_HT40, 11ac_VHT40) 1 channel (Band 1: 11ac_VHT80) 4 channels (Band 2A: 11a/n_HT20, 11ac_VHT20) 2 channels (Band 2A: 11n_HT40, 11ac_VHT40) 1 channel (Band 2A: 11ac_VHT80) 9 channels (Band 2C: 11a/n_HT20, 11ac_VHT20) 4 channels (Band 2C: 11n_HT40, 11ac_VHT40) 2 channels (Band 2C: 11ac_VHT80) 5 channels (Band 3: 11a/n_HT20, 11ac_VHT20) 2 channels (Band 3: 11n_HT40, 11ac_VHT40) 1 channel (Band 3: 11ac_VHT80) Antenna Type Pattern antenna Antenna Gain ଖ 5 150໬~ 5 250 ໬:3.49໒i 5 250 ໬~ 5 350໬:3.98໒i 5470໬~ 5 725໬:4.83໒i 5 725໬~ 5 850໬:2.30໒i H/W Version 1.0 S/W Version 1.0 1.5. Declaration by the Manufacturer -The EUT is a slave without radar detection and TPC. - The EUT is not supported TDWR(5.6 - 5.65 ໭) band. SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003139 Page: 5 of 17 RTT7081-02(2020.10.05)(0)A4(210 mmQ297 mm) 1.6. Test Equipment List EquipmentManufacturerModelS/NCal. Date Cal. Interval Cal. Due Signal GeneratorR&SSMBV100A255834 05/31/2021 Annual 05/31/2022 Spectrum AnalyzerR&SFSV30103210 12/08/2021 Annual 12/08/2022 AttenuatorMCLIFAS-23-2023835 12/07/2021 Annual 12/07/2022 Power SplitterMini-CircuitsZFSC-2-10G001 05/31/2021 Annual 05/31/2022 Power SplitterMini-CircuitsZFSC-2-10G002 05/31/2021 Annual 05/31/2022 DC Power SupplyR&SHMP2020020089489 05/14/2021 Annual 05/14/2022 ൘൘Support EquipmentG DescriptionManufacturerModelFCC ID  Access PointAerohive networks Inc.AP650XWBV-AP650X NotebookDell Inc.Latitude E6320- 1.7. Summary of Test Result The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15 Subpart E, IC RSS-247 Issue 2 Section in FCCGSection in ICGTest ItemResult 15.407(h)G RSS-247 Issue 2 6.3G DFSG -Channel closing transmission timeG -Channel move timeG -Non occupied period Complied 1.8. Test Report Revision RevisionReport NumberDate of IssueDescription 0F690501-RF-RTL0031392022.05.19Initial SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003139 Page: 6 of 17 RTT7081-02(2020.10.05)(0)A4(210 mmQ297 mm) 2. DFS (Dynamic Frequency Selection)G G 2.1. System OverviewG G 2.1.1. Set up of EUTG G G G The radar signal generation equipment consists of a vector signal generatorG G The signal monitoring equipment consists of a spectrum analyzer set to display 8 001 bins on the horizontal axis. The time domain resolution is 2 msec/bin with a 16 second sweep time, meeting the 10 second short pulse reporting criteria. The aggregate ON time is calculated by multiplying the number of bins …

Text truncated - open the document above for the full version.
