2AEIE-JM01Vehicle GPS tracker

User Manual Please read this manual carefully before attempting installation and online activation. Pictures are for indication and illustration purposes only 1 Accessories Pictures are for indication and illustration purposes only. NOTE: After opening the packing box, please check if the accessories are complete. If there is anything missing, please contact your distributor. 2 Interface descriptions 3 LED status indicator and wiring 3.1 Red LED（power/working status indicator） Status Meaning Quick flashing Low battery Slow flashing Fully charged Continuously in bright Charging Continuously in dark No battery/troubleshoot 3.2 Blue LED(GPS signal indicator） Status Meaning Quick flashing Searching GPS signal Slow flashing GPS signal has successfully Continuously in dark GPS stops working 3.3 Green LED(GSM signal indicator） Status Meaning Quick flashing GSM initialization Slow flashing GPRS online Continuously in dark No GSM signal or no SIM card installed 3.4 Armed When red/green/blue 3 LED lights are flashing twice in cycle, it means the terminal is armed. 3.5 Function of the wires No. Function Color Function Illustration 1 V+ Red Positive pole 2 V- Black Negative pole 3 ACC Orange ACC on 4 Relay Yellow Relay controlled wire 5 TX Green Send data / for backup 6 RX Blue Receive data / for backup 7 GND Purple Ground wire 4 Installation 4.1 Wiring 1：Red 2：Black 3：Orange 4：Yellow 5：Green 6：Blue 7：Purple (1) Use multi-meter to find out the negative pole of the battery. (2) Use multi-meter to find out the ACC wire. Method: Use the red pen to connect with the ACC wire while the black pen connects with the ground wire. In this condition, when the ignition lock is off, the voltage is 0; when the ignition lock is turned on, the multi-meter will show the voltage. (3) The red line (positive pole) of the terminal cable should be connected to the positive pole of the battery. (4) Follow the picture above to connect the wires. (5) When the terminal is connected to external power, insert the SIM and the red indicator (power indicator) should be normally on. When the ignition lock is turned off, the red indicator should be flashing slowly. (6) The yellow wire of the relay control line should be connected to 86 as the picture shows. 5 Power ON/OFF 5.1 Power ON The terminal will be automatically on when you insert the SIM card. The battery will connect the internal wires together in the terminal and the external power supply will start providing power to the device and also charging the battery. 5.2 GSM&GPS signal searching After the power is on, it will start searching the GSM and GPS signal. During this period, the green indicator (GSM indicator) will be flashing while the blue indicator will be flashing quickly. When the blue indicator is flashing slowly, it means GPS has located. 5.3 Power OFF Pull out the SIM card, the terminal will be off. 6 Parameters setting 6.1 Set APN Please send SMS command to the number of terminal so as to set up the APN parameter. The terminal will reply “OK” automatically after setting successfully. Send SMS command: APN,APN’s name# e.g: APN, internet# NOTE: The APN of some countries have user name and password, you may need to send SMS command as follows: Send SMS command: APN,APN’s name, user name, password# e.g: APN, internet, CLIENTE, AMENA# 6.2 Set DNS Please send SMS command to the number of terminal so as to set up the DNS parameter. The terminal will reply “OK” automatically after setting successfully. Send SMS command: SERVER,1,DNS,Port,0# e.g. SERVER,1,JM01.szdatasource.com,8841,0# 6.3 Set SOS Number (1) Add SOS number Via SMS command Send SMS command: SOS, A,number1,number2,number3 #(A means add number). You can set 3 SOS numbers in maximum. If set successfully, the terminal will reply “ok”. e.g. SOS,A, 13510****60,135116****6,136126****8# (set all 3 SOS numbers) SOS,A, 13510****60# (set the first SOS number) SOS,A, ,135116****6# (set the second SOS number) SOS,A, , ,136126****8# (set the third SOS number) (2) Delete SOS Numbers Send SMS command: SOS, D,1,2,3# (D means delete SOS number) e.g. SOS, D,1# means delete the first number SOS, D,3# means delete the third number If you do not know the sequence number, you can also delete the number by SMS command like this: SOS, D, number# e.g. SOS, D, 135278****0# means delete this SOS number directly. It will reply “OK” if the number is deleted successfully. (3) Add SOS numbers via platform You can set SOS number via the platform after activating the terminal. 6.4 Set Center Number Send SMS command from the SOS number to set the Center Number. (1) Add Center Number: Send SMS command: CENTER, A, number# e.g. CENTER,A, 135278****0# (2) Delete Center Number Send SMS command :CENTER,D, number# e.g. CENTER,D, 135278****0# NOTE: Center Number can be set ONLY by SOS numbers. 6.5 Check current parameters Send SMS command: PARAM# The terminal will reply messages including: IMEI number, GPRS upload interval, time interval that GPS is activated when ACC is off, SOS numbers, center number, sensor alarm interval, defense time and time zone. 6.6 Set GPS data upload interval (1) Upload by interval The default upload interval is 20 seconds, which means every 20 seconds the terminal will upload its location data to the platform. The interval can be set by sending SMS command: TIMER,T1,T2# (5≤T≤18000 seconds) e.g. TIMER,20,30# It means when ACC is on, GPS data upload interval is 20 seconds; when ACC is off, GPS data upload interval is 30 seconds. (2) Upload by distance Send SMS command: DISTANCE,D# (100≤D≤10000 meters) e.g. DISTANCE,300# It means for every 300 meters, the terminal will upload GPS data to platform. NOTE: if the upload interval is short, the GPRS current will add up. Please set the suitable upload interval. 6.7 Corners upload (ON as def ault) The terminal will upload GPS data to the platform when the vehicle is turning (the turning angle reaches the pre-set value). NOTE: if the speed is too low during turning, the GPS data wi…

Text truncated - open the document above for the full version.

Shenzhen Jimi Electronic Co.,Ltd. DATE ：2015-11-06 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AEIE-JM01 Product Name: Vehicle GPS tracker Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics • Block diagram • Operation description • Tune Up • BOM These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 2015-09-01 By: Aven Ru Signature Printed Title: Manager On behalf of : Shenzhen Jimi Electronic Co.,Ltd. Telephone: +86-755 6664-2510

Label and Label location Label location Label location Vehicle GPS tracker FCC ID: 2AEIE-JM01 Model: JM01 Label

Report No: CCIS15110086201 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS151100862RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 40 of 44 Report No: CCIS15110086201 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS151100862RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 41 of 44 Report No: CCIS15110086201 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS151100862RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 42 of 44 Report No: CCIS15110086201 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS151100862RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 43 of 44 Report No: CCIS15110086201 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS151100862RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 44 of 44 ------End of report------

Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to isotropic R = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal:33.84(dBm) Maximum peak output power at antenna input terminal:2421.0(mW) Antenna gain(typical):0(dBi) Maximum antenna gain:1.000(numeric) Prediction distance:20(cm) Sourse Based Time Average Duty Cycle:100(%) Prediction frequency:824.2(MHz) MPE limit for uncontrolled exposure at prediction frequency:0.549(mW/cm^2) Power density at prediction frequency:0.48165(mW/cm^2) Power density at prediction frequency:4.8165(W/m^2) Margin of Compliance:0.57(dB) 2 4R PG S p =

Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to isotropic R = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal:28.29(dBm) Maximum peak output power at antenna input terminal:674.5(mW) Antenna gain(typical):0(dBi) Maximum antenna gain:1.000(numeric) Prediction distance:20(cm) Sourse Based Time Average Duty Cycle:100(%) Prediction frequency:1850.2(MHz) MPE limit for uncontrolled exposure at prediction frequency:1.000(mW/cm^2) Power density at prediction frequency:0.13419(mW/cm^2) Power density at prediction frequency:1.3419(W/m^2) Margin of Compliance:8.72(dB) 2 4R PG S p =

Shenzhen Zhongjian Nanfang Testing Co., Ltd. Report No: CCIS15110086201 Authorized Signature: Bruce Zhang Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the CCIS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 1. Cover Page FCC REPORT (GSM) Applicant: Shenzhen Jimi Electronic Co., Ltd. Address of Applicant: No.1005, B3 building, Kexing Science Park, Keyuan North Rd, Nanshan District, Shenzhen, China Equipment Under Test (EUT) Product Name: Vehicle GPS tracker Model No.: JM01 Trade mark: JIMI FCC ID: 2AEIE-JM01 Applicable standards: FCC CFR Title 47 Part 2 FCC CFR Title 47 Part 22 Subpart H FCC CFR Title 47 Part 24 Subpart E Date of sample receipt: 03 Nov., 2015 Date of Test: 03 Nov., to 13 Nov., 2015 Date of report issued: 13 Nov., 2015 Test Result: PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No: CCIS15110086201 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS151100862RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 2 of 44 2. Version Version No. Date Description 00 13 Nov., 2015 Original Tested by: Date: 13 Nov., 2015 Test Engineer Reviewed by: Date: 13 Nov., 2015 Project Engineer Report No: CCIS15110086201 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS151100862RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 3 of 44 3. Contents Page 1. COVER PAGE .............................................................................................................................................................. 1 2. VERSION ....................................................................................................................................................................... 2 3. CONTENTS ................................................................................................................................................................... 3 4. TEST SUMMARY ......................................................................................................................................................... 4 5. GENERAL INFORMATION ........................................................................................................................................ 5 5.1 CLIENT INFORMATION ............................................................................................................................................ 5 5.2 GENERAL DESCRIPTION OF E.U.T. ....................................................................................................................... 5 5.3 TEST MODES .......................................................................................................................................................... 7 5.4 RELATED SUBMITTAL(S) / GRANT (S) .................................................................................................................... 7 5.5 TEST METHODOLOGY ............................................................................................................................................ 7 5.6 LABORATORY FACILITY .......................................................................................................................................... 7 5.7 LABORATORY LOCATION ....................................................................................................................................... 7 5.8 TEST INSTRUMENTS LIST ....................................................................................................................................... 8 6. SYSTEM TEST CONFIGURATION .......................................................................................................................... 9 6.1 EUT CONFIGURATION ........................................................................................................................................... 9 6.2 EUT EXERCISE ...................................................................................................................................................... 9 6.3 CONFIGURATION OF TESTED SYSTEM .................................................................................................................. 9 6.4 DESCRIPTION OF TEST MODES ............................................................................................................................. 9 6.5 CONDUCTED OUTPUT POWER ............................................................................................................................ 10 6.6 OCCUPY BANDWIDTH .......................................................................................................................................... 12 6.7 PEAK-TO-AVERAGE POWER RATIO .................................................................................................................... 17 6.8 M…

Text truncated - open the document above for the full version.

Report No: CCIS15110086201 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS151100862RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 34 of 44 7 Test Setup Photo Radiated Spurious Emission
