2AEI92ABGBFP1BOLT

1 Table of Contents Chapter1 General Information .................................................................................................. 3 1.1 Brief introduction ............................................................................................................ 3 1.2 Safety Precautions ............................................................................................................ 4 1.3 General notices .................................................................................................................. 4 1.4 Notice for phone operation ........................................................................................... 4 1.5 Notice for use of battery .............................................................................................. 5 1.6 Caution for using charger ............................................................................................. 6 1.7 Cleaning and Maintenance ............................................................................................... 6 1.8 General Precautions ......................................................................................................... 6 Chapter2 Before Use .................................................................................................................... 7 2.1 SIM card ............................................................................................................................... 7 2.1.1 Insert and pull out the SIM card ....................................................................... 7 2.2 Battery ................................................................................................................................. 8 2.2.1 Disassembly and installation for battery ....................................................... 8 2.2.2 Charge the Battery ................................................................................................... 8 2.3 Power on ............................................................................................................................... 9 2.4 The use of USB data route ............................................................................................. 9 2.5 Install and pull out T-flash card ............................................................................. 9 Chapter3 Basic Description .................................................................................................... 10 3.1 About the Keypads ............................................................................................................ 10 3.1.1 Basic Keys ................................................................................................................. 10 3.2 Call functions ................................................................................................................. 10 3.2.1 Make a call ............................................................................................................... 10 3.2.2 Answer a call ........................................................................................................... 11 3.2.3 Reject a call ........................................................................................................... 11 3.2.4 Menu available during a call ............................................................................. 12 3.3 Handfree function ............................................................................................................ 12 Chapter4 Menu Introduction .................................................................................................... 12 4.1 Contact ............................................................................................... 错误！未定义书签。 4.1.1 Contacts search ....................................................................................................... 13 4.1.2 Add new contact ....................................................................................................... 13 4.1.3 Caller groups ........................................................................................................... 13 4.1.4 Settings ..................................................................................................................... 13 4.2 Message ............................................................................................................................... 13 4.2.1 Write Messages ....................................................................................................... 13 4.2.1.1 New SMS ...................................................................................................................................... 13 4.2.1.2 New MMS ...................................................................................................................................... 14 4.2.2 Inbox ........................................................................................................................... 14 4.2.3 Outbox ....................................................................................................................... 14 2 4.2.4 Draftbox ..................................................................................................................... 14 4.2.5 Sentbox ....................................................................................................................... 14 4.2.6 Delete messages ....................................................................................................... 14 4.2.7 Voice mail ................................................................................................................. 14 4.2.8 Cell broadcast ......................................................................................................... 15 4.2.9 Chat ............................................................................................................................. 15 4.2.10 message memory ............…

Text truncated - open the document above for the full version.

RF_160, Issue 03 Declaration of Authorization We Name: Que Products, LLC Address: 59 East Main Street, Bayshore City: New York Country: United States Declare that: Name Representative of agent: Krystal.mo (1) Agent Company name: Shenzhen STS Test Services Co., Ltd. Address: 1/F., Building B, Zhuoke Science Park, No.190, Chongqing Road, Fuyong Street, Bao’an District, City: Shenzhen Guangdong Country China is authorized to apply for Certification of the following product(s): Product description: BOLT Type designation: P1, P2, P3, P4, P5, P6 Trademark: QUE on our behalf. Date: 20 Janr 2016 (1) City: New York Name: Albert Yedid (2) Function: Director Signature: Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FEDERAL COMMUNICATIONS COMMISSION DECLARATION OF CONFORMITY (DoC) Equipment: BOLT Trademark(s) and Model(s): QUE / P1, P2, P3, P4, P5, P6 Manufacturer: Shenzhen Feipu Communication Technology Co.,Ltd. FCC ID in case other parts of this equipment are subject to certification: 2AEI92ABGBFP1 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The following test reports are subject to this declaration: Test report number: Issue date: STS1601072F01 20 Jan. 2016 STS1601072F02 20 Jan. 2016 STS1601072H01 20 Jan. 2016 The following manufacturer/importer/entity (located in the USA) is responsible for this declaration: Company name: Que Products, LLC Name/Title (legal representative): Albert Yedid / Director Address: 59 East Main Street Suite 7 Bayshore, NY 11706 ,USA Phone: 001917-667-5700 Fax: 001631-206-9311 E-mail: [email protected] Date: 20 Jan. 2016 Signature: FCC

FCC, Request for non-disclosure Date: 16-Jul-10 RF_501, Issue 6 Page 1 of 1 Company Name: Que Products, LLC Address: 59 East Main Street, Bayshore City: New York Country: United States To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: 2AEI92ABGBFP1 Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, applicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Planned Release Date STC: (notes 2, 3, 4, 5) Date: 13 Jan. 2016 Name and signature of applicant: Albert Yedid / Director Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

Project No: STS1601072 P1 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Project No: STS1601072 Photo 3 Photo 4 Project No: STS1601072 Photo 5 Photo 6 Project No: STS1601072 Photo 7 Photo 8 Project No: STS1601072 Photo 9

Label BOLT Model name: P1 FCC ID: 2AEI92ABGBFP1 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

ProjectNo:STS1601072 APPENDIX-PHOTOGRAPHSOFEUTCONSTRUCTIONALDETAILS Photo1 Photo2 BTANTENNA GSMANTENNA ProjectNo:STS1601072 Photo3 Photo4 ProjectNo:STS1601072 Photo5 Photo6 ProjectNo:STS1601072 Photo7 Photo8

Ref : ACR.262.1.14.SATU.A SHENZHEN STS TEST SERVICES CO., LTD. 1/F., BUILDING B, ZHUOKE SCIENCE PARK, No.190, CHONGQING ROAD,FUYONG STREET, BAO’ AN DISTRICT, SHENZHEN,GUANGDONG,CHINA SATIMO COMOSAR DOSIMETRIC E-FIELD PROBE SERIAL NO.: SN 17/14 EP221 Calibrated at SATIMO US 2105 Barrett Park Dr. - Kennesaw, GA 30144 09/01/2015 Summary: This document presents the method and results from an accredited COMOSAR Dosimetric E-Field Probe calibration performed in SATIMO USA using the CALISAR / CALIBAIR test bench, for use with a SATIMO COMOSAR system only. All calibration results are traceable to national metrology institutions. COMOSAR E-Field Probe Calibration Report COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 2/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. Name Function Date Signature Prepared by : Jérôme LUC Product Manager 9/19/2015 Checked by : Jérôme LUC Product Manager 9/19/2015 Approved by : Kim RUTKOWSKI Quality Manager 9/19/2015 Customer Name Distribution : Shenzhen STS Test Services Co., Ltd. Issue Date Modifications A 9/19/2015Initial release COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 3/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. TABLE OF CONTENTS 1 Device Under Test ..................................................................................................... 4 2 Product Description ................................................................................................... 4 2.1 General Information _______________________________________________________ 4 3 Measurement Method ................................................................................................ 4 3.1 Linearity ________________________________________________________________ 4 3.2 Sensitivity _______________________________________________________________ 5 3.3 Lower Detection Limit _____________________________________________________ 5 3.4 Isotropy _________________________________________________________________ 5 3.5 Boundary Effect __________________________________________________________ 5 4 Measurement Uncertainty .......................................................................................... 5 5 Calibration Measurement Results .............................................................................. 6 5.1 Sensitivity in air __________________________________________________________ 6 5.2 Linearity ________________________________________________________________ 7 5.3 Sensitivity in liquid ________________________________________________________ 7 5.4 Isotropy _________________________________________________________________ 8 6 List of Equipment ...................................................................................................... 9 COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 4/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. 1 DEVICE UNDER TEST Device Under Test Device Type COMOSAR DOSIMETRIC E FIELD PROBE Manufacturer Satimo Model SSE5 Serial Number SN 17/14 EP221 Product Condition (new / used) New Frequency Range of Probe 0.4 GHz- 6 GHz Resistance of Three Dipoles at Connector Dipole 1: R1=0.179 M Dipole 2: R2=0.167 M Dipole 3: R3=0.178 M A yearly calibration interval is recommended. 2 PRODUCT DESCRIPTION 2.1 GENERAL INFORMATION Satimo’s COMOSAR E field Probes are built in accordance to the IEEE 1528, OET 65 Bulletin C and CEI/IEC 62209 standards. Figure 1 – Satimo COMOSAR Dosimetric E field Dipole Probe Length 330 mm Length of Individual Dipoles 4.5 mm Maximum external diameter 8 mm Probe Tip External Diameter 5 mm Distance between dipoles / probe extremity 2.7 mm 3 MEASUREMENT METHOD The IEEE 1528, OET 65 Bulletin C, CENELEC EN50361 and CEI/IEC 62209 standards provide recommended practices for the probe calibrations, including the performance characteristics of interest and methods by which to assess their affect. All calibrations / measurements performed meet the fore mentioned standards. 3.1 LINEARITY The evaluation of the linearity was done in free space using the waveguide, performing a power sweep to cover the SAR range 0.01W/kg to 100W/kg. COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 5/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. 3.2 SENSITIVITY The sensitivity factors of the three dipoles were determined using a two step calibration method (air and tissue simulating liquid) using waveguides as outlined in the standards. 3.3 LOWER DETECTION LIMIT The lower detection limit was assessed using the same measurement set up as used for the linearity measurement. The required lower detection limit is 10 mW/kg. 3.4 ISOTROPY The axial isotropy was evaluated by exposing the probe to a reference wave from a standard dipole with the dipole mounted under the flat phantom in the test configuration suggested for system validations and checks. The probe was rotated along its main axis from 0 - 360 degrees in 15 degree steps. The hemispherical isotropy is determined by inserting the probe in a thin plastic box filled with …

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC SAR TEST REPORT Report No: STS1601072H01 Issued for Que Products, LLC 59 East Main Street Suite 7 Bayshore, NY 11706 ,USA Product Name: BOLT Brand Name: QUE Model No.: P1 Series Model: P2, P3, P4, P5, P6 FCC ID: 2AEI92ABGBFP1 Test Standard: ANSI/IEEE Std. C95.1 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 Max. SAR (1g): Head:0.752 W/kg Body:0.496 W/kg S T L A B S Page 2 of 52 Report No.: STS1601072H01 Test Report Certification Applicant’s name ................. : Que Products, LLC Address ................................. : 59 East Main Street Suite 7 Bayshore, NY 11706 ,USA Manufacture's Name ............ : Shenzhen Feipu Communication Technology Co.,Ltd. Address ................................. : 21/F,Electronic Science and Technology Building A ,ShenNan Road, Futian District, Shenzhen City,Guangdong Provice,China. Product description Product name ........................ : BOLT Trademark ........................... : QUE Model and/or type reference : P1 Serial Model： P2, P3, P4, P5, P6 Standards ............................. : ANSI/IEEE Std. C95.1-1992 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 The device was tested by Shenzhen STS Test Services Co., Ltd. in accordance with the measurement methods and procedures specified in KDB 865664 The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Date of Test ........................................... : Date (s) of performance of tests ............. : 17 Jan. 2016 Date of Issue .......................................... : 21 Jan. 2016 Test Result.............................................. : Pass Testing Engineer : (Allen Chen) Technical Manager : (John Zou) Authorized Signatory : (Bovey Yang) Page 3 of 52 Report No.: STS1601072H01 TABLE OF CONTENS 1. General Information 4 1.1 EUT Description 4 1.2 Test Environment 5 1.3 Test Facility 5 2. Test Standards And Limits 6 3. SAR Measurement System 7 3.1 Definition Of Specific Absorption Rate (SAR) 7 3.2 SAR System 7 3.2.1 Probe 8 3.2.2 Phantom 9 3.2.3 Device Holder 9 4. Tissue Simulating Liquids 10 4.1 Simulating Liquids Parameter Check 10 5. SAR System Validation 11 5.1 Validation System 11 5.2 Validation Result 11 6. SAR Evaluation Procedures 12 7. EUT Test Position 13 7.1 Define Two Imaginary Lines On The Handset 13 8. Uncertainty 15 8.1 Measurement Uncertainty 15 8.2 System validation Uncertainty 17 9. Conducted Power Measurement 19 11. EUT And Test Setup Photo 21 11.1 EUT Photo 21 11.2 Setup Photo 24 12. SAR Result Summary 28 12.1 Head SAR 28 12.2 Body SAR And Hotspot 28 13. Equipment List 30 Appendix A. System Validation Plots 31 Appendix B. SAR Test Plots 39 Appendix C. Probe Calibration And Dipole Calibration Report 52 Page 4 of 52 Report No.: STS1601072H01 1. General Information Environmental evaluation measurements of specific absorption rate (SAR) distributions in emulated human head and body tissues exposed to radio frequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 1.1 EUT Description Equipment BOLT Brand Name QUE Model No. P1 Serial Model P2, P3, P4, P5, P6 FCC ID 2AEI92ABGBFP1 Model Difference Only different in model name Adapter Input: AC110-220V, 200mA,50/60Hz output: DC5V, 350~500mA Battery Rated Voltage: 3.7V Charge Limit: 4.2V Capacity: 600mAh Hardware Version V4.0 Software Version N/A Frequency Range GSM 850: 824.2 ~ 848.8 MHz PCS1900: 1850.2 ~ 1909.8 MHz Bluetooth: 2402 ~ 2480 MHz Transmit Power(MAX): GSM 850: 31.65 dBm GSM 1900: 27.90 dBm Bluetooth: 1.172 dBm Max. Reported SAR(1g): Band Mode Head(W/kg) Body (W/kg) PCE GSM 850 0.447 0.496 PCE GSM 1900 0.752 0.237 DSS Bluetooth Note 0.059 0.029 1-g Sum SAR(W/kg) 0.811 0.525 FCC Equipment Class Licensed Portable Transmitter Held to Ear (PCE) Part 15 Spread Spectrum Transmitter (DSS) Operating Mode: GSM: GSM Voice, GPRS Class 12 Bluetooth: V2.1 Antenna Specification: GSM: PIFA Antenna BT: Dipole Antenna Hotspot Mode: Not Support DTM Mode: Not Support Note：Bluetooth SAR was estimated. Page 5 of 52 Report No.: STS1601072H01 1.2 Test Environment Ambient conditions in the SAR laboratory: Items Required Actual Temperature (°C) 18-25 22~23 Humidity (%RH) 30-70 55~65 1.3 Test Facility Shenzhen STS Test Services Co., Ltd. Add. : 1/F, Building B, Zhuoke Science Park,No.190, Chongqing Road, Fuyong, Baoan District, Shenzhen, Guangdong, China CNAS Registration No.: L7649 FCC Registration No.: 842334; IC Registration No.: 12108A-1 Page 6 of 52 Report No.: STS1601072H01 2. Test Standards And Limits No. Identity Document Title 1 47 CFR Part 2 Frequency Allocations and Radio Treaty Matters; General Rules and Regulations 2 ANSI/IEEE Std. C95.1-1992 IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz 3 IEEE Std. 1528-2013 Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques 4 FCC KDB 447498 D01 v05r02 Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies 5 FCC KDB 865664 D01 v01r04 SAR Measurement 100 MHz to 6 GHz 6 FCC KDB 865664 D02 v01r02 RF Exposure Reporting This device belongs to portable device category because its radiating structure is allowed to be used within 20 centimeters of the body of the user…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No: STS1601072F01 Issued for Que Products, LLC 59 East Main Street Suite 7 Bayshore, NY 11706 ,USA Product Name: BOLT Brand Name: QUE Model No.: P1 Series Model: P2,P3,P4,P5,P6 FCC ID: 2AEI92ABGBFP1 Test Standard: FCC Part 22H and 24E S T L A B S 2 of 55 Report No.: STS1601072F01 Testing Engineer : (Jin Ming) Technical Manager : (Vita Li) Authorized Signatory : (Bovey Yang) TEST RESULT CERTIFICATION Applicant’s name ................. : Que Products, LLC Address ................................. : 59 East Main Street Suite 7 Bayshore, NY 11706 ,USA Manufacture's Name ............ : Shenzhen Feipu Communication Technology Co.,Ltd. Address ................................. : 21/F,Electronic Science and Technology Building A ,ShenNan Road,Futian District, Shenzhen City,Guangdong Provice,China. Product name ........................ : BOLT Brand name ......................... : QUE Model and/or type reference .. : P1 Standards ............................. : FCC Part 22H and 24E Test procedure ........................... : TIA 603 C This device described above has been tested by STS and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ........................................... : Date of performance of tests .................. : 12 Jan. 2016 ~19 Jan. 2016 Date of Issue .......................................... : 20 Jan. 2016 Test Result .............................................. : Pass 3 of 55 Report No.: STS1601072F01 TABLE OF CONTENTS Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 6 1.2 MEASUREMENT UNCERTAINTY 6 2. GENERAL INFORMATION 7 2.1 PRODUCT DESCRIPTION 7 2.2 RELATED SUBMITTAL(S) / GRANT (S) 8 2.3 SPECIAL ACCESSORIES 8 2.4 EUT CONFIGURATION 8 2.5 EUT EXERCISE 8 2.6 CONFIGURATION OF EUT SYSTEM 9 2.7 MEASUREMENT INSTRUMENTS 10 3. DESCRIPTION OF TEST MODES 10 4. OUTPUT POWER 11 4.1 CONDUCTED OUTPUT POWER 11 4.2 PEAK-TO-AVERAGE RADIO (PAR) OF TRANSMITTER 14 4.3 RADIATED OUTPUT POWER 17 5. SPURIOUS EMISSION 20 5.1 SPURIOUS EMISSION 20 5.2 RADIATED SPURIOUS EMISSION 22 6. FREQUENCY STABILITY 26 6.1 MEASUREMENT METHOD 26 6.2 PROVISIONS APPLICABLE 27 6.3 MEASUREMENT RESULT 28 7. OCCUPIED BANDWIDTH 30 7.1 MEASUREMENT METHOD 30 7.2 PROVISIONS APPLICABLE 30 7.3 MEASUREMENT RESULT 30 8. EMISSION BANDWIDTH 31 8.1 MEASUREMENT METHOD 31 8.2 PROVISIONS APPLICABLE 31 8.3 MEASUREMENT RESULT 31 9. BAND EDGE 32 9.1 MEASUREMENT METHOD 32 9.2 PROVISIONS APPLICABLE 32 4 of 55 Report No.: STS1601072F01 9.3 MEASUREMENT RESULT 32 APPENDIX I 33 TEST PLOTS FOR CONDUCTED SPURIOUS EMISSION 33 APPENDIX II 43 TEST PLOTS FOR OCCUPIED BANDWIDTH (99%) 43 EMISSION BANDWIDTH (-26DBC) 43 APPENDIX III 51 TEST PLOTS FOR BAND EDGES 51 APPENDIX IV 55 PHOTOS OF TEST SETUP 55 5 of 55 Report No.: STS1601072F01 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 20 Jan. 2016 STS1601072F01 ALL Initial Issue 6 of 55 Report No.: STS1601072F01 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: The radiated emission testing was performed according to the procedures of ansi C63.10: 2009; TIA 603 C and fcc cfr 47 rules of 2.1046, 2.1047, 2.1049, 2.1051, 2.1053, 2.1055, 2.1057 Item Number Item Description FCC Rules 1 Output Power Conducted output power 22.913(a) / 24.232 (b) Radiated output power 2 Spurious Emission Conducted spurious emission 2.1051 / 22.917 / 24.238 Radiated spurious emission 3 Frequency Stability 2.1055 /24.235 4 Occupied Bandwidth 2.1049 (h)(i) 5 Emission Bandwidth 22.917(b) / 24.238 (b) 6 Band Edge 22.917(b) / 24.238 (b) NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 TEST FACTORY Shenzhen STS Test Services Co., Ltd. Add. : 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China CNAS Registration No.: L7649; FCC Registration No.: 842334; IC Registration No.: 12108A-1 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission (9KHz-150KHz) ±2.88dB 2 Conducted Emission (150KHz-30MHz) ±2.67dB 3 RF power,conducted ±0.70dB 4 Spurious emissions,conducted ±1.19dB 5 All emissions,radiated(<1G) 30MHz-200MHz ±2.83dB 6 All emissions,radiated(<1G) 200MHz-1000MHz ±2.94dB 7 All emissions,radiated(>1G) ±3.03dB 8 Temperature ±0.5°C 9 Humidity ±2% 7 of 55 Report No.: STS1601072F01 2. GENERAL INFORMATION 2.1 PRODUCT DESCRIPTION A major technical description of EUT is described as following: Product Designation: BOLT Hardware version: V4.0 Software version: N/A FCC ID: 2AEI92ABGBFP1 Frequency Bands: GSM 850 PCS 1900 (U.S. Bands) GSM 900 DCS 1800 (Non-U.S. Bands) U.S. Bands: UMTS FDD Band II UMTS FDD Band V Non-U.S. Bands: UMTS FDD Band I UMTS FDD Band VIII Max RF Output Power: GSM850:31.99 dBm,GSM1900:28.18dBm Type of Emission: GSM(850):317KGXW: GSM(1900):320KGXW GPRS(850):323KGXW; GPRS(1900):319KGXW Description test modes (worst case) SIM 1 and SIM 2 is a chipset unit and tested as single chipset,SIM 1 is used to tested Antenna: PIFA Antenna Antenna gain: GSM 850/ WCDMA Band V : 0.5 dBi …

Text truncated - open the document above for the full version.

P1 PCE Setup photo PCE radiation L PCE radiation H

P1_SAR Setup photo Right Touch Right Tilt Left Touch Left Tilt Body Front side Body Back side 10mm
