2AENRZ07-5FSelfie Stick

Shenzhen Bolutek Electronic Technology Co.,Ltd 4th Floor, Building 5, District A, Internet Industry Base, Baoan, Shenzhen, China TEL: +86-755-26509941 FAX: +86-755-26509942 DATE 05-08-2015 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AENRZ07-5F Product Name: Selfie Stick Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 05-08-2015 By: Tang Lingping Signature Printed Title: Engineer On behalf of : Shenzhen Bolutek Electronic Technology Co.,Ltd Telephone: +86-755-26509941

Shenzhen Bolutek Electronic Technology Co.,Ltd 4th Floor, Building 5, District A, Internet Industry Base, Baoan, Shenzhen, China TEL: +86-755-26509941 FAX: +86-755-26509942 Series Models Description FCC ID: 2AENRZ07-5F Date: May 08, 2015 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: To whom concern: The device (Product Name:Selfie Stick) Models Name: Z07-5F, Z07-5, Z07-5E, Z07-5SE, Z07-5SF, Z07-5A, Z07-5AF, Z07-5G, Z07-6T, Z07-6P, Z07-1AC, Z07-1AF have same electrical, PCB and BOM, only the model’s name and colour are different for marketing requirements. Sincerely, Tang Lingping/ Engineer Z07-1AF are electrically identical, only the model’s name and color are different for marketing requirements.

Shenzhen Bolutek Electronic Technology Co.,Ltd 4th Floor, Building 5, District A, Internet Industry Base, Baoan, Shenzhen, China TEL: +86-755-26509941 FAX: +86-755-26509942 USB Port Statement FCC ID: 2AENRZ07-5F Date: May 08, 2015 To whom it may concern: We, the undersigned, state that the device's (Model: Z07-5F, Z07-5, Z07-5E, Z07-5SE, Z07-5SF, Z07-5A, Z07-5AF, Z07-5G, Z07-6T, Z07-6P, Z07-1AC, Z07-1AF) USB port only used for charge, no any data transfer to PC. Sincerely, Tang Lingping/ Engineer

Listed Modes

FCC ID Label Information 1. Label location: 2. FCC ID Label: Shenzhen Bolutek Electronic Technology Co.,Ltd Model: Z07-5F FCC ID: 2AENRZ07-5F FCCID Label Location

RF Exposure evaluation According to KDB 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m)---3m So pt = (EXd) 2 /30 x gt Field strength = 96.28dBuV/m @3m Ant gain 0dBi; so Ant numeric gain=1 So pt={[10 (96.28/20) /10 6 x3] 2 /30x1}x1000mW = 1.274mW So (1.274mW/5mm)x √2.441GHz = 0.398<3 Then SAR evaluation is not required

- Shenzhen CTL Testing Technology Co., Ltd. Tel: +86-755-89486194 Fax: +86-755-26636041 FCC PART 15 SUBPART C TEST REPORT Report Reference No......................: CTL1504210969-WF Compiled by ( position+printed name+signature)..: File administrators Happy Guo Name of the organization performing the tests ( position+printed name+signature)..: Test Engineer Nice Nong Approved by ( position+printed name+signature)..: Manager Tracy Qi Date of issue.....................................: May 07, 2015 Test Firm..........................................: Shenzhen CTL Testing Technology Co., Ltd. Address.............................................: Floor 1-A, Baisha Technology Park, No. 3011, Shahexi Road, Nanshan, Shenzhen 518055 China. Applicant’s name............................: Shenzhen Bolutek Electronic Technology Co.,Ltd Address.............................................: 4th Floor, Building 5, District A, Internet Industry Base, Baoan, Shenzhen, China Test specification: Standard ...........................................: FCC Part 15.249: Operation within the bands 920-928 MHz, 2400- 2483.5 MHz, 5725-5850 MHz and 24.0 - 24.25 GHz. TRF Originator ..................................: Shenzhen CTL Testing Technology Co., Ltd. Master TRF.......................................: Dated 2011-01 Shenzhen CTL Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : Selfie Stick Trade Mark .......................................: N/A Models/Type reference.....................: Z07-5F, Z07-5, Z07-5E, Z07-5SE, Z07-5SF, Z07-5A, Z07-5AF, Z07-5G, Z07-6T, Z07-6P, Z07-1AC, Z07-1AF Modulation .......................................: FHSS Work Frequency...........................: 2402 MHz~2480 MHz Antenna Type..............................: internal FCC ID .............................................: 2AENRZ07-5F Result................................................: Positive V1.0 Page 2 of 48 Report No.: CTL1504210969-WF T E S T R E P O R T Test Report No. :CTL1504210969-WF May 07, 2015 ______________________________________________________________________________________________ Date of issue Equipment under Test : Selfie Stick Model /Type : Z07-5F Listed Modes Z07-5, Z07-5E, Z07-5SE, Z07-5SF, Z07-5A, Z07-5AF, Z07-5G, Z07-6T, Z07-6P, Z07-1AC, Z07-1AF Difference Description Only the color and model's name is different Applicant : Shenzhen Bolutek Electronic Technology Co.,Ltd Address : 4th Floor, Building 5, District A, Internet Industry Base, Baoan, Shenzhen, China Manufacturer Shenzhen Bolutek Electronic Technology Co.,Ltd Address 4th Floor, Building 5, District A, Internet Industry Base, Baoan, Shenzhen, China Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 48 Report No.: CTL1504210969-WF Contents 1.TEST STANDARDS .................................................................. 4 2.SUMMARY............................................................................. 5 2.1.General Remarks 5 2.2.Equipment Under Test 5 2.3.Short description of the Equipment under Test (EUT) 5 2.4.EUT operation mode 6 2.5.EUT configuration 6 2.6.Related Submittal(s) / Grant (s) 6 2.7.Modifications 6 3. TEST ENVIRONMENT............................................................... 7 3.1.Address of the test laboratory 7 3.2.Test Facility 7 3.3.Environmental conditions 7 3.4.Configuration of Tested System 7 3.5.Statement of the measurement uncertainty 8 3.6.Equipments Used during the Test 9 4. TEST CONDITIONS AND RESULTS ............................................ 10 4.1.Conducted Emissions Test 10 4.2.Fundamental Emissions 13 4.3.Transmitter Radiated Unwanted Emissions 14 4.4.Band Edge Measurement 30 4.5.Occupied Bandwidth Measurement 39 5. ANTENNA REQUIREMENT ....................................................... 41 6.TEST SETUP PHOTOS OF THE EUT .......................................... 42 7.EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 44 V1.0 Page 4 of 48 Report No.: CTL1504210969-WF 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 15.249: Operation within the bands 902 - 928 MHz, 2400 - 2483.5 MHz, 5725 - 5875 MHz, and 24.0 - 24.25 GHz. ANSI C63.4-2009 ANSI C63.4-2014 V1.0 Page 5 of 48 Report No.: CTL1504210969-WF 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Apr. 28, 2015 Testing commenced on : Apr. 28, 2015 Testing concluded on : May 07, 2015 2.2.Equipment Under Test Power supply system utilised Power supply voltage : o 120V / 60 Hz o 115V / 60Hz o 12 V DC o 24 V DC ƽ Other (specified in blank below) DC 3.7V from battery 2.3. Short description of the Equipment under Test (EUT) The EUT is a Selfie Stick work at 2402~2480 MHz support Bluetooth 3.0. Channel List: Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 00 2402 27 2429 54 2456 01 2403 28 2430 55 2457 02 2404 29 2431 56 2458 03 2405 30 2432 57 2459 04 2406 31 2433 58 2460 05 2407 32 2434 59 2461 06 2408 33 2435 60 2462 07 2409 34 2436 61 2463 08 2410 35 2437 62 2464 09 2411 36 2438 63 2465 10 2412 37 2439 64 2466 11 2413 38 2440 65 2467 12 2414 39 2441 66 2468 13 2415 40 2442 67 2469 14 2416 41 2443 68 2470 15 2417 42 2444 69 2471 16 2418 43 2445 70 2472 17 2419 44 2446 71 2473 18 2420 45 2447 72 2474 19 2421 46 2448 73 2475 20 2422 47 2449 74 2476 21 2423 48 2450 75 2477 22 2424 49 2451 76 2478 23 2425 50 2452 …
