2AEGTSGL001Levitating Bluetooth Speaker

Levitating Bluetooth Speaker User Manual Levitating Bluetooth Speaker User Manual Levitating Bluetooth Speaker User Manual 1. Overview  Bluetooth 4.1  Wireless range 10 meters  Speaker: 5W x 1  Built-in rechargeable battery  USB port in the base for charging speaker orb or smart phone  Frequency range: 40Hz ~ 20KHz  Distortion: THD <0.5%  SNR: S / N ≥ 85db  Speaker orb charging input: 5V, 1A  Magnetic base power input: 12V, 1.5A  Magnetic base USB port output: 5V, 1A  Speaker orb dimensions: 85mm diameter  Base dimensions: 150mm diameter, 25mm Height  Speaker orb weight: 280g  Base weight: 645g Levitating Bluetooth Speaker User Manual Declarations Welcome to choose our produce, please read this manual carefully. Functions and performance may change without prior notice. If any difference between produce and this manual, please visit our website Levitating Bluetooth Speaker User Manual 2. Know Your Speaker Levitating Bluetooth Speaker User Manual 3. Operation ● How to use the bluetooth speaker 1. Press and hold the speaker power key“C”for 3 second to turn on the speaker orb. 2. Search bluetooth device on smart phone / tablet, when find bluetooth device “CXF01” , pair smart phone/tablet with this device. If smart phone/ Tablet are with NFC function, put the smart phone/ tablet close to the NFC point “F” on the top of speaker for 3second. Bluetooth speaker will pair with smart phone/tablet automatically. 3. Play music on smart phone/tablet, music comes out from the bluetooth speaker orb. 4. Press and hold the bluetooth pair key “D” for 3 second, the speaker will stop pairing with current smart phone/ tablet, and be waiting for new device to pair. 5. Connect charging cable with USB port on the base and speaker orb for battery charging. And this also can work as for “reset” function for Levitating Bluetooth Speaker User Manual speaker orb. When battery charging, can turn on the power and play during battery charging. ● How to float the speaker orb 1. Please place the base on an absolutely horizontal surface. If the surface is not flat and horizontal, the speaker orb can not levitate normally 2. Connect the power adapter to the base power port “A” 3. Turn on the speaker orb and pair with smart phone/tablet. 4. Hold the orb with your two hands and put your fingers under the orb to hold tight the orb, move the orb vertically downwards the center of the base. 5. Make the orb approach the center of the base slowly, and please move it towards left and right, or front and back to try to get the levitating point. 6. When you feel a strong force which is holding the orb from the base, this position is the Levitating Bluetooth Speaker User Manual levitation place. At this moment, the four “Levitating position Indicator Light G” all turn on and without flashing. Release the orb gently. 7. If you cannot success to posit the orb 3 times, you can take away the speaker orb from base and take off the adapter from the base for few second, and then re-connect adapter with the base to try again positing. ● How to turn off the levitating bluetooth speaker. 1. Take away the speaker orb from the base, press and hold the speaker power key “C” for 5 second. The bluetooth speaker turns off. 2. Take away the adapter from the base to shut down the base. 3. Keep the speaker orb and base separated, do not stick together. 4. Cautions Levitating Bluetooth Speaker User Manual ● If you cannot success to posit the orb within 1minute, please take away the speaker orb from the base and take off the adapter from the base for 5 minutes, and then try again. Otherwise the base will become too hot and be damaged ● Do not keep the speaker orb always stick directly on the base for more than 1 hour. Keep the base and the speaker orb separated. ● Keep other electronic items at least 20cm away from the levitating base and speaker orb, like computer, laptop, smart phone etc. ● Base or Orb drop to floor from high may be damaged ● This is not a toy and it is not suitable for the children under 12years old. Levitating Bluetooth Speaker User Manual ● For indoor use only ● FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user Levitating Bluetooth Speaker User Manual is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for Levitating Bluetooth Speaker User Manual compliance could void the user's authority to operate the equipment.

Shenzhen S&G International LTD 4F,No.8 Bldg,Weidonglong Industry Zone,Qinghu,Longhua, Shenzhen, P.R.China Confidentiality Letter To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AEGTSGL001 Product: Levitating Bluetooth Speaker Model: SGL001, SGL002, SGL003, SGL004, SGL005 We hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, signature : name / title: Luo Ting / Engineer address: 4F,No.8 Bldg,Weidonglong Industry Zone,Qinghu,Longhua, Shenzhen, P.R.China

M/N: SGL001 FCC ID: 2AEGTSGL001 Label location

Antenna Location NFC Antenna

FCC ID: 2AEGTSGL001 Keyway Testing Technology Co., Ltd. Report No. 15KWE033147F Page 1 of 30 FCC TEST REPORT(Bluetooth) for SHENZHEN S&G INTERNATIONAL LTD Levitating Bluetooth Speaker Model Number: SGL001, SGL002, SGL003, SGL004, SGL005 FCC ID: 2AEGTSGL001 Prepared for : SHENZHEN S&G INTERNATIONAL LTD Address : 4F,No.8 Bldg,Weidonglong Industry Zone,Qinghu, Longhua, Shenzhen, P.R.China Prepared by : Keyway Testing Technology Co., Ltd. Address : Buliding 1, Baishun Industrial Zone, Zhangmutou Town, Dongguan, Guangdong, China Tel: 86-769-8718 2258 Fax: 86-769-8718 1058 Report No. : 15KWE033147F Date of Test : Mar. 22~25, 2015 Date of Report : Mar. 26, 2015 FCC ID: 2AEGTSGL001 Keyway Testing Technology Co., Ltd. Report No. 15KWE033147F Page 2 of 30 TABLE OF CONTENTS Test Report Declaration Page 1. TEST SUMMARY .......................................................................................................................... 4 2. GENERAL PRODUCT INFORMATION ......................................................................................... 4 2.1. Product Function .................................................................................................................... 4 2.2. Description of Device (EUT) .................................................................................................. 4 2.3. Difference between Model Numbers ...................................................................................... 4 2.4. Independent Operation Modes .............................................................................................. 4 2.5. Test Supporting System ......................................................................................................... 4 2.6. Test Facilities ......................................................................................................................... 5 2.7. List of Test and Measurement Instruments ............................................................................ 6 3. TEST SET-UP AND OPERATION MODES .................................................................................. 7 3.1. Principle of Configuration Selection ....................................................................................... 7 3.2. Block Diagram of Test Set-up ................................................................................................ 7 3.3. Test Operation Mode and Test Software ............................................................................... 7 3.4. Special Accessories and Auxiliary Equipment ....................................................................... 7 3.5. Countermeasures to Achieve EMC Compliance .................................................................... 7 3.6. Test Environment: .................................................................................................................. 7 4. EMISSION TEST RESULTS ......................................................................................................... 8 4.1. Conducted Emission at the Mains Terminals Test ................................................................. 8 4.2. Radiated Emission Test ....................................................................................................... 11 5. 20DB OCCUPY BANDWIDTH ..................................................................................................... 22 5.1. Limits .................................................................................................................................... 22 5.2. Test setup ............................................................................................................................ 22 6. BAND EDGE COMPLIANCE TEST ............................................................................................. 25 6.1. Limits .................................................................................................................................... 25 6.2. Test setup ............................................................................................................................ 25 7. ANTENNA REQUIREMENTS ...................................................................................................... 26 7.1. Limits .................................................................................................................................... 26 7.2. Result ................................................................................................................................... 26 8. PHOTOGRAPHS OF TEST SET-UP .......................................................................................... 27 9. PHOTOGRAPHS OF THE EUT .................................................................................................. 29 FCC ID: 2AEGTSGL001 Keyway Testing Technology Co., Ltd. Report No. 15KWE033147F Page 3 of 30 Keyway Testing Technology Co., Ltd. Applicant: Address: SHENZHEN S&G INTERNATIONAL LTD 4F,No.8 Bldg,Weidonglong Industry Zone,Qinghu,Longhua, Shenzhen, P.R.China Manufacturer: Address: V-PHOTRON TECHNOLOGY(SHENZHEN) CO., LTD 4F,No.8 Bldg,Weidonglong Industry Zone, Qinghu, Longhua, Shenzhen, P.R.China E.U.T: Levitating Bluetooth Speaker Model Number: SGL001, SGL002, SGL003, SGL004, SGL005 Trade Name: ------ Serial No.: 01 Date of Receipt: Mar. 22, 2015 Date of Test: Mar. 22~25, 2015 Test Specification: FCC Part 15, Subpart C Section 15.249: 2014 ANSI C63.4:2014 Test Result: The equipment under test was found to be compliance with the requirements of the standards applied. Issue Date: Mar. 26, 2015 Tested by: Reviewed by: Approved by: William Huang / Engineer Andy Gao / Supervisor Jade Yang/ Supervisor Other Aspects: None. Abbreviations: OK/P=passed fail/F=failed n.a/N=not applicable E.U.T=equipment under tested This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Keyway Testin…
