Coverletter: Lautsprecher Teufel GmbH wants to get FCC-Certification for the following product: Part 15 modular transceiver for 2.4GHz (15.247) and 5 GHz U-NII bands (15.407) ‘Stream800’. The unit will get the following FCC-ID: 2ADQS-STREAM800 List of documents: Exhibit Thema File Exhibit 01 Label and placement label proposal including FCC ID.pdf 150226_Raumfeld_StereoM_Label_silkscreen_US_bl ack_active.pdf Exhibit 02 Not needed -------------------- Exhibit 03 External Photos extern_15-137.pdf * Exhibit 04 Block Diagrams Blockdiagram.pdf * Exhibit 05 Schematic Diagrams Stream800_DDR3_Schematics_L1_24022015.pdf Exhibit 06 Testreport 15-137.pdf 15-138.pdf Exhibit 07 Test Set-up Photos setup_15-137.pdf Exhibit 08 User Manual 92958_20150226_K2.pdf Exhibit 09 Internal Photos intern_15-137.pdf Exhibit 10 Informations -------------------- Exhibit 11 RF exposure RF exposure compliance statement.pdf * Exhibit 12 Operational Description functional description Stream800 FCCupdate_20150317.pdf Exhibit 13 Cover letter Request for confidentiality This file 2ADQS-Stream800_FCC_ConfidentialityRequest-1.pdf For the Exhibits marked with ‘*’ Lautsprecher Teufel GmbH requested Confidentiality according to 47 CFR 0.457 and 0.459 of the FCC rules because these are sensitive parts owned by this company and include much of Know-How or sensitive data, it will not be provided to the public. The labelling on some photos may not be the actual status. The correct labelling you can see on the label and placement photos in Exhibit 1. This modular transceiver is intended to be incorporated into mobile devices only.

FCC ID: 2ADQS-Stream800 placeholder for Canada mark 150122/SHE95139A S2E-H 2.05B1.05

RAUMFELD ® STEREO M ACTIVE SPEAKER BERLIN ACOUSTICS CORPORATION ALL RIGHTS RESERVED WWW.RAUMFELD.COM DESIGNED AND ENGINEERED IN BERLIN, GERMANY, ASSEMBLED IN CHINA CONTAINS FCC ID: 2ADQS-STREAM800 BLACK US US THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. S/N

This Part 15 modular transceiver is intended to be incorporated into mobile devices as per 47 CFR 2.1091. As its ERP is far below 3 watts it is therefore categorically excluded from routine environmental evaluation for RF exposure prior to equipment authorization or use.
