2AE6PFFC100ARemote Control

User Manual FFC100A 一． Main functions: this p roduct is mainly to control a motor running and stop and can control the speed increase and decrease. 二． 1. The motor switch button ON/OFF 2. Speed increase buttons 3. Reduced speed button 4. Inching control buttons 三． The wire connection diagram: 1. C on n ec t a motor as follows 2 . The transmitter used 12V/ 23A battery, the receiver connect DC 12V battery. 2. Connect two motor as follows: 3. Connect three motor as follows: 4. Connect four motor as follows: FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

R&C Oregon inc, Dba Feather Flyers Confidentiality Letter To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AE6PFFC100A Product: Remote Control Model: FFC100A,FFC100B,ZD-OF04,ZD-MF04,ZD-QF04,ZD-DF04,ZD-HF12,ZD-NF04,ZD-LF04,ZD-FF04 Trade: We hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, signature : name / title: Gary Odenbaugh / Manager address: Room 2301, Building B, East Times Of Square, Hua Qiang Bei Road, Futian District, 518031, Shenzhen, China

M/N: FFC100A FCC ID: 2AE6PFFC100A Label location

Antenna location

Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15060083 FCC Part 15C Test Report FCC ID: 2AE6PFFC100A Product Name: Remote Control Trademark: Model Name : FFC100A,FFC100B,ZD-OF04,ZD-MF04,ZD-QF04,ZD-DF04,ZD-HF12,Z D-NF04,ZD-LF04,ZD-FF04 Prepared For : R&C Oregon inc, Dba Feather Flyers Address : 2075 West Lowry Street, Meridian, Idaho, 83646, United States Prepared By : Shenzhen BCTC Technology Co., Ltd. Address : No.101,Yousong Road,Longhua New District, Shenzhen,China Test Date: Jun. 15 - Jun. 18, 2015 Date of Report : Jun. 19, 2015 Report No.: BCTC-15060083 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15060083 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 2 of 30 VERIFICATION OF COMPLIANCE Applicant’s name ................. : R&C Oregon inc, Dba Feather Flyers Address ................................. : 2075 West Lowry Street, Meridian, Idaho, 83646, United States Manufacture's Name ............ : Hangzhou Zhengdian Technology Co., Ltd. Address ................................. : No.1 building Wangshan Community Xingqiao Street Yuhang District Hangzhou, China Product description Product name ........................... : Remote Control Trademark: Model Name: FFC100A,FFC100B,ZD-OF04,ZD-MF04,ZD-QF04, ZD-DF04,ZD-HF12,ZD-NF04,ZD-LF04,ZD-FF04 Test procedure FCC Part15.231 Standards ANSI C63.10-2009 This device described above has been tested by BCTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Test Result ............................................... : Pass Testing Engineer : (Eric Yang) Technical Manager : (Sophia Lee) Authorized Signatory : (Carson. Zhang) Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15060083 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 3 of 30 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 8 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 8 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 9 3 . EMC EMISSION TEST 10 3.1 CONDUCTED EMISSION MEASUREMENT 10 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 10 3.1.2 TEST PROCEDURE 11 3.1.3 DEVIATION FROM TEST STANDARD 11 3.1.4 TEST SETUP 11 3.1.5 EUT OPERATING CONDITIONS 11 3.1.6 TEST RESULTS 11 3.2 RADIATED EMISSION MEASUREMENT 12 3.2.1 RADIATED EMISSION LIMITS 12 3.2.2 TEST PROCEDURE 13 3.2.3 TEST SETUP 14 3.2.4 EUT OPERATING CONDITIONS 15 3.2.5 TEST RESULTS 16 4 . BANDWIDTH TEST 21 4.1 APPLIED PROCEDURES / LIMIT 21 4.1.1 TEST PROCEDURE 21 4.1.2 DEVIATION FROM STANDARD 21 4.1.3 TEST SETUP 21 4.1.4 EUT OPERATION CONDITIONS 21 4.1.5 TEST RESULTS 22 5 . CALCULATION OF AVERAGE FACTOR 23 6 . DWELL TIME 26 6.1 DEVIATION FROM STANDARD 26 6.2 TEST SETUP 26 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15060083 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 4 of 30 Table of Contents Page 6.3 EUT OPERATION CONDITIONS 26 6.4 TEST RESULTS 27 7 . ANTENNA REQUIREMENT 28 7.1 STANDARD REQUIREMENT 28 7.2 EUT ANTENNA 28 8 . EUT TEST PHOTO 29 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15060083 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 5 of 30 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.231) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A 15.209,15.231b Radiated Emission Test PASS 15.231c 20dB Occupy Bandwidth PASS 15.231a Dwell time PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15060083 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 6 of 30 1.1 TEST FACILITY Shenzhen BCTC Technology Co., Ltd. Add.:No.101,Yousong Road,Longhua New District, Shenzhen,China FCC Registration No.:187086 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15060083 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 7 of 30 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Remote Control Trade Name Model Name FFC100A Serial Model FFC100B,ZD-OF04,ZD-MF04,ZD-QF04,ZD-DF04,ZD-H F12,ZD-NF04,ZD-LF04,ZD-FF04 Model Difference All the same,Only model name is different. Product Description The EUT is a Remote Control Operation Frequency: 433.92MHz Modulation Type: ASK Antenna Designation: Integral Antenna Gain 3dBi Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Adapter N/A Battery DC 12V Connecting I/O Port(s) Please refer to the User's Manual Hardware Version V1.1 Software Version V0.1 Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15060083 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 8 of 30 2.2 DESCRIPTION OF TEST MOD…
