2ADSN531001001THRUST E Pedals

XPEDO THRUST E USER MANUAL V1 XPEDO THRUST E Pedals XRF12 Owner’s Manual This product is ANT+ certified and complies with the bicycle power ANT+ Device Profile. For a complete listing ofANT+ Certified Products and their specific interoperability, please visit www.thisisant.com 2 TABLE OF CONTENTS PACKAGE CONTENTS ....................................................................................................4 THRUST E ANATOMY ......................................................................................................5 INSTALLATION OVERVIEW ............................................................................................6 PRE INSTALLATION ........................................................................................................7 Battery Information .........................................................................................................7 PAIRING ............................................................................................................................8 Pairing Quick Guide .......................................................................................................9 INSTALLING THE PEDALS .............................................................................................9 INSTALLING THE CLEATS ........................................................................................... 10 CALIBRATION ............................................................................................................... 10 Cadence Calibration ................................................................................................... 10 Static Calibration ......................................................................................................... 12 Static Calibration Quick Guide .................................................................................... 12 RIDE ................................................................................................................................ 13 MAINTENANCE AND CARE ......................................................................................... 13 TROUBLESHOOTING ................................................................................................... 13 SPECIFICATIONS .......................................................................................................... 14 3 ATTENTION! • Before beginning a power-based training program, be sure to consult your physician. • If you use a pacemaker or implanted electronic device, please consult your physician before using. • When using the THRUST E pedals for the first time, please be sureto practice engaging and disengaging in a safe and secure environment. • Please read "Battery Information" carefully before using THRUST E rechargeable batteries. • Carefully read the manual and follow instructions to prevent accidents and possible injury. Warranty Info XPEDO THRUST E is warrantied to be free from defects in materials or workmanship for one year from the date of purchase. Within this period, XPEDO will, at its discretion, repair or replace any components that fail in normal use. Repairs or replacement will be made at no charge to the customer for parts or labor. Customer shall be responsible for any necessary shipping costs to warranty center. This warranty does not apply to: (i) cosmetic damage, such asscratches and nicks; (ii) damage caused by improper installation by an unauthorized dealer; (iii) damagecaused by a crash, accident, abuse, misuse, fire, or other external causes; (iv) damage caused by service performed by anyone who is not an authorized XPEDO dealer; or (v) damage to a product that has been modified or altered without the written permission of XPEDO. Additionally, XPEDO reserves the right to refusewarranty claims against products or services that it deems fraudulent. 4 PACKAGE CONTENTS THRUST E Pedals • Right pedal (1) • Left pedal (1) 3.6v/600mA Rechargeable Batteries (3) Battery Charger with USB Connector (1) Cleats • THRUST 7 6° 9 (red)(2) • THRUST 7 Fixed (black)(2) Cleat Hardware • 11mm cleat bolts (6) • 13mm cleat bolts (6) • Cleat washer (12) 5 THRUST E ANATOMY ANT+ LED Identification Light Stress Gauge Device ID number Tension Indicator Calibration Button Battery -Negative Battery – Positive Transmitter Sensor B Sensor A 6 INSTALLATION OVERVIEW 1. Pre Installation (charging batteries) 2. Pair THRUST E with a ANT + compatible console 3. Install THRUST E pedals on your bike 4. Install cleats to the shoes 5. Ride Tools Needed: 1. 8mm allen wrench for pedal installation and battery cap placement 2. 4mm allen wrench for cleat installation 3. 3mm allen wrench for tension adjustment 4. Grease 3mm 4mm 8mm Grease 7 PRE INSTALLATION Battery Information The THRUST E comes with three rechargeable 3.6V batteries (one spare). These batteries must be fully charged prior to installation. A USB battery charger is included and it will take approximately 6 hours to fully charge the two batteries for the first time. After initial full charge, it will only take around 2 hours for a full charge cycle. Under normal riding conditions, a full charge will operate for approximately 150 hours. Red LED indicates it is charging. Green LED indicates the charge is complete. Notes: • A single battery can be recharged up to 500 times. • If the THRUST E had not been used for more than 3 month, please do charge the batteries again before riding Caution Use only the battery specified for this device. Failure to do so may result in malfunction and damage to the pedals and even fire. Caution Risk of explosion if battery is replaced by an incorrect type. Caution Dispose of used batteries according to local recycling policy. Battery Warning Failure to comply with these guidelines, the lithium-ion battery life may be shortened or cause damage to the charger, fire, chemical burn, electrolyte leakage and / or risk of injury may occur. • Do not place the charger close to a heat source s…
