2AE4P-SKY70QTablet phone

1 ALL RIGHTS RESERVED All rights are reserved by Our company. No part of this document can be reproduced without permission. All trademarks and brand names mentioned in this publication are property of their respective owners. While all the efforts have been made to ensure the accuracy of contents in this manual, we presume no responsibility for errors or omissions or statements of any kind, whether such errors are omissions or statements resulting from negligence, accidents, or any other cause. We operate a policy of continuous development and reserve the right to make changes, modifications and improvements to the device, device features/specifications or any of its parts without prior notice. Your device may have preinstalled bookmarks and links for third party internet sites and may allow you to access third party sites. These are no affiliated with our company, and we don’t endorse or assume liability for them. If you access such sites, take precautions for security or content. The limited warranty does not cover user manuals or any third party software, settings, content, data or links, whether included/downloaded in the product, whether included during installment, assembly, shipping or any other time in the delivery chain or otherwise and in any way acquired by you. To the extent permitted by applicable law(s), we don’t warrant that any other software will meet your requirements, will work in combination with any hardware or software applications provided by a third party, that the operations of the software will be uninterrupted or error free or that any defects in the software are correctable or will be corrected. User’s Manual is provided just to guide the user about the functionality of the device. This does not seem to be any certificate of technology. Some functions may vary due to modifications and up-gradations of software or due to printing mistake. 2 SAFETY PRECAUTIONS Please read the following safety guidelines before using the device. ¾ Do not use the tablet while you are driving. ¾ Do not place magnetic storage media near your tablet. Radiation from the tablet may erase the information stored on them. ¾ Keep your tablet and its accessories away from children. ¾ Tablets can interfere with the functioning of medical devices such as hearing aids or pacemakers. People having active medical implants should keep their cell tablet at least 15 cm away from the implant. ¾ Permanent hearing loss may occur if you use eartablets or headtablets at high volume. ¾ Use a wireless hands-free system (headtablet/ headset) with a low power Bluetooth emitter. ¾ Keep your calls short or send a text message (SMS) instead. This advice applies specially to children adolescents and pregnant women. ¾ Use cell tablet when the signal quality is good. Notice: ¾ Do not dismantle the device or accessories otherwise, manufacturer is not liable to pay for damages as the device and accessories are not covered by warranty. Use only original batteries and charging devices. ¾ Please back up your important data timely and keep them properly. The company is not liable for any failure to call or loss of data due to mis-operation, poor signal or power cut, etc. ¾ All the screens in this manual are for reference only, and some contents actually displayed may depend upon the presetting of the service provider or the network operator, or the SIM card. If any functions referred to in this manual are different from those of your device, please follow your device. ¾ Do not put use it in a place with flammable gas such as a petrol pumps. The temperature recommended for using the device is 5-35 . Do not touch the charger, power cable or socket °C with wet hands. This may cause an electric shock. If your tablet or any of its accessories do not function normally, then please visit your nearest authorized service facility. The qualified personnel will assist you, and if necessary, will arrange for the service. 3 *What’s in the Box? Your package comes with the following items. If any of these is missing, please contact your retailer ¾ SKY 7.0Q ¾ USB Cable ¾ Charger ¾ User’s Manual ¾ Headset ¾ Battery ¾ Warranty Card 4 Contents ALL RIGHTS RESERVED·······························································································································1 SAFETY PRECAUTIONS································································································································2 I．UNDERSTANDING YOUR DEVICE···········································································································6 1. GENERAL INFO······················································································································································· 6 2. DESCRIPTION OF BUTTONS·································································································································· 7 II．GETTING STARTED··································································································································7 1. POWER ON/OFF·····································································································································7 2. TURN ON /OFF SCREEN ········································································································································ 7 3. LOCK AND UNLOCK ·············································································································································· 8 4. FINGER GUSTURES ··············································································································································· 8 5. SWITCH DESKTOPS ··············································································································································· 9 6. HOT BUTTONS ··································································································…

Text truncated - open the document above for the full version.

ShenZhen KINODA Technology Co.,Ltd ROOM 5B-9, CHE KUNG TEMPLE OF TRADE AND INDUSTRY PARK 213, FUTIAN DISTRICT, SHENZHEN, CHINA TEL: +86-755-88351189 FAX: +86-755-88351195 DOC ATTESTATION LETTER FCC ID: 2AE4P-SKY70Q Date: July 07, 2015 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: I, the undersigned, hereby attest to the fact that I will apply the Declaration of Conformity procedure to the computer peripheral. I understand the following FCC requirements: 1. Devices subject to the DoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to-government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm (Select the "accredited" option to search for FCC recognized accredited test firms.) 2. Test facilities located in countries, where the U.S. does not have an operational Telcom MRA are not recognized by the FCC to test for the DoC procedure. 3. Pt 2.1077 contains the list of information that must be included in the Declaration of Conformity, which must be supplied with each product sold. The DoC compliance info shall be included in the User’s Manual or as a separate sheet. The info must contain the name, address, and phone number of the responsible party, which must be located within the United States. According to 2.909(c)(2), the responsible party is either the Manufacturer or if the product is imported the Importer. Sincerely, Chen Lichang/Manager

ShenZhen KINODA Technology Co.,Ltd ROOM 5B-9, CHE KUNG TEMPLE OF TRADE AND INDUSTRY PARK 213, FUTIAN DISTRICT, SHENZHEN, CHINA TEL: +86-755-88351189 FAX: +86-755-88351195 DATE 07-07-2015 FCC ID: 2AE4P-SKY70Q Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Shenzhen CTL Testing Technology Co., Ltd.(MR. Tracy Qi) at Floor 1-A, Baisha Technology Park, No. 3011, Shahexi Road, Nanshan, Shenzhen 518055 China to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with ShenZhen KINODA Technology Co.,Ltd at ROOM 5B-9, CHE KUNG TEMPLE OF TRADE AND INDUSTRY PARK 213, FUTIAN DISTRICT, SHENZHEN, CHINA. Dated this 07-07-2015 Agency agreement expiration date: 07-06-2016 By: Chen Lichang Signature Printed Title: Manager On behalf of : ShenZhen KINODA Technology Co.,Ltd Telephone: +86-755-88351189

ShenZhen KINODA Technology Co.,Ltd ROOM 5B-9, CHE KUNG TEMPLE OF TRADE AND INDUSTRY PARK 213, FUTIAN DISTRICT, SHENZHEN, CHINA TEL: +86-755-88351189 FAX: +86-755-88351195 DATE 07-07-2015 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AE4P-SKY70Q Product Name: Tablet phone Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram • Operation description • BOM These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 07-07-2015 By: Chen Lichang Signature Printed Title: Manager On behalf of : ShenZhen KINODA Technology Co.,Ltd Telephone: +86-755-88351189

FCC ID Label Information 1. Label location: 2. FCC ID Label: ShenZhen KINODA Technology Co.,Ltd Tablet phone Model: SKY 7.0Q FCC ID: 2AE4P-SKY70Q This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCCID Label Location

- Shenzhen CTL Testing Technology Co., Ltd. Tel: +86-755-89486194 Fax: +86-755-26636041 FCC PART 15 SUBPART C TEST REPORT Report Reference No.: CTL1505301453-WB01 Compiled by: ( position+printed name+signature) Happy Guo (File administrators) Tested by: ( position+printed name+signature) Nice Nong (Test Engineer) Approved by: ( position+printed name+signature) Tracy Qi (Manager) Product Name...............................: Tablet phone Model/Type reference..................: SKY 7.0Q List Model(s).................................: / Trade Mark....................................: N/A FCC ID...........................................: 2AE4P-SKY70Q Applicant’s name.........................: ShenZhen KINODA Technology Co.,Ltd Address of applicant...................: ROOM 5B-9, CHE KUNG TEMPLE OF TRADE AND INDUSTRY PARK 213, FUTIAN DISTRICT, SHENZHEN, CHINA Test Firm.......................................: Shenzhen CTL Testing Technology Co., Ltd. Address of Test Firm...................: Floor 1- A, Baisha Technology Park, No.3011, Shahexi Road, Nanshan District, Shenzhen, China 518055 Test specification.........................: Standard........................................: FCC Part 15.249: Operation within the bands 920-928 MHz, 2400- 2483.5 MHz, 5725-5850 MHz and 24.0 - 24.25 GHz. TRF Originator..........................: Shenzhen CTL Testing Technology Co., Ltd. Master TRF..............................: Dated 2011-01 Date of Receipt.............................: May 30, 2015 Date of Test Date..........................: May 30, 2015 - July 02, 2015 Data of Issue.................................: July 02, 2015 Result............................................: Positive Shenzhen CTL Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. V1.0 Page 2 of 51 Report No.: CTL1505301453-WB01 T E S T R E P O R T Test Report No. : CTL1505301453-WB01 July 02, 2015 ______________________________________________________________________________________________ Date of issue Equipment under Test : Tablet phone Model /Type : SKY 7.0Q Applicant : ShenZhen KINODA Technology Co.,Ltd Address : ROOM 5B-9, CHE KUNG TEMPLE OF TRADE AND INDUSTRY PARK 213, FUTIAN DISTRICT, SHENZHEN, CHINA Manufacturer ShenZhen KINODA Technology Co.,Ltd Address ROOM 5B-9, CHE KUNG TEMPLE OF TRADE AND INDUSTRY PARK 213, FUTIAN DISTRICT, SHENZHEN, CHINA Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 51 Report No.: CTL1505301453-WB01 Contents 1. TEST STANDARDS .................................................................. 4 2. SUMMARY............................................................................. 5 2.1. Equipment Under Test 5 2.2. Description of The Equipment Under Test (EUT) 5 2.3. EUT operation mode 7 2.4. EUT configuration 7 2.5. Related Submittal(s) / Grant (s) 7 2.6. Modifications 7 3. TEST ENVIRONMENT............................................................... 8 3.1. Address of the test laboratory 8 3.2. Test Facility 8 3.3. Environmental conditions 8 3.4. Configuration of Tested System 8 3.5. Statement of the measurement uncertainty 9 3.6. Equipments Used during the Test 10 4. TEST CONDITIONS AND RESULTS ............................................ 10 4.1. Conducted Emissions Test 11 4.2. Fundamental Emissions 13 4.3. Transmitter Radiated Unwanted Emissions 15 4.4. Band Edge Measurement 31 4.5. Occupied Bandwidth Measurement 40 5. ANTENNA REQUIREMENT ....................................................... 42 6. TEST SETUP PHOTOS OF THE EUT .......................................... 43 7. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 45 V1.0 Page 4 of 51 Report No.: CTL1505301453-WB01 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 15.249: Operation within the bands 902 - 928 MHz, 2400 - 2483.5 MHz, 5725 - 5875 MHz, and 24.0 - 24.25 GHz. ANSI C63.10-2013 V1.0 Page 5 of 51 Report No.: CTL1505301453-WB01 2. SUMMARY 2.1. Equipment Under Test Power supply system utilised Power supply voltage : ● 120V / 60 Hz o 115V / 60Hz o 12 V DC o 24 V DC ● Other (specified in blank below) DC 3.7V from battery 2.2. Description of The Equipment Under Test (EUT) The ShenZhen KINODA Technology Co., Ltd’s Model: SKY 7.0Q or the “EUT” as referred to in this report; more general information as follows, for more details, refer to the user’s manual of the EUT. General Description Name of EUT Tablet phone Brand / Model SKY 7.0Q Hardware version M699_8312_MB_V1.2_150430 Software version V1.2 IMEI 352585060680174 Device category Portable Device Exposure category General population/uncontrolled environment EUT Type Production Unit Rated Vlotage DC 3.70 Battery Hotsopt Supported, power not reduced when Hotspot open The EUT is GSM850/900/DCS1800/PCS1900, UMTS Band I,II,V Tablet phone. the Tablet phone is intended for speech and Multimedia Message Service (MMS) transmission. It is equipped with GPRS/EDGE class 12 for GSM850, PCS1900, UMTS Band II, Band V and Bluetooth, WiFi, and camera functions. For more information see the following datasheet Technical Characteristics 2G Support Networks GSM, GPRS, EDGE Support Band GSM850/PCS1900 Uplink Frequency GSM/GPRS/EDGE 850: 824~849MHz GSM/GPRS/EDGE 1900: 1850~1910MHz Downlink Frequency GSM/GPRS/EDGE 850: 869~894MHz GSM/GPRS/EDGE 1900: 1930~1990MHz Type of Modulation GMSK, 8PSK for only downlink Antenna Type Internal Antenna Antenna G…

Text truncated - open the document above for the full version.

- Shenzhen CTL Testing Technology Co., Ltd. Tel: +86-755-89486194 Fax: +86-755-26636041 FCC PART 15 SUBPART C TEST REPORT Report Reference No.: CTL1505301453-WB02 Compiled by: ( position+printed name+signature) Happy Guo (File administrators) Tested by: ( position+printed name+signature) Nice Nong (Test Engineer) Approved by: ( position+printed name+signature) Tracy Qi (Manager) Product Name...............................: Tablet phone Model/Type reference..................: SKY 7.0Q List Model(s).................................: / Trade Mark....................................: N/A FCC ID...........................................: 2AE4P-SKY70Q Applicant’s name.........................: ShenZhen KINODA Technology Co.,Ltd Address of applicant...................: ROOM 5B-9, CHE KUNG TEMPLE OF TRADE AND INDUSTRY PARK 213, FUTIAN DISTRICT, SHENZHEN, CHINA Test Firm.......................................: Shenzhen CTL Testing Technology Co., Ltd. Address of Test Firm...................: Floor 1- A, Baisha Technology Park, No.3011, Shahexi Road, Nanshan District, Shenzhen, China 518055 Test specification.........................: Standard........................................: FCC Part 15.249: Operation within the bands 920-928 MHz, 2400- 2483.5 MHz, 5725-5850 MHz and 24.0 - 24.25 GHz. TRF Originator..........................: Shenzhen CTL Testing Technology Co., Ltd. Master TRF..............................: Dated 2011-01 Date of Receipt.............................: May 30, 2015 Date of Test Date..........................: May 30, 2015 – July 02, 2015 Data of Issue.................................: July 02, 2015 Result............................................: Positive Shenzhen CTL Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. V1.0 Page 2 of 51 Report No.: CTL1505301453-WB02 T E S T R E P O R T Test Report No. : CTL1505301453-WB02 July 02, 2015 ______________________________________________________________________________________________ Date of issue Equipment under Test : Tablet phone Model /Type : SKY 7.0Q Applicant : ShenZhen KINODA Technology Co.,Ltd Address : ROOM 5B-9, CHE KUNG TEMPLE OF TRADE AND INDUSTRY PARK 213, FUTIAN DISTRICT, SHENZHEN, CHINA Manufacturer ShenZhen KINODA Technology Co.,Ltd Address ROOM 5B-9, CHE KUNG TEMPLE OF TRADE AND INDUSTRY PARK 213, FUTIAN DISTRICT, SHENZHEN, CHINA Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 51 Report No.: CTL1505301453-WB02 Contents 1. TEST STANDARDS .................................................................. 4 2. SUMMARY............................................................................. 5 2.1. Equipment Under Test 5 2.2. Description of The Equipment Under Test (EUT) 5 2.3. EUT operation mode 7 2.4. EUT configuration 7 2.5. Related Submittal(s) / Grant (s) 7 2.6. Modifications 7 3. TEST ENVIRONMENT............................................................... 8 3.1. Address of the test laboratory 8 3.2. Test Facility 8 3.3. Environmental conditions 8 3.4. Configuration of Tested System 8 3.5. Statement of the measurement uncertainty 9 3.6. Equipments Used during the Test 10 4. TEST CONDITIONS AND RESULTS ............................................ 10 4.1. Conducted Emissions Test 11 4.2. Fundamental Emissions 14 4.3. Transmitter Radiated Unwanted Emissions 15 4.4. Band Edge Measurement 4.5. Occupied Bandwidth Measurement 40 5. ANTENNA REQUIREMENT ....................................................... 42 6. TEST SETUP PHOTOS OF THE EUT .......................................... 43 7. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 45 V1.0 Page 4 of 51 Report No.: CTL1505301453-WB02 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 15.249: Operation within the bands 902 - 928 MHz, 2400 - 2483.5 MHz, 5725 - 5875 MHz, and 24.0 - 24.25 GHz. ANSI C63.10-2013 V1.0 Page 5 of 51 Report No.: CTL1505301453-WB02 2. SUMMARY 2.1. Equipment Under Test Power supply system utilised Power supply voltage : ● 120V / 60 Hz o 115V / 60Hz o 12 V DC o 24 V DC ● Other (specified in blank below) DC 3.7V from battery 2.2. Description of The Equipment Under Test (EUT) The ShenZhen KINODA Technology Co., Ltd’s Model: SKY 7.0Q or the “EUT” as referred to in this report; more general information as follows, for more details, refer to the user’s manual of the EUT. General Description Name of EUT Tablet phone Brand / Model SKY 7.0Q Hardware version M699_8312_MB_V1.2_150430 Software version V1.2 IMEI 352585060680174 Device category Portable Device Exposure category General population/uncontrolled environment EUT Type Production Unit Rated Vlotage DC 3.70 Battery Hotsopt Supported, power not reduced when Hotspot open The EUT is GSM850/900/DCS1800/PCS1900, UMTS Band I,II,V Tablet phone. the Tablet phone is intended for speech and Multimedia Message Service (MMS) transmission. It is equipped with GPRS/EDGE class 12 for GSM850, PCS1900, UMTS Band II, Band V and Bluetooth, WiFi, and camera functions. For more information see the following datasheet Technical Characteristics 2G Support Networks GSM, GPRS, EDGE Support Band GSM850/PCS1900 Uplink Frequency GSM/GPRS/EDGE 850: 824~849MHz GSM/GPRS/EDGE 1900: 1850~1910MHz Downlink Frequency GSM/GPRS/EDGE 850: 869~894MHz GSM/GPRS/EDGE 1900: 1930~1990MHz Type of Modulation GMSK, 8PSK for only downlink Antenna Type Internal Antenna Antenna Gain…

Text truncated - open the document above for the full version.
