2ADTWTHL4000smart phone

user manual Model name:thl 4000 Brand name:thl 1 Contents Safety .................................................................................................................... 3 Environment ........................................................................................................ 4 1 Getting Started ................................................................................................. 5 1.1 Getting to know your touch phone .................................................... 5 1.2 Installing the SIM card, battery, and storage card ............................. 5 1.3 Charging the Battery .......................................................................... 6 1.4 Starting up the device ......................................................................... 7 1.5 Status Icons ........................................................................................ 9 2 Using phone features ..................................................................................... 11 2.1 Turning the phone function on and off ............................................ 11 2.2 Making a call ................................................................................... 11 2.3 Answering and Ending a call ........................................................... 12 2.4 In-call options .................................................................................. 12 2.5 Using call history ............................................................................. 13 2.6 Call settings ...................................................................................... 13 3 Setting on your device .................................................................................... 14 4 ActiveSync ....................................................................................................... 17 5 Contacts .......................................................................................................... 20 6 Exchanging Messages .................................................................................... 22 7 Internet ........................................................................................................... 27 7.1 Ways of Connecting to the Internet ................................................. 27 7.2 Browser ............................................................................................ 27 8 Experiencing Multimedia .............................................................................. 29 8.1 Camera & Picture ............................................................................. 29 8.2 Music ................................................................................................ 32 8.3 FM Radio ......................................................................................... 34 8.4 Sound record .................................................................................... 34 9 Other applications .......................................................................................... 34 2 9.1 Calendar ........................................................................................... 34 9.2 Alarm Clock ..................................................................................... 35 9.3 Calculator ......................................................................................... 36 10 Play Store* .................................................................................................... 37 3 Safety Never attempt to disassemble your phone. You alone are responsible for how you use your phone and any consequences of its use. As a general rule, always switch off your phone wherever the use of a phone is prohibited. Use of your phone is subject to safety measures designed to protect users and their environment. Do not use your phone in damp areas (bathroom, swimming pool...). Protect it from liquids and other moisture. Do not expose your phone to extreme temperatures lower than - 10°C and higher than + 55°C. The physicochemical processes created by chargers impose temperature limits when charging the battery. Your phone automatically protects the batteries in extreme temperatures. Do not leave your phone within the reach of small children (certain removable parts may be accidentally ingested). Electrical safety: Only use the chargers listed in the manufacturer’s catalogue. Using any other charger may be dangerous; it would also invalidate your warranty. Line voltage must be exactly the one indicated on the charger’s serial plate. Aircraft safety: When traveling by plane, you will need to switch your phone off when so instructed by the cabin crew or the warning signs. Using a mobile phone may be dangerous to the operation of the aircraft and may disrupt the phone network. Its use is illegal and you could be prosecuted or banned from using cellular networks in the future if you do not abide by these regulations. Explosive materials: Please comply with warning signs at petrol station asking you to switch your phone off. You will need to comply with radio equipment usage restrictions in places such as chemical plants, fuel depots and at any location where blasting operations are under way. Electronic equipment: To avoid the risk of demagnetization, do not let electronic devices close to your phone for a long time. Electronic medical equipment: Your phone is a radio transmitter which may interfere with electronic medical equipment or implants, such as hearing aids, pacemakers, insulin pumps, etc. It is recommended that a minimum separation of 15 cm be maintained between the phone and an implant. Your doctor or the 4 manufacturers of such equipment will be able to give you any advice you may need in this area. Hospitals: Always make sure that your phone is switched off in hospitals when so instructed by warning signs or by medical staff. Road safety: Do not use your phone when driving. In order to give your full attention to driving, stop and p…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2Rev 5.0 Shenzhen Hongjiayuan Communication Technology Co.,Ltd. 2014.12.18 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, Shenzhen Hongjiayuan Communication Technology Co.,Ltd. (client’s company name) hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): (Product description, model name): Product description: smart phone model name: thl 4000/thl 4000S/thl 4000C/thl 4000 pro/thl T7/ thl T7S/thl T7C/thl T7 pro FCC ID: 2ADTWTHL4000 Sincerely, Client’s signature : mayitian Client’s name / title: manager Applicant company：Shenzhen Hongjiayuan Communication Technology Co.,Ltd. address：6 Floor,Block 12,Dongfangjianfuyusheng Industrial,Gushu,Baoan District,Shenzhen City,China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Shenzhen Hongjiayuan Communication Technology Co.,Ltd. 2014.12.18 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ADTWTHL4000 We hereby request confidential treatment of information accompanying this application as outlined below: - e.g. Block Diagram - e.g. Schematics - e.g. Operational Description - e.g. Tune up Procedure - e.g. Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : mayitian Client’s name / title : manager Applicant company：Shenzhen Hongjiayuan Communication Technology Co.,Ltd. address：6 Floor,Block 12,Dongfangjianfuyusheng Industrial,Gushu,Baoan District,Shenzhen City,China

Differences Description We Shenzhen Hongjiayuan Communication Technology Co.,Ltd. state: Product： smart phone Model Name： thl 4000/thl 4000S/thl 4000C/thl 4000 pro/thl T7/ thl T7S/thl T7C/thl T7 pro Trade Name: thl FCC ID: 2ADTWTHL4000 The electrical circuit design, layout, components used and internal wiring for above models are identical, only the model name is different. Signatory Date 2014-12-18 Signature Name: mayitian Title: Manger Company: Shenzhen Hongjiayuan Communication Technology Co.,Ltd. Address: 6 Floor,Block 12,Dongfangjianfuyusheng Industrial,Gushu,Baoan District,Shenzhen City,China

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8 Photo 9 Photo 10 Photo 12 Photo 11

Label smart phone Model name: thl 4000 Brand name: thl FCC ID: 2ADTWTHL4000 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. label

BT/WIFI/GPS Antenna WCDMA/GSM Antenna 12.6CM 3.5cm 1.2cm 3.4cm 1.1cm

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 GSM/WCDMA ANTENNA BT/WIFE/GPS ANTENNA Photo 3 Photo 4 Photo 6 Photo 5

Ref : ACR.262.1.14.SATU.A SHENZHEN STS TEST SERVICES CO., LTD. 1/F, BUILDING 2, ZHUOKE SCIENCE PARK, CHONGQING ROAD FUYONG, BAO’ AN DISTRICT, SHENZHEN,CHINA SATIMO COMOSAR DOSIMETRIC E-FIELD PROBE SERIAL NO.: SN 17/14 EP221 Calibrated at SATIMO US 2105 Barrett Park Dr. - Kennesaw, GA 30144 09/01/2014 Summary: This document presents the method and results from an accredited COMOSAR Dosimetric E-Field Probe calibration performed in SATIMO USA using the CALISAR / CALIBAIR test bench, for use with a SATIMO COMOSAR system only. All calibration results are traceable to national metrology institutions. COMOSAR E-Field Probe Calibration Report COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 2/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. Name Function Date Signature Prepared by : Jérôme LUC Product Manager 9/19/2014 Checked by : Jérôme LUC Product Manager 9/19/2014 Approved by : Kim RUTKOWSKI Quality Manager 9/19/2014 Customer Name Distribution : Shenzhen STS Test Services Co., Ltd. Issue Date Modifications A 9/19/2014 Initial release COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 3/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. TABLE OF CONTENTS 1 Device Under Test ..................................................................................................... 4 2 Product Description ................................................................................................... 4 2.1 General Information _______________________________________________________ 4 3 Measurement Method ................................................................................................ 4 3.1 Linearity ________________________________________________________________ 4 3.2 Sensitivity _______________________________________________________________ 5 3.3 Lower Detection Limit _____________________________________________________ 5 3.4 Isotropy _________________________________________________________________ 5 3.5 Boundary Effect __________________________________________________________ 5 4 Measurement Uncertainty .......................................................................................... 5 5 Calibration Measurement Results .............................................................................. 6 5.1 Sensitivity in air __________________________________________________________ 6 5.2 Linearity ________________________________________________________________ 7 5.3 Sensitivity in liquid ________________________________________________________ 7 5.4 Isotropy _________________________________________________________________ 8 6 List of Equipment ...................................................................................................... 9 COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 4/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. 1 DEVICE UNDER TEST Device Under Test Device Type COMOSAR DOSIMETRIC E FIELD PROBE Manufacturer Satimo Model SSE5 Serial Number SN 17/14 EP221 Product Condition (new / used) New Frequency Range of Probe 0.4 GHz- 6 GHz Resistance of Three Dipoles at Connector Dipole 1: R1=0.179 M Dipole 2: R2=0.167 M Dipole 3: R3=0.178 M A yearly calibration interval is recommended. 2 PRODUCT DESCRIPTION 2.1 GENERAL INFORMATION Satimo’s COMOSAR E field Probes are built in accordance to the IEEE 1528, OET 65 Bulletin C and CEI/IEC 62209 standards. Figure 1 – Satimo COMOSAR Dosimetric E field Dipole Probe Length 330 mm Length of Individual Dipoles 4.5 mm Maximum external diameter 8 mm Probe Tip External Diameter 5 mm Distance between dipoles / probe extremity 2.7 mm 3 MEASUREMENT METHOD The IEEE 1528, OET 65 Bulletin C, CENELEC EN50361 and CEI/IEC 62209 standards provide recommended practices for the probe calibrations, including the performance characteristics of interest and methods by which to assess their affect. All calibrations / measurements performed meet the fore mentioned standards. 3.1 LINEARITY The evaluation of the linearity was done in free space using the waveguide, performing a power sweep to cover the SAR range 0.01W/kg to 100W/kg. COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 5/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. 3.2 SENSITIVITY The sensitivity factors of the three dipoles were determined using a two step calibration method (air and tissue simulating liquid) using waveguides as outlined in the standards. 3.3 LOWER DETECTION LIMIT The lower detection limit was assessed using the same measurement set up as used for the linearity measurement. The required lower detection limit is 10 mW/kg. 3.4 ISOTROPY The axial isotropy was evaluated by exposing the probe to a reference wave from a standard dipole with the dipole mounted under the flat phantom in the test configuration suggested for system validations and checks. The probe was rotated along its main axis from 0 - 360 degrees in 15 degree steps. The hemispherical isotropy is determined by inserting the probe in a thin plastic box filled with tissue-equivalent liquid,…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F, Building B, Zhuoke Science Park, Chongqing Road, Fuyong, Baoan District, Shenzhen, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC SAR TEST REPORT Report No: STS1412027H01 Issued for Shenzhen Hongjiayuan Communication Technology Co.,Ltd. 6 Floor,Block 12,Dongfangjianfuyusheng Industrial,Gushu,Baoan District,Shenzhen City,China Product Name: smart phone Brand Name: THL Model No.: THL 4000 Series Model: thl 4000S/thl 4000C/thl 4000 pro/thl T7/ thl T7S/thl T7C/thl T7 pro FCC ID: 2ADTWTHL4000 Test Standard: ANSI/IEEE Std. C95.1 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 Max. SAR (1g): Head:0.309 W/kg Body:0.775 W/kg S T L A B S Page 2 of 103 Report No.: STS1412027H01 Test Report Certification Applicant’s name ................. : Shenzhen Hongjiayuan Communication Technology Co.,Ltd. Address ................................. : 6 Floor,Block 12,Dongfangjianfuyusheng Industrial,Gushu,Baoan District,Shenzhen City,China Manufacture's Name ............ : Shenzhen Hongjiayuan Communication Technology Co.,Ltd. Address ................................. : 6 Floor,Block 12,Dongfangjianfuyusheng Industrial,Gushu,Baoan District,Shenzhen City,China Product description Product name ........................ : smart phone Trademark ............................ : THL Model and/or type reference : THL 4000 Serial Model： thl 4000S/thl 4000C/thl 4000 pro/thl T7/ thl T7S/thl T7C/thl T7 pro Standards ............................. : ANSI/IEEE Std. C95.1-1992 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 The device was tested by Shenzhen STS Test Services Co., Ltd. in accordance with the measurement methods and procedures specified in KDB 865664 The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Date of Test ............................................ : Date (s) of performance of tests ............. : 15 Dec.. 2014 Date of Issue ........................................... : 18 Dec.. 2014 Test Result ............................................... : Pass Testing Engineer : (Tony Liu) Technical Manager : (Vita Li) Authorized Signatory : (Bovey Yang) Page 3 of 103 Report No.: STS1412027H01 TABLE OF CONTENS 1. General Information 4 1.1 EUT Description 4 1.2 Test Environment 5 1.3 Test Facility 5 2. Test Standards And Limits 6 3. SAR Measurement System 7 3.1 Definition Of Specific Absorption Rate (SAR) 7 3.2 SAR System 7 3.2.1 Probe 8 3.2.2 Phantom 9 3.2.3 Device Holder 9 4. Tissue Simulating Liquids 10 4.1 Simulating Liquids Parameter Check 10 5. SAR System Validation 11 5.1 Validation System 11 5.2 Validation Result 11 6. SAR Evaluation Procedures 12 7. EUT Antenna Location Sketch 13 7.1 SAR TEST EXCLUSION CONSIDER TABLE 14 8. EUT Test Position 16 8.1 Define Two Imaginary Lines On The Handset 16 8.2 Hotspot mode exposure position condition 17 9. Measurement Uncertainty 18 10. Conducted Power Measurement 20 11. EUT And Test Setup Photo 24 11.1 EUT Photo 24 11.2 Setup Photo 27 12. SAR Result Summary 32 12.1 Head SAR 32 12.2 Body SAR And Hotspot 33 13. Equipment List 36 Appendix A. System Validation Plots 37 Appendix B. SAR Test Plots 49 Appendix C. Probe Calibration And Dipole Calibration Report 103 Page 4 of 103 Report No.: STS1412027H01 1. General Information 1.1 EUT Description Equipment smart phone Brand Name THL Model No. THL 4000 Serial Model thl 4000S/thl 4000C/thl 4000 pro/thl T7/ thl T7S/thl T7C/thl T7 pro FCC ID 2ADTWTHL4000 Model Difference Only difference in model name Adapter Input: AC100-240V, 0.3 A, 50/60 Hz Output: DC 5V, 1000mA Battery Rated Voltage: 3.7V Charge Limit: 4.2V Capacity: 4000mAh Hardware Version V02 Software Version thl.4000.168B.1479M.8P64.QHD.EN.COM.20141128.MT6582KK.GC5004 Frequency Range GSM 850: 824.2 ~ 848.8 MHz PCS1900: 1850.2 ~ 1909.8 MHz WCDMA II: 1852.4~1907.6 MHz WCDMA V: 826.4~846.6 MHz WLAN 802.11 b/g/n(HT20):2412-2462 MHz WLAN 802.11 n(HT40):2422-2452 MHz Bluetooth：2402~2480MHz Transmit Power(MAX): GSM 850: 32.11dBm GSM 1900: 27.77dBm WCDMA II: 20.30dBm WCDMA V: 22.20dBm 802.11b: 11.57dBm 802.11g: 7.85dBm 802.11 n(HT20): 7.35dBm 802.11 n(HT40): 4.86dBm Bluetooth: -7.477 dBm Max. Reported SAR(1g): Head: GSM 850: 0.204 W/kg GSM 1900: 0.140 W/kg WCDMA II: 0.298 W/kg WCDMA V: 0.154 W/kg WIFI: 0.309W/kg Body: GSM 850: 0.465W/kg GSM 1900: 0.357 W/kg WCDMA II: 0.663 W/kg WCDMA V: 0.334 W/kg WIFI: 0.270W/kg Hotspot: GSM 850: 0.775W/kg GSM 1900: 0.353 W/kg WCDMA II: 0.663 W/kg WCDMA V: 0.334 W/kg WIFI: 0.270W/kg Operating Mode: GSM: GSM Voice/GPRS/EGPRS Class 12; WCDMA: RMC/HSDPA/HSUPA Release 6; WLAN: 802.11 b/g/n; Bluetooth: V4.0 (GFSK) Antenna Specification: GSM/WCDMA: PIFA Antenna BT/WIFI: PIFA Antenna SIM Card Support dual-SIM, dual standby, the multiple SIM card with two lines cannot transmitting at the same time Hotspot Mode: Support DTM Mode: Not Support Page 5 of 103 Report No.: STS1412027H01 1.2 Test Environment Ambient conditions in the SAR laboratory: Items Required Actual Temperature (°C) 18-25 22~23 Humidity (%RH) 30-70 55~65 1.3 Test Facility Shenzhen STS Test Services Co., Ltd. Add. : 1/F, Building 2, Zhuoke Science Park, Chongqing Road, Fuyong, Baoan District, Shenzhen, China FCC Registration No.: 842334;IC Registration No.: 12108A-1 Page 6 of 103 Report No.: STS1412027H01 2. Test Standards And Limits No. Identity Document Title 1 47 CFR Part 2 Frequency Allocations and Radio Treaty Matters; General Rules and Regulations 2 ANSI/IEEE Std. C95.1-1992 IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz 3 IEEE Std. 1528-2013 Recommended Prac…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F, Building B, Zhuoke Science Park, Chongqing Road, Fuyong, Baoan District, Shenzhen, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC RADIO REPORT Report No: STS1412027F01 Issued for Shenzhen Hongjiayuan Communication Technology Co.,Ltd. 6 Floor,Block 12,Dongfangjianfuyusheng Industri- al,Gushu,Baoan District,Shenzhen City,China Product Name: smart phone Brand Name: thl Model No.: thl 4000 Series Model: thl 4000S/thl 4000C/thl 4000 pro/thl T7/ thl T7S/thl T7C/thl T7 pro FCC ID: 2ADTWTHL4000 Test Standard: FCC Part 22H and 24E S T L A B S 2 of 113 Report No.: STS1412027F01 Testing Engineer : (Tony Liu) Technical Manager : (Vita Li) Authorized Signatory : (Bovey Yang) TEST RESULT CERTIFICATION Applicant’s name .....................: Shenzhen Hongjiayuan Communication Technology Co.,Ltd. Address .....................................: 6 Floor,Block 12,Dongfangjianfuyusheng Industrial,Gushu,Baoan District,Shenzhen City,China Manufacture's Name ...............: Shenzhen Hongjiayuan Communication Technology Co.,Ltd. Address .....................................: 6 Floor,Block 12,Dongfangjianfuyusheng Industrial,Gushu,Baoan District,Shenzhen City,China Product name ............................: smart phone Band name ..............................: thl Model and/or type refer- ence ...........................................: thl 4000 Standards .................................: FCC Part 22H and 24E Test procedure ............................... : TIA 603 C This device described above has been tested by STS and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test .............................................. : Date of performance of tests ..................... : 10 Dec . 2014 ~16 Dec . 2014 Date of Issue ............................................ : 18 Dec. 2014 Test Result ................................................ : Pass 3 of 113 Report No.: STS1412027F01 TABLE OF CONTENTS 1.SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2. GENERAL INFORMATION 6 2.1 PRODUCT DESCRIPTION 6 2.2 RELATED SUBMITTAL(S) / GRANT (S) 7 2.3 SPECIAL ACCESSORIES 7 2.4 EUT CONFIGURATION 7 2.5 EUT EXERCISE 7 2.6 CONFIGURATION OF EUT SYSTEM 7 2.7 MEASUREMENT INSTRUMENTS 8 3. SUMMARY OF TEST RESULTS 9 4. DESCRIPTION OF TEST MODES 9 5. OUTPUT POW ER 10 5.1 CONDUCTED OUTPUT POWER 10 5.2 PEAK-TO-AVERAGE RADIO (PAR) OF TRANSMITTER 16 5.3 RADIATED OUTPUT POWER 21 6. SPURIOUS EMISSION 25 6.1 SPURIOUS EMISSION 25 6.2 RADIATED SPURIOUS EMISSION 27 7. FREQUENCY STABILITY 33 7.1 MEASUREMENT METHOD 33 7.2 PROVISIONS APPLICABLE 34 7.3 MEASUREMENT RESULT 35 8. OCCUPIED BANDW IDTH 40 8.1 MEASUREMENT METHOD 40 8.2 PROVISIONS APPLICABLE 40 8.3 MEASUREMENT RESULT 40 9. EMISSION BANDW IDTH 43 9.1 MEASUREMENT METHOD 43 9.2 PROVISIONS APPLICABLE 43 9.3 MEASUREMENT RESULT 43 10. BAND EDGE 46 10.1 MEASUREMENT METHOD 46 10.2 PROVISIONS APPLICABLE 46 10.3 MEASUREMENT RESULT 46 APPENDIX I 47 4 of 113 Report No.: STS1412027F01 TEST PLOTS FOR CONDUCTED SPURIOUS EMISSION 47 APPENDIX II 76 TEST PLOTS FOR OCCUPIED BANDW IDTH (99%) 77 EMISSION BANDW IDTH (-26DBC) 77 APPENDIX III 101 TEST PLOTS FOR BAND EDGES 101 APPENDIX IV 113 PHOTOS OF TEST SETUP 113 5 of 113 Report No.: STS1412027F01 1.SUMMARY OF TEST RESULTS Test procedures according to the technical standards: The radiated emission testing was performed according to the procedures of ansi C63.10: 2009; TIA 603 C and fcc cfr 47 rules of 2.1046, 2.1047, 2.1049, 2.1051, 2.1053, 2.1055, 2.1057 Item Number Item Description FCC Rules 1 Output Power Conducted output power 22.913(a) / 24.232 (b) Radiated output power 2 Spurious Emission Conducted spurious emission 2.1051 / 22.917 / 24.238 Radiated spurious emission 3 Frequency Stability 2.1055 /24.235 4 Occupied Bandwidth 2.1049 (h)(i) 5 Emission Bandwidth 22.917(b) / 24.238 (b) 6 Band Edge 22.917(b) / 24.238 (b) NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 TEST FACILITY Shenzhen STS Test Services Co., Ltd. Add. : 1/F, Building 2, Zhuoke Science Park, Chongqing Road, Fuyong, Baoan District, Shenzhen, China. FCC Registration No.: 842334; IC Registration No.: 12108A-1 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% 6 of 113 Report No.: STS1412027F01 2. GENERAL INFORMATION 2.1 PRODUCT DESCRIPTION A major technical description of EUT is described as following: Product Designation: smart phone Hardware version: V02 Software version: thl.4000.168B.1479M.8P64.QHD.EN.COM.20141128.MT6582KK.GC5004 FCC ID: 2ADTWTHL4000 Frequency Bands: GSM 850 PCS 1900 (U.S. Bands) GSM 900 DCS 1800 (Non-U.S. Bands) U.S. Bands: UMTS FDD Band II UMTS FDD Band V Non-U.S. Bands: UMTS FDD Band I UMTS FDD Band VIII Max RF Output Pow- er: GSM850:32.11dBm,GSM1900:27.77dBm WCDMA Band V:22.20dBm,WCDMA Band II:20.30dBm Type of Emission: GSM(850):246KGXW: GSM(1900):247KGXW GPRS(850):251KGXW; GPRS(1900):248KGXW EDGE(850):249KG7W: EDGE(1900):247KG7W WCDMA850:4M18F9W WCDMA1900:4M17F9W SIM CARD Support dual-SIM, dual…

Text truncated - open the document above for the full version.

PCESetup photo PCEradiation L PCEradiation H PCE RF conduction test photos PCE High and low temperature test photos
