AFFIX Elite Aquarius User Manual Model Name: Aquarius Brand Name: AFFIX 2 Contents CONTENTS ................................................................................................... 2 1.UNDERSTANDING YOUR DEVICE ......................................................... 4 1.0 GENERAL INFO .................................................................................. 4 1.1 DEVICE OVERVIEW ........................................................................... 5 2. GETTING STARTED ................................................................................. 6 2.1 INSTALLING CARDS & BATTERY .................................................. 6 2.2 POWERING ON/OFF THE DEVICE.................................................. 8 3.BASIC OPERATIONS ................................................................................. 9 3.1 CALLING .............................................................................................. 9 3.2 MESSAGING ..................................................................................... 10 3.3 CONTACTS ........................................................................................ 11 3.4 EMAIL ................................................................................................. 12 3.5 BROWSER ......................................................................................... 12 4.HOME SCREEN ......................................................................................... 13 4.1 QUICK START: HOME SCREEN .................................................... 13 4.2 STATUS BAR ..................................................................................... 14 4.3 APPLICATION TAB .......................................................................... 14 4.4 CUSTOMIZING SCREEN................................................................. 15 5.MULTIMEDIA ........................................................................................... 17 5.1 ES FILE EXPLORE ........................................................................... 17 5.2 PLAY MUSIC...................................................................................... 17 5.3 SOUND RECORDER ........................................................................ 17 5.4 GALLERY .......................................................................................... 18 5.5 CAMERA ............................................................................................ 18 5.6 FM RADIO .......................................................................................... 18 6.NETWORK ................................................................................................. 19 6.1 WI-FI .................................................................................................... 19 6.2 3G ........................................................................................................ 19 3 6.3 BLUETOOTH ..................................................................................... 19 7.SETTINGS .................................................................................................. 20 7.1 WIRELESS & NETWORKS ............................................................. 20 7.2 AUDIO PROFILES ............................................................................ 20 7.3 DISPLAY ............................................................................................ 20 7.4 STORAGE .......................................................................................... 20 7.5 BATTERY ........................................................................................... 21 7.6 APPS .................................................................................................. 21 7.7 DUAL SIM SETTINGS ...................................................................... 21 7.8 LOCATION ......................................................................................... 21 7.9 SECURITY ......................................................................................... 21 7.10 LANGUAGE & INPUT .................................................................... 22 7.11 BACKUP & RESET ......................................................................... 22 7.12 TIMER SWITCH MACHINE ........................................................... 23 7.13 ACCOUNTS ..................................................................................... 23 7.14 DATE & TIME ................................................................................... 23 7.15 ACCESSIBILITY ............................................................................. 23 7.16 PRINTING ........................................................................................ 23 7.17 ABOUT PHONE .............................................................................. 24 8.APPLICATIONS AND UTILITES ........................................................... 25 8.1 CALCULATOR .................................................................................. 25 8.2 CLOCK ............................................................................................... 25 8.3 GMAIL ................................................................................................ 25 8.4 CALENDAR ....................................................................................... 25 8.5 PLAY STORE ..................................................................................... 26 9.SPECIFICATIONS ..................................................................................... 27 4 1.UNDERSTANDING YOUR DEVICE 1.0 GENERAL INFO elite Aquarius is a multi SIM phone that encloses features, such as Android version 4.4, Wi-Fi, 1.3 GHz Quad-core Processor, 5 MP Camera, etc. 5 1.1 DEVICE OVERVIEW Position of keys 1.Volume Keys 2.Earphone Jack 3.Receiver 4.Menu Key 5.Home Key 6.Back Key 7.Charge/USB Port 8.Power/Lock Key 9.Back Camera Lens 10.Flash 11.Speaker 6 2. GETTING STARTED …

Text truncated - open the document above for the full version.

Differences Description We SACO LLC state: Product： AFFIX Elite Aquarius Model Name： Aquarius, Elite Trade Name: AFFIX FCC ID: 2AEEX-AQUARIUS The electrical circuit design, layout, components used and internal wiring for above models are identical, only the model name is different. Signatory Date 2015-3-27 Signature Name: Brett Schmulian Title: manager Company: SACO LLC Address: 2170 NW 87th Ave, Doral Florida, 33172

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2Rev 5.0 SACO LLC 2015.3.18 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, SACO LLC hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): (Product description, model name): Product description: AFFIX Elite Aquarius model name: Aquarius, Elite FCC ID: 2AEEX-AQUARIUS Sincerely, Client’s signature : Brett Schmulian Client’s name / title: manager Applicant company: SACO LLC address：2170 NW 87th Ave, Doral Florida, 33172

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 SACO LLC 2015.3.27 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AEEX-AQUARIUS We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description - Tune up Procedure - Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Brett Schmulian Client’s name & title : manager Contact information / address: SACO LLC / 2170 NW 87th Ave, Doral Florida, 33172

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8 Photo 9 Photo 10 Photo 11

Label AFFIX Elite Aquarius Model name: Aquarius Brand name: AFFIX FCC ID: 2AEEX-AQUARIUS This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. label

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 BT/WIFI ANTENNA GSM/WCDMA ANTENNA GPS ANTENNA Photo 3 Photo 4 Photo 5

Ref : ACR.262.1.14.SATU.A SHENZHEN STS TEST SERVICES CO., LTD. 1/F, BUILDING 2, ZHUOKE SCIENCE PARK, CHONGQING ROAD FUYONG, BAO’ AN DISTRICT, SHENZHEN,CHINA SATIMO COMOSAR DOSIMETRIC E-FIELD PROBE SERIAL NO.: SN 17/14 EP221 Calibrated at SATIMO US 2105 Barrett Park Dr. - Kennesaw, GA 30144 09/01/2014 Summary: This document presents the method and results from an accredited COMOSAR Dosimetric E-Field Probe calibration performed in SATIMO USA using the CALISAR / CALIBAIR test bench, for use with a SATIMO COMOSAR system only. All calibration results are traceable to national metrology institutions. COMOSAR E-Field Probe Calibration Report COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 2/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. Name Function Date Signature Prepared by : Jérôme LUC Product Manager 9/19/2014 Checked by : Jérôme LUC Product Manager 9/19/2014 Approved by : Kim RUTKOWSKI Quality Manager 9/19/2014 Customer Name Distribution : Shenzhen STS Test Services Co., Ltd. Issue Date Modifications A 9/19/2014 Initial release COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 3/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. TABLE OF CONTENTS 1 Device Under Test ..................................................................................................... 4 2 Product Description ................................................................................................... 4 2.1 General Information _______________________________________________________ 4 3 Measurement Method ................................................................................................ 4 3.1 Linearity ________________________________________________________________ 4 3.2 Sensitivity _______________________________________________________________ 5 3.3 Lower Detection Limit _____________________________________________________ 5 3.4 Isotropy _________________________________________________________________ 5 3.5 Boundary Effect __________________________________________________________ 5 4 Measurement Uncertainty .......................................................................................... 5 5 Calibration Measurement Results .............................................................................. 6 5.1 Sensitivity in air __________________________________________________________ 6 5.2 Linearity ________________________________________________________________ 7 5.3 Sensitivity in liquid ________________________________________________________ 7 5.4 Isotropy _________________________________________________________________ 8 6 List of Equipment ...................................................................................................... 9 COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 4/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. 1 DEVICE UNDER TEST Device Under Test Device Type COMOSAR DOSIMETRIC E FIELD PROBE Manufacturer Satimo Model SSE5 Serial Number SN 17/14 EP221 Product Condition (new / used) New Frequency Range of Probe 0.4 GHz- 6 GHz Resistance of Three Dipoles at Connector Dipole 1: R1=0.179 M Dipole 2: R2=0.167 M Dipole 3: R3=0.178 M A yearly calibration interval is recommended. 2 PRODUCT DESCRIPTION 2.1 GENERAL INFORMATION Satimo’s COMOSAR E field Probes are built in accordance to the IEEE 1528, OET 65 Bulletin C and CEI/IEC 62209 standards. Figure 1 – Satimo COMOSAR Dosimetric E field Dipole Probe Length 330 mm Length of Individual Dipoles 4.5 mm Maximum external diameter 8 mm Probe Tip External Diameter 5 mm Distance between dipoles / probe extremity 2.7 mm 3 MEASUREMENT METHOD The IEEE 1528, OET 65 Bulletin C, CENELEC EN50361 and CEI/IEC 62209 standards provide recommended practices for the probe calibrations, including the performance characteristics of interest and methods by which to assess their affect. All calibrations / measurements performed meet the fore mentioned standards. 3.1 LINEARITY The evaluation of the linearity was done in free space using the waveguide, performing a power sweep to cover the SAR range 0.01W/kg to 100W/kg. COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 5/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. 3.2 SENSITIVITY The sensitivity factors of the three dipoles were determined using a two step calibration method (air and tissue simulating liquid) using waveguides as outlined in the standards. 3.3 LOWER DETECTION LIMIT The lower detection limit was assessed using the same measurement set up as used for the linearity measurement. The required lower detection limit is 10 mW/kg. 3.4 ISOTROPY The axial isotropy was evaluated by exposing the probe to a reference wave from a standard dipole with the dipole mounted under the flat phantom in the test configuration suggested for system validations and checks. The probe was rotated along its main axis from 0 - 360 degrees in 15 degree steps. The hemispherical isotropy is determined by inserting the probe in a thin plastic box filled with tissue-equivalent liquid,…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F, Building B, Zhuoke Science Park, Chongqing Road, Fuyong, Baoan District, Shenzhen, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC SAR TEST REPORT Report No: STS1503055H01 Issued for SACO LLC 2170 NW 87th Ave Doral, FL 33172 Product Name: AFFIX Elite Aquarius Brand Name: AFFIX Model No.: Aquarius Series Model: Elite FCC ID: 2AEEX-AQUARIUS Test Standard: ANSI/IEEE Std. C95.1 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 Max. SAR (1g): Head:0.465 W/kg Body:1.229 W/kg S T L A B S Page 2 of 101 Report No.: STS1503055H01 Test Report Certification Applicant’s name ................. : SACO LLC Address ................................. : 2170 NW 87th Ave Doral, FL 33172 Manufacture's Name ............ : Shanghai YiXi Technology Co.,LTD Address ................................. : 8F,Modern Logistics Plaza,102,Rd Qinjiang,Caohengjing Hi-Tech Park,Shanghai City,200233,P.R.China Product description Product name ........................ : AFFIX Elite Aquarius Trademark ........................... : AFFIX Model and/or type reference : Aquarius Serial Model： Elite Standards ............................. : ANSI/IEEE Std. C95.1-1992 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 The device was tested by Shenzhen STS Test Services Co., Ltd. in accordance with the measurement methods and procedures specified in KDB 865664 The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Date of Test ........................................... : Date (s) of performance of tests ............. : 25 Mar. 2015 Date of Issue .......................................... : 26 Mar. 2015 Test Result.............................................. : Pass Testing Engineer : (Allen Chen) Technical Manager : (John Zou) Authorized Signatory : (Bovey Yang) Page 3 of 101 Report No.: STS1503055H01 TABLE OF CONTENS 1. General Information 4 1.1 EUT Description 4 1.2 Test Environment 5 1.3 Test Facility 5 2. Test Standards And Limits 6 3. SAR Measurement System 7 3.1 Definition Of Specific Absorption Rate (SAR) 7 3.2 SAR System 7 3.2.1 Probe 8 3.2.2 Phantom 9 3.2.3 Device Holder 9 4. Tissue Simulating Liquids 10 4.1 Simulating Liquids Parameter Check 10 5. SAR System Validation 11 5.1 Validation System 11 5.2 Validation Result 11 6. SAR Evaluation Procedures 12 7. EUT Antenna Location Sketch 13 7.1 SAR TEST EXCLUSION CONSIDER TABLE 14 8. EUT Test Position 16 8.1 Define Two Imaginary Lines On The Handset 16 8.2 Hotspot mode exposure position condition 17 9. Measurement Uncertainty 18 10. Conducted Power Measurement 20 11. EUT And Test Setup Photo 24 11.1 EUT Photo 24 11.2 Setup Photo 27 12. SAR Result Summary 33 12.1 Head SAR 33 12.2 Body SAR And Hotspot 34 12.3 repeated SAR measurement 35 13. Equipment List 38 Appendix A. System Validation Plots 39 Appendix B. SAR Test Plots 51 Appendix C. Probe Calibration And Dipole Calibration Report 101 Page 4 of 101 Report No.: STS1503055H01 1. General Information 1.1 EUT Description Equipment AFFIX Elite Aquarius Brand Name AFFIX Model No. Aquarius Serial Model Elite FCC ID 2AEEX-AQUARIUS Model Difference Only different in model name Adapter Input: AC100-240V, 200m A, 50/60 Hz Output: DC 5V, 1000mA Battery Rated Voltage: 3.7V Capacity: 1800mAh Hardware Version T8960A_MB_V1.0_VCA1_YUEHU Software Version N/A Frequency Range GSM 850: 824.2 ~ 848.8 MHz PCS1900: 1850.2 ~ 1909.8 MHz WCDMA II: 1852.4~1907.6 MHz WCDMA V: 826.4~846.6 MHz WLAN 802.11 b/g/n(HT20):2412-2462 MHz WLAN 802.11 n(HT40):2422-2452 MHz Bluetooth：2402~2480MHz Transmit Power(MAX): GSM 850: 32.70dBm GSM 1900: 29.11dBm WCDMA II: 22.42dBm WCDMA V: 22.75dBm 802.11b: 14.94dBm 802.11g:12.51dBm 802.11 n(HT20): 12.33dBm 802.11 n(HT40): 11.22dBm Bluetooth: 3.858dBm Max. Reported SAR(1g): Head: GSM 850: 0.341 W/kg GSM 1900: 0.183 W/kg WCDMA II: 0.465 W/kg WCDMA V: 0.344 W/kg WIFI: 0.381 W/kg Body: GSM 850: 0.642 W/kg GSM 1900: 0.642 W/kg WCDMA II: 1.229 W/kg WCDMA V: 0.511 W/kg WIFI: 0.135 W/kg Operating Mode: GSM: GSM Voice, GPRS, EGPRS Class 12; WCDMA: RMC, HSDPA, HSUPA Release 6; WLAN: 802.11 b/g/n; Bluetooth: V2.1 + EDR (GFSK +π/4DQPSK+8DPSK) Antenna Specification: GSM/WCDMA: PIFA Antenna BT/WIFI: PIFA Antenna SIM Card Support dual-SIM, dual standby, the multiple SIM card with two lines cannot transmitting at the same time Hotspot Mode: Support DTM Mode: Not Support Page 5 of 101 Report No.: STS1503055H01 1.2 Test Environment Ambient conditions in the SAR laboratory: Items Required Actual Temperature (°C) 18-25 22~23 Humidity (%RH) 30-70 55~65 1.3 Test Facility Shenzhen STS Test Services Co., Ltd. Add. : 1/F, Building 2, Zhuoke Science Park, Chongqing Road, Fuyong, Baoan District, Shenzhen, China FCC Registration No.: 842334;IC Registration No.: 12108A-1 Page 6 of 101 Report No.: STS1503055H01 2. Test Standards And Limits No. Identity Document Title 1 47 CFR Part 2 Frequency Allocations and Radio Treaty Matters; General Rules and Regulations 2 ANSI/IEEE Std. C95.1-1992 IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz 3 IEEE Std. 1528-2013 Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques 4 FCC KDB 447498 D01 v05r02 Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies 5 FCC KDB 865664 D01 v01r03 SAR Measurement 100 MHz to 6 GHz 6 FCC KDB 865664 D01 v01r03 SAR Measurement 100 MHz to 6 GHz 7 FCC KDB 941225 D01 SAR Measurement Procedures for 3G Devices 8 FCC KDB 248227 D…

Text truncated - open the document above for the full version.

GSM/WCDMA ANTENNA BT/WIFI ANTENNA TOTA L 3CM 2CM 5.43CM TOTAL 3.8CM GPS ANTENNA 15.15CM 5.4CM 13.6CM

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F, Building B, Zhuoke Science Park, Chongqing Road, Fuyong, Baoan District, Shenzhen, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC RADIO REPORT Report No: STS1503055F04 Issued for SACO LLC 2170 NW 87th Ave, Doral Florida, 33172 Product Name: AFFIX Elite Aquarius Brand Name: AFFIX Model No.: Aquarius Series Model: Elite FCC ID: 2AEEX-AQUARIUS Test Standard: FCC Part 22H and 24E S T L A B S 2 of 114 Report No.: STS1503055F04 Testing Engineer : (Tony Liu) Technical Manager : (Vita Li) Authorized Signatory : (Bovey Yang) TEST RESULT CERTIFICATION Applicant’s name .................... : SACO LLC Address .................................... : 2170 NW 87th Ave, Doral Florida, 33172 Manufacture's Name .............. : Shanghai YiXi Technology Co.,LTD Address .................................... : 8F,Modern Logistics Plaza,102,Rd Qinjiang,Caohengjing Hi-Tech Park,Shanghai City,200233,P.R.China Product name ........................... : AFFIX Elite Aquarius Band name ............................. : AFFIX Model and/or type reference .... : Aquarius Standards ................................ : FCC Part 22H and 24E Test procedure ............................... : TIA 603 C This device described above has been tested by STS and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ................................................ : Date of performance of tests ...................... : 24 Mar. 2015 ~31 Mar. 2015 Date of Issue ............................................... : 01 April. 2015 Test Result ................................................... : Pass 3 of 114 Report No.: STS1503055F04 TABLE OF CONTENTS 1.SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2. GENERAL INFORMATION 6 2.1 PRODUCT DESCRIPTION 6 2.2 RELATED SUBMITTAL(S) / GRANT (S) 7 2.3 SPECIAL ACCESSORIES 7 2.4 EUT CONFIGURATION 7 2.5 EUT EXERCISE 7 2.6 CONFIGURATION OF EUT SYSTEM 7 2.7 MEASUREMENT INSTRUMENTS 9 3. DESCRIPTION OF TEST MODES 10 4. OUTPUT POWER 11 4.1 CONDUCTED OUTPUT POWER 11 4.2 PEAK-TO-AVERAGE RADIO (PAR) OF TRANSMITTER 17 4.3 RADIATED OUTPUT POWER 22 5. SPURIOUS EMISSION 26 5.1 SPURIOUS EMISSION 26 5.2 RADIATED SPURIOUS EMISSION 28 6. FREQUENCY STABILITY 34 6.1 MEASUREMENT METHOD 34 6.2 PROVISIONS APPLICABLE 35 6.3 MEASUREMENT RESULT 36 7. OCCUPIED BANDWIDTH 41 7.1 MEASUREMENT METHOD 41 7.2 PROVISIONS APPLICABLE 41 7.3 MEASUREMENT RESULT 41 8. EMISSION BANDWIDTH 44 8.1 MEASUREMENT METHOD 44 8.2 PROVISIONS APPLICABLE 44 8.3 MEASUREMENT RESULT 44 9. BAND EDGE 47 9.1 MEASUREMENT METHOD 47 9.2 PROVISIONS APPLICABLE 47 9.3 MEASUREMENT RESULT 47 APPENDIX I 48 4 of 114 Report No.: STS1503055F04 TEST PLOTS FOR CONDUCTED SPURIOUS EMISSION 48 APPENDIX II 78 TEST PLOTS FOR OCCUPIED BANDWIDTH (99%) 78 EMISSION BANDWIDTH (-26DBC) 78 APPENDIX III 102 TEST PLOTS FOR BAND EDGES 102 APPENDIX IV 114 PHOTOS OF TEST SETUP 114 5 of 114 Report No.: STS1503055F04 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: The radiated emission testing was performed according to the procedures of ansi C63.10: 2009; TIA 603 C and fcc cfr 47 rules of 2.1046, 2.1047, 2.1049, 2.1051, 2.1053, 2.1055, 2.1057 Item Number Item Description FCC Rules 1 Output Power Conducted output power 22.913(a) / 24.232 (b) Radiated output power 2 Spurious Emission Conducted spurious emission 2.1051 / 22.917 / 24.238 Radiated spurious emission 3 Frequency Stability 2.1055 /24.235 4 Occupied Bandwidth 2.1049 (h)(i) 5 Emission Bandwidth 22.917(b) / 24.238 (b) 6 Band Edge 22.917(b) / 24.238 (b) NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 TEST FACILITY Shenzhen STS Test Services Co., Ltd. Add. : 1/F, Building 2, Zhuoke Science Park, Chongqing Road, Fuyong, Baoan District, Shenzhen, China. FCC Registration No.: 842334; IC Registration No.: 12108A-1 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% 6 of 114 Report No.: STS1503055F04 2. GENERAL INFORMATION 2.1 PRODUCT DESCRIPTION A major technical description of EUT is described as following: Product Designation: AFFIX Elite Aquarius Model No: o.: Aquarius Series Model:: Elite Model difference: Only difference in mode name Hardware version: T8960A_MB_V1.0_VCA1_YUEHU Software version: N/A FCC ID: 2AEEX-AQUARIUS Frequency Bands: GSM 850 PCS 1900 (U.S. Bands) GSM 900 DCS 1800 (Non-U.S. Bands) U.S. Bands: UMTS FDD Band II UMTS FDD Band V Non-U.S. Bands: UMTS FDD Band I UMTS FDD Band VIII Max RF Output Power: GSM850:32.91dBm,GSM1900:29.33dBm WCDMA Band V:23.01dBm,WCDMA Band II:22.64dBm Type of Emission: GSM(850):246KGXW: GSM(1900):250KGXW GPRS(850):247KGXW; GPRS(1900):248KGXW EDGE(850):250KG7W: EDGE(1900):251KG7W WCDMA850:4M17F9W WCDMA1900:4M19F9W SIM CARD Support dual-SIM, dual standby, the multiple SIM card with two lines cannot transmitting at the same time Antenna: PIFA Antenna Antenna gain: 0 dBi Power Supply: DC 3.7V by battery or DC 5.0V supplied by adapter Battery parameter: DC 3.7V/1800mAh Adapter Input: AC100-240V, 5…

Text truncated - open the document above for the full version.

PCESetup photo PCEradiation L PCEradiation H PCE RF conduction test photos PCE High and low temperature test photos
