2AEKLFZ999Car DVD player

FZ-999 D VD PLAYER Car Model:FZ-999 A.Precautions... 1Play/Pause..11 B.Notice before operation .. 2Fast backward/Fast forward11 C.Accessories... 3Previous/Next.. 11 D.Features.. 4S top/Return... 11 E.Video disk type..4Program.. 12 F.S ystem connection and installation.5Repeat.12 G.Key parts in front of the player.. 7MENU/PCB... 12 H.Precautions for remote controller .8Display13 I.Application of remote controller. 8Mute.13 J.Description for the pressing-key of remote controller. 9Zoom... 14 K.Basic operations10Goto.14 1.Power ON/OFF10Audio... 14 2.Disc loading . 10S ubtitle... 14 3.Disc removing. 10Title..... 14 4.US B and card reading10Vol+Vol-.. 15 L. Functions of keys..11S etup... 15 POWER11Direction key. 15 Open key. 11Angle... 15 Number key10+..15Audio Setup... 21 US B/CARD .161.Tone. 21 MENU .. 16Video setup... 21 DVD/AV... 161.Brightbess contrast hue,saturation,sharpness... 21 TFT ON/OFF.. 16Dolby Digital S etup.. 22 IR-TX161. Output Mode..... 22 FM-TX. 162. Dynamic Range22 M. Function menu operation. 173. Dual mono. 23 Menu option.. 17N. Description for playing disks...24 1.Resume... 17Electronic Album.. 25 2.Auto play. 18Playing JPEG Discs.25 3.TV S ystem18Playing MP3&JPEG Discs..... 25 4.Aspect Ratio... 19MPEG 4 Decoding Technology..... 26 5.Default Value.. 19Description for Playing MP4 Discs.. 26 Language setup.. 20O.Operation for Game Function... 27 1. OS D Display Language.. 20P.Troubleshooting.. 28 2. Audio Language/subtitle /menu language.. 20Q.Technical specifications and parameters. 29

Eurofins Product Service GmbH Storkower Str. 38C 15526 Reichenwalde b. Berlin Tel +49-33631-888 0 Fax +49-33631-888 650 www.eurofins.com Sitz der Gesellschaft: Hamburg Registergericht Hamburg, HRB 103428 Ust.-ID: DE257676793 Geschäftsführung: Christian Keding, Norddeutsche Landesbank Konto-Nr.: 199 917 204 BLZ: 250 500 00 SWIFT: NOLADE2HXXX Deutschland www.product-testing.eurofins.com Dr. Matthias-Wilbur Weber IBAN: DE 37250500000199917204 REQUEST FOR CONFIDENTIALITY [ Reference Document: FCC KDB# # 726920 D02 Confidentiality Procedures Detail v01] NOTE: If you do not require confidentiality your exhibits are visible on the FCC website for everyone. A request for confidentiality must be indicated in item 8 of the 731 form and a letter making specific request for confidentiality must accompany the application as a separate exhibit. This letter must state exactly which portions of the application are to be held in confidence and for what specific reason. Exhibit types that are commonly held confidential are: (1) schematic diagrams, (2) detailed block diagrams, (3) detailed operational descriptions, (4) parts lists, and (5) tune up procedures (if applicable). Internal photos and user's manual exhibits, while not typically held confidential, may be eligible for confidentiality in certain circumstances. Additional justification must be provided in these cases: (6) Internal Photos (may be held confidential when i.e. - the circuit board is enclosed in epoxy or some sort of material that would destroy the circuit board if it was removed; - the device is sealed using special fasteners that cannot be opened using common hand tools or if the PCB’s are completely potted; Æ Provide photos justifying the attestation. Æ Provide justification as to how the device is sealed and how disassembly would destroy the product and circuit board. (7) Users manuals (may be held in confidence when i.e. - the manual will only be available to licensed or specially trained personnel. - the manual is very technical and is not provided to the consumer because the consumer cannot service the device Æ Submit an agreement such as a non-disclosure agreement, purchase agreement or installation agreement, between the grantee and the purchaser that is consistent with the submitted confidentiality request with regard to the internal photos, manual or any installation requirements such as located in an inaccessible area. The agreement should be on company's letter head. If applicable, the agreement should indicate how the purchaser will install the device and how the internal photo(s) or manual will not be given to the public The FCC is a federal agency and as such has duties to the public to disclose information made known to it (see 47 CFR 0). The FCC has a procedure to handle confidential items and any request will be delivered to the FCC for them to decide if it can be held in confidence (PBA procedure). A request for confidentially does not guarantee that the FCC will grant it. Please find below a sample letter for confidentiality request.

External Photo Model: FZ‐999

Label and label location Label size: L*W=40*20mm Label Location Shenzhen Forzen Technology Co., Ltd MODEL NO.: FZ-999 FCC ID: 2AEKLFZ999 This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation

Internal Photo Model: FZ‐999

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID: 2AEKLFZ999 Product: Car DVD player Model No.: FZ-999 Additional Model No.: FZ-666, FZ-1003, FZ-1004, FZ-1005, FZ-669, FZ-888, FZ-901, FZ-3004 Trade Mark: N/A Report No.: TCT150413E011 Issued Date: Apr. 27, 2015 Issued for : Shenzhen Forzen Technology Co.,Ltd Forzen Technology Park, Fuyuan No.2 Rd, Fuyong, Bao’an district, Shenzhen, China Issued By: Shenzhen Tongce Testing Lab. 1F, Leinuo Watch Building, Fuyong Town, Baoan Dist, Shenzhen, China TEL: +86-755-27673339 FAX: +86-755-27673332 Note: This report shall not be reproduced except in full, without the written approval of Shenzhen Tongce Testing Lab. This document may be altered or revised by Shenzhen Tongce Testing Lab. personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT150413E011 Page 2 of 18 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TABLE OF CONTENTS 1. Test Certification....................................................................................... 3 2. Test Result Summary ............................................................................... 4 3. EUT Description ........................................................................................ 5 4. Genera Information................................................................................... 6 4.1. T EST E NVIRONMENT AND M ODE .................................................................................. 6 4.2. D ESCRIPTION OF S UPPORT U NITS ............................................................................... 6 5. Facilities and Accreditations ................................................................... 7 5.1. FACILITIES................................................................................................................. 7 5.2. L OCATION ................................................................................................................. 7 5.3. M EASUREMENT U NCERTAINTY .................................................................................... 7 6. Test Results and Measurement Data ...................................................... 8 6.1. A NTENNA R EQUIREMENT ............................................................................................ 8 6.2. C ONDUCTED E MISSION ............................................................................................... 9 6.3. R ADIATED E MISSION M EASUREMENT ......................................................................... 10 6.4. 20 D B O CCUPIED B ANDWIDTH ................................................................................... 15 Report No.: TCT150413E011 Page 3 of 18 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. Test Certification Product: Car DVD player Model No.: FZ-999 Additional Model No.: FZ-666, FZ-1003, FZ-1004, FZ-1005, FZ-669, FZ-888, FZ-901, FZ-3004 Applicant: Shenzhen Forzen Technology Co.,Ltd Address: Forzen Technology Park, Fuyuan No.2 Rd, Fuyong, Bao’an district, Shenzhen, China Manufacturer: Shenzhen Forzen Technology Co.,Ltd Address: Forzen Technology Park, Fuyuan No.2 Rd, Fuyong, Bao’an district, Shenzhen, China Date of Test: Apr. 15 – Apr. 24, 2015 Applicable Standards: FCC CFR Title 47 Part 15 Subpart C Section 15.239 The above equipment has been tested by Shenzhen Tongce Testing Lab . and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Tested By: Date:Apr. 24, 2015 Sky Reviewed By: Date:Apr. 27, 2015 Joe Zhou Approved By: Date:Apr. 27, 2015 Tomsin Report No.: TCT150413E011 Page 4 of 18 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. Test Result Summary Requirement CFR 47 Section Result Antenna requirement §15.203 PASS AC Power Line Conducted Emission §15.207 N/A Field strength of the fundamental signal §15.239 (b) PASS Spurious emissions §15.239 (b) (c)/ §15.209 PASS Occupied Bandwidth §15.215 (c) PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. Report No.: TCT150413E011 Page 5 of 18 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. EUT Description Product Name: Car DVD player Model : FZ-999 Additional Model: FZ-666, FZ-1003, FZ-1004, FZ-1005, FZ-669, FZ-888, FZ-901, FZ-3004 Trade Mark: N/A Operation Frequency: 88.1-88.7MHz Channel Separation: 200 kHz Number of Channel: 4 Modulation Technology: FM Antenna Type: Internal Antenna Antenna Gain: 1dBi Power Supply: DC12V Model difference： All models above are identical in interior structure, electrical circuits and components, and just differ in look and model for the marketing requirement. Operation Frequency Each of Channel Channel FrequencyChannel FrequencyChannelFrequencyChannel Frequency 1 88.1MHz 4 88.7MHz 2 88.3MHz 3 88.5MHz Note: In section 15.31(m), regards to the operating frequency range over 10 MHz, the Lowest frequency, the middle frequency, and the highest frequency of channel were selected to perform the test, and the selected channel see below: Channel Frequency The lowest channel 88.1MHz The middle channel 88.3MHz The Highest channel 88.7MHz Report No.: TCT150413E011 Page 6 of 18 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 4. Genera Information 4.1. Test Environment and Mode Operating Environment: Temperature: 24.0 °C Humidity: 54 % RH Atmospheric Pressure: 1010 mbar Test Mode: Operat…
