2ADU5-4902HDMI Digital Media Receiver

Quick Start Guide [DRAFT] WHAT’S IN THE BOX • Device • Power adaptor • Device Remote Control • 2 AAA batteries CONNECTING DEVICE 1. Connect one end of the HDMI cable (not included) into the HDMI port on your Device. Connect the other end into the HDMI port on your TV. 2. Plug the included power cable into your Device and then into a power outlet. 3. Turn on your TV, and select the appropriate input 4. Insert the included batteries into the remote. If the remote does not automatically connect, make sure that the batteries are properly installed. 5. Your Device is now connected to your TV. Simply follow the on-­‐screen guide to complete your setup. CONNECTING DEVICE TO YOUR HOME NETWORK You can connect your Device to your network using one of the methods below: Wired network 1. Connect one end of an Ethernet cable (not included) to your router. Connect the other end to the Ethernet port on the back of your Device. 2. Your Device will automatically detect your network and continue the set up process. Wi-­‐Fi network 1. Using the remote control, select your network from the list displayed on the screen. If your network is hidden, enter your network name. 2. If required, enter your network password using the on-­‐screen keyboard. REGISTERING YOUR DEVICE If you purchased your Device online, it is already registered to you. If you received your Device as a gift or if it is not yet registered, please follow the on-­‐screen instructions to register your Device. IMPORTANT PRODUCT INFORMATION For safety, compliance, recycling, and other important information regarding your Device, please refer to the Legal & Compliance section on the Settings menu of your Device.

User Guide [DRAFT] Product Information Safety and Compliance Information Using Your Device Around Other Electronic Devices The Device, uses, and can radiate radio frequency (RF) energy and, if not used in accordance with its instructions, may cause interference to radio communications and electronic equipment. External RF signals may affect improperly installed or inadequately shielded electronic operating systems, entertainment systems, and personal medical devices. While most modern electronic equipment is shielded from external RF signals, if in doubt, check with the manufacturer. For personal medical devices (such as pacemakers and hearing aids), consult with your physician or the manufacturer to determine if they are adequately shielded from external RF signals. There are some places where RF signals could constitute a hazard, such as health care facilities, and construction sites. If you are not sure, look around for signs indicating that two-­‐way radios or mobile phones should be turned off. This device should be installed and operated with at least 20cm between the radiator and your body. FCC Compliance Information Radio Frequency Information This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Changes or modifications that are not expressly approved by the party responsible for compliance could make the device no longer comply with the FCC Rules. Information on your device is on file with the FCC and can be found by inputting your device’s FCC ID, which can be found on the back of Device, into the FCC ID Search form available at transition.fcc.gov/oet/ea/fccid. Information Regarding Exposure to Radio Frequency Energy The output power of the radio technology used in the Device is below the radio frequency exposure limits set by the FCC. Nevertheless, it is advised to use the Device in such a manner that minimizes the potential for human contact during normal operations. Recycling Product Properly In some areas, the disposal of certain electronic devices is regulated. Make sure you dispose of or recycle the Products in accordance with your local laws and regulations. Product Specifications Model #: DV83YW Ports: USB2.0, Ethernet 10/100, microSD, DC Power input, HDMI 2.0, Power — 15V 1.4A output power adapter (sold in-­‐box) Operating Voltage – 14.25VDC to 15.75VDC Connectivity — Dual Band Wi-­‐Fi (2.4/5 GHz); 802.11 a/b/g/n/ac; BT 2.1 BDR/EDR, BT 3.0, BT 4.1LE Operating temperature — 0 °C to 35 °C

Report No. : EP511534-02 Page Number : 1 of 12 Report Version : Rev. 01 Report No. : EP511534-02 Page Number : 2 of 12 Report Version : Rev. 01 Report No. : EP511534-02 Page Number : 3 of 12 Report Version : Rev. 01 Report No. : EP511534-02 Page Number : 4 of 12 Report Version : Rev. 01 Report No. : EP511534-02 Page Number : 5 of 12 Report Version : Rev. 01 Report No. : EP511534-02 Page Number : 6 of 12 Report Version : Rev. 01 720510 Report No. : EP511534-02 Page Number : 7 of 12 Report Version : Rev. 01

Model No: DV83YW FCC ID: 2ADU5-­‐4902 Label Located on Rear of device

Report No. : EP511534-02 Page Number : 8 of 12 Report Version : Rev. 01 Report No. : EP511534-02 Page Number : 9 of 12 Report Version : Rev. 01 Report No. : EP511534-02 Page Number : 10 of 12 Report Version : Rev. 01 Report No. : EP511534-02 Page Number : 11 of 12 Report Version : Rev. 01 Report No. : EP511534-02 Page Number : 12 of 12 Report Version : Rev. 01 720510

SPORTON INTERNATIONAL INC. Page Number : 1 of 7 TEL : 886-3-327-3456 Report Issued Date : Jul. 10, 2015 FAX : 886-3-328-4978 Report Version : Rev. 03 FCC ID : 2ADU5-4902 RF Exposure Evaluation Report APPLICANT : Quill Royal LLC EQUIPMENT : HDMI Digital Media Receiver MODEL NAME : DV83YW FCC ID : 2ADU5-4902 STANDARD : 47 CFR Part 2.1091 We, SPORTON INTERNATIONAL INC., would like to declare that the device has been evaluated in accordance with 47 CFR Part 2.1091, and pass the limit. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. SPORTON INTERNATIONAL INC. No.52, Hwa Ya 1st Rd., Hwa Ya Technology Park, Kwei-Shan District, Taoyuan City, Taiwan (R.O.C.) Approved by: Jones Tsai / Manager Reviewed by: Eric Huang / Deputy Manager SPORTON INTERNATIONAL INC. Page Number : 2 of 7 TEL : 886-3-327-3456 Report Issued Date : Jul. 10, 2015 FAX : 886-3-328-4978 Report Version : Rev. 03 FCC ID : 2ADU5-4902 Table of Contents 1. ADMINISTRATION DATA ........................................................................................................................... 3 1.1. Testing Laboratory ............................................................................................................................. 3 2. DESCRIPTION OF EQUIPMENT UNDER TEST (EUT) ............................................................................. 3 3. MAXIMUM RF AVERAGE OUTPUT POWER AMONG PRODUCTION UNITS ........................................ 4 4. RF EXPOSURE LIMIT INTRODUCTION .................................................................................................... 6 5. RADIO FREQUENCY RADIATION EXPOSURE EVALUATION ............................................................... 7 5.1. Standalone Power Density Calculation ............................................................................................. 7 5.2. Collocated Power Density Calculation ............................................................................................... 7 Revision History REPORT NO. VERSION DESCRIPTION ISSUED DATE FA511534-02 Rev. 01 Initial issue of report Jun. 10, 2015 FA511534-02 Rev. 02 Additional more channel number in the report Jul. 06, 2015 FA511534-02 Rev. 03 Re-calculating Power Density results Jul. 06, 2015 FA511534-02 Rev. 04 Revised the tune-up limit Jul. 10, 2015 SPORTON INTERNATIONAL INC. Page Number : 3 of 7 TEL : 886-3-327-3456 Report Issued Date : Jul. 10, 2015 FAX : 886-3-328-4978 Report Version : Rev. 03 FCC ID : 2ADU5-4902 1. Administration Data 1.1. Testing Laboratory Testing Laboratory Test Site SPORTON INTERNATIONAL INC. Test Site Location No.52, Hwa Ya 1st Rd., Hwa Ya Technology Park, Kwei-Shan District, Taoyuan City, Taiwan (R.O.C.) TEL: +886-3-327-3456 FAX: +886-3-328-4978 Applicant Company Name Quill Royal LLC Address 950 Bannock Street, Suite 1100 Boise, Idaho 83702 2. Description of Equipment Under Test (EUT) Product Feature & Specification EUT Type HDMI Digital Media Receiver Model Name DV83YW FCC ID 2ADU5-4902 Wireless Technology and Frequency Range WLAN 2.4GHz Band: 2412 MHz ~ 2462 MHz WLAN 5.2GHz Band: 5180 MHz ~ 5240 MHz WLAN 5.3GHz Band: 5260 MHz ~ 5320 MHz WLAN 5.5GHz Band: 5500 MHz ~ 5720 MHz WLAN 5.8GHz Band: 5745 MHz ~ 5825 MHz Bluetooth: 2402 MHz ~ 2480 MHz Mode •802.11 a/b/g/n/ac HT20/HT40/VHT20/VHT40/VHT80 •Bluetooth v3.0+EDR，Bluetooth v4.1-LE Antenna Type Fixed Internal Antenna Remark: The above EUT's information was declared by manufacturer. Please refer to the specifications or user's manual for more detailed description. SPORTON INTERNATIONAL INC. Page Number : 4 of 7 TEL : 886-3-327-3456 Report Issued Date : Jul. 10, 2015 FAX : 886-3-328-4978 Report Version : Rev. 03 FCC ID : 2ADU5-4902 3. Maximum RF average output power among production units Mode / Band Average Power (dBm) 1Mbps (GFSK) 2Mbps (π/4-DQPSK) 3Mbps (8-DPSK) BT4.1-LE (GFSK) 2.4 GHz Bluetooth 7.50 5.50 5.50 7.50 2.4GHz Channel / Frequency IEEE 802.11 Average Power (dBm) 11b 11g HT20 HT40 SISO SISO SISO MIMO SISO MIMO CH 1 (2412MHz) 19.50 14.00 13.00 15.50 CH 2 (2417MHz) 17.50 15.50 19.00 CH 3 (2422MHz) 8.50 12.50 CH 4 (2427MHz) 11.00 13.50 CH 6 (2437MHz) 17.50 21.00 21.00 24.50 14.50 18.00 CH 8 (2447MHz) 11.50 15.50 CH 9 (2452MHz) 11.50 15.00 CH 10 (2457MHz) 16.50 17.00 20.00 CH 11 (2462MHz) 16.50 14.50 13.50 17.50 5.2GHz Channel / Frequency IEEE 802.11 Average Power (dBm) 11a HT20 / VHT20 HT40 / VHT40 VHT80 SISO SISO MIMO SISO MIMO SISO MIMO CH 36 (5180MHz) 17.50 17.50 18.50 CH 38 (5190MHz) 13.00 16.00 CH 40 (5200MHz) 19.50 19.50 21.50 CH 42 (5210MHz) 11.00 11.50 CH 44 (5220MHz) 19.50 19.50 21.50 CH 46 (5230MHz) 19.50 21.50 CH 48 (5240MHz) 19.50 19.50 21.50 5.3GHz Channel / Frequency IEEE 802.11 Average Power (dBm) 11a HT20 / VHT20 HT40 / VHT40 VHT80 SISO SISO MIMO SISO MIMO SISO MIMO CH 52 (5260MHz) 20.00 20.00 22.00 CH 54 (5270MHz) 20.00 22.00 CH 56 (5280MHz) 20.00 20.00 22.00 CH 58 (5290MHz) 19.00 15.50 CH 60 (5300MHz) 20.00 20.00 22.00 CH 62 (5310MHz) 14.50 16.00 CH 64 (5320MHz) 18.00 18.00 20.00 SPORTON INTERNATIONAL INC. Page Number : 5 of 7 TEL : 886-3-327-3456 Report Issued Date : Jul. 10, 2015 FAX : 886-3-328-4978 Report Version : Rev. 03 FCC ID : 2ADU5-4902 5.5GHz Channel / Frequency IEEE 802.11 Average Power (dBm) 11a HT20 / VHT20 HT40 / VHT40 VHT80 SISO SISO MIMO SISO MIMO SISO MIMO CH 100 (5500MHz) 20.00 20.00 21.50 CH 102 (5510MHz) 14.00 13.50 CH 104 (5520MHz) 20.00 20.00 21.50 CH 106 (5530MHz) 12.00 12.50 CH 108 (5540MHz) 20.00 20.00 21.50 CH 110 (5550MHz) 19.00 21.50 CH 112 (5560MHz) 20.00 20.00 21.50 CH 116 (5580MHz) 20.00 20.00 21.50 CH 118 (5590MHz) 19.00 19.50 CH 120 (5600MHz) 20.00 20.00 21.50 CH 122 (5610MHz) 17.50 18.00 CH 124 (5620MHz) 20.00 20.00 21.50 CH 126 (5630MHz) 19.00 19.50 CH 128 (5640MHz) 20.00 20.00 21.50 CH 132 (5660MHz) 20.00 20.00 21.50 CH 134 (5670MHz) 19.00 19.50 CH 136 (5680MHz) 20.00 20.00 21.50 CH 138 (5690MHz) 19.00 21.50 CH 140 (5700MHz) 17.00 17.00 17.50 CH 142 (5710MHz) 19.00 21.50…

Text truncated - open the document above for the full version.

Report No. : FR511534-02D Report Version : Rev. 03 Page Number : 1 of 51 Report Template No.: BU5-FR15EWLB4 AC MA Version 1.0 FCC RF Test Report APPLICANT : Quill Royal LLC EQUIPMENT : HDMI Digital Media Receiver MODEL NAME : DV83YW FCC ID : 2ADU5-4902 STANDARD : FCC Part 15 Subpart E §15.407 CLASSIFICATION : (NII) Unlicensed National Information Infrastructure The testing was completed on Jun. 11, 2015. We, SPORTON INTERNATIONAL INC., would like to declare that the tested sample has been evaluated in accordance with the test procedures and has been in compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: Joseph Lin / Supervisor Approved by: Jones Tsai / Manager SPORTON INTERNATIONAL INC. No. 52, Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan District, Tao Yuan City, Taiwan, R.O.C. Report No. : FR511534-02D Report Version : Rev. 03 Page Number : 2 of 51 Report Template No.: BU5-FR15EWLB4 AC MA Version 1.0 TABLE OF CONTENTS SUMMARY OF TEST RESULT ......................................................................................................................... 4 1 GENERAL DESCRIPTION .......................................................................................................................... 5 1.1 Applicant ............................................................................................................................................ 5 1.2 Feature of Equipment Under Test ..................................................................................................... 5 1.3 Product Specification of Equipment Under Test ................................................................................ 5 1.4 Modification of EUT ........................................................................................................................... 7 1.5 Testing Location ................................................................................................................................ 7 1.6 Applicable Standards ......................................................................................................................... 8 2 TEST CONFIGURATION OF EQUIPMENT UNDER TEST ........................................................................ 9 2.1 Carrier Frequency and Channel ...................................................................................................... 10 2.2 Pre-Scanned RF Power ................................................................................................................... 11 2.3 Test Mode ........................................................................................................................................ 13 2.4 Connection Diagram of Test System ............................................................................................... 16 2.5 Support Unit used in test configuration and system ........................................................................ 17 2.6 EUT Operation Test Setup .............................................................................................................. 17 2.7 Measurement Results Explanation Example ................................................................................... 17 3 TEST RESULT ........................................................................................................................................... 18 3.1 26dB Bandwidth Measurement ....................................................................................................... 18 3.2 Maximum Conducted Output Power Measurement ........................................................................ 20 3.3 Power Spectral Density Measurement ............................................................................................ 23 3.4 Unwanted Emissions Measurement ................................................................................................ 26 3.5 AC Conducted Emission Measurement........................................................................................... 41 3.6 Frequency Stability Measurement ................................................................................................... 45 3.7 Automatically Discontinue Transmission ......................................................................................... 46 3.8 Antenna Requirements .................................................................................................................... 48 4 LIST OF MEASURING EQUIPMENT ........................................................................................................ 50 5 UNCERTAINTY OF EVALUATION ........................................................................................................... 51 APPENDIX A. CONDUCTED TEST RESULTS APPENDIX B. RADIATED TEST RESULTS Report No. : FR511534-02D Report Version : Rev. 03 Page Number : 3 of 51 Report Template No.: BU5-FR15EWLB4 AC MA Version 1.0 REVISION HISTORY REPORT NO. VERSION DESCRIPTION ISSUED DATE FR511534-02D Rev. 01 Initial issue of report Jun. 08, 2015 FR511534-02D Rev. 02 Update report of adding straddle channels at page 6/7 and adding Ch122/Ch138 at page 14. Jul. 03, 2015 FR511534-02D Rev. 03 Update report of revising conducted power Jul. 10, 2015 Report No. : FR511534-02D Report Version : Rev. 03 Page Number : 4 of 51 Report Template No.: BU5-FR15EWLB4 AC MA Version 1.0 SUMMARY OF TEST RESULT Report Section FCC Rule Description Limit Result Remark 3.1 2.1049 15.403(i) 26dB Bandwidth - Pass - 3.2 15.407(a) Maximum Conducted Output Power ≤ 24 dBm (depend on band) Pass - 3.3 15.407(a) Power Spectral Density ≤ 11 dBm (depend on band) Pass - 3.4 15.407(b) Unwanted Emissions ≤ -17, -27 dBm (depend on band)&15.209(a) Pass Under limit 0.50 dB at 5149.850 MHz 3.5 15.207 AC Conducted Emission 15…

Text truncated - open the document above for the full version.

Report No. : FR511534-02E Report Version : Rev. 01 Page Number : 1 of 44 Report Template No.: BU5-FR15EWLB4 AC MA Version 1.0 FCC RF Test Report APPLICANT : Quill Royal LLC EQUIPMENT : HDMI Digital Media Receiver MODEL NAME : DV83YW FCC ID : 2ADU5-4902 STANDARD : FCC Part 15 Subpart E §15.407 CLASSIFICATION : (NII) Unlicensed National Information Infrastructure The testing was completed on Jun. 11, 2015. We, SPORTON INTERNATIONAL INC., would like to declare that the tested sample has been evaluated in accordance with the test procedures and has been in compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: Joseph Lin / Supervisor Approved by: Jones Tsai / Manager SPORTON INTERNATIONAL INC. No. 52, Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan District, Tao Yuan City, Taiwan, R.O.C. Report No. : FR511534-02E Report Version : Rev. 01 Page Number : 2 of 44 Report Template No.: BU5-FR15EWLB4 AC MA Version 1.0 TABLE OF CONTENTS REVISION HISTORY .......................................................................................................................................... 3 SUMMARY OF TEST RESULT ......................................................................................................................... 4 1 GENERAL DESCRIPTION .......................................................................................................................... 5 1.1 Applicant ............................................................................................................................................ 5 1.2 Feature of Equipment Under Test ..................................................................................................... 5 1.3 Product Specification of Equipment Under Test ................................................................................ 6 1.4 Modification of EUT ........................................................................................................................... 6 1.5 Testing Location ................................................................................................................................ 7 1.6 Applicable Standards ......................................................................................................................... 7 2 TEST CONFIGURATION OF EQUIPMENT UNDER TEST ........................................................................ 8 2.1 Carrier Frequency and Channel ........................................................................................................ 8 2.2 Pre-Scanned RF Power ..................................................................................................................... 9 2.3 Test Mode ........................................................................................................................................ 11 2.4 Connection Diagram of Test System ............................................................................................... 12 2.5 Support Unit used in test configuration and system ........................................................................ 13 2.6 EUT Operation Test Setup .............................................................................................................. 13 2.7 Measurement Results Explanation Example ................................................................................... 13 3 TEST RESULT ........................................................................................................................................... 14 3.1 6dB Bandwidth Measurement ......................................................................................................... 14 3.2 Maximum Conducted Output Power Measurement ........................................................................ 16 3.3 Power Spectral Density Measurement ............................................................................................ 17 3.4 Unwanted Emissions Measurement ................................................................................................ 20 3.5 AC Conducted Emission Measurement........................................................................................... 34 3.6 Frequency Stability Measurement ................................................................................................... 38 3.7 Automatically Discontinue Transmission ......................................................................................... 39 3.8 Antenna Requirements .................................................................................................................... 41 4 LIST OF MEASURING EQUIPMENT ........................................................................................................ 43 5 UNCERTAINTY OF EVALUATION ........................................................................................................... 44 APPENDIX A. CONDUCTED TEST RESULTS APPENDIX B. RADIATED TEST RESULTS Report No. : FR511534-02E Report Version : Rev. 01 Page Number : 3 of 44 Report Template No.: BU5-FR15EWLB4 AC MA Version 1.0 REVISION HISTORY REPORT NO. VERSION DESCRIPTION ISSUED DATE FR511534-02E Rev. 01 Initial issue of report Jun. 15, 2015 FR511534-02E Rev. 02 Update report of revising MIMO HT20 CH165 and HT40 CH 159 of conducted power. Jul. 10, 2015 Report No. : FR511534-02E Report Version : Rev. 01 Page Number : 4 of 44 Report Template No.: BU5-FR15EWLB4 AC MA Version 1.0 SUMMARY OF TEST RESULT Report Section FCC Rule Description Limit Result Remark 3.1 15.403(i) 6dB Bandwidth > 500kHz Pass - 3.2 15.407(a) Maximum Conducted Output Power ≤ 30 dBm Pass - 3.3 15.407(a) Power Spectral Density ≤ 30 dBm/500kHz Pass - 3.4 15.407(b) Unwanted Emissions ≤ -17, -27 dBm/MHz &15.209(a) Pass Under limit 0.50 dB at 5712.600 MHz 3.…

Text truncated - open the document above for the full version.

Report No. : FZ511534-02 Report Version : Rev. 03 Page Number : 1 of 20 Report Template No.: BU5-FZ15EDFS Version 1.0 DYNAMIC FREQUENCY SELECTION DFS Test Report APPLICANT : Quill Royal LLC EQUIPMENT : HDMI Digital Media Receiver MODEL NAME : DV83YW FCC ID : 2ADU5-4902 STANDARD : FCC Part 15 Subpart E CLASSIFICATION : (NII) Unlicensed National Information Infrastructure The product completely tested on May 13, 2015. We, SPORTON INTERNATIONAL INC., would like to declare that the tested sample has been evaluated in accordance with the procedures and shown to be compliant with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: Jones Tsai / Manager SPORTON INTERNATIONAL INC. No. 52, Hwa Ya 1st Rd., Hwa Ya Technology Park, Kwei-Shan District, Tao Yuan City, Taiwan, R.O.C. Report No. : FZ511534-02 Report Version : Rev. 03 Page Number : 2 of 20 Report Template No.: BU5-FZ15EDFS Version 1.0 TABLE OF CONTENTS REVISION HISTORY .......................................................................................................................................... 3 SUMMARY OF DYNAMIC FREQUENCY SELECTION TEST .......................................................................... 4 1 GENERAL DESCRIPTION .......................................................................................................................... 5 1.1 Applicant ........................................................................................................................................... 5 1.2 Feature of Equipment Under Test .................................................................................................... 5 1.3 Product Specification of Equipment Under Test ............................................................................... 5 1.4 Testing Site ....................................................................................................................................... 6 1.5 Applied Standards ............................................................................................................................ 6 1.6 Support Unit used in test configuration and system ......................................................................... 6 2 REQUIREMENTS AND PARAMETERS FOR DFS TEST .......................................................................... 7 2.1 Applicability of DFS Requirements ................................................................................................... 7 2.2 Interference Threshold values, Master or Client incorporating In-Service Monitoring ..................... 9 2.3 DFS Response requirement values ................................................................................................ 10 2.4 Short Pulse Radar Test Waveforms ............................................................................................... 11 3 CALIBRATION SETUP AND DFS TEST RESULTS ................................................................................ 12 3.1 Calibration of Radar Waveform ...................................................................................................... 12 3.2 In-Service Monitoring: Channel Move Time, Channel Closing Transmission Time and Non-Occupancy Period ................................................................................................................... 14 4 LIST OF MEASURING EQUIPMENT ........................................................................................................ 20 Report No. : FZ511534-02 Report Version : Rev. 03 Page Number : 3 of 20 Report Template No.: BU5-FZ15EDFS Version 1.0 REVISION HISTORY REPORT NO. VERSION DESCRIPTION ISSUED DATE FZ511534-02 Rev. 01 Initial issue of report May 25, 2015 FZ511534-02 Rev. 02 Update report of revising EUT support WLAN function at page 5 Jul. 03, 2015 FZ511534-02 Rev. 03 Update report of revising EUT support frequency range at page 5 Jul. 06, 2015 Report No. : FZ511534-02 Report Version : Rev. 03 Page Number : 4 of 20 Report Template No.: BU5-FZ15EDFS Version 1.0 SUMMARY OF DYNAMIC FREQUENCY SELECTION TEST UNII Bandwidth and Channel Description Measured Limit Result UNII Band 2-C 5470-5725MHz 40MHz (CH102) 5510MHz Channel Move Time 0.5722 sec 10 sec Pass Channel Closing Transmission time <200ms + 1.2 ms (aggregate) 200 ms + aggregate of 60 ms over remaining 10 s period Pass Non-Occupancy Period and Client Beacon Test No transmission or Beacons occurred 30 minutes Pass Note: Since the product is client without radar detection function, only Channel Move Time, Channel Closing Transmission Time and Non-Occupancy Period Test are required to be performed. Report No. : FZ511534-02 Report Version : Rev. 03 Page Number : 5 of 20 Report Template No.: BU5-FZ15EDFS Version 1.0 1 General Description 1.1 Applicant Quill Royal LLC 950 Bannock Street, Suite 1100 Boise, Idaho 83702 1.2 Feature of Equipment Under Test Product Feature Equipment HDMI Digital Media Receiver Model Name DV83YW FCC ID 2ADU5-4902 EUT supports Radios application WLAN 11a/b/g/n HT20/HT40 WLAN 11ac VHT20/VHT40/VHT80 Bluetooth 4.1 EDR/LE Remark: The above EUT's information was declared by manufacturer. Please refer to the specifications or user's manual for more detailed description. 1.3 Product Specification of Equipment Under Test Product Specification subjective to this standard DFS Function Client without radar detection function Tx/Rx Channel Frequency Range 5260 MHz ~ 5320 MHz 5500 MHz ~ 572…
