2AEGPMK6RSURoad-Side (Transceiver) Unit for infrastructure.

Cohda Wireless Pty Ltd. 2 7 Greenhill Road, Wayville 5034, Australia Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Col umbia, MD 21046 USA Date: August 28, 2023 Ref: Attestation Statements Part 2.911{d){7) Filing FCC ID : 2AEGPMl<6RSU A pplicant FRN: 0013759030 Cohda Wireless Pty Ltd. ("the applicant") certifies that, as of the date of the filing of the application, Cohda Wireless America LLC is our designated U.S. agent for service of process for the above referenced FCC ID. Cohda Wireless Pty Ltd. accepts to maintain an agent for no less than one year after t he grantee has terminated all marketing and importation or the conclusion of any Commission­ related proceeding i nvolving the equipment. Cohda Wireless America LLC accepts, as of the date of the filing of the application, the obligation of t he designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Name: Cohda Wireless America LLC U .S. Agent FRN: 0028233229 A ddress: 450, East 96 th S t, Suite 500, Indianapolis, IN 46240 3760, State: IN DIANA Contact Pe rson: Daniel Kiel Tel.: +1-248-385-4673 E mail: [email protected] Sincerely, Cohda Wireless Pty Ltd. Kash Munir Rev 1/26/2023 Cohda Wireless America LLC Daniel Kiel

Cohda Wireless Pty Ltd. 27 Greenhill Road,Wayville 5034,Australia Date: August 24, 2023 Statement and ex且lanations Th e host MK6 RSU (FCC ID: 2AEGPMK6RSU) is a new product with one ce1iifie d module AG550Q-NA (Module ID: XMR2022AG550QNA;Grant Date: 09/08/2022) and one module ST60-SIPT(Module ID: SQG-60SIPT). The referenced ce1iified module AG550Q-NA report number is: SEW A22050000 l 5RGO 1/ SEWA2205000015RG02, and the referenced mod ule ST60-SIPT report number is: FR740701AD R02/ FR740701AE R02 /FR740701AC R02. This AG 550Q-NA module is a single modular and it was integrated into the host that not any effect on RF performance. Huarui ?Layers High Tec hnology (Suzhou) Co., Ltd. have performed MPE for the host and the ERP/EIRP and RSE re-tested. Plea se refer to the lab test results accordingly. The module AG550Q-NA supports GSM 1900/WCDMA B2/ 4/ 5 and LTE B 2/4/5/7 /l 2 /13/l 4/l 7 /25/26/41/66/71 /48 and 50 NR 112/5/25/41/66/7 l/77 /78/48, but the host with the i ntegrated module AG550Q-NA suppor ts GSMl 900/WCDMA B2/ 4/ 5 and LTE B2/4/5/7/12/17/25/41/66/71 and 50 NR n2/5/25/66/71/77/7 8, it disable other bands by software. This ST60-SIPT module is a single modular and it was integrated into the host that not any effect on RF performance. Huarui 7Lay ers High Tech nology (Suzhou) Co., Lt d. have performed MPE for the host (BT/2.40 WIFI) and the EIRP and CE and RSE re-tested. Please refer to the lab test results accordingly. 50 WIFI (FCC part 15.407) is the fu ll tes t. Consequently, Radio test data retrieved from the initial application FCC ID: XMR2022AG550QNA and FCC ID:SQG-60SIPT can be re-used for the FCC ID: 2AEGPMK6RSU. Spot check te st data are described as below: FCC Rule Part Frequency Band Re-test items FCC Pati 22 WCDMA B5,LTE B5,5G Conducted output power NR n5 Effective Radiated Power Radiated spurious emissions FCC Pa1i 24 GSM 1900,WCDMA Conducted output power B2,LTE B2,LTE B25,5G Equivalent Isotropic Radiated power NR 112, 5G NR 1125 Radiated spurious emissions FCC part 27 WCDMA B4,LTE B4, LTE Conducted output power B7, LTE B 12, LTE B 17, Effective Radiated power LTE B4 l, LTE B66, LTE Equivalent Isotropic Radiated power B71, 5G NR 1166, 5G NR Radiated spurious emissions Cohda Wireless Pty Ltd. 27 Greenhill Road,Wayville 5034,Austral' n71,5G NR n77,5G NR n78 FCC pati 15.247 2412-2462MHz for Conducted emission 11 b/g/n(HT20/40) Radiated spurious emissions 2402-2480MHz for BT Conducted output power EDR/LE Equivalent Isotropic Radiated power Should you have any question or comment regarding this matter, please have my best attention. Sincerely yours, Name: Kash Muyrir, Cohda Wireless Pty Ltd. Tel: +61870995500 Fax:+61883644597 / E-mail: [email protected]

Huarui 7layers High Technology (Suzhou) Co., Ltd. Tower N, Innovation Center, 88 Zhuyi Road, High-tech District, Suzhou City, Anhui Province Tel: +86 (0557) 368 1008 Page 1 of 4 Report Version 1 Reference No.: PSU-QSU2306260109 FCC ID: 2AEGPMK6RSU PHOTOGRAPHS OF THE EUT Huarui 7layers High Technology (Suzhou) Co., Ltd. Tower N, Innovation Center, 88 Zhuyi Road, High-tech District, Suzhou City, Anhui Province Tel: +86 (0557) 368 1008 Page 2 of 4 Report Version 1 Reference No.: PSU-QSU2306260109 FCC ID: 2AEGPMK6RSU Huarui 7layers High Technology (Suzhou) Co., Ltd. Tower N, Innovation Center, 88 Zhuyi Road, High-tech District, Suzhou City, Anhui Province Tel: +86 (0557) 368 1008 Page 3 of 4 Report Version 1 Reference No.: PSU-QSU2306260109 FCC ID: 2AEGPMK6RSU Huarui 7layers High Technology (Suzhou) Co., Ltd. Tower N, Innovation Center, 88 Zhuyi Road, High-tech District, Suzhou City, Anhui Province Tel: +86 (0557) 368 1008 Page 4 of 4 Report Version 1 Reference No.: PSU-QSU2306260109 FCC ID: 2AEGPMK6RSU

1 A 2 3 4 5 678 12 3 4 5 678 B C D E F A B C D E F Dept.Technical referenceCreated byApproved by Document typeDocument status TitleDWG No. Rev.Date of issueSheet 8/09/2023 1/1 mk6_rsu_housing_Label4 Suhant Raval

Revision MK6 RSU Product Label (Enclosure) 0 MK6 RSU Product Label (Packaging Box) DateRemark Bar code Info Code 128 Barcode + serial number size - 4mm (H) x 30 mm (L) Serial number range – Obtain from Cohda QR Code size Square box outline: 12mm x 12mm QR code size: 10mm x 10mm Print box outline Overall label Size 30mm (H) x 60mm (L) UV resistant Waterproof Black on white printing Do Not print outline. CE marking size 5mm height All label wording size should be Min. 2 mm height Bar code Info) Barcode type – Code 128 Barcode + serial number size - 4mm (H) x 30 mm (L) Serial number range – Obtain from Cohda QR Code sizeSquare box outline: 12mm x 12mm QR code size: 10mm x 10mm Overall label Size 30mm (H) x 60mm (L) UV resistant Waterproof Black on white printing Do Not print outline. CE marking size 5mm height 7 Jun 22Official released Prepared by: Confidential: This drawing is confidential and proprietary to Cohda Wireless. Reproduction is prohibited without the written consent of Cohda Wireless. Approved by: Date Date Suhant Raval Do cument DescriptionDrawing P art Number MK6 RSU Product Label - US Nil 05-Sept-2023 Gavin Phang05-Sept-2023 1.016 Nov 22 Production released 2.0 08 Jun 23 EU certificate update QR Code info – NA ) CWP-RSUsA-MK06-US00102 MK6 RSU FCC xxxxx refer to derivative. QR Code info – NA CWP-RSUsA-MK06-US00202 MK6 RSU FCC xxxxx refer to derivative. 3.005 Sept 23FCC certifica te update MK6 RSU Made In Au stralia Ref er Q uick Start Guide Befo re Use ! Rev 0.00 DC YYWW EU PS: POE+ 802.3at - 48 Vdc 25,5 W (max.) www.co hdawireless.co m FCC ID : 2AEGPMK6RSU MK6 RSU Made In Au stralia Ref er Q uick Start Guide Befo re Use ! Rev 0.00 DC YYWW EU PS: POE+ 802.3at - 48 Vdc 25,5 W (max.) www.co hdawireless.co m FCC ID : 2AEGPMK6RSU This device com plies with part 15 of the FCC Ru les. Operation is sub jec t to the following two co nditio ns: (1) This device may n ot c au se harm ful interference, and (2) this devic e m ust accept any interference received, includ in g interf erence that m ay cause un desired operation.

FCC RF Exposure Test Report Report Format Version 5.0.0 Issued Date : Nov. 03, 2023 Report No. : PSU-QSU2306260109SA01 FCC RF Exposure Test Report Report No. : PSU-QSU2306260109SA01 Applicant : Cohda Wireless Pty Ltd. Address : 27 Greenhill Road Wayville SA 5034 Australia Product : Road-Side (Transceiver) Unit for infrastructure. FCC ID : 2AEGPMK6RSU Brand : Cohda Wireless Model No. : MK6 RSU Standards : FCC Part 2 (Section 2.1091) KDB 447498 D01 General RF Exposure Guidance v06 Sample Received Date : Jun. 26, 2023 Date of Testing : Jun. 26, 2023 ~ Nov. 03, 2023 CERTIFICATION: The above equipment have been tested by HUARUI 7LAYERS HIGH TECHNOLOGY (SUZHOU) CO., Ltd. and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s SAR characteristics under the conditions specified in this report. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by A2LA or any government agencies. Prepared By : Approved By : Chao Wu/ Engineer Peibo Sun / Manager This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our-business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. FCC RF Exposure Test Report Report Format Version 5.0.0 Issued Date : Nov. 03, 2023 Report No. : PSU-QSU2306260109SA01 TABLE OF CONTENTS RELEASE CONTROL RECORD .................................................................................................................................................... 3 1. DESCRIPTION OF EQUIPMENT UNDER TEST .................................................................................................................... 4 LIST OF ACCESSORY: ................................................................................................................................................................. 5 2. MPE(MAXIMUM PERMISSIBLE EXPOSURE) ASSESSMENT ............................................................................................. 6 2.1 INTRODUCTION .......................................................................................................................................................... 6 2.2 RF RADIATION EXPOSURE LIMITS ........................................................................................................................... 6 2.3 MPE ASSESSMENT METHOD .................................................................................................................................... 7 2.4 MPE CALCULATION FOR STANDALONE OPERATIONS .......................................................................................... 7 2.5 CONCLUSION OF SIMULTANEOUS TRANSMITTER ................................................................................................ 9 3. INFORMATION ON THE TESTING LABORATORIES ......................................................................................................... 10 FCC RF Exposure Test Report Report Format Version 5.0.0 Issued Date : Nov. 03, 2023 Report No. : PSU-QSU2306260109SA01 Release Control Record Report No. Reason for Change Date Issued PSU-QSU2306260109SA01 Initial release Nov. 03, 2023 FCC RF Exposure Test Report Report Format Version 5.0.0 Issued Date : Nov. 03, 2023 Report No. : PSU-QSU2306260109SA01 1. Description of Equipment Under Test EUT Type* Road-Side (Transceiver) Unit for infrastructure. Brand Name* Cohda Wireless Model Name* MK6 RSU Tx Frequency Bands (Unit: MHz) GSM1900 : 1850.2MHz ~ 1909.8MHz WCDMA Band II : 1852.4 MHz ~ 1907.6 MHz WCDMA Band IV: 1712.4 MHz ~ 1752.6 MHz WCDMA Band V : 826.4 MHz ~ 846.6 MHz LTE Band 2 : 1850.7 MHz ~ 1909.3 MHz LTE Band 4 : 1710.7 MHz ~ 1754.3 MHz LTE Band 5 : 824.7 MHz ~ 848.3 MHz LTE Band 7 : 2502.5 MHz ~ 2567.5 MHz LTE Band 12 : 699.7 MHz ~ 715.3 MHz LTE Band 17 : 2502.5MHz ~ 2567.5MHz LTE Band 25 : 1850.7MHz ~ 1914.3 MHz LTE Band 29 : 717MHz ~ 728MHz(DL Only) LTE Band 30 : 2307.5MHz ~ 2312.5MHz(DL Only) LTE Band 41 : 2498.5MHz~ 2687.5MHz LTE Band 66 : 1710.7 MHz ~ 1779.3 MHz LTE Band 71 : 665.5 MHz ~ 695.5 MHz NR Band n2: 1852.5MHz ~ 1907.5MHz NR Band n5: 826.5MHz ~ 846.5MHz NR Band n25: 1852.5MHz ~1912.5MHz NR Band n66: 1712.5MHz ~ 1777.5MHz NR Band n71: 665.5MHz ~ 695.5MHz NR Band n77(Part27Q):3460.02MHz ~ 3540MHz NR Band n77(Part27O):3710.01MHz ~ 3969.99MHz NR Band n78 (Part27Q):3460.02 MHz ~ 3540…
