REALOV T001 迷你智能震动棒 (Smartphone Controlled Vibrator ) Welcome to use REALOV TM T001. T001 can be used as a conventional vibrator, as well as be connected to a smartphone through an APP, therefore providing you and your lover with a sensational and unexpected experience. For more functions, please download the APP and refer to the “User’s Guide”, or visit www.realov.com The product package includes, 1) T001 Vibrator 2) USB Cord 3) Storage Bag 4) User’s Guide To Charge: Insert one end of the data wire into the T001 and connect the other end to the USB port or USB/AC adapter (not included). A red light indicates the T001 is charging . When the T001 has fully charged the light will turn to green. To Turn On and Off To Turn On: Hold the button for 3 seconds until you feel it vibrate once. . To Turn Off : Hold the button for 3 seconds until you feel it vibrate three times . How To Use: Manual mode (No Need for Smartphones) After it is turned on, press the button briefly to shift through the 10 vibration modes. Smartphone Control Mode: Download and Install the App: 1)IOS System: Through the APP store, search “REALOV” to download and install. Android System: Through Google Play, search “REALOV” for downloads and installations. 2) Scan the QR code on the packaging and follow the directions . 3) Download the APP at : www.realov.com Initial Pairing After T001 has been turned on, enable Bluetooth on the smartphone, the APP and the smartphone will automatically search T001 and finish the pairing process, then “Connected” will be displayed on the left upper corner of the smartphone screen. Caution: 1.First time pairing in the Setting is a must for part of the Android smartphone.( Methods: Smartphone-Settings - Bluetooth - Scan – Pairing ), then run the APP . ( However in any case, please try to run the APP directly first ) 2.When the T001 or the cell phone is low in power, the pairing will be affected. Please recharge it immediately. Pairing cancellation: Click the “Connected” button on the left upper corner of the screen to disconnect . Successive Pairing (shaking for connection): As long as the APP is not cancelled, shaking the cell phone can automatically begin the process. For more function, please refer to the “User’s Guide” in the APP, or log on to : www.realov.com Product parameters: Material Human-safe silicone ABS Dimension 16X3.6X3.4 (cm) Water-proof Completely water proof Weight 55g Color Cherry red, enchanted purple and ocean blue Re-charging time T001-FC: 3h T001-HC: 1h Battery Lithium ion battery Use time Max. 4h Motor speed 1100r/m Maintenance During Use: It is recommended that the T001 be used with water based lubricant, Do not use with silicone or oil lubricant as it will damage the surface of the product. Cleaning: After each use, please wash with warm water and scented soap, or a toy cleaner. Warranty: There is a one-year warranty from the date of purchase. However, in case of the following circumstances, the warranty is invalid: 1. The product was damaged due to the improper use or unauthorized alterations. 2. The product was damaged due to a natural disaster such as earthquake ,flood etc. Designed and developed by REALOV IDEAL LLC, USA Made in China © Realov Ideal LLC 2013-2015 copyright reserved. www.realov.com Federal Communications Commission (FCC) Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ●Reorient or relocate the receiving antenna. ●Increase the separation between the equipment and receiver. ●Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ●Consult the dealer or an experienced radio/TV technician for help. Warning: Changes or modifications made to this device not expressly approved by Shanghai Realov Electronic Technology Co., Ltd may void the FCC authorization to operate this device. Note: The manufacturer is not responsible for any radio or tv interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment.

Shanghai Realov Electronic Technology Co.,Ltd Fl.3, No.26, Middle Jia Song Road, Qing Pu District, Shanghai, China TEL: +86-21-69785619 FAX: +86-21-69785619 DATE 03-18-2015 FCC ID: 2AEEO-T002 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Shenzhen CTL Testing Technology Co., Ltd.(MR. Tracy Qi) at Floor 1-A, Baisha Technology Park, No. 3011, Shahexi Road, Nanshan, Shenzhen 518055 China to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Shanghai Realov Electronic Technology Co.,Ltd at Fl.3, No.26, Middle Jia Song Road, Qing Pu District, Shanghai, China. Dated this 03-18-2015 Agency agreement expiration date: 03-17-2016 By: Song Xin Sig nature Printed T itle: Manager On behalf of : Shanghai Realov Electronic Technology Co.,Ltd Tel ephone: +86-21-69785619

Shanghai Realov Electronic Technology Co.,Ltd Fl.3, No.26, Middle Jia Song Road, Qing Pu District, Shanghai, China TEL: +86-21-69785619 FAX: +86-21-69785619 DATE 03-18-2015 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AEEO-T001 Product Name: Smartphone Controlled Vibrator Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 03-18-2015 By: Song Xin Signature Printed Title: Manager On behalf of : Shanghai Realov Electronic Technology Co.,Ltd Telephone: +86-21-69785619 FCC ID: 2AEEO-T002

Shanghai Realov Electronic Technology Co.,Ltd Fl.3, No.26, Middle Jia Song Road, Qing Pu District, Shanghai, China TEL: +86-21-69785619 FAX: +86-21-69785619 Series Models Description FCC ID: 2AEEO-T001 Date: Mar. 18, 2015 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: To whom concern: The device (Product Name: Smartphone Controlled Vibrator) Models Name: T001, T002 have same electrical, PCB and BOM, only the model’s name and colour are different for marketing requirements. Sincerely, Song Xin/Manager T001, T002 are electrically identical , only the model’s name and colour are different for marketing requirements. FCC ID: 2AEEO-T002

Shanghai Realov Electronic Technology Co.,Ltd Fl.3, No.26, Middle Jia Song Road, Qing Pu District, Shanghai, China TEL: +86-21-69785619 FAX: +86-21-69785619 USB Port Statement FCC ID: 2AEEO-T001 Date: Mar. 18, 2015 To whom it may concern: We, the undersigned, state that the device's (Model: T001, T002) USB port only used for charge, no any data transfer to PC. Sincerely, Song Xin/Manager FCC ID: 2AEEO-T002

FCC ID Label Information 1. Label location: 2. FCC ID Label: Model: T001 FCC ID: 2AEEO-T001 FCCID Label Location Model T002 FCC ID: 2AEEO-T002

RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m)---3m So pt = (EXd) 2 /30 x gt Field strength = 96.04 dBuV/m @3m Ant gain 0dBi ;so Ant numeric gain=1 So pt={ [10 (96.04 /20) /10 6 x3] 2 /30x1 }x1000 mW =1.21mW So ( 1.21mW/5mm)x √2.480GHz = 0.381 <3 Then SAR evaluation is not required
