2ADUV1Beacon Transmitter

Metromile, Inc.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Dec 21, 2014
Application Purpose: Original Equipment
Date of Application: Dec 21, 2014
Equipment Note: Beacon Transmitter
Frequency Range: 2402.00000000 - 2480.00000000
Company: Metromile, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

MMBeacon USER’S MANUAL Please Register your product at www.metromile.com English Metromile, Inc. CONTENTS Caution And Warning FCC Notice Preparing your new MMBeacon for use Using the MMBeacon MMBeacon Features Product Specification Warranty FCC Notice This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. Safety Precautions 1. Read all instructions. 2. Do not use the MMBeacon in water. 3. Clean with a dry cloth. 4. Only use attachments specified by the manufacturer. 5. The MMBeacon is not serviceable. 6. Do not attempt to service the MMBeacon. 7. Return the MMBeacon to Metromile for replacement and disposal when the battery is discharged. 8. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Preparing your new MMBeacon for use Activate MMBeacon (Refer to Figure 1) 1. Remove MMBeacon from packaging 2. Pull the plastic tab out of the MMBeacon 3. Beacon is now active The MMBeacon is now ready for use. Figure 1. Using the MMBeacon Place the MMBeacon in a convenient location inside your car. The MMBeacon broadcasts an iBeacon signal. Your Metromile App uses this signal to know when you are driving in your car and records driving statistics and location data. Figure 2. MM Beacon Features 1. Bluetooth Low Energy – 22 month battery life 2. Always on Product Specification •2.4 GHz Bluetooth 4.0 •Low power – Up to 22 months of operation on a CR2032 battery Warranty One Year Limited Warranty for USA Your MMbeacon (the “Product”), and only the Product is warranted by Metromile, Inc. to be free from defects in workmanship or materials, under normal use, for a period of one year from the date of purchase. This limited warranty excludes damage resulting from normal wear and tear, defects or damage caused by mis-‐use, accident (inc luding without limitation collision, fire and spillage of liquid), neglect, abuse, alteration, unusual stress, modification, improper or unauthorized repair, installation, wiring or testing, use with an unapproved device; use not in accordance with the documentation: and damage caused by the equipment with which the Product is used.

Block Diagram

CC2541 (U1) System On Chip Balun (B241) Matching Network (C242,L243) CR2032 Battery (BC1) 3V Lithium TPS62730 DC/DC Converter (U2) 32 MHz Crystal (X1) 32.768kHz Crystal (X2) Battery Voltage 3V System Voltage 3V Rx/Tx signals GPIO RFP,RFN Metromile Beacon Designed by Carinae Sports 9/30/2014 SFR bus SFR bus MEMORY ARBITRATOR 8051 CPU CORE DMA FLASH SRAM FLASH CTRL DEBUG INTERFACE RESET RESET_N P2_4 P2_3 P2_2 P2_1 P2_0 P1_4 P1_3 P1_2 P1_1 P1_0 P1_7 P1_6 P1_5 P0_4 P0_3 P0_2 P0_1 P0_0 P0_7 P0_6 P0_5 32.768-kHz CRYSTAL OSC 32-MHZ CRYSTAL OSC HIGH SPEED RC-OSC 32-kHz RC-OSC CLOCK MUX and CALIBRATION RAM USART 0 USART 1 TIMER 1 (16-Bit) TIMER 3 (8-bit) TIMER 2 (BLE LL TIMER) TIMER 4 (8-bit) AES ENCRYPTION and DECRYPTION WATCHDOG TIMER IRQ CTRL FLASH UNIFIED RF_P RF_N SYNTH MODULATOR POWER-ON RESET BROWN OUT RADIO REGISTERS POWER MGT. CONTROLLER SLEEP TIMER PDATA XRAM IRAM SFR XOSC_Q2 XOSC_Q1 DSADC AUDIO / DC DIGITAL ANALOG MIXED VDD (2 V–3.6 V) DCOUPL ON-CHIP VOLTAGE REGULATOR Link Layer Engine FREQUENCY SYNTHESIZER I 2 C DEMODULATOR RECEIVE TRANSMIT OP- ANALOG COMPARATOR I/O CONTROLLER 1-KB SRAM Radio Arbiter FIFOCTRL SDA SCL CC2541 SWRS110D – JANUARY 2012 – REVISED JUNE 2013www.ti.com BLOCK DIAGRAM A block diagram of the CC2541 is shown inFigure 9. The modules can be roughly divided into one of three categories: CPU-related modules; modules related to power, test, and clock distribution; and radio-related modules. Figure 9. CC2541 Block Diagram 18Submit Documentation FeedbackCopyright © 2012–2013, Texas Instruments Incorporated Product Folder Links:CC2541

Cover Letter(s)

Dec 2014 Metromile, Inc. 292 Townsend Street San Francisco, CA 94107 Letter of Agency "I, an officer of Metromile, Inc. do hereby authorize Intertek Testing Services (Mr. Terry Chan / Kenneth Wong) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and Part 18 of the FCC Rules until further notice." I further certify that no party (as defined in §1.2002(b) of CFR 47, 2004) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.,862. Dated this 3rd day of December, 2014 By Signature Dan Preston Printed Name CEO Title Remark: The person who signs this authorization letter must be the grantee contact of record in the Grantee Code data base. DocuSign Envelope ID: EF5AC70F-80CE-4131-B924-4F1487FEBF9C

Cover Letter(s)

Metromile, Inc. 292 Townsend Street San Francisco, CA 94107 Confidential Request Letter Sample Attention: Application Examiner Re: Request for confidentiality Applicant: Metromile, Inc. FCC ID: [List FCC ID number here] To whom it may concern, Short-term Confidentiality Request is hereby submitted by {Your company name] to withhold from public review for a period of 45 days from the date of the Grant of Equipment Authorization and prior to marketing, certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept confidential for a period of 45 days from the date of Authorization: xSchematics xDetailed Block diagrams xDetailed Operational/Functional Description xTune up procedure xParts list xTest setup photos xExternal photos xInternal photos xUser manual Rationale for request for confidentiality: Metromile, Inc. has invested considerable time and materials in research and development to produce the referenced product. [Permanent confidentiality: Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us.][Short term confidentiality: Disclosure of the short-term confidential portions of this application during the period of importation and/or distribution would reveal key aspects of proprietary technology to competitors and diminish the value of our investment in research and development.] The fee for confidentiality has been submitted along with the fee for certification. If you have questions or need further information, please contact the undersigned. Sincerely, Dan Preston CEO Metromile, Inc. DocuSign Envelope ID: EF5AC70F-80CE-4131-B924-4F1487FEBF9C Metromile, Inc. 2ADUV1

External Photos

INTERTEK TESTING SERVICE Report No.: 14110700HKG-001 FCC ID: 2ADUV1 Equipment Photographs Model : M1401 (External)

External Photos

INTERTEK TESTING SERVICE Report No.: 14110700HKG-001 FCC ID: 2ADUV1 Equipment Photographs Model : M1401 (External)

ID Label/Location Info

INTERTEK TESTING SERVICE Report No.: 14110700HKG-001 FCC ID: 2ADUV1 Equipment Photographs Model : M1401 (Label location) METROMILE, BEACON, AWRK, FCC ID, TOP CASE121814rev.003 REV.DESCRIPTION SHEETS REV’D 001INITIAL RELEASEALL SHEET 1 OF 1 DRAWN BYDAT E HARTE11/26/14 NOTES UNLESS OTHERWISE SPECIFIED 1 2 3 4 5 DO NOT SCALE; ARTWORK PLACEMENT 1:1 PRINTED GRAPHIC CENTER ARTWORK ALONG MIDPLANE COLOR: PMS BLACK C PRINTING TOLERANCE ± 0.2MM 002ETCHING TO PAD PRINT ALLHARTE12/15/14 003REVISE FCC IDALL HARTE12/18/14 14.60mm C L 1 Font: Gotham ScreenSmart Book Size: 5pt 14.60mm 1.31mm 1.00mm offset from edge Black C

Internal Photos

INTERTEK TESTING SERVICE Report No.: 14110700HKG-001 FCC ID: 2ADUV1 Equipment Photographs Model: M1401 (Internal) INTERTEK TESTING SERVICE Report No.: 14110700HKG-001 FCC ID: 2ADUV1 Equipment Photographs Model: M1401 (Internal) INTERTEK TESTING SERVICE Report No.: 14110700HKG-001 FCC ID: 2ADUV1 Equipment Photographs Model: M1401 (Internal) INTERTEK TESTING SERVICE Report No.: 14110700HKG-001 FCC ID: 2ADUV1 Equipment Photographs Model: M1401 (Internal)

Internal Photos

Operational Description

The Equipment Under Test (EUT) is a Beacon Transmitter which is placed inside a vehicle. The EUT broadcasts a Bluetooth BLE signal. The corresponding Metromile Apps program running in an IOS device (e.g. Apple iphone) uses this signal to know when the driver driving in the vehicle and records driving statistics and location data. The EUT can only support Bluetooth 4.0 BLE only. The Bluetooth portion occupies a frequency range of 2402MHz to 2480MHz (40 channels with channel spacing of 2MHz). The EUT is powered by a CR2032 3V Lithium battery. The main components are described below: 1. U1 (CC2541) is a System-On-Chip (SOC) solution incorporating with Bluetooth 4.0 BLE Compliant radio, 8051 MCU, 8k RAM, CODEC and other I/O peripherals. 2. B241 (LFB182G45BG2D280) is the balance matching band-pass filter for the 2.4GHz ISM band. 3. C242 and L243 are components of the antenna matching network. 4. X1 (32MHz crystal) provides system clock for U1 (CC2541). 5. X2 (32.768kHz crystal) provides a slow clock for reducing operating energy. 6. BC1 is CR2032 3.0V Lithium battery. 7. U2 (TPS62730) is DC/DC converter provides 3V regulated power supply. 8. PB1 is Tact switch for activating the EUT. 9. D1 is green LED indicator. Bluetooth Portion Modulation Type: GFSK Antenna Type: Internal, Internal (PCB Trace) Frequency Range: 2402MHz to 2480MHz, 2MHz channel spacing, 40 channels Antenna Gain: 0dBi Normal rated field strength: 99.8dB μV/m @ 3m Maximum allowed field strength of production tolerance: +/-3dB CC2541 Bluetooth 4.0 BLE Channel Table Channel Frequency (MHz) 1 2402 2 2404 3 2406 4 2408 5 2410 6 2412 7 2414 8 2416 9 2418 10 2420 11 2422 12 2424 13 2426 14 2428 15 2430 16 2432 17 2434 18 2436 19 2438 20 2440 21 2442 22 2444 23 2446 24 2448 25 2450 26 2452 27 2454 28 2456 29 2458 30 2460 31 2462 32 2464 33 2466 34 2468 35 2470 36 2472 37 2474 38 2476 39 2478 40 2480 CC2541 www.ti.comSWRS110D– JANUARY2012– REVISEDJUNE2013 2.4-GHzBluetooth™lowenergyandProprietarySystem-on-Chip CheckforSamples:CC2541 1 FEATURES 23 •RF –High-PerformanceandLow-Power8051 MicrocontrollerCoreWithCodePrefetch –2.4-GHzBluetoothlowenergyCompliant andProprietaryRFSystem-on-Chip–In-System-ProgrammableFlash,128-or 256-KB –Supports250-kbps,500-kbps,1-Mbps,2- MbpsDataRates–8-KBRAMWithRetentioninAllPower Modes –ExcellentLinkBudget,EnablingLong- RangeApplicationsWithoutExternalFront–HardwareDebugSupport End –ExtensiveBasebandAutomation,Including –ProgrammableOutputPowerupto0 dBmAuto-AcknowledgmentandAddress Decoding –ExcellentReceiverSensitivity(–94dBmat 1 Mbps),Selectivity,andBlocking–RetentionofAllRelevantRegistersinAll PerformancePowerModes –SuitableforSystemsTargetingCompliance•Peripherals WithWorldwideRadioFrequency –PowerfulFive-ChannelDMA Regulations:ETSIEN300328andEN300 –General-PurposeTimers(One16-Bit,Two 440Class2 (Europe),FCCCFR47Part15 8-Bit) (US),andARIBSTD-T66(Japan) –IRGenerationCircuitry •Layout –32-kHzSleepTimerWithCapture –FewExternalComponents –AccurateDigitalRSSISupport –ReferenceDesignProvided –BatteryMonitorandTemperatureSensor –6-mm× 6-mmQFN-40Package –12-BitADCWithEightChannelsand –Pin-CompatibleWithCC2540(WhenNot ConfigurableResolution UsingUSBorI 2 C) –AESSecurityCoprocessor •LowPower –TwoPowerfulUSARTsWithSupportfor –Active-ModeRXDownto:17.9mA SeveralSerialProtocols –Active-ModeTX(0dBm):18.2mA –23General-PurposeI/OPins –PowerMode1 (4-μs Wake-Up):270μA (21× 4 mA,2 × 20mA) –PowerMode2 (SleepTimerOn):1 μA –I 2 C interface –PowerMode3 (ExternalInterrupts):0.5μA –2 I/OPinsHaveLEDDrivingCapabilities –WideSupply-VoltageRange(2V–3.6V) –WatchdogTimer •TPS62730CompatibleLowPowerinActive –IntegratedHigh-PerformanceComparator Mode •DevelopmentTools –RXDownto:14.7mA(3-Vsupply) –CC2541EvaluationModuleKit –TX(0dBm):14.3mA(3-Vsupply) (CC2541EMK) Whitespace –CC2541MiniDevelopmentKit(CC2541DK- Whitespace MINI) Whitespace –SmartRF™Software Whitespace –IAREmbeddedWorkbench™Available Whitespace Whitespace •Microcontroller 1 Pleasebeawarethatanimportantnoticeconcerningavailability,standardwarranty,andusein criticalapplicationsof TexasInstrumentssemiconductorproductsanddisclaimerstheretoappearsattheendofthisdatasheet. 2Bluetoothis a trademarkofBluetoothSIG,Inc.. 3ZigBeeis a registeredtrademarkofZigBeeAlliance. PRODUCTIONDATAinformationis currentasofpublicationdate. Copyright© 2012–2013,TexasInstrumentsIncorporated ProductsconformtospecificationsperthetermsoftheTexas Instrumentsstandardwarranty.Productionprocessingdoesnot necessarilyincludetestingofallparameters. CC2541 SWRS110D– JANUARY2012– REVISEDJUNE2013www.ti.com SOFTWAREFEATURESCC2541WITHTPS62730 •Bluetoothv4.0CompliantProtocolStackfor•TPS62730isa 2-MHzStep-DownConverter Single-ModeBLESolutionWithBypassMode –CompletePower-OptimizedStack,•ExtendsBatteryLifetimebyupto20% IncludingControllerandHost •ReducedCurrentinAllActiveModes –GAP– Central,Peripheral,Observer,or •30-nABypassModeCurrenttoSupportLow- Broadcaster(IncludingCombination PowerModes Roles) •RFPerformanceUnchanged –ATT/ GATT– ClientandServer •SmallPackageAllowsforSmallSolutionSize –SMP– AES-128Encryptionand •CC2541Controllable Decryption –L2CAP DESCRIPTION –SampleApplicationsandProfiles TheCC2541isa power-optimizedtruesystem-on- chip(SoC)solutionforbothBluetoothlowenergyand –GenericApplicationsforGAPCentral proprietary2.4-GHzapplications.Itenablesrobust andPeripheralRoles networknodestobebuiltwithlowtotalbill-of-material –Proximity,Accelerometer,SimpleKeys, costs.TheCC2541combinestheexcellent andBatteryGATTServices performanceofaleadingRFtransceiverwithan –MoreApplicationsSupportedinBLE industry-standardenhanced8051MCU,in-system programmableflashmemory,8-KBRAM,andmany SoftwareStack otherpowerfulsupportingfeaturesandperipherals. –MultipleConfigurationOptions TheCC2541ishighlysuitedforsystemswhere –Single-ChipConfiguration,Allowing ultralowpowerconsumptionisrequired.Thisis ApplicationstoRunonCC2541 specifiedbyvariousoperatingmodes.Shorttransition timesbetweenoperatingmodesfurtherenablelow –NetworkProcessorInterfacefor …

Text truncated - open the document above for the full version.

RF Exposure Info

Analysis Report Report No.: 14110700HKG-001 The Equipment Under Test (EUT) is a Beacon Transmitter which is placed inside a vehicle. The EUT broadcasts a Bluetooth BLE signal. The corresponding Metromile Apps program running in an IOS device (e.g. Apple iphone) uses this signal to know when the driver driving in the vehicle and records driving statistics and location data. The EUT can only support Bluetooth 4.0 BLE only. The Bluetooth portion occupies a frequency range of 2402MHz to 2480MHz (40 channels with channel spacing of 2MHz). The EUT is powered by a CR2032 3V Lithium battery. Antenna Type: Internal integral antenna Antenna Gain: 0dBi Nominal rated field strength: 99.8dBμV/m at 3m Maximum allowed field strength of production tolerance: +/- 3dB According to the KDB 447498: Based on the Maximum allowed field strength of production tolerance was 102.8dBμV/m at 3m in frequency 2.4GHz, thus; The EIRP = [(FS*D) ^2*1000 / 30] = 5.716mW Conducted power = Radiated Power (EIRP) – Antenna Gain So; Conducted Power = 5.716mW. The SAR Exclusion Threshold Level: = 3.0 * (min. test separation distance, mm) / sqrt(freq. in GHz) = 3.0 * 5 / sqrt (2.480) mW = 9.53 mW Since the above conducted output power is well below the SAR Exclusion threshold level, so the EUT is considered to comply with SAR requirement without testing.

RF Exposure Info

Test Report

- Intertek's standard Terms and Conditions can be obtained at our website http://www.intertek.com/terms/. - The test report only allows to be revised within the retention period unless further standard or the requirement was noticed. - This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com TEST REPORT Report No.: 14110700HKG-001 Metromile, Inc. Application For Certification (Original Grant) (FCC ID: 2ADUV1) Transceiver Prepared and Checked by: Approved by: Signed On File Wong Cheuk Ho, Herbert Lead Engineer Wong Kwok Yeung, Kenneth Lead Engineer Date: December 22, 2014 INTERTEK TESTING SERVICES Report No.: 14110700HKG-001 i FCC ID: 2ADUV1 GENERAL INFORMATION Grantee: Metromile, Inc. Grantee Address: 292 Townsend St., San Francisco, California 94107, United States. Contact Person: Dan Preston Tel: (888) 244-1702 Fax: N/A e-mail: [email protected] Manufacturer: Dongguan Kwan Hong Electronics Co., Ltd. Manufacturer Address: KwanHong Building, Xiao Bian 2nd Industrial Zone, Chang An, Dongguan, China. Brand Name: Metromile Beacon Model: M1401 Type of EUT: Transceiver Description of EUT: Beacon Transmitter Serial Number: N/A FCC ID: 2ADUV1 Date of Sample Submitted: November 18, 2014 Date of Test: November 18, 2014 to November 26, 2014 Report No.: 14110700HKG-001 Report Date: December 22, 2014 Environmental Conditions: Temperature: +10 to 40°C Humidity: 10 to 90% INTERTEK TESTING SERVICES Report No.: 14110700HKG-001 ii FCC ID: 2ADUV1 SUMMARY OF TEST RESULT TEST SPECIFICATION REFERENCE RESULTS Radiated Emission Radiated Emission on the Bandedge 15.249 Pass Radiated Emission in Restricted Bands 15.205 Pass Digital Device Radiated Emissions 15.209 Pass The equipment under test is found to be complying with the following standards: FCC Part 15, October 1, 2013 Edition Note: 1. The EUT uses a permanently attached antenna which, in accordance to section 15.203, is considered sufficient to comply with the pervisions of this section. 2. Pursuant to FCC part 15 Section 15.215(c), the 20 dB bandwidth of the emission was contained within the frequency band designated (mentioned as above) which the EUT operated. The effects, if any, from frequency sweeping, frequency hopping, other modulation techniques and frequency stability over excepted variations in temperature and supply voltage were considered. INTERTEK TESTING SERVICES Report No.: 14110700HKG-001 iii FCC ID: 2ADUV1 Table of Contents 1.0 General Description.........................................................................................1 1.1 Product Description ........................................................................................1 1.2 Related Submittal(s) Grants............................................................................1 1.3 Test Methodology ...........................................................................................1 1.4 Test Facility ....................................................................................................1 2.0 System Test Configuration ..............................................................................2 2.1 Justification.....................................................................................................2 2.2 EUT Exercising Software................................................................................2 2.3 Special Accessories .......................................................................................2 2.4 Measurement Uncertainty...............................................................................2 2.5 Support Equipment List and Description.........................................................2 3.0 Emission Results .............................................................................................3 3.1 Field Strength Calculation...............................................................................3 3.2 Radiated Emission Configuration Photograph ................................................4 3.3 Radiated Emission Data .................................................................................4 4.0 Equipment Photographs ..................................................................................9 5.0 Product Labelling .............................................................................................9 6.0 Technical Specifications .................................................................................9 7.0 Instruction Manual ...........................................................................................9 8.0 Miscellaneous Information ............................................................................10 8.1 Radiated Emission on the Bandedge............................................................10 8.2 Discussion of Pulse Desensitization .............................................................13 8.3 Calculation of Average Factor.......................................................................13 8.4 E…

Text truncated - open the document above for the full version.

Test Setup Photos

INTERTEK TESTING SERVICE Report No: 14110700HKG-001 FCC ID: 2ADUV1 Configuration Photographs Worst-Case Radiated Emissions (Front View) Model: M1401 INTERTEK TESTING SERVICE Report No: 14110700HKG-001 FCC ID: 2ADUV1 Configuration Photographs Worst-Case Radiated Emissions (Rear View) Model: M1401
