2AEMO-CUPBluetooth glass

Operation manual Thank you for choosing OZNER Smart Cup, please read this manual carefully before using. OZNER Smart Cup will lead you step into a new era of access to healthy drinking water. Make sure to read before using Please make sure to read the following notes for safety in order to avoid any inconvenience caused to you. Please don’t dip the cup into the boiled water. Please don’t dip the cup into the water for a long time. Never heavily strike the cup due to ceramic cup body used in this product to avoid any damage. Never clean the cup into the dishwasher or heat in the microwave oven. Always charge the cup with standard USB interface or high-quality USB charger, and make sure no water stain left on the charging outlet before charging. Never heavily strike the cup when using. Water drinking volume is collected by the high-precision sensors. Strong impact may cause the sensor error increases, or even damaged. Register using flow Step I: Download the APP of OZNER, please scan the QR code as follow : Scan the QR code, focus on Ozner water purification technology, enter my menu, click on "I", download mobile phone APP. Step II: Log in APP to match the OZNER Cup. First, reversely place the OZNER Cup while matching the OZNER Cup, and then match according to the tips of APP. Step III. Complete personal data and set the reminder of smart water Drinking. You can start using the OZNER Smart Cup. Introduction to functions 01. Bottom navigation There are four buttons at the bottom of the navigation: Smart control: a. OZNER Cup: Enter the control page of OZNER Cup b. Water purifier: Enter the product page of water purifier Have a test: a. Determine the TDS of this cup of water: This function automatically reads the TDS of the cup connected currently, the firstly activated cup shall work if two and above cups are connected. Click on the question mark to view the explanation and description of TDS numeric value meaning. Share it in the moments via the sharing button on the top of right corner. b. Detect the temperature of this cup Awake the cup, and view current temperature of this cup via APP. c. Determine the volume of water drinking Awake the cup. And view the drinking volume via APP at this time. Discovery: Health Group : Recommendation of Healthy Products Water Knows Health : Share of Water Purification Tips Gift card : Enter the gift member page of OZNER Service branches search : View the national service networks of OZNER Me : Individual data card : View and modify personal data My private coffer : View personal scores My advice : Comment, suggestion and feedback 02. Home page of OZNER Cup Dynamic report of water drinking today: Count the TDS, water drinking state and drinking temperature today. And at the same time, display the state and distribution of three indexes on the same day. 03.Navigation on the left The content of navigation column on the left differs when current user selects each smart products. The navigation column may be either marked out from the left of the screen or click and call out from the icon on the top left corner. Currently for smart cup products, the content of navigation column is as follows: Healthy water drinking report View the water drinking report of current week and month. View water drinking details of my cup and family members. Choose the specific cup and then view the data when some cups of families are added. My list member a. Add the list member: The user may find and add his/her list member via mobile number or nick name. b. View the ranking: It can view the water drinking volume of other friends and check the TDS and ranking of water drinking volume in current week and month. Know the water drinking volume of friends in current week. c. OZNER Cup matching First, the “cup matching” page is skipped when the user clicks “Add the cup”. After scanning the pairing is successful, fill in the name of OZNER Cup and choose “My Cup” or “Cup of Family Member” to conduct matching setting. Smart water drinking reminder This function mainly aims at setting the water drinking reminder of OZNER Cup, there are different pages for my cup and cup of family, the content of this page will automatically change when the user selects “My Cup” and “Cup of Family Member”. For the setting of optic circle, it displays the TDS and temperature (Optional). State of OZNER Cup Check the remaining battery of cup and the Bluetooth is connected or not. About OZNER Cup Introduction and operation manual of OZNER Cup Main technical parameters Model CUP B1 office white series CUP B2 office black series Dual-cup of CUP P friends series Triple-cup of CUP H family series Communication protocol Bluetooth 4.0 Power supply mode Standard USB 5V 500mA Applicable water temperature 0~100 °C Appropriate environment temperature 0~40°C Cup volume 300±20ml Size 138 x Φ72 mm Weight 350g Online Upgrade The system can automatically monitor the software situation of APP new version. When the APP has a new version , the user is prompted to upgrade. For Apple users, they can prompt the upgrade and automatically jump to the APP Store to upgrade; For Android users, the system can alert the user to upgrade and confirm. If the user clicks "OK", the system will automatically download the latest installation package and automatically upgrade. Support phone and systems Android smart devices Bluetooth 4.0, above android 4.3 Iphone 4s and above, above IOS 7 systems Fittings of OZNER Cup Single-cup Dual-cup Triple-cup Cup(number) 1 2 3 Charging Cable(number) 1 2 3 Certificate(page) 1 1 1 Warranty card(page) 1 2 3 FAQs treatment After-Sale Service Hotline If you can not solve the problem, please call 400-820-2667, there is our customer service staff to serve you. Question Solution Confirm open Bluetooth , and make sure the phone models are supported. When searching for the cup match, please make sure the cup is received within Bluetooth range. Confirm cups have adequate power. Unable to find cups If not resolved, ple…

Text truncated - open the document above for the full version.

Shanghai Ozner Comfort Environment & Science Company Limited No.60, Guiqiao Road, Pudong New Area, Shanghai, China TEL: +86-21-58995060 FAX: +86-21-50325399 DATE 04-22-2015 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AEMO-CUP Product Name: Bluetooth glass Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 04-22-2015 By: Duan jianbing Signature Printed Title: Manager On behalf of : Shanghai Ozner Comfort Environment & Science Company Limited Telephone: +86-21-58995060

Shanghai Ozner Comfort Environment & Science Company Limited No.60, Guiqiao Road, Pudong New Area, Shanghai, China TEL: +86-21-58995060 FAX: +86-21-50325399 USB Port Statement FCC ID: 2AEMO-CUP Date: Apr. 22, 2015 To whom it may concern: We, the undersigned, state that the device's (Model: CUP B1, CUP B2, CUP P, CUP H) USB port only used for charge, no any data transfer to PC. Sincerely, Duan jianbing/Manager

FCC ID Label Information 1. Label location: 2. FCC ID Label: Model: CUP B1 FCC ID: 2AEMO-CUP FCCID Label Location

RF Exposure evaluation According to KDB 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m)---3m So pt = (EXd) 2 /30 x gt Field strength = 90.17dBuV/m @3m Ant gain 0dBi; so Ant numeric gain=1 So pt={[10 (90.17/20) /10 6 x3] 2 /30x1}x1000mW = 0.312mW So (0.312mW/5mm)x √2.480GHz = 0.098<3 Then SAR evaluation is not required

- Shenzhen CTL Testing Technology Co., Ltd. Tel: +86-755-89486194 Fax: +86-755-26636041 FCC PART 15 SUBPART C TEST REPORT Report Reference No......................: CTL1503270727-WF Compiled by ( position+printed name+signature)..: File administrators Happy Guo Name of the organization performing the tests ( position+printed name+signature)..: Test Engineer Nice Nong Approved by ( position+printed name+signature)..: Manager Tracy Qi Date of issue.....................................: Apr. 23, 2015 Test Firm..........................................: Shenzhen CTL Testing Technology Co., Ltd. Address.............................................: Floor 1-A, Baisha Technology Park, No. 3011, Shahexi Road, Nanshan, Shenzhen 518055 China. Applicant’s name............................: Shanghai Ozner Comfort Environment & Science Company Limited Address.............................................: No.60, Guiqiao Road, Pudong New Area, Shanghai, China Test specification: Standard ...........................................: FCC Part 15.249: Operation within the bands 920-928 MHz, 2400- 2483.5 MHz, 5725-5850 MHz and 24.0 - 24.25 GHz. TRF Originator ..................................: Shenzhen CTL Testing Technology Co., Ltd. Master TRF.......................................: Dated 2011-01 Shenzhen CTL Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : Bluetooth glass Trade Mark .......................................: Models/Type reference.....................: CUP B1, CUP B2, CUP P, CUP H Modulation .......................................: GFSK Work Frequency...........................: 2402 MHz~2480 MHz Antenna Type..............................: internal FCC ID .............................................: 2AEMO-CUP Result................................................: Positive V1.0 Page 2 of 49 Report No.: CTL1503270727-WF T E S T R E P O R T Test Report No. :CTL1503270727-WF Apr. 23, 2015 ______________________________________________________________________________________________ Date of issue Equipment under Test : Bluetooth glass Model /Type : CUP B1 Listed Models CUP B2, CUP P, CUP H Difference Description Only the color and model's name is different Applicant : Shanghai Ozner Comfort Environment & Science Company Limited Address : No.60, Guiqiao Road, Pudong New Area, Shanghai, China Manufacturer Shanghai Ozner Comfort Environment & Science Company Limited Address No.60, Guiqiao Road, Pudong New Area, Shanghai, China Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. See clause 2.8 of this report V1.0 Page 3 of 49 Report No.: CTL1503270727-WF Contents 1.TEST STANDARDS .................................................................. 4 2.SUMMARY............................................................................. 5 2.1.General Remarks 5 2.2.Equipment Under Test 5 2.3.Short description of the Equipment under Test (EUT) 5 2.4.EUT operation mode 6 2.5.EUT configuration 6 2.6.Related Submittal(s) / Grant (s) 6 2.7.Modifications 6 3. TEST ENVIRONMENT............................................................... 7 3.1.Address of the test laboratory 7 3.2.Test Facility 7 3.3.Environmental conditions 7 3.4.Configuration of Tested System 7 3.5.Statement of the measurement uncertainty 8 3.6.Equipments Used during the Test 9 4. TEST CONDITIONS AND RESULTS ............................................ 10 4.1.Conducted Emissions Test 10 4.2.Fundamental Emissions 13 4.3.Transmitter Radiated Unwanted Emissions 14 4.4.Band Edge Measurement 30 4.5.Occupied Bandwidth Measurement 39 5. ANTENNA REQUIREMENT ....................................................... 41 6.TEST SETUP PHOTOS OF THE EUT .......................................... 42 7.EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 44 2.8. Model difference 6 V1.0 Page 4 of 49 Report No.: CTL1503270727-WF 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 15.249: Operation within the bands 902 - 928 MHz, 2400 - 2483.5 MHz, 5725 - 5875 MHz, and 24.0 - 24.25 GHz. ANSI C63.4-2009 V1.0 Page 5 of 49 Report No.: CTL1503270727-WF 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Mar. 30, 2015 Testing commenced on : Mar. 30, 2015 Testing concluded on : Apr. 21, 2015 2.2.Equipment Under Test Power supply system utilised Power supply voltage : o 120V / 60 Hz o 115V / 60Hz o 12 V DC o 24 V DC ƽ Other (specified in blank below) DC 3.7V from battery 2.3. Short description of the Equipment under Test (EUT) The EUT is a Bluetooth glass work at 2402~2480 MHz support Bluetooth 4.0LE Channel List: Channel Frequency (MHz) Channel Frequency (MHz) 00 2402 20 2442 01 2404 21 2444 02 2406 22 2446 03 2408 23 2448 04 2410 24 2450 05 2412 25 2452 06 2414 26 2454 07 2416 27 2456 08 2418 28 2458 09 2420 29 2460 10 2422 30 2462 11 2424 31 2464 12 2426 32 2466 13 2428 33 2468 14 2430 34 2470 15 2432 35 2472 16 2434 36 2474 17 2436 37 2476 18 2438 38 2478 19 2440 39 2480 Modulation: GFSK For more details, refer to the user’s manual of the EUT. Serial number: Prototype V1.0 Page 6 of 49 Report No.: CTL1503270727-WF 2.4. EUT operation mode Test Mode(TM) Description Remark TM1 Bottom Channel Transmitting / TM2 Middle Channel Transmitting / TM3 Top Channel Transmitting / TM4 Charging and keeping TX USB power by PC The field strength of radiation emission was measured in the f…

Text truncated - open the document above for the full version.
