2AELF-LF01Tracker with wooden case

USER MANUAL ENG This section contains important information about the operation of your device. It also contains information about how to use the device safely. Read this informa- tion carefully before using your device. The Bellabeat LEAF is a sleep, stress and movement monitor. It can be worn as a necklace, bracelet or a clip. The Bellabeat LEAF syncs with the Bellabeat app, and all the data is transferred wirelessly. Accurate sensors inside the Leaf measure your breathing, how active you are and all your movements throughout the day and night. Based on all the collected data the Leaf App provides useful insights to improve your health. The LEAF also vibrates to remind you to either increase your activity or reduce the intensity of your workouts, depending on your preferences. WHAT’S INCLUDED Bellabeat Leaf Necklace Bracelet User manual ABOUT BELLABEAT LEAF POWERING ON Your Bellabeat LEAF is shipped with one CR2032 coin cell battery that has been previously installed. Remove the plastic tab from the battery to power on your LEAF. FIRST STEPS INSTALL THE APPLICATION 1. Connect your phone to the Internet and follow the instructions from www.bellabeat.com to install the application. 2. Open the Bellabeat application. 3. Double tap your Bellabeat LEAF to start pairing. 4. Connect the Bellabeat LEAF with your mobile phone. FIRST STEPS HOW TO WEAR THE LEAF You can wear your Bellabeat Leaf as a clip, necklace or bracelet. CLIP – Lift the metal clip and slide the fabric of your garment between the metal clip and wooden housing. It can be attached to the hem of your top or shirt, or the waistband. Please be informed - clipping the LEAF to fabrics thicker than 2 mm could damage the clip. Avoid pulling the LEAF more than 4mm away from the wooden housing when guiding your fabric through. The LEAF device should be treated with the same care as a piece of jewelry to protect its construction. FIRST STEPS NECKLACE – Make sure you pull the necklace through the metal clip hoop so that the tip of the LEAF is facing down. The little hole on the side is used only when worn as a bracelet. FIRST STEPS BRACELET – Attach the metal clip to the large hoop at the top of the Leaf. Lay the Leaf on the top of your wrist (with the Leaf design facing out) and wrap the leather strap around your wrist twice. Guide the other end of the leather bracelet strap through the opposite metal loop from the underside so that the tip of the strap is pointing up. Pull the strap so that the bracelet feels firmly in place, and attach the appropriate hole over the metal peg. Guide the leather ring over the strap to hold in place. Style tip: You can loop the extra strap back through the leather ring. FIRST STEPS  Dimensions: Height: 1,89 inches (48 mm) Width: 1,18 inches (30 mm) Depth: 0,51 inches (13 mm) Weight: 0,635 ounces (18 g)  Power Source: CR2032 coin cell battery  Connectivity: Wireless  Sensors: tri-axis accelerometer  Haptic vibration motor for alarms and notifications  OTA update (Over the Air update) Bellabeat LEAF works with Android 4.3 and later, iPhone 4s, iPhone 5, iPhone 5c, iPhone 5s, iPhone 6, iPhone 6 Plus, iPod Touch 5th Gen, iPad 3rd Gen, iPad Mini, iPad Air SPECIFICATIONS REPLACING THE BATTERY 1. Unscrew all four screws and remove the metal clip (1) 2. Remove the rubber cover (2) 3. Remove the battery and replace it with a new one (3) 4. Put the rubber cover back 5. Put the metal clip back 6. Put back and tighten all four screws 1 2 3 SAFETY INFORMATION FOR THE BATTERY In exceptional circumstances, batteries may leak fluids that can cause a chemical burn injury or ruin your product. To avoid battery leakage:  Do not mix old and new batteries or batteries of different types: alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium).  Insert batteries as indicated inside the battery compartment.  Remove batteries during long periods of non-use. Always remove exhausted batteries from the product. Dispose of batteries safely. Do not dispose of this product in a fire. The batteries inside may explode or leak.  Never short-circuit the battery terminals.  Use only batteries of the same or equivalent type, as recommended.  Do not charge non-rechargeable batteries. REPLACING THE BATTERY DO NOT throw the battery in household waste. The symbol of the crossed out wheeled bin indicates that the battery should not be placed in household waste. Instead they shall be handed over to the appropriate collection point for the recycling batteries. DO NOT throw this product in household waste. This symbol indicates that this product shall not be treated as household waste. Instead it shall be handed over to the appropriate collection point for the recycling of electrical and electronic equipment. The recycling materials will help to conserve natural resources PROPER DISPOSAL CERTIFICATION The FCC ID is located under the battery. To see the FCC ID please remove the battery. FCC PART 15 Compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this devise may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes of modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the product. CERTIFICATION NOTE: This equipment has been tested and found to comply with the limited for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instruction, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio …

Text truncated - open the document above for the full version.

SANDROMUR CEO

SANDROMUR CEO

Product Name:Tracker with wooden case Model Name:LEAF FCC ID:2AELF-LF01 Bellabeat, Inc.

Label Location:

FCC ID: 2AELF-LF01 According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where --f(GHz) is the RF channel transmit frequency in GHz --Power and distance are rounded to the nearest mW and mm before calculation --The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m) ---3m So pt = (EXd) 2 /30 x gt Field strength = 88.80dBuV/m @3m Ant gain=0dBi; so Ant numeric gain=1 So pt={[10 (88.80/20) /10 6 x3] 2 /(30x1)}x1000 mW = 0.228mW So (0.228 mW /5mm)x √2.44 = 0.071<3 Then SAR evaluation is not required

Global United Technology Services Co., Ltd. Report No.: GTSE15040056101 Authorized Signature: Robinson Lo Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the GTS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of GTS or testing done by GTS in connection with, distribution or use of the product described in this report must be approved by GTS in writing. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. FCC REPORT Applicant: Bellabeat, Inc. Address of Applicant: 2443 Fillmore Street #380-5580 San Francisco California 94115 United States Equipment Under Test (EUT) Product Name: Tracker with wooden case Model No.: LEAF FCC ID: 2AELF-LF01 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.249:2014 Date of sample receipt: May 11, 2015 Date of Test: May 11-18, 2015 Date of report issued: May 18, 2015 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTSE15040056101 Global United Technology Services Co., Ltd. Project No.: GTSE150400561RF Room 301-309, 3th Floor, Block A, Huafeng Jinyuan Business Building, No. 300 Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, China Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 26 2 Version Version No. Date Description 00 May 18, 2015 Original Prepared By: Date: May 18, 2015 Project Engineer Check By: Date: May 18, 2015 Reviewer Report No.: GTSE15040056101 Global United Technology Services Co., Ltd. Project No.: GTSE150400561RF Room 301-309, 3th Floor, Block A, Huafeng Jinyuan Business Building, No. 300 Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, China Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 26 3 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 VERSION .................................................................................................................................................. 2 3CONTENTS .............................................................................................................................................. 3 4TEST SUMMARY ..................................................................................................................................... 4 4.1MEASUREMENT UNCERTAINTY ............................................................................................................ 4 5GENERAL INFORMATION ...................................................................................................................... 5 5.1CLIENT INFORMATION ......................................................................................................................... 5 5.2GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.3TEST MODE ........................................................................................................................................ 7 5.4DESCRIPTION OF SUPPORT UNITS ....................................................................................................... 7 5.5TEST FACILITY .................................................................................................................................... 7 5.6TEST LOCATION ................................................................................................................................. 7 5.7OTHER INFORMATION REQUESTED BY THE CUSTOMER ......................................................................... 7 6TEST INSTRUMENTS LIST ..................................................................................................................... 8 7TEST RESULTS AND MEASUREMENT DATA ...................................................................................... 9 7.1ANTENNA REQUIREMENT ..................................................................................................................... 9 7.2RADIATED EMISSION METHOD ........................................................................................................... 10 7.2.1Field Strength of The Fundamental Signal ................................................................................ 12 7.2.2Spurious emissions .................................................................................................................... 13 7.2.3Bandedge emissions.................................................................................................................. 17 7.320DB OCCUPY BANDWIDTH .............................................................................................................. 18 8TEST SETUP PHOTO ............................................................................................................................ 20 9EUT CONSTRUCTIONAL DETAILS ..................................................................................................... 21 Report No.: GTSE150400561…

Text truncated - open the document above for the full version.

Radiated Emission
