2AEF8-GT03Smart Audio Bluetooth Glasses

Chipset :Realtek 8763BFP Bluetooth version:BT V5.0 Driver diameter ：ø11 mm lmpedance ：16 Ω Sensitivity(S.P.L)：105±3 dB Frequency response ：20 Hz-20K Hz Microphone F.S. ：42 dB SNR ：97 dBA Audio codec supported ：SBC、AAC Total Harmonic Distortion ： ≤0.2% Dual modeDual mode Support Bluetooth profiles supported： A2DP AVRCP HFP HSP SPP Bluetooth class：Class 2 Bluetooth range ：＞10 M Battery capacity of one earphone ：63 mAh x 2 Play time： 8 H Call time ： 10-15 H Standby time ：100 H Charging time ：2 H Dust/water protection level ： IPX5 Other function ：Replaceable frames “Low battery” White lightWhite light White light Low battery - needs charging White light keeps shining during charging White light gets off after fully charging 5S 1、What’s in package 1、BT glasses 2、Glasses box 3、High-end glasses cloth 4、User guide 5、Portable storage bag 6、Dedicated charging cable 7、Magic Stick TWS GlASSES HEADSET MANUAL 2、Connecting cellphone Press Left button 2s for previous track Single click Left button for play & pause Under power-on state, double click either MFB for mode-switching When battery gets low, glasses gives hint tone “Low Battery” every 2 minutes, white indicator flashes every 5 seconds (Devices gets off automatically in half an hour). Please charge the glasses with dedicated charge cable. When the glasses are off, press and hold both MFB for 6s to enter pairing mode, and 5-click at both MFB, the white LED indicator keeps luminous for 1 second and being powered off afterwards and resetting is done. ( Reset device when earphone gets disconnected to each other or device get disconnected to both earphones) Gaming modeMusic mode Different frames can be replaced 4 optional sizes sticks Receiving calls Single click either button for answering Double click either button for rejecting Ending calls Single click either button for ending Press Right button 2s for next track Single click Right button for play & pause 4、 Voice assistant function Warranty Card Certificate 5、Play music 7、Mode-switch 10、Charging 11、Product specifications 8、Reset 9、Replace Magic sticks / Glasses frames 6、Make phone calls On connected state, triple-click any side to turn on the Siri or Android voice assistant; Click the MFB button on either side of the headset to turn off the Siri/Android voice assistant. The following situations will not be repaired free of charge 1.No warranty card or warranty card is damaged 2.Device damage caused by self disassembly 3.Damage caused by water, dropping or man made mechanical destruction 4.Damage or fault caused by force majeure Warranty content ( Fill in this card truthfully for warranty ) Product Name Product Model Purchase Date Purchase Seller User’s Name User’s Address Contact Detail Fault Description Inspector Inspection Date Manufacture Date 3、Shut down In the power-on state, long press the left MFB button or the right MFB button for about 4 seconds, the machine will turn off. In the off state, press and hold the left MFB key and the right MFB key at the same time for about 4 seconds to turn on the machine. The left and right side will be automatically paired and enter the TWS normal pairing mode. Turn on the Bluetooth device to search for "GT03" and perform pairing. GSE CO.,LTD Liuhua West Street, Xiakou, Dongcheng District, Dongguan, Guangdong Province, China Designed by DIVINUS / Made in China https://divinustech.com FCC Warning Statement: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be u sed in portable exposure condition without restriction

Dongguan XinYao Electronic Industrial Co. LTD (2023.02.06) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (Smart Audio Bluetooth Glasses / GT03 / FCC ID: 2AEF8-GT03 ) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No required to be submitted with this application be permanently withheld from public review. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Signature: Name: Benny Tan Title: CEO

Dongguan XinYao Electronic Industrial Co. LTD (2023.02.06) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (Shenzhen CTB Testing Technology Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Signature: Name: Benny Tan Title: CEO

External Photos

FCC ID LABEL: Label Location: FCC ID: 2AEF8-GT03 Model No.: GT03

Internal Photos ANT ANT

Shenzhen CTB Testing Co., Ltd. FCC ID: 2AEF8-GT03 Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V06 The 1-g SAR and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[√f(GHZ)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f(GHZ) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. EDR: Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion 2.402 0.762 1.19 0±1 1.00 1.26 <5 0.39023 3.00 YES 2.441 0.567 1.14 0±1 1.00 1.26 <5 0.39338 3.00 YES 2.480 0.849 1.22 0±1 1.00 1.26 <5 0.39651 3.00 YES 2.402 1.622 1.45 1±1 2.00 1.58 <5 0.49127 3.00 YES 2.441 1.386 1.38 1±1 2.00 1.58 <5 0.49524 3.00 YES 2.480 1.64 1.46 1±1 2.00 1.58 <5 0.49918 3.00 YES 2.402 1.964 1.57 1±1 2.00 1.58 <5 0.49127 3.00 YES 2.441 1.694 1.48 1±1 2.00 1.58 <5 0.49524 3.00 YES 2.480 2.046 1.60 2±1 3.00 2.00 <5 0.62843 3.00 YES GFSK π /4DQPSK 8DQPSK Conclusion: For the max result : 0.62843≤ FCC Limit 3.0 for 1g SAR.

Shenzhen CTB Testing Technology Co., Ltd. Report No.:CTB230202001RFX Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 58 TEST REPORT Compiled by: Reviewed by: Approved by: Chen Zheng Arron Liu Bin Mei / Director Note: If there is any objection to the inspection results in this report, please submit a written report to the company within 15 days from the date of receiving the report. The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen CTB Testing Technology Co., Ltd. this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. “*” indicates the testing items were fulfilled by subcontracted lab. “#” indicates the items are not in CNAS accreditation scope. Product Name: Smart Audio Bluetooth Glasses FCC ID: 2AEF8-GT03 Trademark: DIVINUS Model Number: GT03 Prepared For: Dongguan XinYao Electronic Industrial Co. LTD Address: Liuhua Street, Xiakou, Dongcheng District, Dongguan, Guangdong, Dongguan, China Manufacturer: Dongguan XinYao Electronic Industrial Co. LTD Address: Liuhua Street, Xiakou, Dongcheng District, Dongguan, Guangdong, Dongguan, China Prepared By: Shenzhen CTB Testing Technology Co., Ltd. Address: 1&2/F., Building A, No.26, Xinhe Road, Xinqiao, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: Jan.11, 2023 Sample tested Date: Jan.11, 2023 to Feb. 02, 2023 Issue Date: Feb. 02, 2023 Report No.: CTB230202001RFX Test Standards FCC Part15.247 ANSI C63.10:2013 Test Results PASS Remark: This is Bluetooth radio test report. Shenzhen CTB Testing Technology Co., Ltd. Report No.:CTB230202001RFX Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 58 TABLE OF CONTENT Test Report Declaration Page 1. VERSION .......................................................................... 4 2. TEST SUMMARY ................................................................... 5 3. MEASUREMENT UNCERTAINTY ..................................................... 6 4. PRODUCT INFORMATION AND TEST SETUP .......................................... 7 4.1 Product Information .................................................................... 7 4.2 Test Setup Configuration ............................................................... 7 4.3 Support Equipment .................................................................... 7 4.4 Channel List .......................................................................... 8 4.5 Test Mode ............................................................................ 8 4.6 Test Environment ...................................................................... 8 5. TEST FACILITY AND TEST INSTRUMENT USED ....................................... 9 5.1 Test Facility ........................................................................... 9 5.2 Test Instrument Used .................................................................. 9 6. AC POWER LINE CONDUCTED EMISSION ............................................ 11 6.1 Block Diagram Of Test Setup .......................................................... 11 6.2 Limit ................................................................................ 11 6.3 Test procedure ....................................................................... 11 6.4 Test Result .......................................................................... 13 7. RADIATED SPURIOUS EMISSION ................................................... 15 7.1 Block Diagram Of Test Setup .......................................................... 15 7.2 Limit ................................................................................ 15 7.3 Test procedure ....................................................................... 16 7.4 Test Result .......................................................................... 17 8. BAND EDGE AND RF COUNDUCTED SPURIOUS EMISSIONS .......................... 26 8.1 Block Diagram Of Test Setup .......................................................... 26 8.2 Limit ................................................................................ 26 8.3 Test procedure ....................................................................... 26 8.4 Test Result .......................................................................... 27 9. COUDUCTED PEAK OUTPUT POWER ............................................... 34 9.1 Block Diagram Of Test Setup .......................................................... 34 9.2 Limit ................................................................................ 34 9.3 Test procedure ....................................................................... 34 9.4 Test Result .......................................................................... 35 10. 20DB OCCUPIED BANDWIDTH...................................................... 39 10.1 Block Diagram Of Test Setup ......................................................... 39 10.2 Limit ............................................................................... 39 10.3 Test procedure ...................................................................... 39 10.4 Test Result ......................................................................... 39 11. CARRIERFREQUENCIES SEPARATION .............................................. 43 11.1 Block Diagram Of Test Setup ......................................................... 43 11.2 Limit ............................................................................... 43 11.3 Test procedure ...................................................................... 43 11.4 Test Result ......................................................................... 43 12. HOPPING CHANNEL NUMBER ...................................................... 47 12.1 Block Diagram Of Test Setup ......................................................... 47 12.2 Limit ..…

Text truncated - open the document above for the full version.

Radiated Emission Below 1G Above 1G Conducted emissions
