Beam Trainer QF11A-T and QF11-S User’s Manual Table of Contents Purpose of use ............................................................................................................................................... 1 Precautions .................................................................................................................................................... 2 Change of batteries ....................................................................................................................................... 3 Functional description ................................................................................................................................... 3 How is the Beam Trainer system used .......................................................................................................... 4 Switching it on ........................................................................................................................................... 4 Switching it of ............................................................................................................................................ 4 Selecting a channel .................................................................................................................................... 4 The meaning of LED blinking (QF11A-T) ........................................................................................................ 5 Choosing the strength of IR beam (QF11-S) .................................................................................................. 5 The meaning of LED blinking (QF11-S) .......................................................................................................... 6 Storing and maintenance .............................................................................................................................. 6 Environment-friendly disposal ...................................................................................................................... 7 FCC Regulatory Compliance Information ...................................................................................................... 8 Technical data ............................................................................................................................................... 9 Purpose of use Beam Trainer QF11A-T and QF11-S devices form a time measuring system. They consist of infra-red photo cell technology, where the athlete breaks the infra-red beam that marks the starting time, finish and intermediate time. A complete system can be used for:  Measuring sprint time (athletic competition time measurements)  Testing in fast sports (athletics, football, basketball, tennis or similar)  Assistance at trainings, like carrying out specific drill exercises for agility improvement or reaction time measurements) User’s Manual Beam Trainer QF11A-T and QF11-S ©2014 Domago d.o.o. www.beamtrainer.com 2 Precautions Read this manual carefully before use, especially the warnings. In the case of not fulfilling the recommended instructions for use, we do not take any responsibility for any damage or injury what so ever. The guarantee in these cases is invalid. Please consider the following instructions:  Do not use Beam Trainer devices in rainy weather. They are only resistant to light water sprinkle. In the case of use in rain, follow instructions under “Storing and maintenance”.  Do not expose devices to mechanical burdens and keep from mechanical damage.  Do not expose Beam Trainer devices to extreme temperatures.  Do not expose Beam Trainer devices to direct sun for longer periods.  You need to insure the Beam Trainer devices against high humidity, inflammable substances, vapors and fumes.  Immediately turn off devices in case of mechanical damage, exposure to high humidity or inappropriate use and discontinue further use.  Use with care to avoid eventual incorrect function and to prolong life time. User’s Manual Beam Trainer QF11A-T and QF11-S ©2014 Domago d.o.o. www.beamtrainer.com 3 Change of batteries Press lightly on the marked battery supporter space lid and pull slightly. In order to remove batteries, pull a strip that is lying under the batteries. When inserting batteries, take care with correct polarity and positioning of the strip that has to lie underneath them. Always insert alkaline 1.5 V AA size batteries. Take care that the batteries are the same and both new. In cases of no use of Beam Trainer devices for a longer period taking batteries out, is recommended. Functional description Beam Trainer devices QF11A-T contain an infra-red sensor that senses the interruption or breaking of the infra-red beam positioned e.g. on the finish line as the athlete crosses it. QF11A-T devices have a radio transmitter to deliver timing information of beam breaking moment to other devices, which receives and analyzes this information. Every QF11A-T has to be in a pair with QF11-S (as shown below) that forms the timing gate. Attention: the devices must be facing each other by the red windows to form the timing gate. User’s Manual Beam Trainer QF11A-T and QF11-S ©2014 Domago d.o.o. www.beamtrainer.com 4 How is the Beam Trainer system used Switching it on The Beam Trainer system is switched on by pressing the POWER/MODE button for about half a second. As the LED light goes on, pressure to it should be discontinued. Switching it of The Beam Trainer system is switched off by pressing the POWER/MODE button for about three seconds. After that the LED light turns on which means that the system will eventually turn off, after we release the button. Selecting a channel The Beam trainer device QF11A-T needs radio wave connection with the frequency of 915MHz. Four channels are available. After the device is switched on, the first channel is chosen. One LED blink denotes the first channel selected. If a change of channel is needed, pressing the “POWER/MODE” button…

Text truncated - open the document above for the full version.

Long/Short-term Confidentiality Request PHOENIX TESTLAB GmbH Product Certification Konigswinkel 10 D 32825 Blomberg Date: 09 February 2015 FCC ID: To Whom it may concerns, Pursuant to sections 0.457(d) and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, we hereby requests long-term confidential treatment of information accompanying this application as outlined below: 'Schematics Block Diagram [ Operational Description Parts List Tune-Up Info In addition we hereby request the following exhibits contained in this application to be temporarily (short-term confidentiality) withheld from the public disclosure an initial period of >f()Q days Q until: _ Q not applicable External Photos Internal Photos Test Setup Photos Users Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to rule 0.457(d), disclosure of this application and all accompanying documentation will not be made before the date of the GRANT for this application. Thank you for your attention in this matter. Applicant's Company i)Qff ^ 0 address Signature : Job Title and Dept. : - 0- Ersteller: D. Brandhorst Erstelldatum: 02.01.2012 Revision: 00 Datum: 00.00.0000Seite 1 von 1

Test Setup Photos_C20142226 1 (3) Št. / No. Stran / Page 1 GENERAL Environmental conditions: Ambient temperature: 15°C to 35°C Relative humidity: 30% to 60% Atmospheric pressure: 860 mbar to 1060 mbar 1.1 Equipment under test Error! Reference source not found. Type: Error! Reference source not found. 1.1.1 General product information Tested sample number: S20145068 FCC ID: 2ADRPQ1C1 Test Setup Photos_C20142226 2 (3) Št. / No. Stran / Page Figure 1: Radiated emission test Figure 2: Radiated emission test Test Setup Photos_C20142226 3 (3) Št. / No. Stran / Page Figure 3: Radiated emission test
