Pedestrian Detection Aid System USER MANUAL SA-TX1 PST SAS 1, rue Brindejonc des Moulinais – ZAC de la Plaine – 31500 TOULOUSE, FRANCE Tel. : + 33 (0)5 67 77 94 46 – Fax : +33 (0)5 67 77 94 49 Email : [email protected] Web : http://www.savex-securite.fr USER MANUAL Version 1.3 SA-TX1 Oct 2015 2/8 All mentioned specifications subject to change without notice. Table of Contents I Overview of the SaveX device ........................................................................................ 3 Principle of operation (example of 2 detection zones) ......................................................... 3 II Disclaimer ...................................................................................................................... 4 III Precautions .................................................................................................................... 4 IV Precaution in the use of the SA-TX1 battery ................................................................... 5 V Charging warnings ......................................................................................................... 5 VI Technical characteristics of the SA-TX1 ......................................................................... 6 1. SA-TX1 portable device display led indicators ............................................................. 7 2. SA-TX1 portable device detected faults ....................................................................... 8 USER MANUAL Version 1.3 SA-TX1 Oct 2015 3/8 All mentioned specifications subject to change without notice. I Overview of the SaveX device Principle of operation (example of 2 detection zones) The SaveXSA-IHM devices’s display installed in the driver cab indicates the number of pedestrians detected in the pre-alert or alert zones. An audible signal (parameterizable) is generated according to the pedestrian zone closest to the machine. In the above figure, the SA-IHM display indicates "02" and an audible signal is triggered (parameterizable). If no pedestrian enters the detection zone, a red point on the SA-IHM1’s display signals to the driver that no pedestrian is present in the safety perimeter around his machine. The distances of the detection zones and the associated bells can be parameterized (distance coverable up to 25 metres, audio signal timing, power, bell, etc.) USER MANUAL Version 1.3 SA-TX1 Oct 2015 4/8 All mentioned specifications subject to change without notice. II Disclaimer CAREFULLY AND COMPLETELY READ ALL THE INSTRUCTIONS before using the SA-TX1 portable device. KEEP THIS USER MANUAL HANDY. III Precautions WARNING ! NEVER let a person with a pacemaker use a SA-TX1 portable device. WARNING ! NEVER use battery packs or chargers that are not recommended by PST because performances may be altered and would cancel the portable device’s warranty. REMARK : Keep the battery terminals clean. It is recommended to clean the battery terminals once a week. AVOID using the portable device in direct sunshine or exposing it to it, or in a location where the temperature is below - 20°C or above +55°C. NEVER modify the portable device whatever the reason. The portable device’s warranty does not cover problems due to an unauthorised change. WARNING ! The SA-TX1 portable device’s box is sealed and meets IP67 (immersion to a depth of 1 m for 30 minutes). However, the portable device’s waterproofing can no longer be warranted after a fall on account of, among others, resulting box cracks or seal damages. Federal Communications Commission (FCC) Compliance Statement: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and(2) This device must accept any interference received, including interference that may cause undesired operation. Industry Canada (IC) Compliance Statement: This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. NOTE: THE GRANTEE IS NOT RESPONSIBLE FOR ANY CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. USER MANUAL Version 1.3 SA-TX1 Oct 2015 5/8 All mentioned specifications subject to change without notice. IV Precaution in the use of the SA-TX1 battery If Lithium-Ion batteries are incorrectly used, the following risks can result : release of smoke, fire or explosion of the battery. Incorrect use can also damage the battery or degrade performances. WARNING : A risk of explosion is possible if the battery is replaced by an incorrect type of battery. Discard used batteries following the instructions. SA-TX1 portable device batteries can only be changed by a PST after-sales service technician or an approved dealer. Use and charge only the PST specified battery pack with portable devices or the PST chargers. It is recommended to recharge any unused battery pack every six months. V Charging warnings DANGER ! NEVER charge the battery pack in a location where the temperature is extremely high, for example, in the vicinity of a fire or a stove, in direct sunshine, or in a car exposed to sunlight. In such an environment, the charge is automatically interrupted by the battery’s protection or the safety internal circuit. DANGER ! NEVER charge or leave the battery in the battery charger longer than the indicated charge time. If the battery is not completely charged at the end of the indicated time, interrupt the charging and remove the battery from the charger. Charging longer than the indicated time may cause a fire, overheating or explosion of the battery. DANGER ! NEVER insert the portable device wet or dirty (battery attached to the device) in the charger to avoid corroding the…

Text truncated - open the document above for the full version.

SA-TX : Externals pictures FRONT : SIDE : BACK:

SA-TX Labels Samples Label located in the back of the case : Label located at on the back of the electronic board :

SA-TX : Labels localizations Back of the case: Back of the electronic card:

SA-TX : Internals pictures FRONT : Radiofrequency components area BACK (with label):

 Siège Social : Emitech ‐ 3, rue des Coudriers ‐ CAP 78 ‐ ZA de l’Observatoire ‐78180 MONTIGNY LE BX ‐France Siret : 344 545 645 00022 ‐ Tél. : 33 (0)1 30 57 55 55 ‐ Fax : 33 (0)1 30 43 74 48 ‐ E‐mail : [email protected] ‐ URL : www.emitech.fr S.A. au capital de 1 560 000 € ‐ R.C.S. VERSAILLES 344 545 645 ‐ APE 7112B R041-14-104959-2A - DM / CBU  This test report cancels and replaces the report R041-14-104959-2A Ed.1 RADIO TEST REPORT According to the standard(s): FCC part 15 Subpart C Equipment under test: SA-TX1 (RADIO MODULE: SA-TX) FCC ID: 2AE4JSATX Company: PST Diffusion: Mr AGUIERE (Company: PST) Number of pages: 22 including 1 annex Ed. Date Modified page(s) Written by Name Visa Technical verification Quality approval Name Visa 2 04 Nov. 15 Refer to lines in the margin David MONTAULON Olivier HEYER Duplication of this report is only permitted for an integral photographic facsimile. It includes the number of pages referenced above. This document is the result of testing a specimen or a sample of the product submitted. It does not imply an assessment of the conformity of the whole production of the item tested. R041-14-104959-2A Ed.2 PAGE: 2  NAME OF THE EQUIPMENT UNDER TEST (E.U.T.) : SA-TX1 Serial number : None Part number : FCC ID: 2AE4JSATX Software Version : None MANUFACTURER’S NAME : PST APPLICANT’S ADDRESS: Company : PST Address : ZAC de la Plaine - 1 rue Brindejonc des Moulinais - 31500 TOULOUSE FRANCE Person(s) present during the tests : Mr AGUIERE Responsible : Mr AGUIERE DATE(S) OF TESTS : From December 5 th of 2014 and February 23 th to 24 th of 2014 TESTS LOCATION(S) : EMITECH MONTPELLIER laboratory in VENDARGUES (34) - FRANCE Open area test site in SALINELLES (30) - FRANCE FCC Test Firm Registration Number: 954701 TESTS SUPERVISOR(S) : None TESTS OPERATOR(S) : David MONTAULON R041-14-104959-2A Ed.2 PAGE: 3  CONTENTS 1. INTRODUCTION ..................................................................................................................................... 4 2. REFERENCE DOCUMENT(S) ................................................................................................................ 4 3. EQUIPMENT UNDER TEST CONFIGURATION .................................................................................... 4 4. EQUIPMENT UNDER TEST CONFIGURATION SCHEME .................................................................... 5 5. SUMMARY OF TEST RESULTS ............................................................................................................ 6 6. UNWANTED RADIATED EMISSIONS – SECTION 15.209 ................................................................... 7 ANNEX: PHOTOGRAPH(S) .......................................................................................................................... 19 R041-14-104959-2A Ed.2 PAGE: 4  1. INTRODUCTION This document submits the results of Electromagnetic Compatibility tests performed on the equipment SA- TX1 (denominated hereafter E.U.T.: equipment under test) according to document(s) listed below. 2. REFERENCE DOCUMENT(S) FCC Part 15 Code of Federal Regulations Title 47 – Telecommunications Chapter 1 – Federal Communications Commission Part 15 – Radio frequency devices Subpart C – Intentional Radiators ANSI C 63.4:2009 American National Standard for Methods of measurement of Radio- Noise from low-voltage. Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz 3. EQUIPMENT UNDER TEST CONFIGURATION Equipment under test (E.U.T.) description: Applicant: PST Model: SA-TX FCC ID: 2AE4JSATX R041-14-104959-2A Ed.2 PAGE: 5  4. EQUIPMENT UNDER TEST CONFIGURATION SCHEME Presentation of equipment for testing purposes: SA-TX1 Integral antennas Powered by internal batteries E.U.T. Frequency ranges used by the transmitter: 447.656kHz – 452.344kHz Equipment single-frequency two-frequency multi-frequency Total channel available / Channel separation: 51 Type of Modulation: CW Duty cycle: Not communicated Frequency ranges used by the receiver: 447.656kHz – 452.344kHz Choice of model for testing: Test(s) frequency(ies): 447.656kHz(CH0), 449.9kHz(CH24) & 452.344kHz(CH50) Cycle and operating mode during emission tests: Permanent emission mode. Equipment modifications applied during tests: No R041-14-104959-2A Ed.2 PAGE: 6  5. SUMMARY OF TEST RESULTS Tests designation Results satisfying? Comments Antenna requirement - FCC part 15.203 YES Integrated antennas Restricted band of operation - FCC part 15.205 YES Conducted power lines - FCC part 15.207 N.A. Powered by internal batteries Unwanted radiated emissions - FCC part 15.209 YES N.P.: Not Performed. N.A.: Not Applicable.  In emission : Sample subject to the test complies with prescriptions of the standard(s) FCC Part 15 Subpart C according to limits specified in this test report. R041-14-104959-2A Ed.2 PAGE: 7  6. UNWANTED RADIATED EMISSIONS – SECTION 15.209 Standards: FCC part 15 Radio part 15.209 Test method: ANSI C63.4:2009 a) Pre-measurement in semi anechoic chamber: Frequency band Tested side Resolution bandwidth Video bandwidth Detection mode E.U.T. height 9kHz-150kHz Front side 200Hz 1kHz Peak 80cm 150kHz-30MHz Front side 10kHz 30kHz Peak 80cm 30MHz-1GHz Front side 100kHz 300kHz Peak 80cm Measurements below 30MHz are done with a loop antenna as describe in the standard. Measurements are done in semi anechoic chamber at 3m. E.U.T. is set on a wooden table. E.U.T. measurements are maximized at 360° in max-hold peak detection. The device was tested in three orthogonal planes. Limits: From 9 kHz to 30MHz: Limit indicated on the curves is calculated with 40 dB/decade extrapolation factor and 51.5 dB conversion factor. From 30MHz to 1GHz: quasi peak limit provided is the limit given in 15.209 Test method deviation: From 9 kHz to 30MHz: measurements are made in peak detection instead of average mode in frequency band 9 kHz-500 kHz - Measurements are given in dBμA/m instead of μV/m - Measuring distance is 3 meters instead of 30 and 300 met…
