2AEAYK-W019M2.4G wireless mouse

2.4GHz Wireless Mouse with Windows 8 Hotkeys US ER 'S GUIDE Ver.:1.00 CAUTION: To use this product properly, please read th e user's guide before installing. 1 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 2 How to ...recognize the parts 1. Left button 2. Right button 3. Scrolling Wheel 4. Fro nt hotkey 5. Ba ck hotkey 6. LED switch key 7. Nano Receiver How to... set up your wireless mouse Step 1: Take the battery cover off. Step 2: Insert the batteries as shown inside the battery compartment. Step 3: Replace the battery cover Step 4: Turn on power switch. Step 5: Your mouse will connect automatically, letting you use your mouse wirelessly 3 How to... pair your wireless mouse and computer If your wireless Laptop Mouse has not been connected to your computer after completing the previous steps, the following information will help you to complete the connection. 1. Turn off and turn on the POWER SWITCH on your mouse. 2. Make sure the computer is switch on. 3. Disconnect then reconnect the NANO RECEIVER on the computer. 4. Press the CONNECT BUTTON on the underside of the mouse. 5. The LED SWITCH KEY will flash 10 seconds to indicate the mouse is pairing with the nano receiver on the computer. 6. Your mouse will connect automatically. How to... recognize the operating system Step 1 : makes sure your wireless mouse is properly connected to your computer Step 2 : press the LED SWITCH KEY, follow the indication of below LED lighting on the switch key. LED SWITCH KEY Change to which system BLUE LED on 10sec Window 8 BLUE LED OFF Window7 ,window Vista, Window XP, Windows 2000, Mac OS x 10.5 or later Step 3 : If you need to travel with your wireless mouse, you can disc onnect the nano receiver. Your mouse will remember the last operating system until the next time you reconnect the nano receiver to 4 the computer. Your wireless mouse has special FRONT HOTKEY and BACKHOT KEY designed for windows systems. For instructions on understanding the functions see below. FRONT HOTKEY System function Window 8 APPs Manu Window 7 Window Vista Windows XP Windows 2000 Backward Mac OS x 10.5 or later Not Support BACK HOTKEY system function Window 8 Charms Manu Window7 Window Vista Windows XP Windows 2000 Forward Mac OS x 10.5 or later Not Support Battery Warning Statement... 1. Please insert the batteries with the correct position according to the instruction labeled in the mouse. 2. The batteries shall not be exposed to excessive heat such as sunshine, fire or the like. 3. Do not mix old and new batteries 4. Do not mix alkaline, standard (carbon-zinc), or rechargeable (ni-cad, ni -mh, etc) batteries.

DECLARATION OF IDENTITY FCC ID: 2AEAYK-W019M Hereby we: KINGLETIAN INTERNATIONAL ELECTRONIC CO.,LTD (Name of Manufacturer) Basic Model Number: K-W019M Basic Brand Name: / Basic Product Name: 2.4G wireless mouse Declare the Circuit, PCB Layout, shape of enclosure and Electrical Parts of the following product(s) are identical to the basic model: New / Additional Model Number(s): K-W037M,K-W035M,K-W030M,K-W005M,K-W003M,K- W001M,K-W014M,K-W020M,K-W018M,K-W149M New / Additional Brand Name(s): / Except the following(s) : Model numbers，outlook color Signature with Company Chop : Printed Name : Lear Lee DATE: 2015-3-3

M/N: K-W019M FCC ID: 2AEAYK-W019M Label location

Antenna Location

FCC ID: 2AEAYK-W019M Keyway Testing Technology Co., Ltd. Report No. 15KWE032326F Page 1 of 20 FCC TEST REPORT for Kingletian International Electronic Co.,Ltd 2.4G wireless mouse Model Number: K-W019M, K-W037M,K-W035M, K-W030M,K-W005M,K-W003M,K-W001M, K-W014M,K-W020M,K-W018M,K-W149M FCC ID: 2AEAYK-W019M Prepared for : KINGLETIAN INTERNATIONAL ELECTRONIC CO.,LTD Address : No.6 Xiaoqian East Road, Xinwei Village, Xintang Town, Zengcheng District, Guangzhou, China Prepared by : Keyway Testing Technology Co., Ltd. Address : Buliding 1, Baishun Industrial Zone, Zhangmutou Town, Dongguan, Guangdong, China Tel: 86-769-8718 2258 Fax: 86-769-8718 1058 Report No. : 15KWE032326F Date of Test : Feb. 24~29, 2015 Date of Report : Mar. 4, 2015 FCC ID: 2AEAYK-W019M Keyway Testing Technology Co., Ltd. Report No. 15KWE032326F Page 2 of 20 TABLE OF CONTENTS Test Report Declaration Page 1. TEST SUMMARY ........................................................................................................................ 4 2. GENERAL PRODUCT INFORMATION........................................................................................ 4 2.1. Product Function .................................................................................................................. 4 2.2. Description of Device (EUT) ................................................................................................. 4 2.3. Difference between Model Numbers..................................................................................... 4 2.4. Independent Operation Modes ............................................................................................. 4 2.5. Test Supporting System ....................................................................................................... 4 2.6. Test Facilities ....................................................................................................................... 5 2.7. List of Test and Measurement Instruments ........................................................................... 6 3. TEST SET-UP AND OPERATION MODES ................................................................................. 7 3.1. Principle of Configuration Selection ...................................................................................... 7 3.2. Block Diagram of Test Set-up ............................................................................................... 7 3.3. Test Operation Mode and Test Software .............................................................................. 7 3.4. Special Accessories and Auxiliary Equipment ...................................................................... 7 3.5. Countermeasures to Achieve EMC Compliance ................................................................... 7 3.6. Test Environment: ................................................................................................................ 7 4. EMISSION TEST RESULTS ........................................................................................................ 8 4.2. Radiated Emission Test........................................................................................................ 8 5. 20DB OCCUPY BANDWIDTH ................................................................................................... 14 5.1. Limits.................................................................................................................................. 14 5.2. Test setup .......................................................................................................................... 14 6. BAND EDGE COMPLIANCE TEST ........................................................................................... 16 6.1. Limits.................................................................................................................................. 16 6.2. Test setup .......................................................................................................................... 16 7. ANTENNA REQUIREMENTS .................................................................................................... 17 7.1. Limits.................................................................................................................................. 17 7.2. Result ................................................................................................................................. 17 8. PHOTOGRAPHS OF TEST SET-UP ......................................................................................... 18 9. PHOTOGRAPHS OF THE EUT ................................................................................................. 19 FCC ID: 2AEAYK-W019M Keyway Testing Technology Co., Ltd. Report No. 15KWE032326F Page 3 of 20 Keyway Testing Technology Co., Ltd. Applicant: Address: Kingletian International Electronic Co.,Ltd No.6 Xiaoqian East Road, Xinwei Village, Xintang Town, Zengcheng District, Guangzhou, China Manufacturer: Address: Guangzhou Wesdar Electronic Co.,Ltd No.6 Xiaoqian East Road, Xinwei Village, Xintang Town, Zengcheng District, Guangzhou, China E.U.T: 2.4G wireless mouse Model Number: K-W019M, K-W037M,K-W035M,K-W030M,K-W005M,K-W003M, K-W001M,K-W014M,K-W020M,K-W018M,K-W149M Trade Name: ------ Serial No.: ------ Date of Receipt: Feb. 24, 2015 Date of Test: Feb. 24~29, 2015 Test Specification: FCC Part 15, Subpart C Section 15.249: 2014 ANSI C63.4:2009 Test Result: The equipment under test was found to be compliance with the requirements of the standards applied. Issue Date: Mar. 4, 2015 Tested by: Reviewed by: Approved by: William Huang / Engineer Andy Gao / Supervisor Jade Yang/ Supervisor Other Aspects: None. Abbreviations: OK/P=passed fail/F=failed n.a/N=not applicable E.U.T=equipment under tested This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Keyway Testing Tec…
