Fangguang Inspection & Testing Co., Ltd. Tel:+86-020-38699960-6006 Email: [email protected] http://www.fgtest.cn TRF No.:FG.WI-EMC-07-010(1.1) Page Number: 1 of 8 RF Exposure Evaluation Declaration Report No.: S20250923539902E03 Issue Date: Applicant: Huizhou Foryou General Electronics Co., Ltd. Address: No.2 District A, Foryou Industry Park, No. 1 North Shangxia Road,Dongjiang Hi-tech Industry Park, 516005 Huizhou city, Guangdong Province, China(PROC) FCC ID: 2AEIN-HA1030A Application Type: Certification Product: RADIO Model No.: HA1030A Trade Mark: / FCC Rule Part(s): CFR 47, FCC Part 2.1091 Radio frequency radiation exposure evaluation: mobile devices. Item Receipt date: Sep. 17, 2025 Test Date: Sep. 17, 2025~ Oct. 20, 2025 Compiled By (Stone Zhang) Senior Test Engineer Approved By (Line Chen) Engineer Manager The test results relate only to the samples tested. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in KDB 558074 D01. Test results reported herein relate only to the item(s) tested. The test report shall not be reproduced except in full without the written approval of Fangguang Inspection & Testing Co., Ltd. Wuxi Branch The test report must not be used by the client to claim product certifications, approval, or endorsement by NVLAP, NIST or any agency of U.S. Government. Verified code：446603 2025-12-19 Report No.: S20250923539902E03 Page Number: 2 of 8 Revision History Report No. Version Description Issue Date S20250923539902E03 Rev. 01 / 2025-12-19 Report No.: S20250923539902E03 Page Number: 3 of 8 CONTENTS Description Page §2.1033 General Information ............................................................................................. 4 1. Product Information .................................................................................................... 5 1.1. Equipment Description ........................................................................................... 5 1.2. Product Specification Subjective to this Report ................................................. 5 2. RF Exposure Evaluation ............................................................................................. 6 2.1. Limits ......................................................................................................................... 6 2.2. Calculation Method ................................................................................................. 7 Report No.: S20250923539902E03 Page Number: 4 of 8 §2.1033 General Information Applicant: Huizhou Foryou General Electronics Co., Ltd. Applicant Address: No.2 District A, Foryou Industry Park, No. 1 North Shangxia Road,Dongjiang Hi-tech Industry Park, 516005 Huizhou city, Guangdong Province, China(PROC) Manufacturer: Huizhou Foryou General Electronics Co., Ltd. Manufacturer Address: No.2 District A, Foryou Industry Park, No. 1 North Shangxia Road,Dongjiang Hi-tech Industry Park, 516005 Huizhou city, Guangdong Province, China(PROC) Factory: Huizhou Foryou General Electronics Co., Ltd. Factory Address: No.2 District A, Foryou Industry Park, No. 1 North Shangxia Road,Dongjiang Hi-tech Industry Park, 516005 Huizhou city, Guangdong Province, China(PROC) Test Site: Fangguang Inspection & Testing Co., Ltd. LAB ID: CN5037 LAB registration number： 600222-0 Test Site Address: No.8 Ningyun Rd., Xinwu District Wuxi, Jiangsu 214000 China FCC Rule Part(s): FCC Part 2.1091 FCC ID: 2AEIN-HA1030A Test Device Serial No.: S/N.: / Production Pre-Production Engineering Report No.: S20250923539902E03 Page Number: 5 of 8 1. Product Information 1.1. Equipment Description Note: This information is provided by the Customer and its authenticity is the responsibility of the Customer. 1.2. Product Specification Subjective to this Report Note: The maximum Antenna Gain was declared by the manufacturer Product Name: RADIO Test Model: HA1030A Trade Mark: / Input Voltage Range: 17V~32.5V DC (24V) Software Version: DEC-A0 Hardware Version: 1230150144100/A2 EUT sample number: S20250923539902-1-1 (Conducted) S20250923539902-1-2 (Radiated) Operating Frequency BT: 2402~2480MHz BLE: 2402~2480MHz Number of Channels BT: 79 BLE: 40 Channel Spacing BT: 1MHz BLE: 2MHz Type of modulation BT: GFSK, Π/4 DQPSK, 8DPSK BLE: GFSK Antenna Type: Integral PCB antenna Antenna Gain: 1.06dBi Report No.: S20250923539902E03 Page Number: 6 of 8 2. RF Exposure Evaluation 2.1. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 300-1500 -- -- f/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/ Uncontrolled Exposures 300-1500 -- -- f/1500 6 1500-100,000 -- -- 1 30 f= Frequency in MHz Calculation Formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 r = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1mW/cm². If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. For simultaneous transmission exposure cases, calculation formula is: Report No.: S20250923539902E03 Page Number: 7 of 8 2.2. Calculation Method Temperature: 20.5 °C Relative Humidity: 54 % ATM Pressure: 102.9 kPa Test Data: 2025-10-20 Test Engineer: Stone Zhang Product RADIO Test Item RF Exposure Evaluation Mode Frequency (MHz) Maximum Conducted Output Power (dBm) Antenna Gain (dBi) PG MPE (mW/cm 2 ) MPE Limits (mW/cm 2 ) (dBm) …

Text truncated - open the document above for the full version.

Fangguang Inspection & Testing Co., Ltd. Tel:+86-020-38699960-6006 Email: [email protected] http://www.fgtest.cn TRF No.:FG.WI-EMC-07-010(1.1) Page Number: 1 of 119 Report No.: S20250923539902E01 Issue Date: Applicant: Huizhou Foryou General Electronics Co., Ltd. Address: No.2 District A, Foryou Industry Park, No. 1 North Shangxia Road,Dongjiang Hi-tech Industry Park, 516005 Huizhou city, Guangdong Province, China(PROC) FCC ID: 2AEIN-HA1030A Product: RADIO Model No.: HA1030A FCC Classification: FCC Part 15 Spread Spectrum Transmitter (DSS) FCC Rule Part(s): Part 15 Subpart C (15.247) Test Procedure(s): ANSI C63.10-2020, KDB 558074 D01v05r02 Result: Pass Item Receipt Date: Sep. 17, 2025 Test Date: Sep. 17, 2025~ Oct. 20, 2025 MEASUREMENT REPORT FCC PART 15.247 Bluetooth Compiled By (Stone Zhang) Senior Test Engineer Approved By (Line Chen) Engineer Manager The test results relate only to the samples tested. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.10-2020. Test results reported herein relate only to the item(s) tested. The test report shall not be reproduced except in full without the written approval of Fangguang Inspection & Testing Co., Ltd. Wuxi Branch The test report must not be used by the client to claim product certifications, approval, or endorsement by NVLAP, NIST or any agency of U.S. Government. Verified code：416695 2025-12-19 Report No.: S20250923539902E01 Page Number: 2 of 119 Revision History Report No. Version Description Issue Date S20250923539902E01 Rev. 01 / 2025-12-19 Report No.: S20250923539902E01 Page Number: 3 of 119 CONTENTS Description Page §2.1033 General Information ......................................................................................................... 6 1. Introduction ............................................................................................................................ 7 1.1. Scope ........................................................................................................................... 7 1.2. Fangguang Test Location ............................................................................................. 7 2. Product Information ............................................................................................................... 8 2.1. Equipment Description .................................................................................................. 8 2.2. Product Specification Subjective to this Standard ......................................................... 8 2.3. Operation Frequency / Channel List ............................................................................. 9 2.4. Pseudorandom Frequency Hopping Sequence ........................................................... 10 2.5. Device Capabilities ..................................................................................................... 10 2.6. Description of Test Software ....................................................................................... 15 2.7. Test Configuration ...................................................................................................... 15 2.8. EMI Suppression Device(s)/Modifications ................................................................... 15 2.9. EUT Photo .................................................................................................................. 15 2.10. Labeling Requirements ............................................................................................... 15 2.11. Calculation with all conversion and correction factors used ........................................ 16 3. Description of Test ............................................................................................................... 17 3.1. Evaluation Procedure ................................................................................................. 17 3.2. AC Line Conducted Emissions ................................................................................... 17 3.3. Radiated Emissions .................................................................................................... 18 4. Antenna Requirements ........................................................................................................ 19 5. Test Equipment Calibration Date......................................................................................... 20 6. Measurement Uncertainty .................................................................................................... 22 7. Test Result ............................................................................................................................ 23 7.1. Summary .................................................................................................................... 23 7.2. 20dB Bandwidth Measurement ................................................................................... 24 7.2.1. Test Limit .................................................................................................................... 24 7.2.2. Test Procedure used ................................................................................................... 24 7.2.3. Test Setting ................................................................................................................. 24 7.2.4. Test Setup .................................................................................................................. 24 7.2.5. Test Result .................................................................................................................. 25 7.3. Output Power Measurement ....................................................................................... 30 7.3.1. Test Limit ................................................................................................…

Text truncated - open the document above for the full version.

Report No.: S20250923539902E01 Page Number: 30 of 119 7.3. Output Power Measurement 7.3.1.Test Limit The maximum out power permissible output power is 1 Watt for frequency hopping systems operating in the 2400–2483.5 MHz band employing at least 75 non-overlapping hopping channels, and all frequency hopping systems in the 5725–5850 MHz band. For all other frequency hopping systems in the 2400–2483.5 MHz band: 0.125 watts.And for antenna gain greater than 6dBi the limit shall reduce by the amount in dB that the directional gain of the antenna exceeds 6 dBi. 7.3.2.Test Procedure Used ANSI C63.10-2020 - Section 7.8.5 7.3.3.Test Setting 1. Span: Approximately five times the 20 dB bandwidth, centered on a hopping channel. 2. RBW > 20 dB bandwidth of the emission being measured. 3. VBW ≥ RBW. 4. Sweep: No faster than coupled (auto) time. 5. Detector function: Peak. 6. Trace: Max-hold. 7. Allow the trace to stabilize, Use the marker-to-peak function to set the marker to the peak of the emission. The indicated level is the peak output power, after any corrections for external attenuators and cables. Report No.: S20250923539902E01 Page Number: 31 of 119 7.3.4.Test Setup Report No.: S20250923539902E01 Page Number: 32 of 119 7.3.5.Test Result Temperature: 23.4 °C Relative Humidity: 63 % ATM Pressure: 101.1 kPa Test Data: 2025-09-24 Test Engineer: Stone Zhang Test Mode Antenna Frequency (MHz) Conducted Peak Power[dBm] Conducted Limit[dBm] Verdict DH5 Ant1 2402 4.46 ≤20.97 PASS 2441 4.61 ≤20.97 PASS 2480 4.17 ≤20.97 PASS 2DH5 Ant1 2402 6.64 ≤20.97 PASS 2441 6.96 ≤20.97 PASS 2480 6.38 ≤20.97 PASS 3DH5 Ant1 2402 7.37 ≤20.97 PASS 2441 7.59 ≤20.97 PASS 2480 7.19 ≤20.97 PASS DH5_Ant1_2402 Report No.: S20250923539902E01 Page Number: 33 of 119 DH5_Ant1_2441 DH5_Ant1_2480 Report No.: S20250923539902E01 Page Number: 34 of 119 2DH5_Ant1_2402 2DH5_Ant1_2441 Report No.: S20250923539902E01 Page Number: 35 of 119 2DH5_Ant1_2480 3DH5_Ant1_2402 Report No.: S20250923539902E01 Page Number: 36 of 119 3DH5_Ant1_2441 3DH5_Ant1_2480 Report No.: S20250923539902E01 Page Number: 37 of 119 7.4. Carrier Frequency Separation Measurement 7.4.1.Test Limit Frequency hopping systems operating in the 2400-2483.5 MHz band may have hopping channel carrier frequencies that are separated by 25 kHz or two-thirds of the 20 dB bandwidth of the hopping channel, whichever is greater, provided the systems operate with an output power no greater than 125 mW. 7.4.2.Test Procedure Used ANSI C63.10-2020 - Section 7.8.2 7.4.3.Test Setting 1. Span = wide enough to capture the peaks of two adjacent channels. 2. Start with the RBW set to approximately 30% of the channel spacing; adjust as necessary to best identify the center of each individual channel. 3. Video (or average) bandwidth (VBW) ≥ RBW. 4. Sweep: No faster than coupled (auto) time. 5. Detector = Peak 6. Trace mode = Max hold 7. Allowed the trace to stabilize 8. Use the marker-delta function to determine the separation between the peaks of the adjacent channels. Report No.: S20250923539902E01 Page Number: 38 of 119 7.4.4.Test Setup Report No.: S20250923539902E01 Page Number: 39 of 119 7.4.5.Test Result Temperature: 23.4 °C Relative Humidity: 63 % ATM Pressure: 101.1 kPa Test Data: 2025-09-24 Test Engineer: Stone Zhang Test Mode Antenna Frequency (MHz) Result [MHz] Limit [MHz] Verdict DH5 Ant1 Hop 1.014 ≥0.642 PASS 2DH5 Ant1 Hop 1.002 ≥0.892 PASS 3DH5 Ant1 Hop 1.040 ≥0.874 PASS DH5_Ant1_Hop Report No.: S20250923539902E01 Page Number: 40 of 119 2DH5_Ant1_Hop 3DH5_Ant1_Hop Report No.: S20250923539902E01 Page Number: 41 of 119 7.5. Number of Hopping Channels Measurement 7.5.1.Test Limit Regulation 15.247 (a) (1)(iii) Frequency hopping systems in the 2400-2483.5 MHz band shall use at least 15 channels. 7.5.2.Test Procedure Used ANSI C63.10-2020 - Section 7.8.3 7.5.3.Test Setting 1. Span = the frequency band of operation. Depending on the number of channels the device supports, it may be necessary to divide the frequency range of operation across multiple spans, to allow the individual channels to be clearly seen. 2. To identify clearly the individual channels, set the RBW to less than 30% of the channel spacing or the 20 dB bandwidth, whichever is smaller. 3. VBW ≥ RBW 4. Sweep: No faster than coupled (auto) time. 5. Detector function: Peak. 6. Trace mode = Max hold 7. Allow the trace to stabilize Report No.: S20250923539902E01 Page Number: 42 of 119 7.5.4.Test Setup Report No.: S20250923539902E01 Page Number: 43 of 119 7.5.5.Test Result Temperature: 23.4 °C Relative Humidity: 63 % ATM Pressure: 101.1 kPa Test Data: 2025-09-24 Test Engineer: Stone Zhang Test Mode Antenna Frequency (MHz) Result [Num] Limit [Num] Verdict DH5 Ant1 Hop 79 ≥15 PASS 2DH5 Ant1 Hop 79 ≥15 PASS 3DH5 Ant1 Hop 79 ≥15 PASS DH5_Ant1_Hop Report No.: S20250923539902E01 Page Number: 44 of 119 2DH5_Ant1_Hop 3DH5_Ant1_Hop Report No.: S20250923539902E01 Page Number: 45 of 119 7.6. Time of Occupancy Measurement 7.6.1.Test Limit The maximum permissible time of occupancy is 400ms within a period of 400ms multiplied by the number of hopping channels employed. 7.6.2.Test Procedure Used ANSI C63.10-2020 - Section 7.8.4 7.6.3.Test Stetting 1. Span = zero span, centered on a hopping channel. 2. RBW shall be ≤ channel spacing and where possible RBW should be set >> 1 / T, where T is the expected dwell time per channel. 3. VBW ≥ RBW 4. Sweep time = Set so that the start of the first transmission and end of the last transmission for the hop are clearly captured. Setting the sweep time to be slightly longer than the hopping period per channel (hopping period = 1/hopping rate) should achieve this. 5. Detector = Peak 6. Trace: Clear-write, single sweep. 7. Place markers at the start of the first transmission on the channel and at the end of the last transmission. The dwell time per hop is the time between these two markers. Use the marker-delta function to determine the transmit time per hop. If this value varies with different modes of operatio…

Text truncated - open the document above for the full version.

Report No.: S20250923539902E01 Page Number: 59 of 119 7.7.5.Test Result Temperature: 23.4 °C Relative Humidity: 63 % ATM Pressure: 101.1 kPa Test Data: 2025-09-24 Test Engineer: Stone Zhang Test Mode Antenna Ch Name Frequency (MHz) Ref Level [dBm] Result [dBm] Limit [dBm] Verdict DH5 Ant1 Low 2402 4.14 -49.10 ≤-15.86 PASS High 2480 4.21 -49.65 ≤-15.79 PASS Low Hop_2402 3.08 -50.33 ≤-16.93 PASS High Hop_2480 3.93 -49.57 ≤-16.07 PASS 2DH5 Ant1 Low 2402 4.03 -48.59 ≤-15.97 PASS High 2480 3.78 -49.32 ≤-16.22 PASS Low Hop_2402 1.56 -48.96 ≤-18.44 PASS High Hop_2480 3.58 -49.51 ≤-16.42 PASS 3DH5 Ant1 Low 2402 4.38 -48.05 ≤-15.62 PASS High 2480 4.03 -49.17 ≤-15.97 PASS Low Hop_2402 1.34 -49.34 ≤-18.67 PASS High Hop_2480 3.59 -49.20 ≤-16.41 PASS Report No.: S20250923539902E01 Page Number: 60 of 119 DH5_Ant1_Low_2402 DH5_Ant1_High_2480 Report No.: S20250923539902E01 Page Number: 61 of 119 DH5_Ant1_Low_Hop_2402 DH5_Ant1_High_Hop_2480 Report No.: S20250923539902E01 Page Number: 62 of 119 2DH5_Ant1_Low_2402 2DH5_Ant1_High_2480 Report No.: S20250923539902E01 Page Number: 63 of 119 2DH5_Ant1_Low_Hop_2402 2DH5_Ant1_High_Hop_2480 Report No.: S20250923539902E01 Page Number: 64 of 119 3DH5_Ant1_Low_2402 3DH5_Ant1_High_2480 Report No.: S20250923539902E01 Page Number: 65 of 119 3DH5_Ant1_Low_Hop_2402 3DH5_Ant1_High_Hop_2480 Report No.: S20250923539902E01 Page Number: 66 of 119 7.8. Conducted Spurious Emissions Measurement 7.8.1.Test Limit In any 100 kHz bandwidth outside the frequency band in which the spread spectrum or digitally modulated intentional radiator is operating, the radio frequency power that is produced by the intentional radiator shall be at least 20 dB below that in the 100 kHz bandwidth within the band that contains the highest level of the desired power, based on either an RF conducted or a radiated measurement, provided the transmitter demonstrates compliance with the peak conducted or a radiated measurement, provided the transmitter demonstrates compliance with the peak conducted power limits. If the transmitter complies with the conducted power limits based on the use of RMS averaging over a time interval, the attenuation required under this paragraph shall be 30 dB instead of 20 dB. 7.8.2.Test Procedure Used ANSI C63.10-2020 - Section 7.8.7 7.8.3.Test Setting 1. Span = The frequency range of testing shall span 30 MHz to 10 times the operating frequency and this may be done in a single sweep or, to aid resolution, across a number of sweeps. 2. RBW = 100 kHz 3. VBW =300 kHz 4. Detector = peak 5. Sweep time = auto couple 6. Trace mode = max hold 7. Trace was allowed to stabilize 8. Set the marker on the peak of any spurious emission recorded. The level displayed must comply with the limit specified in this section. 9. The limit is based on the highest in-band level across all channels measured using the same Report No.: S20250923539902E01 Page Number: 67 of 119 instrument settings (resolution bandwidth of 100 kHz, video bandwidth of 300 kHz, and a coupled sweep time with a peak detector). To help clearly demonstrate compliance a display line may be set at the required offset (typically 20 dB) below the highest in-band level. Where the highest in-band level is not clearly identified in the out-of-band measurements a separate spectral plot showing the in-band level shall be provided. 7.8.4.Test Setup Report No.: S20250923539902E01 Page Number: 68 of 119 7.8.5.Test Result Temperature: 23.4 °C Relative Humidity: 63 % ATM Pressure: 101.1 kPa Test Data: 2025-09-24 Test Engineer: Stone Zhang Test Mode Antenna Frequency (MHz) Freq Range [MHz] Ref Level [dBm] Result [dBm] Limit [dBm] Verdict DH5 Ant1 2402 Reference 4.21 4.21 --- PASS 30~1000 4.21 -39.47 ≤-15.79 PASS 1000~26500 4.21 -25.57 ≤-15.79 PASS 2441 Reference 4.56 4.56 --- PASS 30~1000 4.56 -41.18 ≤-15.44 PASS 1000~26500 4.56 -25.48 ≤-15.44 PASS 2480 Reference 4.08 4.08 --- PASS 30~1000 4.08 -41.35 ≤-15.92 PASS 1000~26500 4.08 -30.1 ≤-15.92 PASS 2DH5 Ant1 2402 Reference 4.13 4.13 --- PASS 30~1000 4.13 -31.26 ≤-15.87 PASS 1000~26500 4.13 -20.5 ≤-15.87 PASS 2441 Reference 4.49 4.49 --- PASS 30~1000 4.49 -40.83 ≤-15.51 PASS 1000~26500 4.49 -21.08 ≤-15.51 PASS 2480 Reference 3.90 3.90 --- PASS 30~1000 3.90 -37.55 ≤-16.10 PASS 1000~26500 3.90 -29.32 ≤-16.10 PASS 3DH5 Ant1 2402 Reference 4.34 4.34 --- PASS 30~1000 4.34 -36.14 ≤-15.66 PASS 1000~26500 4.34 -28.91 ≤-15.66 PASS 2441 Reference 4.59 4.59 --- PASS 30~1000 4.59 -34.79 ≤-15.41 PASS 1000~26500 4.59 -21.58 ≤-15.41 PASS 2480 Reference 4.03 4.03 --- PASS 30~1000 4.03 -41.48 ≤-15.97 PASS 1000~26500 4.03 -22.54 ≤-15.97 PASS Report No.: S20250923539902E01 Page Number: 69 of 119 DH5_Ant1_2402_0~Reference DH5_Ant1_2402_30~1000 Report No.: S20250923539902E01 Page Number: 70 of 119 DH5_Ant1_2402_1000~26500 DH5_Ant1_2441_0~Reference Report No.: S20250923539902E01 Page Number: 71 of 119 DH5_Ant1_2441_30~1000 DH5_Ant1_2441_1000~26500 Report No.: S20250923539902E01 Page Number: 72 of 119 DH5_Ant1_2480_0~Reference DH5_Ant1_2480_30~1000 Report No.: S20250923539902E01 Page Number: 73 of 119 DH5_Ant1_2480_1000~26500 2DH5_Ant1_2402_0~Reference Report No.: S20250923539902E01 Page Number: 74 of 119 2DH5_Ant1_2402_30~1000 2DH5_Ant1_2402_1000~26500 Report No.: S20250923539902E01 Page Numbe…
