2AEFAODINW1602.4 GHz Module with H5D-50C Camera

1 USER MANUAL v11 2 INTRODUCTION 3 Medium format photography is about professionalism. Camera systems have to be professional, handling has to be professional and captures have to be professional in quality. Hasselblad knows it and delivers it; professionals know that too. The Hasselblad H series of cameras consists of building new developments on the shoulders of the previous generation. In this way all the previous work-experience based and branch-demanding features are automatically included. So, just when you think things can't get much better, they do. And the H5D is that model - all the good things from before and then some! The H5D series heralds a step up that is noticeably greater than before. There are changes and many are 'from the ground up'. The H spirit thrives but has now matured to reinforce further its position in the rapidly changing world of digital imaging. Future proofing is key to a secure placing for working photographers. The H5D provides a reliable connection to the fleeting environment of digital imaging technology so when the wind changes direction, the H5D remains as the safeguarding companion to provide support. There are six models to choose from to suit the varied demands from the professional world. They start with the entry level 40 MPixel model that right from the outset confidently takes on most rivals from all brands and beats them with star quality results. The models then just get better and better. At the other end of the scale is the 200 MPixel MultiShot CMOS sensor model with high ISO settings and up to an amazing 1.5 frames per second that raises the bar so much that it is in a league of its own. True to Hasselblad philosophy, interchangeability and versatility span all models regarding lenses and accessories with minimal restrictions. This applies not only to H5 but all H1, H2, H3 and H4 models as well. The H system additionally breaks rank regarding series limitations with the ability to use other lenses from the V system or when using the sensor unit on view cameras. In short, you have access to a more comprehensive world to apply medium format quality to. Hasselblad's best kept secret is knowing that every link in the chain that leads to the page in the magazine has to reach a certain standard; it is that simple. That's why Hasselblad spends so much time and energy into checking those almost endless behind-the-scenes details and standards because they understand this simple concept. There is no magical formula to Hasselblad success other than an understanding of what is required to produce the best results available in the world today and an acceptance that there are no short cuts in this process. Hasselblad does its best to produce the best; there is no other way to achieve the Hasselblad star quality. a league of its own. hilosophy, interchangeability and dels regarding lenses and accessories ns. This applies not only to H5 butaallll dels as well. The H system additionally eries limitations with the abbility toouuse system or whenuusisingngtthehessenesor ununiti short,yyououhhave access to aamomre o apply mediuummformat quality to. secret is knowing that every link in the e page in the magaazine has to reach a that simple. That't's s whwhy yHasselblbladad nd energy into checcking those almmosost t enes details and sttandards bebecause simple concept. Theereeiiss no magical uccess otoher than an understanding of oduce thhe best resultts available in the eptance that there arre no short cuts inn d does its best to pproduce the bestst;; achieve the Hasselbblad star qualilityty. Wi-Fi 4 The H5 models have a good deal in common. Stainless steel and aluminium were the materials chosen to endure the treatment handed out in professional use – and that can be pretty tough. The sturdy but ergonomic integral grip incorporates not only the battery but one of the user interfaces too. It is here, by way of the surrounding buttons, that you enter the ‘control room’. Customization is a very prominent concept that you experience in the Hasselblad world that ensures it is the photographer that controls the camera, not vice versa. Accessed through the grip alone, there are 34 separate custom options. The standard prism viewfinder provides not only the most popular way of viewing but the sophisticated light metering system too. Don’t forget the waist-level accessory model if you prefer it. And when all the hustle and bustle and rushing around is over for the latest glossy cover and you settle back into a more reflective mode for some seriously detailed product shot you consider your Hasselblad. You remove the sensor unit and slip it onto your large format your studio set up where movements, controlled depth of field and close-up clarity rule. Now that is versatility. On the softer side of things all models share features that professionals rely on for fast tracking their progress. Camera Configuration in conjunction with Phocus offers a powerful tool to provide intuitive, easy and rapid control of all the parameters you don't want to forget in the heat of the moment. Custom build camera profiles with total control in advance to ensure the optimum in shooting security. HNCS – Hasselblad Natural Color Solution – saves time and secures the job because skin tones or specific product tones are going to be rendered automatically, accurately and immediately without any fuss. That can be worth a lot. True Focus is the pet feature for many fashion photographers who work fast and by instinct. They don’t have the time to double check focus for every single split second shot and neither do they have the time to get it wrong. True Focus delivers the sharpness in an intuitive manner, at speed. IFC – Immediate Focus Confirm – for True Focus users who have a second to spare and a desire to know the focus is exactly on target regarding specific areas. Intuitively and directly displays inspection of captures at 100% pinpointing the original focus selection. JPEG & RAW files (no…

Text truncated - open the document above for the full version.

DIGITAL CAMERAS www.hasselblad.com Wi-Fi The Hasselblad H5D-50c – the worlds first CMOS medium format camera – represents a huge leap forward in camera development and will break new grounds for photographers that now will be able to shoot with the ultimate in image quality regardless of lighting condition. The extremely good high-ISO performance will lift available light photography to new heights and significantly widen the usability of the Hasselblad H System cameras. The camera is backed by a lens range of 12 extremely high perfor- mance lenses – outperforming even the iconic Carl Zeiss lenses for the classic V System. The added Wi-Fi capability provides an even more flexible camera where you can use an iPhone/iPad to control the camera and view images conveniently even on loca- tion. The H5D-50c has been developed with one goal: to produce the best image quality possible. The result is stunning and paired with the user-friendliness and wealth of functionality, it is maybe one of the best cameras ever designed. Pick it up, feel the grip, look through the viewfinder and you will have a hard time putting it down. IMPORTANT FEATURES • 50 Mpixel CMOS sensor with amazing image quality • Excellent high ISO performance (ISO 100 - 6400) • Longer shutter speeds up to 34 minutes. No extra black exposure is required. • Faster capture rate: 1.5 frames per second • Live Video with high frame rate • Live View on rear display • Built-in Wi-Fi • Much improved camera handling • Improved weather sealings • True Focus auto-focus system with Absolute Position Lock and camera controls. • A range of 12 high performing lenses with built-in central shutter. The H5D-50c camera system has been especially designed to meet demands for both flexibility and ultimate image quality. This includes: • the freedom to choose between eye-level and waist-level view- finders both providing the best viewfinder image on any camera. • the choice of combining point-and–shoot and tilt/shift to solve creative commercial challenges. • the ability to combine working tethered and untethered to get the most of your camera system both on location and in the studio. • the option of processing your raw images in Hasselblad’s Phocus imaging toolbox, or working with your raw images directly in Adobe Photoshop Lightroom. • Phocus Mobile application (iPhone/iPad) for camera control and image browsing tethered or on location. DIGITAL CAMERAS www.hasselblad.com Wi-Fi New CMOS sensor The H5D-50c features a brand new CMOS sensor measuring 43.8 × 32.9mm - almost twice the physical size of the largest 35mm DSLR sensors. Basic ISO rating is from ISO 100 to ISO 6400. The high sensitivity of the new sensor enables completely new application areas for all professional medium format photographers. It is now totally possible to capture super high quality images even at high ISO settings making low light photography easy. This high sensitivity and fast capture speed together with the high dynamic range of 14 stops makes this camera a true all-round camera that can be used for almost any type of photography. The H5D-50c is built around a high speed architecture that can cap- ture full resolution images at the rate of 1.5 captures per second, working either mobile or tethered to a computer. The combination of these features makes the H5D-50c the natural choice for the professional photographer wanting to work with the ultimate in image quality whether working in the studio with con- trolled lighting or on location. Medium Format digital capture advantage In digital photography, the advantages of large format cameras have become even more obvious. The basic 6×4.5 cm design allows the H5D-50c to use one of the largest image sensors currently avail- able in digital photography. Consequently the sensor holds more and larger pixels, which deliver the highest possible image quality in terms of moiré-free color rendering without gradation break-ups in even the finest lit surfaces. An impressive lens line outperforming even the Carl Zeiss icons The highly renowned H system lens line includes 12 Auto-Focus lenses, all with central lens shutters. Range is from 24mm to 300mm, 50-110mm zoom, 35-90mm zoom, a 1.7X Converter and a dedicated wide angle Macro Converter. The built-in central shutter allows flash to be used at all shutter speeds up to 1/800s. making flash photography in daylight easy. It also improves image quality by gernerating extremely low camera vibration. The HTS 1.5 tilt/shift adapter delivers an easy to use, portable tilt/ shift solution for 6 H System lenses ranging from 24mm to 100mm. The CF lens adapter allows use of the classic CF-lenses from the Hasselblad V-camera, with full use of their central shutters, allowing flash to be employed at shutter speeds up to 1/500s. And thanks to the large format of the H System cameras, there is a consider- ably shallower depth of field range, making it much easier to utilise selective focus to creative effect. A choice of bright viewfinders One of the important traditional advantages of the medium format is the extra-large and bright viewfinder image, enabling extremely pre- cise compositions and easy operation in dim lighting. The H5D-50c comes with the HVD 90x viewfinder designed for full performance over the large sensor. Hasselblad has added an interchangeable waist-level viewfinder, the HVM, for the entire range of H system cameras. The bright and large viewfinder image is ideal for creative composing and the photographer is able to shoot in the fashion that suits them most; maintaining eye contact with the model, or gaining impact by shooting from a point lower than eye-level, for example. Built-in Wi-Fi This allows for complete camera control from iPhone or iPad even when the camera is not connected to a computer. Using the iOS app Phocus Mobile, you can see previews, browse images and remote control the camera from your iPhone or iPad. Digital Lens Correction and Ultra-Focus for image perfection Th…

Text truncated - open the document above for the full version.

u-blox Copyright © 2014 u-blox AGPage 1 of 24 ODIN-W160 USER MANUAL u-blox Copyright © 2014 u-blox AGPage 2 of 24 1 Table of Content 1 Table of Content 2 Introduction 2.1 Document Overview 2.2 Key Features 2.3 Product Variants 3 Electrical Interface and Connectors 3.1 Primary Side Connector 3.2 Secondary Side Connector 3.3 J6 External Antenna Connector 3.4 Electrical Characteristics 3.4.1 Power Supply 3.4.2 I/O DC Characteristics 3.4.3 LPO Requirements 3.5 Host Interface 3.5.1 Wireless LAN and SDIO 3.5.2 Bluetooth UART 3.6 Environmental Characteristics 3.7 Mechanical Characteristics 4 Antenna Information 4.1 External Antennas 4.2 Antenna Accessories 4.3 Antennas 4.3.1 Recommended antennas 4.3.2 Alternative antennas 5 Mounting Information 5.1 Module Dimensions 5.2 PCB Solder Lands 5.2.1 Host Board 5.2.2 Mounting Process 6 Regulatory Information 6.1 CE compliance 6.1.1 Equipment classes 6.1.2 Declaration of Conformity 6.2 IC and FCC compliance 6.2.1 IC compliance 6.2.2 Conformité aux normes d’IC 6.2.3 FCC statement 6.3 Compliance with RoHS Directive 7 Guidelines for Efficient and Safe Use 7.1 General 7.2 Product Care 7.3 Radio Frequency Exposure 7.4 Electronic Equipment 7.5 Potentially Explosive Atmospheres 7.6 Safety Compliance u-blox Copyright © 2014 u-blox AGPage 3 of 24 2 Introduction The ODIN-W160 is a Multi Radio Module providing both IEEE 802.11a,b,g,n Wireless LAN and Bluetooth 4.0, including Classic Bluetooth . It has been developed for integration in industrial devices. The module provides features such as low power,and Bluetooth low energy robustness, reliability and compatibility. By using the module the work needed to implement IEEE 802.11 and/or Bluetooth in a device is minimized as it provides, together with the driver package, all software, hardware, type approval, EMC certification etc. It is developed for reliable, high demanding industrial devices and applications and delivers high performance. The Wireless LAN section of the module can be operated on 5 frequency bands and conforms to IEEE 802.11a,b,g and 802.11n single stream. ISM Band (2412 – 2472 MHz), 13 channels with a separation of 5MHz UNII band-1 (5180 – 5240 MHz), 4 channels with a separation of 20MHz UNII band-2 (52605320 MHz), 4 channels with a separation of 20MHz – UNII band-2e (5500 – 5700 MHz), 11 channels with a separation of 20MHz UNII band-3 (5745 – 5825 MHz),5 channels with a separation of 20MHz The Bluetooth section of ODIN-W160 operates in the unlicensed ISM band between 2402 – 2480 MHz hasand two operating modes . with somewhat different behaviour Bluetooth Classic (BT+EDR) In this operating mode it uses 79 RF channels with 1 MHz spacing Bluetooth Low Energy (BLE) In this operating mode it uses 39 RF channels with 2 MHz spacing ODIN-W160 u-blox Copyright © 2014 u-blox AGPage 4 of 24 2.1 Document Overview This User Manual is applicable to the following Wireless LAN module: ODIN-W160 2.2 Key Features Multiradio module: Dual-band Wireless LAN operation (IEEE 802.11-2007a,b,g and single stream IEEE 802.11n) Bluetooth 4.0 Ready-to-use: No production tests required RF tuned from factory Contains own MAC address Host interfaces: Wireless LAN: SDIO Bluetooth: UART RF parameters and MAC address: IC 2 Small footprint 22.3 x 14.8 x 2.9 mm WEP, AES hardware accelerators WPA and WPA2 support - both personal and enterprise modes Quality of Service: 802.11e and WMM Ad-hoc and infrastructure mode Radio type approved for Europe Unlicensed Modular Transmitter Approval for US (FCC) and Canada (IC) Compliant with EMC standards Medical approval Industrial temperature range -40 to +85 °C Support for low power modes External antenna via U.FL connector 2.3 Product Variants Product nameRegulatory ID FCC ID IC ID Description ODIN-W160Model: ODIN-W160 PVH0953 5325A-0953 Wireless LAN IEEE 802.11a,b,g,n module with U.FL. coaxial connector for external antenna u-blox Copyright © 2014 u-blox AGPage 5 of 24 3 Electrical Interface and Connectors Host interface and control signals are accessible via PCB solder lands at the edge of the PCB. 3.1 Primary Side Connector Top view of module, J6 is a HIROSE type U.FL coaxial connector for external antenna. 3.2 Secondary Side Connector u-blox Copyright © 2014 u-blox AGPage 6 of 24 3.3 J6 External Antenna Connector J6 is the external antenna connector. It is used for both transmit and receive. The port impedance to match is 50 ohm. J6 pin nrPin nameSignal levelTypeDescription 1Ant-1RFI/OU.FL. external antenna port (50 ohm) 3.4 Electrical Characteristics 3.4.1 Power Supply 3.4.1.1 Supply Voltage Requirements SymbolParameterMinTyp.MaxUnit V DD Supply voltage3.03.33.6V V IO IO Supply voltage1.751.81.9V 3.4.2 I/O DC Characteristics SymbolParameterMinTypMaxUnit V IL LOW level input voltage0 0.35 x V IO V V IH HIGH level input voltage0.65 x VIO V IO V V OL LOW level output voltage0.0 0.45V V OH HIGH level output voltageV - 0.45 IO V IO V I IO Sink and source current 8.0mA C IO Input capacitance 8 pF 3.4.3 LPO Requirements SymbolParameterMinTypMaxUnit LPO-32kHzFrequency327633276832773Hz 3.5 Host Interface The module has two primary host interfaces, SDIO for the Wireless LAN section and UART for the Bluetooth section. 3.5.1 Wireless LAN and SDIO The interface between the host and the module is a standard SDIO interface (See SDIO spec Version 2.0) with Out Of Band interrupt, supporting maximum clock rate of 25MHz. The SDIO interface also supports the following features: Both 1 and 4 bit data bus Functions number 0 and 2 Multi-Block data transfer The WLAN block uses function 2. Function 0 is used for the common I/O area. Read the safety notes in section Guidelines for Efficient and Safe Use before using the modules. u-blox Copyright © 2014 u-blox AGPage 7 of 24 3.5.2 Bluetooth UART The module incorporates one UART dedicated to the Bluetooth Host Controller Interface (HCI) transport layer. The HCI interface is used to transport commands, events, ACL and synchronous data between the device and its host u…

Text truncated - open the document above for the full version.

VICTOR HASSELBLAD AB Utveckllngsgaten 2, BOX 220 SE-401 23, Göteborg, Sweden Telephone +46 (0) 311.0 2400 Telefax +46(0) 3113 5074 Vat No. SE556528312301 www hasselblad.corn Dear Sir/Mam, Hereby Victor Hasseiblad AB deciares that the following functions in the WiF1 module ODIN-W160 with FCC ID: 2AEFAODINWI6O, used in our camera “H5D-50c wifi”, are disabled: • Bluetooth • WiFi5GHz Gothenburg 2015-03-26 Åke Wåssén Project Manager 1-IASSEIBLA D

VICTOR HASSELBLAD AB Utvecklingsgatan 2, BOX 220 SE-401 23, Göteborg, Sweden Telephone +46 (0) 3110 2400 Telefax +46 (0) 3113 5074 Vat No. SE556528312301 www.hasselblad.com Equipment Autorisation Division Federal Communications Commission 7435 Oakland Milis Road Columbia, MD 21046 FCC ID: 2AEFAODINW16O Product Name: 2,4 GHz wifi module with H5D-50c camera Reguest for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality —for example ...) • Schematics • Block diagram • Operational Description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disciosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 23rd Day of March 20 15 By: .74Z2 4ij/4__ Ak Wassen ignature Printed Title: Project Manager On behaif of: Victor Hasseiblad AB 1-lASSE! BLAD Telephone: +46(0)31 102439

VICTOR HASSELBLAD AB titvecklingsgatan 2, BOX 220 SE-401 23, Göteborg, Sweden Telephone +46 (0) 3110 2400 Telefax +46 (0) 3113 5074 Vat No. SE556528312301 Limited Modular Approval (LMA) Limited module approval for use in the grantee’s own products. FCC ID: 2AEFAODINW16O 15.212(a)(1) Single modular transmitters must meet the following requirements to obtain a modular transmitter approval. (i) The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. The module has its RF-parts covered by a shield box that is soldered on to the module ground plane. (ii) The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with part 15 requirements under conditions of excessive data rates or over-modulation. The electrical connection consists of power supply, UART, SDIO, SPI and digital ‘lo. The interface signals (UART, SDIO, SPI and digital-IlO) are internally buffered by the module SoC (System on Chip) and cannot affect the modulation. (iii) The modular transmitter must have its own power supply regulation. The module has its own voltage regulators. In case the supply voltage chan ges, the interna! volta ges will be kept unchanged. (iv) The modular transmitter must comply with the antenna and transmission system requirements of 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. The module is equipped with a LLFL antenna connector that is considered to be unique. (v) The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing for compliance with part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see §15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially available (see §15.31(i)). hA SS EL BLAD The module was tested in a stand-alone con figuration. 1-lA SS El BLAD (vi) The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. (A) If using a permanently affixed label, the modular transmitter must be labeled with its own FCC identification number, and, if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. (B) If the modular transmitter uses an electronic display of the FCC identification number, the information must be readily accessible and visible on the modular transmitter or on the device in which it is installed. If the module is installed inside another device, then the outside of the device into which the module is installed must display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains FCC certified transmitter module(s).” Any similar wording that expresses the same meaning may be used. The user manual must include instructions on how to access the electronic display. A copy of these instructions must be inciuded in the application for equipment authorization. The module is marked with its own FCC ID number. The fina! product will be labelled with the Contains FCC ID: statement as documented in this tung. (vii) The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be inciuded in the application for equipment authorization. The modu!e is comp!iant with all applicab!e FCC rules. (viii) The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. The module was tested for SAR in a specific host as documented in this fiilng. Hereby Victor Hasseiblad AB deciares that conditions described in this document is valid. Gotheurg 2015-03-23 Ake Wåssén Project Manager Phone: +46 (0)31102439 2/3

VICTOR HASSELBLAD AB Utveckllngsgatan 2, BOX 220 SE-401 23, Göteborg, Sweden Telephone +46 (0) 3110 2400 Telefax +46 (0) 3113 5074 Vat No. SE556528312301 www.hiss&bIadcom STATEMENT Radio test under FCC ID: PVH0953, IC 5325A-0953, test report no. F136117E1, model ODIN-W160, issue date 10 July 2014, has been used in the verification under FCCID 2AEFAODINW16O. SAR-test has been performed to verify RE exposure. Only the 2,4GHz function of ODIN-W160 is used. Because that no changes have been made of the module ODIN-W160 under FCC-ID PVH0953, test result accurately represents the new conditions of the radio module used in Camera under FCC-ID 2AEFAODINW16O. Victor Hasselbiad AB Gothenburg 2015-03-23 Åke Wåssén Project Manager Phone: +46 (0)3 1 10 24 39 I-IASSELBIA D If

ANNEX C: INTERNAL PHOTOGRAPHS Examiner: Paul NEUFELD Test Report No.: F136117E1 Date of issue: 10 July 2014 Order No.: 13-116117 page 1 of 3 136117_11.JPG: EUT - top view, with shielding ANNEX C: INTERNAL PHOTOGRAPHS Examiner: Paul NEUFELD Test Report No.: F136117E1 Date of issue: 10 July 2014 Order No.: 13-116117 page 2 of 3 136117_13.JPG: EUT - top view, shielding removed ANNEX C: INTERNAL PHOTOGRAPHS Examiner: Paul NEUFELD Test Report No.: F136117E1 Date of issue: 10 July 2014 Order No.: 13-116117 page 3 of 3 136117_12.JPG: EUT – bottom view

ANNEX C: INTERNAL PHOTOGRAPHS Examiner: Paul NEUFELD Test Report No.: F136117E1 Date of issue: 10 July 2014 Order No.: 13-116117 page 1 of 3 136117_11.JPG: EUT - top view, with shielding ANNEX C: INTERNAL PHOTOGRAPHS Examiner: Paul NEUFELD Test Report No.: F136117E1 Date of issue: 10 July 2014 Order No.: 13-116117 page 2 of 3 136117_13.JPG: EUT - top view, shielding removed ANNEX C: INTERNAL PHOTOGRAPHS Examiner: Paul NEUFELD Test Report No.: F136117E1 Date of issue: 10 July 2014 Order No.: 13-116117 page 3 of 3 136117_12.JPG: EUT – bottom view

Antenna Wifi-module Antenna Wifi-module

fl hASSEL BLAD VICTOR HASSELBLAD AB Utvecklingsgatan 2, BOX 220 SE4O1 23, Göteborg, Sweden Telephone +46(0) 3110 2400 Telefax +46 (0) 3113 5074 Vat No. SE566528312301 wwwhasselblad.corn Dear Sir/Mam, Hereby Victor Hasselbiad AB deciares that the distance from the Wi-Fi antenna in our camera “H5D-50c wifi” to the closest part of the face (the eye) is more than 40 mm. >40 mm Gothen rg 2015-03-19 Ake Wassen Project Manager

SAR_Report_Nemko_60320_6140533_FCC_WiFi_Body_H5D-50C Page 1 of 30 The Testcenter facility ‘Dosimetric Test Lab’ within IMST GmbH is accredited by the German National ‘Deutsche Akkreditierungsstelle GmbH (DAkkS)’ for testing according to the scope as listed in the accreditation certificate: D-PL-12139-01-00. SAR Test Report Dosimetric Assessment of the Portable Device Hasselblad H5D-50C (Contains FCC ID: 2AEFAODINW160) According to the FCC Requirements March 23, 2015 IMST GmbH Carl-Friedrich-Gauß-Str. 2 - 4 47475 Kamp-Lintfort Germany Customer Victor Hasselblad AB Box 220 SE-401 23 Göteborg Sweden The test results only relate to the items tested. This report shall not bereproduced except in full without the written approval of the testing laboratory. SAR_Report_Nemko_60320_6140533_FCC_WiFi_Body_H5D-50C Page 2 of 30 SAR_Report_FCC_DECT_WiFI_Head_Body_1.0/10.12.2013/AR Executive Summary The H5D-50C is a new digital camera (portable device) from Hasselblad operating in the 2.4 GHz frequency range. The camera has an integrated antenna and works in the IEEE 802.11 b/g/n standards. The objective of the measurements done by IMST was the dosimetric assessment of one device in a worst case setup in body supported and head exposure configuration. Since there was a special test software available, SAR tests in IEEE 802.11 b/g/n are conducted with a specific channel, data rate and maximum output power. The examinations have been carried out with the dosimetric assessment system „DASY4“. The measurements were made according to the 47 CFR § 2.1093 [47CFR] for evaluating compliance of mobile and portable devices with FCC limits for human exposure (general population) to radiofrequency emissions and IEEE 1528-2013 [IEEE1528-2013]. Additional information and guidelines given by the following FCC documents were used:  SAR Measurement Requirements for 100 MHz to 6 GHz [KDB 865664 D01 v01r03]  Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies [KDB 447498 D01 v05r02]  SAR Measurement Procedures for 802.11 a/b/g Transmitters [KDB 248227 v01r02] All measurements have been performed in accordance to the recommendations given by the system manufacturer SPEAG AG, Switzerland. SAR_Report_Nemko_60320_6140533_FCC_WiFi_Body_H5D-50C Page 3 of 30 SAR_Report_FCC_DECT_WiFI_Head_Body_1.0/10.12.2013/AR Compliance Statement The Hasselblad H5D-50C digital camera (FCC ID: 2AEFAODINW160) is in compliance with the following standards for uncontrolled exposure:  47 CFR § 2.1093 [47CFR],  IEEE Std. C95.1 - 1999 [C95.1-1999],  IEEE 1528-2013 [IEEE1528-2013]  The latest version of all relevant F…
