ES061B ES061B(MANUAL) OUTSIDE INSIDE PRINTER SPECIFICATIONS FILE NAME: SCALE: 100% SIZE: Trim: W 431mm x H 165mm PAPER STOCK: 80g Art Paper FILE INFORMATION DATE: 5/22/15 MODEL NUMBER: ES061B-Manual_052215 ES061B 0 ES061B COMMENTS (Internal reference only) File created by Michelle Samuels - Please include this manual in all packaging - Greyscale - Double sided printing for ES061B The USB port can charge the speaker, or transmite analogue signal or transmite analogue signal

< DONGGUANELEELECTRICALTECH.,LTD. > Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2015.07.01 Subject; Request for Confidentiality FCCID:2ADYXELES061B To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure indefinitely. SchematicDiagram  Block Diagram OperationalDescription Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Lei Ji Title: M anager Email: [email protected]

DONGGUAN ELEELECTRICAL TECH.,LTD. Letter of Authorization Company: DONGGUAN ELE ELECTRICAL TECH., LTD. Address:2F, Block C1, JingBo Industrial park, BuXin Industrial area, YanTian, FengGang, DongGuan, GuangDong, China. Product Name:Bluetooth Speaker Model Number:ES061B We authorize MiCOM Labs Inc, 575 Boulder Court, Pleasanton, CA 94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. This shall include the following: Testing Approvalapplications(includescompleteproductdocumentationpackage, including Confidential information) and procedures Paymentofapprovalfees We declare that MiCOM Labs Inc, 575 Boulder Court, Pleasanton, CA 94566, USA, is allowed to forward all information related to the approval project to the applied notified body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: Lei JiDate: 2015.07.01 Title: Manager Signature of applicant:

Page1of7 AppendixB: PhotographsofEUT Model:ES061B ExternalPhotos Page2of7 Page3of7 Page4of7 Page5of7

LABELARTWORKANDLOCATION DONGGUAN ELEELECTRICAL TECH.,LTD. Model:ES061B FCCID:2ADYXELES061B 10mm*20mm FCCIDLocation

Page6of7 Model:ES061B InternalPhotos Page7of7

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID: 2ADYXELES061B Product: Bluetooth Speaker Model No.: ES061B Additional Model: MI-SPB61 Trade Mark: N/A Report No.: TCT150616E001 Issued Date: July 2, 2015 Issued for : DONGGUAN ELE ELECTRICAL TECH., LTD. 2F, Block C1, JingBo Industrial park, BuXin Industrial area, YanTian, FengGang, DongGuan, GuangDong, China. Issued By: Shenzhen Tongce Testing Lab. 1F, Leinuo Watch Building, Fuyong Town, Baoan Dist, Shenzhen, China TEL: +86-755-27673339 FAX: +86-755-27673332 Note: This report shall not be reproduced except in full, without the written approval of Shenzhen Tongce Testing Lab. This document may be altered or revised by Shenzhen Tongce Testing Lab. personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. ReportNo.: TCT150616E001 Page 2 of 50 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TABLE OF CONTENTS 1. Test Certification...........................................................................................3 2. Test Result Summary...................................................................................4 3. EUT Description............................................................................................5 4. Genera Information.......................................................................................6 4.1. Test environment and mode...........................................................................................6 4.2. Description of Support Units..........................................................................................6 5. Facilities and Accreditations.......................................................................7 5.1. Facilities...............................................................................................................................7 5.2. Location................................................................................................................................7 5.3. Measurement Uncertainty...............................................................................................7 6. Test Results and Measurement Data.........................................................8 6.1. Antenna requirement........................................................................................................8 6.2. Conducted Emission.........................................................................................................9 6.3. Conducted Output Power..............................................................................................13 6.4. 20dB Occupy Bandwidth...............................................................................................18 6.5. Carrier Frequencies Separation..................................................................................23 6.6. Hopping Channel Number.............................................................................................28 6.7. Dwell Time.........................................................................................................................31 6.8. Pseudorandom Frequency Hopping Sequence......................................................34 6.9. Conducted Band Edge Measurement........................................................................35 6.10. Conducted Spurious Emission Measurement.......................................................39 6.11.Radiated Spurious Emission Measurement............................................................43 Appendix A: Photographs of Test Setup Appendix B: Photographs of EUT ReportNo.: TCT150616E001 Page 3 of 50 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. Test Certification Product:Bluetooth Speaker Model No.:ES061B Additional Model: MI-SPB61 Applicant:DONGGUAN ELE ELECTRICAL TECH., LTD. Address: 2F, Block C1, JingBo Industrial park, BuXin Industrial area, YanTian, FengGang, DongGuan, GuangDong, China. Manufacturer:DONGGUAN ELE ELECTRICAL TECH., LTD. Address: 2F, Block C1, JingBo Industrial park, BuXin Industrial area, YanTian, FengGang, DongGuan, GuangDong, China. Date of Test:June 16 – July 1, 2015 Applicable Standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 The above equipment has been tested by Shenzhen Tongce Testing Lab . and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Tested By:Date:July 1, 2015 Neil Wong Reviewed By: Date:July 2, 2015 Joe Zhou Approved By:Date:July 2, 2015 Tomsin ReportNo.: TCT150616E001 Page 4 of 50 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. Test Result Summary RequirementCFR 47 SectionResult Antenna Requirement§15.203/§15.247 (c)PASS AC Power Line Conducted Emission §15.207PASS Conducted Peak Output Power §15.247 (b)(1)PASS 20dB Occupied Bandwidth§15.247 (a)(1)PASS Carrier Frequencies Separation §15.247 (a)(1)PASS Hopping Channel Number§15.247 (a)(1)PASS Dwell Time§15.247 (a)(1)PASS Radiated Emission§15.205/§15.209PASS Band Edge§15.247(d)PASS Note: 1.PASS: Testitem meets the requirement. 2.Fail: Test item doesnot meet the requirement. 3.N/A: Test case does not apply to the testobject. 4. The test result judgment is decided by the limitof test standard. ReportNo.: TCT150616E001 Page 5 of 50 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. EUT Description Product Name: Bluetooth Speaker Model : ES061B Additional Model: MI-SPB61 Trade Mark: N/A BT Version: V2.1+EDR. Operation Frequency: 2402MHz~2480MHz Transfer Rate: 1/2/3 Mbits/s Number of Channel: 79 Modulation Type: GFSK, …

Text truncated - open the document above for the full version.

Page 1 of 2 AppendixA: PhotographsofTestSetup Product:Bluetooth Speaker Model:ES061B Radiated Emission Page 2 of 2 Conducted Emission
