2AE46-TXWireless receiving and calling system

Manual for Wireless receiving and calling system Singcall Receiver 1：[FUN] 2：[[ESC]] 3：[[ENT]] 1 2 3 4 5 6 4：[DOWN] 5：[[MOVE]] 6： [UP] Operating Instructions ●call button registering: 1） Standby mode, press key [FUN] 3 seconds till[F1] appears on the screen. 2） Press key [ENT], [01] [001] or [001-01] appears 3） Press key [UP], [[MOVE]] or [DOWN] to choose the register number wanted. 4） Press the call button to be registered, the register number flashes on the screen with music prompt and then stops. 5） Press key [ESC], and [F1] appears. 6） Press key [ESC] again, back to standby mode. The registration is finished. 7） Repeat step 3）~4）to register all the call buttons you need, and then press key [ESC] twice back to standby mode. Done. ●prompt music setting 1) standby mode , press key [FUN] 3 seconds till[F1] appears on the screen. 2) Use key [UP] to choose [F2]. 3) Press key [ENT] and [01] appears. 4) Use the key [UP], [DOWN] to choose prompt music (12 pieces of beautiful music totally). 5) Press key [ENT], and [F2] appears 6) Press key [ESC] again and back to standby mode. Prompt setting is done. ●display time setting for the call button numbers. 1） standby mode, press key [FUN] 3 seconds till[F1] appears on the screen. 2） Use key [UP] to choose [F3]. 3） Press key [ENT], and [20] appears on the screen. 4） Use key [UP], [DOWN] to choose the display time wanted. [00] means unlimited display, the figure of 01~99 mean the corresponding time from 1~99 seconds. 5） Press key [ENT], and [F3] appears. 6） Press key [ESC] and back to standby mode. Done. ●Prompt music length setting. 1) Standby mode, press key [FUN] 3 seconds and [F1] appears on the screen. 2) Use key [UP] to choose [F4]. 3) Press key [ENT] and [01] appears on the screen. 4) Use key [UP] or [DOWN] to choose the prompt music length wanted, number 01-15 means 15 kinds of the length. 01 means 2 seconds, 02 means 4 seconds, and so on, 15 means 30 seconds of the music prompt. 5) Press key [ENT], and [F4] appears again. 6) Press key [ESC] and back to standby mode. Done. ●volume adjusting For APE9000、APE9300、APE9500 and APE9600 only. (The volume of the other models can be changed with the volume controlling knob on the top of the receivers. ) 1. Standby mode, press key [UP] or [DOWN] to choose the volume, 01~15 means 15 kinds of volume. 2. Press key [ESC], and back to standby mode. Done. ● Different prompt music for different call buttons (APE1900/APE2900/APE8000/ APE8200 not included). 1) Standby mode, press key [FUN] 3 seconds and [F1] appears on the screen. 2) Press key [UP] to choose [F5]. 3) Press key [ENT] and [01] appears on the screen. 4) Use key [UP], [MOVE] or [DOWN] to choose the prompt music. 5) Press key [ENT] and [01] or [001] appears. 6) Use key [UP], [MOVE] or [DOWN] to choose the number wanted. 7) Press the call button, and the number flashes on the screen with prompt music and then stops. 8) Press key [ESC] and [F5] appears again, the registration is finished. 9) Press key [ESC] again back to standby mode. 10) Repeat step 4) ~8) if more than one call buttons need to be registered. ●time setting (for APE1900/APE2900/APE8000 /APE8200) 1) Standby mode, press key [FUN] 3 seconds till [F1] appears on the screen. 2) Use key [UP] to choose [F5] 3) Press key [ENT] and the current time, such as [13-29], displayed on the screen, 4) Use key [UP], [MOVE] or [DOWN] to the right time. 5) Press key [ENT], and [F5] appears again. 6) Press key [ESC] and back to standby mode. Time setting done. ● Deleting registered number or initializing the receiver 1) Standby mode, press key [FUN] 3 seconds till [F1] appears on the screen. 2) Use key [UP] to choose [F6]. 3) Press key [ENT], the registered minimum number appears. 4) Use key [UP], [MOVE], or [DOWN] to choose the number to be deleted. 5) Press key [ENT], with the prompt music, the selected number flashed and deleted. The next registered number appears on the screen. Keep pressing key [ENT], the numbers keep changing on the screen. When [00]、[000]or[000-00] appears, the initializing is completed. 6) Press key [ESC] and [F6] appears again 7) Press key [ESC] once more, back to standby mode, the number deleting done. Special functions. ● Optional prompt music for key [cancel] (for multi-key requesters) 1) Standby mode, press key [FUN] 3 seconds till [F1] appears on the screen. 2) Use key [UP] to choose [F7]. 3) Press key [ENT] and [01] appears on the screen. 4) Use key [UP], [MOVE] or [DOWN] to choose a number from 01 to 20. 1-10 means with prompt music, and 11-20 means without prompt music when press key [cancel]. 5) Press key [ENT] and [F7] appears again. 6) Press key [ESC], back to standby mode. Setting done. ● Number display mode setting( all-digital display or digits beginning with an English letter display, for APE1200/APE1500/APE1800/APE1900/APE2000, APE2500/APE2600/APE2900/APE9500 ) 1) Standby mode, press key [FUN] 3 seconds till [F1] appears on the screen. 2) Use key [UP] to choose [F8]. 3) Press key [ENT] and [01] appears. 4) Use key [UP], [MOVE], or [DOWN] to choose a number. 01~10 is all-digital display (default setting), and 11~20 is digits beginning with an English letter ( A,B,C,D,E,F,H,P,J or L) display. 5) Press key [ENT] and [F8] appears on the screen. 6) Press key [ESC], back to standby mode. Done. ● Same or different prompt music for the keys of the multi-key requesters(for APE1600/APE1800/APE2500/APE9600) 1) Standby mode, press key [FUN] 3 seconds till [F1] appears. 2) Use key [UP] to choose [F8] (for APE1600/APE9600) or [F9] (for APE1800 / APE2500) 3) Press key [ENT] and [00] appears on the screen. 4) Use key [UP] or [DOWN] to choose a number. [01] means same prompt music for different keys and [00] means different music for different keys (default setting) . 5) Press key [ENT] and [F8] or [F9] appears on the screen. 6) Press key [ESC] and back to standby mode. The setting finished. Special Instruction for APE8000 ● Register the remote controller 1) Press the key [D] on st…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Yantai Hengtai Electronics Co., Ltd. 2015-07-06 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, _____ Yantai Hengtai Electronics Co., Ltd. _____hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): (Wireless receiving and calling system, APE700, APE560, APE520, APE330, APE730, APE830, APE510, APE100, APE160, SC-T180) FCC ID: 2AE46-TX Sincerely, Client’s signature Client’s name / title Xuefang Wu / Office Clerk Contact information / address Room 201, Building E, Yeda Industry and Technology Park, No. 300, Changjiang Road, Development Zone, Yantai City, Shandong Province, China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 Yantai Hengtai Electronics Co., Ltd. 2015-07-06 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AE46-TX We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Client’s name / title Xuefang Wu / Office Clerk Contact information / address Room 201, Building E, Yeda Industry and Technology Park, No. 300, Changjiang Road, Development Zone, Yantai City, Shandong Province, China

Model Declaration Letter For FCC ID: 2AE46-TX We, the undersigning company Company Name: Yantai Hengtai Electronics Co., Ltd. Address: Room 201, Building E, Yeda Industry and Technology Park, No. 300, Changjiang Road, Development Zone, Yantai City, Shandong Province, China Hereby confirm that the following products: Product description: Wireless receiving and calling system Type designation: APE700, APE560, APE520, APE330, APE730, APE830, APE510, APE100, APE160, SC-T180 Trade name or Brand(s): SINGCALL All models are identical in the same PCB layout, interior structure and electrical circuits, The only difference is model name for commercial purpose. City and Country: Date: Name: Function: Signature: Yantai, China 07/06/2015 Xuefang Wu Office Clerk

Report No.: TB-FCC144561 Page: 3 of 6 TB-RF-075-1.0 Appendix III EUT External Photographs Photo 1 Appearance of EUT Photo 2 Appearance of EUT

Report No.: TB-FCC144561 Page: 1 of 6 TB-RF-074-1.0 Appendix IFCC ID Label FCC ID: 2AE46-TX This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Yantai Hengtai Electronics Co., Ltd. Model: APE700

Report No.: TB-FCC144561 Page: 2 of 6 TB-RF-075-1.0 Appendix II ID Label Location ID LOCATION

Report No.: TB-FCC144561 Page: 4 of 6 TB-RF-075-1.0 Appendix IV EUT Internal Photographs Photo 3 Internal of EUT Photo 4 Internal of EUT Antenna Report No.: TB-FCC144561 Page: 5 of 6 TB-RF-075-1.0 Photo 5 Appearance of PCB Photo 6 Appearance of Battery

Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC144561 Page: 1 of 29 TB-RF-074-1.0 1A/F., Bldg.6, Yusheng Industrial Zone, The National Road No.107 Xixiang Section 467, Xixiang, Bao’an, Shenzhen, China Tel: +86 75526509301 Fax: +86 75526509195 FCC Radio Test Report FCC ID: 2AE46-TX Original Grant Report No. : TB-FCC144561 Applicant : Yantai Hengtai Electronics Co., Ltd. Equipment Under Test (EUT) EUT Name : Wireless receiving and calling system Model No. : APE700 Serial Model No. : Please see page 4. Brand Name : SINGCALL Receipt Date : 2015-06-18 Test Date : 2015-06-18 to 2015-06-23 Issue Date : 2015-06-23 Standards : FCC Part 15, Subpart C (15.231:2014) Test Method : ANSI C63.10:2013 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above, The EUT technically complies with the FCC requirements Test/Witness Engineer : Approved& Authorized : This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC144561 Page: 2 of 29 TB-RF-074-1.0 1A/F., Bldg.6, Yusheng Industrial Zone, The National Road No.107 Xixiang Section 467, Xixiang, Bao’an, Shenzhen, China Tel: +86 75526509301 Fax: +86 75526509195 Contents CONTENTS ............................................................................................................................................. 2 1. GENERAL INFORMATION ABOUT EUT ............................................................................. 4 1.1 Client Information ................................................................................................................. 4 1.2 General Description of EUT (Equipment Under Test) ................................................... 4 1.3 Block Diagram Showing the Configuration of System Tested ...................................... 5 1.4 Description of Support Units .............................................................................................. 5 1.5 Description of Test Mode .................................................................................................... 5 1.6 Description of Test Software Setting ................................................................................ 6 1.7 Measurement Uncertainty .................................................................................................. 6 1.8 Test Facility ........................................................................................................................ 6 2. TEST SUMMARY ....................................................................................................................... 8 3. TEST EQUIPMENT .................................................................................................................... 9 4. CONDUCTED EMISSION TEST ........................................................................................... 10 4.1 Test Standard and Limit .................................................................................................... 10 4.2 Test Setup ........................................................................................................................... 10 4.3 Test Procedure ................................................................................................................... 10 4.4 Test Data ............................................................................................................................. 11 5. RADIATED EMISSION TEST ................................................................................................ 12 5.1 Test Standard and Limit .................................................................................................... 12 5.2 Test Setup ........................................................................................................................... 13 5.3 Test Procedure ................................................................................................................... 14 5.4 EUT Operating Condition ................................................................................................. 15 4.5 Test Data ............................................................................................................................. 15 6. BANDWIDTH ............................................................................................................................ 21 6.1 Test Standard and Limit .................................................................................................... 21 6.2 Test Setup ........................................................................................................................... 21 6.3 Test Procedure ................................................................................................................... 21 6.4 EUT Operating Condition ................................................................................................. 21 6.5 Test Data ............................................................................................................................. 22 Report No.: TB-FCC144561 Page: 3 of 29 TB-RF-074-1.0 7. RELEASE TIME MEASUREMENT ....................................................................................... 23 7.1 Test Standard and Limit .................................................................................................... 23 7.3 Test Procedure ................................................................................................................... 23 7.4 EUT Operating Condition ................................................................................................. 23 7.5 Test Data ............................................................................................…

Text truncated - open the document above for the full version.

Report No.: TB-FCC144561 Page: 6 of 6 TB-RF-075-1.0 Appendix V EUT Test Photographs 15C Test Setup Photo of Setup for Radiated Emission (Above 1 GHz) Photo of Setup for Radiated Emission (Below 1 GHz)
