Red Point Positioning © 2015, Red Point Positioning Corp. DOCK # Total 11 pages RTLS Development Kit Quick Start Guide Version 1.1 Abstract This quick start guide shows the steps to quickly set up a simple RTLS demonstration system using the development kit. Category: Public Revision History Revision Date Author Notes 1.0 22-Sep-15 Anton Shpakovskiy 1.1 05-Oct-15 Chunjie Duan add FCC and IC statements 9/22/2015 RTLS DEVELOPMENT KIT QUICK START GUIDE © 2015, Red Point Positioning Corp. Public 2 Table of Content Abstract ................................................................................................................................ 1 1. Before the Demonstration .............................................................................................. 3 Opening the Box............................................................................................................................................ 3 Charging Radio Nodes ................................................................................................................................... 4 Installing Software ........................................................................................................................................ 4 2. Setting up the Demonstration ......................................................................................... 4 Step 0: Finding a Space ................................................................................................................................. 4 Step 1: Connecting RBS ................................................................................................................................. 4 Step 3: Installing Anchors .............................................................................................................................. 5 Step 4: Launching End User Console ............................................................................................................. 6 Step 5: Setting Anchor Positions ................................................................................................................... 7 Step 6: Adding Mobile Nodes ....................................................................................................................... 8 Step 6: Visualizing Node Locations ............................................................................................................... 8 3. After the Demonstration ................................................................................................. 9 4. Contact Us ...................................................................................................................... 9 9/22/2015 RTLS DEVELOPMENT KIT QUICK START GUIDE © 2015, Red Point Positioning Corp. Public 3 1. Before the Demonstration Opening the Box The following items are included in a standard development kit:  One (1) RTLS Base Station (RBS, also referred to as server)  Two (2) Bridge nodes in black enclosure (Bridges)  Six (6) Anchor/Mobile nodes in red enclosure (A/M nodes)  Two (2) Bluetooth nodes in blue enclosure (BT nodes)  One (1) Wi-Fi router  Two (2) Power-over-Ethernet Injector (POE)  Two (2) Ethernet cables  One (1) USB flash drive with RBS recovery image  One (1) USB flash drive with documentation and software Figure 1 - From left to right, RBS, Bridge, F/M, and BT nodes. The following accessories may also be included in the kit:  USB charge station  micro-USB cables  POE power injector  CAT5e patch cables  Sensors cable Please note that a custom built kit may have different content. Please verify the content with the quotation specifically tailored for you. 9/22/2015 RTLS DEVELOPMENT KIT QUICK START GUIDE © 2015, Red Point Positioning Corp. Public 4 Charging Radio Nodes All A/M nodes and BT nodes have built-in rechargeable batteries and can be charged via the micro-USB port. Before setting up the system, we recommend you fully charge all nodes. While a node is being charged, a green (or yellow) LED is on. The LED is turned off when full charge is reached. Figure 2 – Radio node at charging Installing Software End User Console application is a client GUI software that allows you to manage the system and visualize the node location. The software can be found on the USB flash drive included in the kit. Install it on a Windows® computer by running setup.exe. The installer automatically creates an icon on your desktop. You will also find the program in the Start menu, under Redpoint Positioning 2. Setting up the Demonstration Step 0: Finding a Space You will need a space to set up the demo. The kit is pre-configured for a 10m x 10m area but such a space is not required. There is no specific requirement for the space. However, please be advised that an open space generally gives you better location accuracy. Also the geometry of the anchors affects the position accuracy. A long, narrow space may result in relative poor precision. Step 1: Connecting RBS  Power on the Wi-Fi router  Connect the RBS to one of the router's LAN ports using an Ethernet cable (note, do not connect to the WAN port!)  Power on the RBS by pressing the power button briefly o RBS is on when the blue LED is lit and the hard drive icon starts flashing o It takes about 30 seconds to 1 minute for all RBS services to start 9/22/2015 RTLS DEVELOPMENT KIT QUICK START GUIDE © 2015, Red Point Positioning Corp. Public 5 Figure 3 - Connection of the RBS, a POE powered bridge to the Wi-Fi router Step 3: Installing Anchors Anchors refer to nodes that are in static, known locations. Bridge, A/M, or even BT nodes can all be used as anchors. Note that Anchor nodes and Fixed nodes are used interchangeably in some of Redpoint’s documents. You may find some radio nodes pre-labelled (e.g., SE, SW, NW, NE) in the kit. If the nodes are labelled, simply take 1 bridge, and 3 A/M nodes. You can physically label them for easy identification. Figure 4 illustrates a setup using …
