2AECHFL-418Wireless Selfie Bluetooth Stick

FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation Model: WK-616 Main function: Wireless smart phone selfie shot Support system: Android, IOS system Max load: 1kg Folded lenght: 270mm Max lenght: 780mm Main material: Aluminum Section: 4 Weight: 146g Battery capacity: 60MAH Working current: 3.5MA Charging voltage: 5V Charging time: 1 hour( inicator light is red when charging, and it's off when chanrging full) Standby time: 100 hours above No.of multiple shots: 500 above 1.Open:short press the power switch, LED lights up,after lsecond,the blue LED lights down; 2.Paired/online Press the Camera key for 2 seconds,the blue LED is flashing,the device is pairing mode Open mobile phone search Bluetooth device the bluetooth device is KS-01 Click the self timer-03 link of Bluetooth devices,Wait for 8 seconds,when the green LED is constant lighting,they are paring successful 3.Photos:light press the photo keys,photo is complete 4.Power off:press 3 seconds power key 5.Charging;The MIRCO USB interface is at the bottom of the selftimer,when you charge it,and the red LED is lighting ① ② ③ My selftimer Use methed 120*80mm IOS system indicator light:White Android system indicator light: Blue Charging indicator: Being recharge, red light on; Fully recharged, indicator light off. On/Off indicator light: Blue IOAn Bluetooth light: Blue Shooting Button

Zhongshan Sea Dragon Photographic Equipment Co.,Ltd Letter of Authorization Company: Zhongshan Sea Dragon Photographic Equipment Co.,Ltd Address: 3 Floor, NO.15, Guangwan St.Maowan Village, Sanxiang Town, Zhongshan City, Guangdong Product Name: wireless Bluetooth selfie stick Model Number: WK-616, FL-418, FL-616, GK-716, GL-716, ML-616, PL-418, SK- 616, SL-616, WL-716, ZL-319 We authorize MiCOM Labs Inc, 575 Boulder Court, Pleasanton, CA 94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. This shall include the following: Testing • Approval applications (includes complete product documentation package, including Confidential information) and procedures • Payment of approval fees We declare that MiCOM Labs Inc, 575 Boulder court, Pleasanton, CA 94566, USA, is allowed to forward all information related to the approval project to the applied notified body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own, Name: Kathy Chan Date; 2015.03.13 Title: Foreign Trade Manager Signature of applicant:

LABEL ARTWORK AND LOCATION Label size: L*W=27*23mm Model No.: WK-616 FCC ID: 2AECHFL-418 This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Made in China FCC ID Location

Page 8 of 9 Model: WK-616 Internal Photos Page 9 of 9

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID: 2AECHFL-418 Product: wireless Bluetooth selfie stick Model No.: WK-616 Additional Model: FL-418, FL-616, GK-716, GL-716, ML-616, PL-418, SK-616, SL-616, WL-716, ZL-319 Trade Mark: N/A Report No.: TCT150119E005 Issued Date: Jul. 08, 2015 Issued for : Zhongshan Sea Dragon Photographic Equipment Co.,Ltd 3 Floor, NO.15, Guangwan St.Maowan Village, Sanxiang Town, Zhongshan City, Guangdong Issued By: Shenzhen Tongce Testing Lab. 1F, Leinuo Watch Building, Fuyong Town, Baoan Dist, Shenzhen, China TEL: +86-755-27673339 FAX: +86-755-27673332 Note: This report shall not be reproduced except in full, without the written approval of Shenzhen Tongce Testing Lab. This document may be altered or revised by Shenzhen Tongce Testing Lab. personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT150119E005 Page 2 of 38 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TABLE OF CONTENTS 1. Test Certification....................................................................................... 3 2. Test Result Summary ............................................................................... 4 3. EUT Description ........................................................................................ 5 4. Genera Information ................................................................................... 6 4.1. Test environment and mode ................................................................................. 6 4.2. Description of Support Units ................................................................................ 6 5. Facilities and Accreditations ................................................................... 7 5.1. Facilities ................................................................................................................. 7 5.2. Location ................................................................................................................. 7 5.3. Measurement Uncertainty ..................................................................................... 7 6. Test Results and Measurement Data ...................................................... 8 6.1. Antenna requirement ............................................................................................ 8 6.2. Conducted Emission ............................................................................................. 9 6.3. Conducted Output Power ................................................................................... 13 6.4. 20dB Occupy Bandwidth .................................................................................... 16 6.5. Carrier Frequencies Separation ......................................................................... 19 6.6. Hopping Channel Number .................................................................................. 22 6.7. Dwell Time ............................................................................................................ 24 6.8. Pseudorandom Frequency Hopping Sequence ................................................ 26 6.9. Conducted Band Edge Measurement ................................................................ 27 6.10. Conducted Spurious Emission Measurement ................................................. 29 6.11.Radiated Spurious Emission Measurement ..................................................... 31 Appendix A: Photographs of Test Setup Appendix B: Photographs of EUT Report No.: TCT150119E005 Page 3 of 38 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. Test Certification Product: wireless Bluetooth selfie stick Model No.: WK-616 Additional Model: FL-418, FL-616, GK-716, GL-716, ML-616, PL-418, SK-616, SL-616, WL-716, ZL-319 Applicant: Zhongshan Sea Dragon Photographic Equipment Co.,Ltd Address: 3 Floor, NO.15, Guangwan St.Maowan Village, Sanxiang Town, Zhongshan City, Guangdong Manufacturer: Zhongshan Sea Dragon Photographic Equipment Co.,Ltd Address: 3 Floor, NO.15, Guangwan St.Maowan Village, Sanxiang Town, Zhongshan City, Guangdong Date of Test: Jan. 20 - Mar. 03, 2015 Applicable Standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 The above equipment has been tested by Shenzhen Tongce Testing Lab. and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Tested By:Date:Mar. 03, 2015 Leon Chen Reviewed By:Date:Jul. 08, 2015 Joe Zhou Approved By: Date:Jul. 08, 2015 Tomsin Report No.: TCT150119E005 Page 4 of 38 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. Test Result Summary Requirement CFR 47 Section Result Antenna Requirement §15.203/§15.247 (c) PASS AC Power Line Conducted Emission §15.207 PASS Conducted Peak Output Power §15.247 (b)(1) PASS 20dB Occupied Bandwidth §15.247 (a)(1) PASS Carrier Frequencies Separation §15.247 (a)(1) PASS Hopping Channel Number §15.247 (a)(1) PASS Dwell Time §15.247 (a)(1) PASS Radiated Emission §15.205/§15.209 PASS Band Edge §15.247(d) PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. Report No.: TCT150119E005 Page 5 of 38 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. EUT Description Product Name: wireless Bluetooth selfie stick Model : WK-616 Additional Model: FL-418, FL-616, GK-716, GL-716, ML-616, PL-418, SK-616, SL-616, WL-716, ZL-319 Trade Mark: N/A BT Version: …

Text truncated - open the document above for the full version.

Appendix A: Photographs of Test Setup Radiated Emission Conducted Emission
