2ADUSSCVV5INMOTION SCV V5

FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

INMOTION TECHNOLOGIES CO., LTD Agent Authorization Letter 2015/10/21 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen BCTC Technology Co., Ltd to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s name / title : XiaXinyun/manager Contact information / address: 6TH FLOOR, BUILDING 8, TONGFUYU INDUSTRY CITY, XILI, NAN SHAN, SHEN ZHEN, CHINA 518055

INMOTION TECHNOLOGIES CO., LTD Model Difference FCC ID: 2ADUSSCVV5 Model : INMOTION SCV V5 INMOTION SCV V5+, INMOTION SCV V5A, INMOTION SCV V5B, INMOTION SCV V5C, INMOTION SCV V5D, INMOTION SCV V5E, INMOTION SCV V5F All the models are the same circuit and RF module, except the model names and outlook color. Regards Sincerely Client’s signature Client’s name / title : XiaXinyun/manager Contact information / address: 6TH FLOOR, BUILDING 8, TONGFUYU INDUSTRY CITY, XILI, NAN SHAN, SHEN ZHEN, CHINA 518055

M/N: INMOTION SCV V5 FCC ID: 2ADUSSCVV5 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Label location

Antenna location

Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151012582 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 1 of 30 FCC Part 15C Test Report FCC ID: 2ADUSSCVV5 Product Name: INMOTION SCV V5 Trademark: INMOTION Model Name : INMOTION SCV V5, INMOTION SCV V5, INMOTION SCV V5+, INMOTION SCV V5A, INMOTION SCV V5B, INMOTION SCV V5C, INMOTION SCV V5D, INMOTION SCV V5E, INMOTION SCV V5F Prepared For : INMOTION TECHNOLOGIES CO., LTD. Address : 6th Floor, Building 8, Tongfuyu Industry City, Xili, Nan Shan, Shen Zhen, China 518055 Prepared By : Shenzhen BCTC Technology Co., Ltd. Address : No.101,Yousong Road,Longhua New District, Shenzhen,China Test Date: Oct. 14 – Oct. 19, 2015 Date of Report : Oct. 20, 2015 Report No.: BCTC-151012582 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151012582 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 2 of 30 VERIFICATION OF COMPLIANCE Applicant’s name ................. : INMOTION TECHNOLOGIES CO., LTD. Address ................................. : 6th Floor, Building 8, Tongfuyu Industry City, Xili, Nan Shan, Shen Zhen, China 518055 Manufacture's Name ............ : INMOTION TECHNOLOGIES CO., LTD. Address ................................. : 6th Floor, Building 8, Tongfuyu Industry City, Xili, Nan Shan, Shen Zhen, China 518055 Product description Product name ........................... : INMOTION SCV V5 Trademark: INMOTION Model Name: INMOTION SCV V5, INMOTION SCV V5+, INMOTION SCV V5A, INMOTION SCV V5B, INMOTION SCV V5C, INMOTION SCV V5D, INMOTION SCV V5E, INMOTION SCV V5F Test procedure FCC Part15.249 Standards ANSI C63.10-2013 This device described above has been tested by BCTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Test Result ............................................... : Pass Testing Engineer : (Eric Yang) Technical Manager : (Sophia Lee) Authorized Signatory : (Carson. Zhang) Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151012582 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 3 of 30 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST MODES 7 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 8 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.5 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 8 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 9 3 . EMC EMISSION TEST 10 3.1 CONDUCTED EMISSION MEASUREMENT 10 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 10 3.1.2 TEST PROCEDURE 11 3.1.3 DEVIATION FROM TEST STANDARD 11 3.1.4 TEST SETUP 11 3.1.5 EUT OPERATING CONDITIONS 11 3.1.6 TEST RESULTS 12 3.2 RADIATED EMISSION MEASUREMENT 14 3.2.1 RADIATED EMISSION LIMITS 14 3.2.2 TEST PROCEDURE 15 3.2.3 DEVIATION FROM TEST STANDARD 15 3.2.4 TEST SETUP 16 3.2.5 EUT OPERATING CONDITIONS 17 3.2.6 TEST RESULTS 18 4 . BANDWIDTH TEST 22 4.1 APPLIED PROCEDURES / LIMIT 22 4.1.1 TEST PROCEDURE 22 4.1.2 DEVIATION FROM STANDARD 22 4.1.3 TEST SETUP 22 4.1.4 EUT OPERATION CONDITIONS 22 4.1.5 TEST RESULTS 23 5 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 25 5.1 DEVIATION FROM STANDARD 26 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151012582 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 4 of 30 Table of Contents Page 5.2 TEST SETUP 26 5.3 EUT OPERATION CONDITIONS 26 5.4 TEST RESULTS 26 6 . ANTENNA REQUIREMENT 27 6.1 STANDARD REQUIREMENT 27 6.2 EUT ANTENNA 27 7 . EUT TEST PHOTO 28 8 . EUT PHOTO 30 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151012582 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 5 of 30 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.249) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.249 Fundamental &Radiated Spurious Emission Measurement PASS 15.249 Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 TEST FACILITY Shenzhen BCTC Technology Co., Ltd. Add.:No.101,Yousong Road,Longhua New District, Shenzhen,China FCC Registration No.:187086 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151012582 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 6 of 30 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment INMOTION SCV V5 Trade Name INMOTION Model Name INMOTION SCV V5, INMOTION SCV V5+, INMOTION SCV V5A, INMOTION SCV V5B, INMOTION SCV V5C, INMOTION SCV V5D, INMOTION SCV V5E, INMOTION SCV V5F Model Difference All the models are the same circuit and RF module, except the model names and outlook color. Product Description Operation Frequency: 2402~2480 MHz Modulation Type: GFSK Bluetooth: Bluetooth 4.0 Number Of Channel: 40 CH Antenna Designation: Please see Note 3. Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Channel List Please refer to the Note 2. Power Supply DC 72V DC 84V from adapter Con…

Text truncated - open the document above for the full version.

Radiated Emission Conducted Emission
