Installer Guide 7490 Wireless Remote Outdoor Sensor ® TM smart connect Please read all instructions before proceeding. The wireless remote outdoor sensor monitors temperature at a remote outdoor location and transmits the temperature data wirelessly to the thermostat. The sensor can be used to view the outdoor temperature or for heat pump systems requiring the use of balance points. One wireless outdoor remote sensor can be connected. 1 Specifications Operating Temperature: 40 - 120 ̊F Storage Temperature: 40 - 120 ̊F Operating Humidity: 5 - 95% Rh Battery Power: 3.0 Volt DC Accuracy: +/- 1 ̊F 7490-100-02 Blue LED Indicator - 1 flash every 30 seconds: Normal operation - 3 flashes every 30 seconds: Sending sensor data to thermostat - 1 flash every 2 seconds: Sensor is in pairing mode - Solid for 60 seconds: Successfully paired remote sensor Red LED Indicator - 3 flashes every 30 seconds: Low battery - 1 flash every 10 seconds: Lost communication with thermostat NOTE: LED indicators are only visible with the sensor cover off. IMPORTANT: Before mounting the remote sensor, you should verify there is good wireless communication in the area you wish to mount it by first pairing it in that location. If you are having trouble pairing in that location, try moving the remote sensor to a location closer to the thermostat. Installer Guide 2 2 Pairing Remote Sensor See thermostat Installer Guide for additional information on pairing sensors. 1. Enter the wireless setup mode on the thermostat you wish to pair with the remote sensor. Proceed until you see the word SENS in the display with a flashing symbol. 2. Make sure batteries are properly installed in the remote sensor and then press and hold the CONNECT button for 3 seconds. 3. The remote sensor will enter pairing mode for 60 seconds. During this time the blue LED will flash once every 2 seconds. 4. The thermostat will display ODS indicating that the wireless remote outdoor sensor was successfully paired. The symbol will stop flashing and the blue LED on the remote sensor will turn on for 60 seconds. 5. You can repeat this process to pair additional wireless remote sensors or exit the wireless setup mode on the thermostat. NOTE: Sensors that have already been paired will appear in the thermostat display first, with a solid symbol. A maximum of 1 wireless remote outdoor sensors can be connected. A maximum of 4 wireless remote sensors total can be connected. + + – – Connect Button 3 Installation The outdoor remote sensor should be mounted on an exterior wall, approximately 3 feet from any exhaust fans. For a more accurate temperature reading, mount the sensor on a wall that does not receive direct sunlight and is above the expected snow line. NOTE: Test location by pairing your thermostat before mounting (see section 2). Figure 1 3 Installation 1. Place the small bracket against the wall in the desired location and mark placement of the two mounting holes. Remove bracket and carefully drill your marked areas with a 3/16” drill bit. 2. If needed, gently tap supplied plastic anchors into the holes in the wall and fasten the bracket to the wall using the two supplied screws. EXTERIOR WALL 3. Remove the front cover of the remote sensor. Using a small phillips blade screwdriver, loosen the screw located in the bottom center portion of the sensor housing. Gently squeeze in the ribbed portion of the sides of the housing and slide the cover up to remove. 4. Line up the 2 mounting holes on the remote sensor sub-base up with the 2 holes on the wall bracket. Using the remaining 2 screws, mount the sub-base to the wall bracket. 5. Install the 2 supplied AA lithium batteries into the sensor housing. The blue and red LED will each flash once to indicate the sensor has powered up successfully. If the red LED blinks 3 times every 30 seconds the batteries need to be replaced. 6. Attach cover of remote sensor to the sub-base by sliding the cover on from the top down. Reinstall the small screw to secure the sensor housing. 3 Installer Guide 4 Replacing a Thermostat or a Sensor Replacing a Thermostat – If you are replacing a thermostat that is paired with an existing wireless sensor, you will need to clear the remote sensor and pair it again with the newly installed thermostat. 1. Install the new thermostat. 2. On the wireless remote sensor you want to clear, press and hold the CONNECT button for 10 seconds (see Figure 1) until the red LED turns on solid. 3. Release the CONNECT button and the blue and red LED will each flash once to indicate the sensor was successfully cleared. 4. Pair the sensor again. Replacing a Sensor – If you are replacing a wireless remote sensor that is paired with an existing thermostat, you will need to clear the thermostat’s remote sensor settings before pairing the new wireless remote sensor. 1. Install the new wireless remote sensor. 2. Thermostat remote sensor settings are cleared in the Installer Settings. Refer to the Installer Settings section of the thermostat Installer Guide. 3. Once the remote sensor settings are cleared you will need to pair your new wireless remote sensor. You will also need to pair any other existing wireless remote sensors that were previously connected. Installer Guide 4 5 Communication Loss and Low Battery Communication Loss – If communication between the remote sensor and ther- mostat is lost, the red LED on the remote sensor will begin to flash once every 10 seconds. The thermostat display will also indicate which wireless remote sensor has lost communication. The sensor will attempt to reconnect to the thermostat several times automatically. NOTE: To reconnect manually, press and hold the CONNECT button for 3 seconds. Remote Sensor Low Battery – If the batteries in a wireless remote sensor are low, the red LED will flash 3 times every 30 seconds. The thermostat display will also indicate which wireless remote sensor has a low battery. Replace the remote sensor batteries as soon as possible. Be sure to mainta…

Text truncated - open the document above for the full version.

Braeburn Systems LLC 2215 Cornell Avenue Montgomery, Illinois 60538 United States DATE :2015-02-06 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Hank.Yan of Global United Technology Services Co., Ltd. 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District Shenzhen Guangdong to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Braeburn Systems LLC and 2215 Cornell Avenue Montgomery, Illinois 60538 United States Dated this / Day of 02/06/2015 / Agency agreement expiration date: 02/06/2016 By: Ernest Soderlund Signature Printed Title: Engineering Mgr. On behalf of : Braeburn Systems LLC Telephone: (630) 701-3604

Braeburn Systems LLC 2215 Cornell Avenue Montgomery, Illinois 60538 United States 2015-02-06 Equipment Authorization Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2ADX6-7490 Product Name: Outdoorsensor Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics  Block diagram  Operational Description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 02/06/2015 By: Ernest Soderlund Signature Printed Title: Engineering Mgr. On behalf of : Braeburn Systems LLC Telephone: (630) 701-3604

This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference that may cause undesired operation. Model: 7490 FCC ID: 2ADX6-7490 IC: 12657A-7490 7490-152-01 2215 Cornell Avenue • Montgomery, IL 60538 Phone 630.844.1968 • Fax 866.268.9994 Contact: Victoria Bohler • [email protected] Date: 1.09.15 File: 7490-152-01 Size: 30 mm x 15 mm Stock: White Label Stock Models: 7490 Placement: See drawing for position.

Label location

RF Exposure evaluation According to KDB 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m)---3m So pt = (EXd) 2 /30 x gt Field strength = 91.0 dBuV/m @3m Ant gain 0dBi; so Ant numeric gain=1 So pt={[10 (91.0/20) /10 6 x3] 2 /30x1}x1000 mW = 0.3777mW So (0.3777mW/5mm)x √0.915GHz = 0.0723<3 Then SAR evaluation is not required

Global United Technology Services Co., Ltd. Report No.: GTSE14110206001 Authorized Signature: Robinson Lo Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the GTS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of GTS or testing done by GTS in connection with, distribution or use of the product described in this report must be approved by GTS in writing. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. FCC REPORT Applicant: Braeburn Systems LLC Address of Applicant: 2215 Cornell Avenue Montgomery, Illinois 60538 United States Equipment Under Test (EUT) Product Name: Outdoorsensor Model No.: 7490 FCC ID: 2ADX67490 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.249:2013 Date of sample receipt: November 26, 2014 Date of Test: February 02-06, 2015 Date of report issued: February 06, 2015 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. 2ADX6-7490 Report No.: GTSE14110206001 Global United Technology Services Co., Ltd. Project No.: GTSE141102060RF 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 20 2 Version Version No. Date Description 00 February 06, 2015 Original Prepared By: Date: February 06, 2015 Project Engineer Check By: Date: February 06, 2015 Reviewer Report No.: GTSE14110206001 Global United Technology Services Co., Ltd. Project No.: GTSE141102060RF 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 20 3 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 VERSION .................................................................................................................................................. 2 3CONTENTS .............................................................................................................................................. 3 4TEST SUMMARY ..................................................................................................................................... 4 5GENERAL INFORMATION ...................................................................................................................... 5 5.1CLIENT INFORMATION ......................................................................................................................... 5 5.2GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.3TEST MODE ........................................................................................................................................ 6 5.4DESCRIPTION OF SUPPORT UNITS ....................................................................................................... 6 5.5TEST FACILITY .................................................................................................................................... 6 5.6TEST LOCATION ................................................................................................................................. 6 5.7OTHER INFORMATION REQUESTED BY THE CUSTOMER ......................................................................... 6 6TEST INSTRUMENTS LIST ..................................................................................................................... 7 7TEST RESULTS AND MEASUREMENT DATA ...................................................................................... 8 7.1ANTENNA REQUIREMENT: .................................................................................................................... 8 7.2RADIATED EMISSION METHOD ............................................................................................................. 9 7.2.1Field Strength of The Fundamental Signal ................................................................................ 11 7.2.2Spurious emissions .................................................................................................................... 11 7.2.3Bandedge emissions.................................................................................................................. 14 7.320DB OCCUPY BANDWIDTH .............................................................................................................. 15 8TEST SETUP PHOTO ............................................................................................................................ 16 9EUT CONSTRUCTIONAL DETAILS ..................................................................................................... 17 Report No.: GTSE14110206001 Global United Technology Services Co., Ltd. Project No.: GTSE141102060RF 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +8…

Text truncated - open the document above for the full version.

Radiated Emission
