2AE7XS508ASmart Phone OWN Style

1 Smart User Manual Model: OWN Style Brand:OWN 2 1. For your safety .......................................................................................................................... 3 2. Learn about the phone ............................................................................................................ 4 3. Before using .............................................................................................................................. 5 4. Getting started .......................................................................................................................... 6 5. Communication ........................................................................................................................ 9 6. Multimedia ............................................................................................................................... 10 7. Connecting to networks and devices ............................................................................... 12 8. Warnings and notes .............................................................................................................. 14 3 1. For your safety Read these simple guidelines. Not following them may be dangerous or illegal. SWITCH OFF IN HOSPITALS Follow any restrictions. Switch the device off near medical equipment. Do not use the device where blasting is in progress. Please keep this cell phone away from children, as they could mistake it for a toy, and hurt themselves with it. Don’t try to modify the phone except by the professional. Warning! Only use the authorized spare parts, otherwise it may damage the phone and the warranty will be void. And it may be dangerous. SWITCH OFF WHEN REFUELING Don’t use the phone at a refueling point. Don’t use near fuel or chemicals. SIM CARDS ARE PORTABLE Keep your phone, phone parts and accessories out of children’s reach BATTERY Please do not destroy or damage the battery, it can be dangerous and cause fire. Please do not throw battery in fire to avoid danger When battery cannot be used, please dispose in an environmental safe method Do not try to dismantle the battery. If the battery or the charger is broken or old, please stop using them. And replace with certified genuine battery USE QUALITY EQUIPMENT 4 Use our authorized equipment to avoid danger ROAD SAFETY COMES FIRST Give full attention while driving; pull off the road or park before using your phone. Please follow traffic rules of local city/town INTERFERENCE All wireless devices may be susceptible to cause interference, which could affect performance. SWITCH OFF IN AIRCRAFT Wireless devices can cause interference in aircraft. It’s not only dangerous but also illegal to use mobile phone in an aircraft. 2. Learn about the phone Button Press Press & hold Power key (Right side) Turns on/off the screen. Opens a menu with options for “Turn on airplane ” “Power off” and so on. Volume Up/Down (Right side) When a call is in progress, Increases or decrease the call volume, When the phone is ringing, silences the ringer. On the Home screen when no calls in progress, Increase or decreases the ringtone volume, or sets the phone to be silent instead of ringing. In other applications, controls the volume of music, spoken directions, and other audio. Quickly increasing the ringtone volume to maximum or minimum. 5 IMPORTANT The battery of TM570 mobile phone is fixed, not removable. 3. Before using 1. Switch off the mobile phone and remove the rear cover. 2. Insert the SIM card correctly into the card slot. 3. Finally replace the rear cover of the mobile phone. 4. Know the Keys and parts 6 Note: The SIM card is a small object; please keep the card out of the reach of children to avoid swallowing the card by accident. Do not touch the metal surface of SIM card and keep it away from electromagnetism to avoid loss and damage of the data. You will not be able to connect to the network if the SIM card is damaged. Charger 1. Connect the charger to the charger jack on the phone. 2. Next connect the charger to a power socket, the charging starts, with the charging icon in an animated state. 3. When the charging icon becomes static, it indicates that the battery is full. 4. Disconnect the charger from the power socket and the phone. Note: Slight heating during charging is normal. It indicates that the battery is full, when the charging icon becomes static. 4. Getting started 4 4 . . 1 1 T T u u r r n n o o n n / / o o f f f f y y o o u u r r p p h h o o n n e e  Turn on the phone Long press the power key to start up the cell phone. Back cover. Volume Up/down Power Flashlight Camera lens Flashlight Receiver Home Front camera Back Menu USB jack Speaker 7  Turn off the phone 1. Long press the power key, a context menu will prompt, touch “Power off” to switch off the cell phone.  To wake up the phone 1. Press the Power button. 2. Drag the lock icon to rightward. The last screen you were working on opens. 4 4 . . 2 2 G G e e t t t t i i n n g g t t o o k k n n o o w w t t h h e e H H o o m m e e s s c c r r e e e e n n The Home screen is your starting point to access all the features on your phone. It displays application icons, widgets, shortcuts, and other features. You can customize the Home screen with different wallpaper and display the items you want. 8 At the top of the screen, the Status bar displays the time, information about the status of your phone, and icons for notifications that you’ve received. Touch the Launcher icon at the bottom of the screen to view all installed applications. 4 4 . . 3 3 U U s s i i n n g g t t h h e e t t o o u u c c h h s s c c r r e e e e n n The main way to control Android features is by using your finger to touch icons, buttons, menu items, the onscreen keyboard, and other items on the touch screen. Touch: To act on items on the screen, such as application and settings icons, to type letters and symbols using the onscreen keyboard, or to press onscreen buttons,…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2Rev 5.0 AMER MOBILE CO.,LIMITED 2015.7.1 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, AMER MOBILE CO.,LIMITED hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): (Product description, model name): Product description: Smart Phone OWN Style model name: OWN Style FCC ID: 2AE7XS508A Sincerely, Client’s signature : thomas.lu Client’s name / title: Manager Applicant company: AMER MOBILE CO.,LIMITED address: 9/F, Nongke Business Center, No. 8133, Hongli West Road, Futian District, Shenzhen, China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 AMER MOBILE CO.,LIMITED 2015.7.1 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AE7XS508A We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description - Tune up Procedure - Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : thomas.lu Client’s name & title : Manager Contact information / address: 9/F, Nongke Business Center, No. 8133, Hongli West Road, Futian District, Shenzhen, China

Project No: STS1507007 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Project No: STS1507007 Photo 3 Photo 4 Project No: STS1507007 Photo 5 Photo 6 Project No: STS1507007 Photo 7 Photo 8 Project No: STS1507007 Photo 9

Label Smart Phone OWN Style Model name: OWN Style FCC ID: 2AE7XS508A This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. label

ProjectNo:STS1507007 APPENDIX-PHOTOGRAPHSOFEUTCONSTRUCTIONALDETAILS Photo1 Photo2 BT/WIFI/GPSANTENNA GSM/WCDMAANTENNA ProjectNo:STS1507007 Photo3 Photo4 ProjectNo:STS1507007 Photo5 Photo6 ProjectNo:STS1507007 Photo7 Photo8

FCC ID : 2AE7XS508A RF EXPOSURE EVALUATION METHOD SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. FCC ID : 2AE7XS508A Maximum measured transmitter power. BT The Worst Case frequency Maximum Peak Conducted Output Power Tune up tolerance Max Antenna Gain GHz dBm dBm dBi 2.402 4.712 5.5±1 0 2.441 5.857 5.5±1 0 2.480 6.444 5.5±1 0 Remark: The best case gain of the antenna is 0 dBi. 0 dBi logarithmic terms convert to numeric result is nearly 1 (2.402GHz) -6.5 dbm=4.4668mw (2.441GHz) -6.5 dbm=4.4668mw (2.480GHz) -6.5 dbm=4.4668mw BT: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 4.4668/5*√2.402=1.3646≤3.0 [(mid. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 4.4668/5*√2.441=1.3958≤3.0 [(min. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 4.4668/5*√2.480=1.4069≤3.0 Threshold at which no SAR required is 1.4069 ≤ 3.0 for 1-g SAR, Separation distance is 5mm. Conclusion: No SAR is required. FCC ID : 2AE7XS508A BT 4.0 frequency Maximum Peak Conducted Output Power Tune up tolerance Max Antenna Gain GHz dBm dBm dBi 2.402 -1.740 -2±1 0 2.441 -2.063 -2±1 0 2.480 -1.599 -2±1 0 Remark: The best case gain of the antenna is 0 dBi. 0 dBi logarithmic terms convert to numeric result is nearly 1 (2.402GHz) -1 dbm=0.7943mw (2.441GHz) -1dbm=0.7943mw (2.480GHz) -1 dbm=0.7943mw BT4.0: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 0.7943/5*√2.402=0.2462≤3.0 [(mid. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 0.7943/5*√2.441=0.2482≤3.0 [(min. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 0.7943/5*√2.480=0.2502≤3.0 Threshold at which no SAR required is 0.2502 ≤ 3.0 for 1-g SAR, Separation distance is 5mm. Conclusion: No SAR is required.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No: STS1507007F03 Issued for AMER MOBILE CO.,LIMITED 9/F, Nongke Business Center, No. 8133, Hongli West Road, Futian District, Shenzhen, China Product Name: Smart Phone OWN Style Brand Name: OWN Model No.: OWN Style Series Model: N/A FCC ID: 2AE7XS508A Test Standard: FCC Part 15.247 S T L A B S Page 2 of 70 Report No.: STS1507007F03 TEST RESULT CERTIFICATION Applicant’sname............ AMER MOBILE CO.,LIMITED Address ................................. : 9/F, Nongke Business Center, No. 8133, Hongli West Road, Futian District, Shenzhen, China Manufacture's Name ............ : AMER MOBILE CO.,LIMITED Address ................................. : 9/F, Nongke Business Center, No. 8133, Hongli West Road, Futian District, Shenzhen, China Product description Product name ........................ : Smart Phone OWN Style Band name ............................ : OWN Model and/or type reference .............................................. : OWN Style Ratings ................................... DC 5V/1000mA Standards ............................. : FCC Part 15.247 Test procedure ............................ : ANSI C63.10-2013 This device described above has been tested by STS, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ........................................... : Date (s) of performance of tests ............. : 01 July. 2015 ~07 July. 2015 Date of Issue.......................................... : 08 July. 2015 Test Result ............................................. : Pass Testing Engineer : (Jin Ming) Technical Manager : (Vita Li) Authorized Signatory : (Bovey Yang) Page 3 of 70 Report No.: STS1507007F03 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACILITY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF EUT 8 2.2 DESCRIPTION OF TEST MODES 10 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 10 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 2.5 DESCRIPTION OF SUPPORT UNITS 12 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 13 3. EMC EMISSION TEST 14 3.1 CONDUCTED EMISSION MEASUREMENT 14 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 14 3.1.2 TEST PROCEDURE 15 3.1.3 TEST SETUP 15 3.1.4 EUT OPERATING CONDITIONS 15 3.1.5 TEST RESULTS 16 3.2 RADIATED EMISSION MEASUREMENT 18 3.2.1 RADIATED EMISSION LIMITS 18 3.2.2 TEST PROCEDURE 19 3.2.3 DEVIATION FROM TEST STANDARD 19 3.2.4 TEST SETUP 20 3.2.5 EUT OPERATING CONDITIONS 21 3.2.6 TEST RESULTS 22 4. CONDUCTED SPURIOUS EMISSIONS 28 4.1 REQUIREMENT 28 4.2 TEST PROCEDURE 28 4.3 TEST SETUP 28 4.4 EUT OPERATION CONDITIONS 28 4.5 TEST RESULTS 29 5. NUMBER OF HOPPING CHANNEL 38 5.1 APPLIED PROCEDURES / LIMIT 38 5.2 TEST PROCEDURE 38 5.3 TEST SETUP 38 5.4 EUT OPERATION CONDITIONS 38 Page 4 of 70 Report No.: STS1507007F03 Table of Contents Page 5.5 TEST RESULTS 39 6. AVERAGE TIME OF OCCUPANCY 40 6.1 APPLIED PROCEDURES / LIMIT 40 6.2 TEST PROCEDURE 40 6.3 TEST SETUP 40 6.4 EUT OPERATION CONDITIONS 40 6.5 TEST RESULTS 41 7. HOPPING CHANNEL SEPARATION MEASUREMEN 47 7.1 APPLIED PROCEDURES / LIMIT 47 7.2 TEST PROCEDURE 47 7.3 TEST SETUP 47 7.4 EUT OPERATION CONDITIONS 47 7.5 TEST RESULTS 48 8. BANDWIDTH TEST 54 8.1 APPLIED PROCEDURES / LIMIT 54 8.2 TEST PROCEDURE 54 8.3 TEST SETUP 54 8.4 EUT OPERATION CONDITIONS 54 8.5 TEST RESULTS 55 9. PEAK OUTPUT POWER TEST 61 9.1 APPLIED PROCEDURES / LIMIT 61 9.2 TEST PROCEDURE 61 9.3 TEST SETUP 61 9.4 EUT OPERATION CONDITIONS 61 9.5 TEST RESULTS 62 10. ANTENNA REQUIREMENT 68 10.1 STANDARD REQUIREMENT 68 10.2 EUT ANTENNA 68 Page 5 of 70 Report No.: STS1507007F03 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 08 July. 2015 STS1507007F03 ALL Initial Issue Page 6 of 70 Report No.: STS1507007F03 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247(a)(1) Hopping Channel Separation PASS -- 15.247(b)(1) Peak Output Power PASS -- 15.247(c) Radiated Spurious Emission PASS -- 15.247(d) Conducted Spurious Emission PASS -- 15.247(a)(iii) Number of Hopping Frequency PASS -- 15.247(a)(iii) Dwell Time PASS -- 15.247(a)(1) Bandwidth PASS -- 15.205 Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 7 of 70 Report No.: STS1507007F03 1.1 TEST FACILITY Shenzhen STS Test Services Co., Ltd. Add. : 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China CNAS Registration No.: L7649; FCC Registration No.: 842334; IC Registration No.: 12108A-1 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission (9KHz-150KHz) ±2.88dB 2 Conducted Emission (150KHz-30MHz) ±2.67dB 3 RF power,conducted ±0.70dB 4 Spurious emissions,conducted ±1.19dB 5 All emissions,radiated(<1G) 30MHz-200MHz ±2.83dB 6 All emissions,radiated(<1G) 200MHz-1000MHz ±2.94dB 7 All emissions,radiated(>1G) ±3.03dB 8 Temper…

Text truncated - open the document above for the full version.

DSS&DTSSetup photo DSS&DTS conduction DSS&DTSradiation L DSS&DTSradiation H
