2ADTV-W825Bluetooth Headset

1. ANC button 4. Volume + / Track forward 3.Charging Miro 5. Multifunction button 6. Volume - / Track back 2. LED indicator 7. Air holes 8. Talking mic Following items are included Start here Product overview Status indicator Instruction Power on Power off Standby Incoming call Pairing LED status Stay white about two seconds Stay red about two seconds Blink white once every 5 seconds White light flashing Red and white alternately flashing Voice prompts Power on Power off Pairing / Ringtone Battery low Battery low Blink red Charging Stays on red while charging Stays on white after fully charged / Volume up/down Press the volume"+" to turn volume up Press the volume"-" to turn volume down Power on Power off Pressand hold Multifunction button for about 3 seconds. The earphone says "power on" and the white LED light stays on for 2 seconds Press and hold Multifunction button for about 5 seconds. The earphone says "power off" and the red LED light stays on for 2 seconds Tips: When the distance between the earphone and phone is beyond effective range, earphone disconnects with phone. Earphone will power off automatically once no active for 10 minutes. Pair one phone 1.Make sure the earphone is turned off and within 1 meter of your phone, press and hold the Multifunction button until the LED indicator flashes red and white alternately (About 5 seconds), then release Multifunction button. 2.Activate on your phone (See below for more details).Bluetooth Pairing 3. Select "JPRIDE ANC-510". If your phone asks, enter 0000 (four zeros) for the passcode or accept the connection. The LED indicator stops flashing red and white once successfully paired, you hear "Connection successful". Some phone list an option to "Play through earphone", select to use the earphones. Bluetooth ON Search JPRIDE ANC-510 iPhone a.On your phone, open the menu.Settings b.Select . If Bluetooth is off, turn it on. Bluetooth The iPhone will search for new devices automatically. Android phone a.On your phone, open the menu.Settings b.Select (For old Android phone, is found in the BluetoothBluetooth ). If Bluetooth is off, turn it on. Select Wireless & NetworksSearch for Devices if your phone does not automatically search for new devices. Windows Phone a. On your phone, open the menu.Settings b. Select . If Bluetooth is off, turn it on.Bluetooth The Phone will search for new devices automatically. Note: When the earphone and phone have been paired once, they will automatically connect when the earphone is on and Bluetooth is activated on the phone. Bluetooth ON Search JPRIDE ANC-510 Mute on/off During the call，double press the Multifunction button to mute on/off. Music Music play / pause Press Multifunction button once to play / pause music. (Some phones may require you to start a media player first) . Track back/forward Press the Volume "-" for 2 seconds to skip track backward, press Volume "+" for 2 seconds to skip track forward. Switch Music and Call When a call rings during a music playing, the music automatically pauses to allow you to answer or ignore the call. Once the call is ignored or ends, the music is resumed. (Need media player support). Voice Assistant (Need phone support) In standby mode or music mode double press the Multifunction button to activate the phone voice assistant function. Switch between the earphone and phone Press the multifunction button for about 2 seconds during a call, the call will be switched to the mobile phone, redo this operation again, the call will be switched to the earphone. Call Answer a call When calling , press the Multifunction button once. Reject a call When calling , press and hold the Multifunction button for about 2 seconds. When calling , press the Multifunction button once. End a call Reject the new call hold the current call During the call there is a new call, press the Multifunction button for about 2 seconds to reject a new call, keeping the active call. End current call and answer new call When a new call rings during a call, press the Multifunction button once to answer new call and end current call simultaneously. On hold current call and answer new call When a new call rings during a call, Double press the Multifunction button to hold current call and answer new call. Basic operation Hardware reset Clear paired list Connect earphone to the USB port of a PC or an USB power adaptor and LED shows red light, the earphone is now reset. In the pairing state, press the volume '+' and '-' button for 5 seconds at the same time, the white indicator light will be on for 4 seconds, then the red and white will flash alternately. Charging Your new earphone has enough power to pair and make a few calls.It takes 2 hours to fully charge the earphone; while charging, the battery indicator light is red, the indicator light Stays on white charging is complete. Note: The lifetime of the battery will be significantly reduced if your earphone is left uncharged for a long period. We recommend that you recharge your earphone at least once a month. W825 INSTRUCTION Do not use earphone in thunderstorm weather, the earphone may not work properly in the condition, and increase the risk of being hit by lightning . Safety and care Using earphone at high to moderate volumes for extended periods of time will result in permanent hearing damage .It is advised you keep volume levels moderate to low at all times for your safety. Do not use any corrosive cleaner/oil to clean the earphone. If the earphone comes in contact with liquids, quickly wipe away .If submersed in water, do not turn the earphone on until completely dried. Tips: liquid submersion voids the warranty. Keep the earphone and packaging out of reach of children . Do not use while driving a car, cycling, operating machinery, or performing other activities that require hearing surrounding sounds. Earphone may not work properly under high temperature or high humidity conditions. Do not throw this electronic device into the trash when discarding. T…

Text truncated - open the document above for the full version.

- Page 1 of 3 - Report No.: MTi19072215-6E1-1 Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: No.102A & 302A, East Block, Hengfang Industrial Park, Xingye Road, Xixiang, Bao'an District, Shenzhen, Guangdong, China APPENDIX 1: EUT PHOTO Photo 1 (For model W825) Photo 2 - Page 2 of 3 - Report No.: MTi19072215-6E1-1 Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: No.102A & 302A, East Block, Hengfang Industrial Park, Xingye Road, Xixiang, Bao'an District, Shenzhen, Guangdong, China Photo 3 Photo 4 - Page 3 of 3 - Report No.: MTi19072215-6E1-1 Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: No.102A & 302A, East Block, Hengfang Industrial Park, Xingye Road, Xixiang, Bao'an District, Shenzhen, Guangdong, China Photo 5 ----END OF REPORT----

- Page 1 of 2 - Report No.: MTi19072215-6E1-1 Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: No.102A & 302A, East Block, Hengfang Industrial Park, Xingye Road, Xixiang, Bao'an District, Shenzhen, Guangdong, China APPENDIX 1: EUT PHOTO Photo 1 (For model W825) Photo 2 Ceramic Antenna - Page 2 of 2 - Report No.: MTi19072215-6E1-1 Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: No.102A & 302A, East Block, Hengfang Industrial Park, Xingye Road, Xixiang, Bao'an District, Shenzhen, Guangdong, China Photo 3 Photo 4 ----END OF REPORT----

version01 Shenzhen Cannice Technology Co., Ltd. Declaration concerning Antenna Specification It is hereby declared that the product Model No.: W825 FCC ID: 2ADTV-W825 fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for Internal Antenna antenna type(s) described below: Model No. of antenna: N/A Type of antenna: Ceramic Antenna Gain of the antenna: 1.7 dBi Frequency range: 2402~2480 MHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: Shenzhen Cannice Technology Co., Ltd. Address: 20/F, Tower A, Building 7, Baoneng Science and Technology Park, Qingxiang Road #1, Longhua New District, Shenzhen, China. City: Shenzhen ZIP / Postal code: N/A Country: China Contact: Ankey Wu Date: 10/23/2019 Signature:

RF EXPOSURE REPORT FCC ID:2ADTV-W825 Date of issue: Sept. 27,2019 Report Number: MTi19072215-6E2 Sample Description: Bluetooth Headset Model(s): W825 Applicant: ShenZhen Cannice Technology Co., Ltd. Address: 20/F, Tower A, Building 7, Baoneng Science and Technology Park, Qingxiang Road #1, Longhua New District, Shenzhen, China. Date of Test: Aug. 29, 2019 to Sept. 27, 2019 - Page 2 of 4- Report No.: MTi19072215-6E2 TEST RESULT CERTIFICATION Applicant’s name: ShenZhen Cannice Technology Co., Ltd. Address: 20/F, Tower A, Building 7, Baoneng Science and Technology Park, Qingxiang Road #1, Longhua New District, Shenzhen, China. Manufacture's name: ShenZhen Cannice Technology Co., Ltd. Address: 20/F, Tower A, Building 7, Baoneng Science and Technology Park, Qingxiang Road #1, Longhua New District, Shenzhen, China Product name: Bluetooth Headset Model and/or type reference: W825 Serial Model: N/A RF Exposure Procedures: KDB 447498 D01 v06 This device described above has been tested by Shenzhen Microtest Co., Ltd and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. Tested by: Danny Xu Sept. 27,2019 Reviewed by: Blue Zheng Sept. 27,2019 Approved by: Smith Chen Sept. 27,2019 - Page 3 of 4- Report No.: MTi19072215-6E2 1. Standalone SAR test exclusion considerations Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions. The minimum test separation distance defined in 4.1 f) is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander. To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified, typically in the SAR measurement or SAR analysis report, by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting are required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions. a) For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where  f (GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  The result is rounded to one decimal place for comparison  The values 3.0 and 7.5 are referred to as numeric thresholds in step b) below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm, and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 4.1 f) is applied to determine SAR test exclusion. b) For 100 MHz to 6 GHz and test separation distances > 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following (also illustrated in Appendix B): 1) {[Power allowed at numeric threshold for 50 mm in step a)] + [(test separation distance – 50 mm)·(f(MHz)/150)]} mW, for 100 MHz to 1500 MHz 2) {[Power allowed at numeric threshold for 50 mm in step a)] + [(test separation distance – 50 mm)·10]} mW, for > 1500 MHz and ≤ 6 GHz c) For frequencies below 100 MHz, the following may be considered for SAR test exclusion (also illustrated in Appendix C): 1) For test separation distances > 50 mm and < 200 mm, the power threshold at the corresponding test separation distance at 100 MHz in step b) is multiplied by [1 + log(100/f(MHz))] 2) For test separation distances ≤ 50 mm, the power threshold determined by the equation in c) 1) for 50 mm and 100 MHz is multiplied by ½ 3) SAR measurement procedures are not established below 100 MHz. - Page 4 of 4- Report No.: MTi19072215-6E2 When SAR test exclusion cannot be applied, a KDB inquiry is required to determine SAR evaluation requirements for any SAR test results below 100 MHz to be acceptable. 2. SAR Test Exclucsion Thresholds We use 5mm as separation distance to calculated. Bluetooth DSS: Transmit Frequency (GHz) Mode Measured Power (dBm) Tune-up power (dBm) Max tune- up Result 1g SAR power(dBm) calculation 2.402 GFSK 4.43 4±1 5 0.9802 3 2.441 4.4 4±1 5 0.9881 3 2.48 4.194 4±1 5 0.9960 3 2.402 π/4-DQPSK 4.66 4±1 5 0.9802 3 2.441 4.63 4±1 5 0.9881 3 2.48 3.187 4±1 5 0.9960 3 2.402 8DPSK 4.652 4±1 5 0.9802 3 2.441 4.6 4±1 5 0.9881 3 2.48 3.17 4±1 5 0.9960 3 Conclusion: For the max result: 0.9960≤ 3.0 for 1g SAR, No SAR is required. ----END OF REPORT----

This test report is valid for the tested samples only. It cannot be reproduced except in full without prior written consent of Shenzhen Microtest Co., Ltd. Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: No.102A & 302A, East Block, Hengfang Industrial Park, Xingye Road, Xixiang, Bao'an District, Shenzhen, Guangdong, China Test Report FCC ID: 2ADTV-W825 Date of issue: Sept. 27, 2019 Report number: MTi19072215-6E1 Sample description: Bluetooth Headset Model(s): W825 Applicant: ShenZhen Cannice Technology Co., Ltd. Address: 20/F, Tower A, Building 7, Baoneng Science and Technology Park, Qingxiang Road #1, Longhua New District, Shenzhen, China. Date of test: Aug. 29, 2019 to Sept. 27, 2019 Shenzhen Microtest Co., Ltd. http://www.mtitest.com - Page 2 of 68 - Report No.: MTi19072215-6E1 Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: No.102A & 302A, East Block, Hengfang Industrial Park, Xingye Road, Xixiang, Bao'an District, Shenzhen, Guangdong, China Table of Contents 1 GENERAL INFORMATION ....................................................................................................................................... 5 1.1 DESCRIPTION OF EUT ................................................................................................................................................... 5 1.2 OPERATION CHANNEL LIST .............................................................................................................................................. 5 1.3 TEST CHANNEL LIST ....................................................................................................................................................... 6 1.4 ANCILLARY EQUIPMENT LIST ........................................................................................................................................... 6 1.5 DESCRIPTION OF SUPPORT UNITS .................................................................................................................................... 6 2 SUMMARY OF TEST RESULTS ................................................................................................................................. 7 3 TEST FACILITIES AND ACCREDITATIONS .................................................................................................................. 8 3.1 TEST LABORATORY ........................................................................................................................................................ 8 3.2 ENVIRONMENTAL CONDITIONS ........................................................................................................................................ 8 3.3 MEASUREMENT UNCERTAINTY ........................................................................................................................................ 8 3.4 TEST SOFTWARE ........................................................................................................................................................... 8 4 EQUIPMENT LIST .................................................................................................................................................. 9 5 TEST RESULT ....................................................................................................................................................... 10 5.1 ANTENNA REQUIREMENT ............................................................................................................................................. 10 5.1.1 Standard requirement ....................................................................................................................................... 10 5.1.2 EUT antenna ..................................................................................................................................................... 10 5.2 PEAK OUTPUT POWER ................................................................................................................................................. 11 5.2.1 Limit .................................................................................................................................................................. 11 5.2.2 Test setup .......................................................................................................................................................... 11 5.2.3 Test procedure ................................................................................................................................................... 11 5.2.4 Test results ........................................................................................................................................................ 11 5.3 CONDUCTED EMISSION ................................................................................................................................................ 18 5.3.1 Limits ................................................................................................................................................................. 18 5.3.2 Test setup .......................................................................................................................................................... 18 5.3.3 Test procedure ................................................................................................................................................... 19 5.3.4 Test results ........................................................................................................................................................ 19 5.4 RADIATED SPURIOUS EMISSION ...................................................................................................................................... 24 5.4.1 Limits .................................................................................................................................…

Text truncated - open the document above for the full version.

Model: W825 Radiated emission Conducted emission
