2AE5VGEIAWM002Wireless mouse

2015-06-23 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AE5VGEIAWM002_ Product Name: Wireless mouse Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics Long-term confidential  Block diagram Long-term confidential  Operation description Long-term confidential These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Name Li Chongming Position Manager Company Name Shenzhen Good&Easy Technology Co.,Ltd. Address 2F,Building C6,Hengfeng Industrial Park,Xixiang Town, Bao an District,China Tel 18665386413 Fax +86-755-2999 2441 Email [email protected]

25mm 150mm FCC ID: 2AE5VGEIAWM002 Shenzhen Good&Easy Technology Co.,Ltd. Model name: Wireless mouse Model No.: GEIAWM002 Label Location

FCC ID: 2AE5VGEIAWM002 RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances İ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] g[Ĝf(GHz)] İ 3.0 for 1-g SAR and İ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m)---3m So pt = (EXd) 2 /30 x gt Field strength = 84.18 dBuV/m @3m Ant gain -1 dBi; so Ant numeric gain=0.794 So pt={[10 (84.18/20) /10 6 x3] 2 /30x0.794 }x1000 mW =0.062 mW So ( 0.062 mW/5mm)x √ 2.476 GHz = 0.020 <3 Then SAR evaluation is not required 0.3 0.3 0.1

Page 1 of 27 Report No.: T1850640 01 TEST REPORT FCC ID: 2AE5VGEIAWM002 Applicant : Shenzhen Good&Easy Technology Co.,Ltd. Address : 2F,Building C6,Hengfeng Industrial Park,Xixiang Town, Bao an District,China Equipment Under Test (EUT): Name : Wireless mouse Model : GEIAWM002 In Accordance with: FCC PART 15, SUBPART C : 2014 (Section 15.249) Report No : T1850640 01 Date of Test : June 10, 2015 to June 22, 2015 Date of Issue : June 23, 2015 Test Result : PA S S In the configuration tested, the EUT complied with the standards specified above Authorized Signature (Mark Zhu) General Manager The manufacture should ensure that all the products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of Shenzhen Alpha Product Testing Co., Ltd. Or test done by Shenzhen Alpha Product Testing Co., Ltd. Approvals in connection with, distribution or use of the product described in this report must be approved by Shenzhen Alpha Product Testing Co., Ltd. Approvals in writing . Page 2 of 27 Report No.: T1850640 01 TABLE OF CONTENT 1 General Information ------------------------------------------------------------------------------------ 3 1.1 Description of Device (EUT) --------------------------------------------------------------------- 3 1.2 Description of Test Facility ----------------------------------------------------------------------- 4 2 EMC Equipment List ------------------------------------------------------------------------------------ 4 3 Test Procedure ------------------------------------------------------------------------------------------- 5 4 Summary of Measurement ---------------------------------------------------------------------------- 6 4.1 Summary of test result ---------------------------------------------------------------------------- 6 4.2 Test connection ------------------------------------------------------------------------------------- 6 4.3 Assistant equipment used for test ---------------------------------------------------------------- 6 4.4 Test mode ------------------------------------------------------------------------------------------- 6 4.5 Test Conditions ------------------------------------------------------------------------------------- 7 4.6 Measurement Uncertainty (95% confidence levels, k=2)------------------------------------- 7 5 Spurious Emission ----------------------------------------------------------------------------------- 8 5.1 Radiation Emission -------------------------------------------------------------------------------- 8 5.1.1 Radiation Emission Limits(15.209) ------------------------------------------------------------- 8 5.1.2 Test Setup ------------------------------------------------------------------------------------------- 8 5.1.3 Test Procedure ------------------------------------------------------------------------------------ 10 5.1.4 Test Equipment Setting For emission test Result. ------------------------------------------- 10 5.1.5 Test Condition ------------------------------------------------------------------------------------ 10 5.1.6 Test Result ---------------------------------------------------------------------------------------- 10 6 POWER LINE CONDUCTED EMISSION ------------------------------------------------------- 16 6.1 Conducted Emission Limits(15.207) ---------------------------------------------------------- 16 6.2 Test Setup ----------------------------------------------------------------------------------------- 16 6.3 Test Procedure ------------------------------------------------------------------------------------ 17 6.4 Test Results --------------------------------------------------------------------------------------- 17 7 Bandwidth ---------------------------------------------------------------------------------------------- 18 7.1 Test limit ------------------------------------------------------------------------------------------ 18 7.2 Method of measurement ------------------------------------------------------------------------ 18 7.3 Test Setup ----------------------------------------------------------------------------------------- 18 7.4 Test Results --------------------------------------------------------------------------------------- 18 8 Antenna Requirement ------------------------------------------------------------------------------ 21 8.1 Standard Requirement --------------------------------------------------------------------------- 21 8.2 Antenna Connected Construction -------------------------------------------------------------- 21 8.3 Result ---------------------------------------------------------------------------------------------- 21 9 Photographs of Test Setup ----------------------------------------------------------------------- 22 9.1 Photos of Radiated emission ------------------------------------------------------------------- 22 10 Photographs of EUT--------------------------------------------------------------------------------- 23 Page 3 of 27 Report No.: T1850640 01 1 General Information 1.1 Description of Device (EUT) EUT : Wireless mouse Model No. : GEIAWM002 DIFF N/A Trade mark : N/A Power supply : DC 3V from battery, 2*1.5V AAA battery Radio Technology : MSK Operation frequency : 2409-2476MHz Channel No. 8 Channels Modulation : MSK Antenna Type : Printed Antenna, max gain -1dBi. Applicant : Shenzhen Good&Easy Technology Co.,Ltd. Address : 2F,Building C6,Hengfeng Industrial Park,Xixiang Town, Bao an District,China Manufacturer : Shenzhen Good&Easy Technology Co.,Ltd. Address : 2F,Building C6,Hengfeng Industrial Park,Xixiang Town, Bao an District,China Page 4 of 27 Report No.: T1850640 01 1.2 Description of Test Facility Shenzhen Alpha Product Testing Co., Ltd. Building B, East Area of Nanchang Second, Industrial Zone, Gushu 2nd Road, Bao'an, S…
