2AEQT-DSRDT001Millimeter Wave Corner Radar Sensor

For Internal Only 1 Product Information 1.1.1 Product External Photos Refer to External and Internal Photos. 1.1.2 System Composition The system consists of four radars, with associated components including front left/front right/rear left/rear right radar brackets. The software and hardware of the front left/front right/rear left/rear right radar are identical. After installation, the PIN11 and PIN12 address bits are identified to achieve automatic adaptation of the installation position. 1.1.3 Electronic Diagram Figure 1 Block Diagram 1.1.4 Product Feature List No Feature Feature description 1 BSD Blind Spot Detection 2 LCA Lane Changing Assist 3 RCTA Rear Cross Traffic Alert 4 RCTB Rear Cross Traffic Assist/Brake 5 RAEB Rear Autonomous Emergency Braking 6 DOW Door Open Warning 7 RCW Rear Collision Warning 8 ELK Emergency Lane Keep System For Internal Only 1.1.5 Interface Definition Figure 3 Interface Definition Interfac e no. Interface description Rated Current （A） 12V，25°C Min Current （A） 12V，25°C Circuit Requirement Resistan ce Special cable Terminal coating requirements 1 CAN1_H 2 CAN1_L 3 CAN2_H 4 CAN2_L 5 Blank 6 Blank 7 GND 0.3 0.5 8 Battery 0.3 0.5 9 BSD 0.01 0.1 10 DOW 0.01 0.1 11 ADDRESS1 0.01 0.015 12 ADDRESS2 0.01 0.015 The software and hardware of the left and right radar bodies are identical, and after installation, automatic adaptation is achieved through PIN11 and PIN12 address bit recognition. The address PIN is defined as follows: External address input MCU detection Location or Work Mode Address1 （Pin11） Address2（Pin12） Address1 Address2 NC（Open） NC（Open） Low Low Left Front NC（Open） GND Low High Right front GND NC（Open） High Low Left rear GND GND High High Right rear For Internal Only 1.1.6 Functional Parameters Items Parameters Nearest detection distance 0.2m Nearest detection distance 100m Distance accuracy 0.2m Distance resolution 0.4m Speed dynamic range ±80m/s Speed accuracy 0.1m/s Speed resolution 0.26m/s Horizontal azimuth ±75º Vertical azimuth ±10º Horizontal angle accuracy 0.2º Horizontal angle resolution 5º Vertical angle accuracy 0.5º Minimum target update rate 15Hz Regulatory and Legal Information Frequency band of operation: 76GHz to 77GHz Max RF output power: xxdBm Accessories: N/A Hereby, Huizhou Desay SV Automotive Co., Ltd. declares that the radio equipment type SRD3523/18 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.desaysv.com/compliance. FCC Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. For Internal Only —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Maximum Permissive Exposure Statement This products comply with CE and FCC radiation exposure limits set forth for an uncontrolled environment. It is recommended that equipment should be installed and operated with minimum distance of 20cm between the radiator and your body.

Huizhou Desay SV Automotive Co., Ltd. Attestation Statements Not Covered Entity Applicant To: Federal Communications Commission Date: 07/06/2023 7435 Oakland Mills Road, Columbia, MD 21046, USA Ref: Information Required by Section 2.911(d)(5)(ii) filing FCC ID: 2AEQT-DSRDT001 Huizhou Desay SV Automotive Co., Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely yours, Applicant Signature Printed Name: Jingwen LIANG Title: Manager Address: NO.103, Hechang 5th Road West, Zhongkai National Hi-tech Industrial Development Zone, Huizhou, Guangdong, P.R. China Tel: +86-752-5995888-11598 Email: [email protected]

Huizhou Desay SV Automotive Co., Ltd. Attestation Statements Not Covered Equipment To: Federal Communications Commission Date: 07/06/2023 7435 Oakland Mills Road, Columbia, MD 21046, USA Ref: Information Required by Section 2.911(d)(5)(i) filing FCC ID: 2AEQT-DSRDT001 Huizhou Desay SV Automotive Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section § 2.903 of the FCC rules. Sincerely yours, Applicant Signature Printed Name: Jingwen LIANG Title: Manager Address: NO.103, Hechang 5th Road West, Zhongkai National Hi-tech Industrial Development Zone, Huizhou, Guangdong, P.R. China Tel: +86-752-5995888-11598 Email: [email protected]

DESAY SV AUTOMOTIVE USA CFR 47 §2.911 (d)(7) FCC US Agent Letter of Attestation Date: Mar-9-2023 Grantee code: 2AEQT To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA FCC US Agent Agent Company Name: DESAY SV AUTOMOTIVE USA FRN: 0033522871 Agent Contact Name: Da XU Agent US Address: 840 W LONG LAKE RD STE 150, TROY MI 48098-6356 Agent Email Address: [email protected] This letter is to confirm that we have accepted the responsibility to act as US Agent on behalf of Huizhou Desay SV Automotive Co., Ltd. (“the applicant”) . We are aware of the requirements and responsibilities of the applicant’s agent for service of process as outlined in the FCC section 2.911(d)(7) and Report and Order FCC 22-84 paragraph 63. This agreement is valid until 03/09/2028 Sincerely yours, Authorized Agent Contact Person Name: Da XU Agent contact Job Title: Manager Agent Company name: DESAY SV AUTOMOTIVE USA Printed Name: Jingwen LIANG Title: Manager Address: NO.103, Hechang 5th Road West, Zhongkai National Hi-tech Industrial Development Zone, Huizhou, Guangdong, P.R. China Tel: +86-752-5995888-11598 Email: [email protected] On behalf of Huizhou Desay SV Automotive Co., Ltd.

TCB Authority to Act as Agent Number: MS-0045317 Revision: 0 Effective date: Oct 8, 2021 Page 1 of 1 Authority to Act as Agent Date: 07/06/2023 TUV Rheinland of North America, Inc. 1279 Quarry Lane., Suite. A Pleasanton, CA 94566 To Whom It May Concern: I appoint TÜV Rheinland (Shenzhen) Co., Ltd. to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the FCC or Industry Canada’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by TUV Rheinland Group, still resides with Huizhou Desay SV Automotive Co., Ltd., NO.103, Hechang 5th Road West, Zhongkai National Hi-tech Industrial Development Zone, Huizhou, Guangdong, P.R. China. For TCB applications, We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Date: 07/06/2023 Agreement is valid for 12 months from the above date. Sincerely Yours, Applicant Signature Printed Name: Jingwen LIANG Title: Manager Address: NO.103, Hechang 5th Road West, Zhongkai National Hi-tech Industrial Development Zone, Huizhou, Guangdong, P.R. China Tel: +86-752-5995888-11598 Email: [email protected] On behalf of Huizhou Desay SV Automotive Co., Ltd.

MS-0044715 Page 1 of 1 Revision 1 Huizhou Desay SV Automotive Co., Ltd. Date: 07/06/2023 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road, Columbia, MD 21046, USA Subject: Confidentiality Request for FCC ID: 2AEQT-DSRDT001 Pursuant to FCC 47 CRF 0.457(d), the applicant requests that a part of the subject FCC/IC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term n/a External Photo Short Term Permanent Internal Photos *** Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Schematics Short Term Permanent Test Setup*** Short Term Permanent Tune-Up Procedure Short Term Permanent User’s Manual*** Short Term Permanent Part List/ Antenna Gain Information Datasheet Huizhou Desay SV Automotive Co., Ltd. has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. (*** Exceptional case for Permanent Confidentiality for these Exhibits by PAG only) Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify TUV Rheinland in the event information regarding the product or the product is made available to the public. TUV Rheinland will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely, Applicant Signature Printed Name: Jingwen LIANG Title: Manager Address: NO.103, Hechang 5th Road West, Zhongkai National Hi-tech Industrial Development Zone, Huizhou, Guangdong, P.R. China Tel: +86-752-5995888-11598 Email: [email protected]

Report No.: CQC-IVTS-2023-00311 Page 37 of 43 6. E x t e r n a l a n d I n t e r n a l Ph o tos o f t h e E U T External Photos Report No.: CQC-IVTS-2023-00311 Page 38 of 43 Report No.: CQC-IVTS-2023-00311 Page 39 of 43

Label Location Size: 40x28mm

Report No.: CQC-IVTS-2023-00311 Page 40 of 43 Internal Photos Report No.: CQC-IVTS-2023-00311 Page 41 of 43 Report No.: CQC-IVTS-2023-00311 Page 42 of 43

Test Report Test Report No.: CQC-IVTS-2023-00312 Product Name Millimeter Wave Corner Radar Sensor Model Number SRD3523/18 Applicant Huizhou Desay SV Automotive Co., Ltd. Approval Types FCC ID: 2AEQT-DSRDT001 CQC Internet of Vehicles Technical Service (Shenzhen) Co., Ltd. National Quality Inspection and Testing Center for Internet of Vehicles Products Report No.: CQC-IVTS-2023-00312 Page 2 of 12 Contents 1. T E S T S T A N D A R D S ................................................................. 3 2. S U M M A R Y ............................................................................ 4 2.1. Product Description* 4 2.2. Modifications 4 2.3. Device Data* 4 2.4. Test Conditions* 5 2.5. Additional Information 5 2.6. Test Location 5 2.7. Abnormalities from Standard Conditions 5 2.8. Possible Verdicts of The Results 5 3. R F E X P O S U R E A S S E S S M E N T R E Q U I R E M E N T S ............................ 6 3.1. FCC 47 CFR Part 1.1307 (b)(3) – Determine That They Qualify For An Exemption 6 3.2. FCC 47 CFR Part 1.1310 – Radiofrequency Radiation Exposure Limits 6 3.3. FCC 47 CFR Part 2.1091 – Radiofrequency Radiation Exposure Evaluation: Mobile Devices 7 3.4. FCC 47 CFR Part 2.1093 – Radiofrequency Radiation Exposure Evaluation: Portable Devices 8 3.5. KDB447498 D04 Interim General RF Exposure Guidance v01 9 3.5.1. TOLERANCES IN RF EXPOSURE TEST METHODOLOGIES .................................... 9 3.5.2. 1-MW TEST EXEMPTION FOR MULTIPLE SOURCES ............................................... 9 3.5.3. SIMULTANEOUS TRANSMISSION WITH BOTH SAR-BASED AND MPE-BASED TEST EXEMPTIONS ............................................................................................................................. 9 4. R F E X P O S U R E A S S E S S M E N T M E T H O D ..................................... 10 4.1. Standalone RF Exposure Evaluation Method 10 4.1.1. CONVERSION OF OUTPUT POWER ......................................................................... 10 4.1.2. KDB447498 D04 INTERIM GENERAL RF EXPOSURE GUIDANCE V01 - TOLERANCES IN RF EXPOSURE TEST METHODOLOGIES .......................................................... 10 4.2. Simultaneous Transmission Evaluation Method 11 4.2.1. FCC 47 CFR PART 1.1307 (3) – DETERMINE OF EXEMPTION / (II) FOR MULTIPLE RF SOURCES ...................................................................................................................................... 11 4.2.2. SIMULTANEOUS TRANSMISSION EVALUATION RESULTS ................................... 11 4.3. RF Exposure Assessment Conclusion 11 Report No.: CQC-IVTS-2023-00312 Page 3 of 12 1. T E S T S T A N D A R D S The tests were performed according to following standards: The equipment under test (EUT) has been tested at CQC-IVTS’s (own or subcontracted) laboratories according to the leading reference documents giving table below: No Identify Document Title Version/Date 1 KDB 447498 D04 Interim General RF Exposure Guidance V01 2 FCC 47 CFR Part 1.1307 (b) Actions that may have a significant environmental effect, for which Environmental Assessments (EAs) must be prepared 07/13/2023 3 FCC 47 CFR Part 1.1310 Radiofrequency radiation exposure limits 07/13/2023 4 FCC 47 CFR Part 1.1091 Radiofrequency radiation exposure evaluation: mobile exposure 07/13/2023 5 FCC 47 CFR Part 1.1093 Radiofrequency radiation exposure evaluation: portable exposure 07/13/2023 Report No.: CQC-IVTS-2023-00312 Page 4 of 12 2. S U M M A R Y 2.1. Product Description* Product Name: Millimeter Wave Corner Radar Sensor Trade Mark DESAY SV Model/Type reference: SRD3523/18 FCC ID: 2AEQT-DSRDT001 Hardware Version: 0.0.1 Software Version: 00.00.03 Frequency Range: 76.00 – 78.00 GHz Technology: Radar Modulation Type: FMCW Channel Bandwidth: < 2 GHz Channel Spacing: N/A Receiver Category: N/A Receiver Bandwidth: N/A Antenna: Microstrip Antenna Antenna Gain: 15.00 dBi Specified Rated Output Power E.R.I.P.): ≤ 10.00 dBm Power Supply: DC 12V from vehicle battery Exposure Category: General Population/Uncontrolled Exposure Occupational/Controlled Exposure Device Type: Portable Device Mobile Device Evaluation Distance 0.0005 m to 0.20 m 0.20 m to 0.40 m > 0.40 m Temperature Range: -40°C to +85°C Difference Declaration n/a *: declared by the applicant. CQC-IVTS not responsible for accuary. 2.2. Modifications No modifications were implemented to meet testing criteria 2.3. Device Data* Parameters declared by the manufacturer: The declared maximum output powers including tune-up tolerances are used with regard to the maximum antenna gains to find the maximum EIRP and ERP values. Type Operation Mode Bands / Frequency [GHz] Maximum EIRP (average) including tune up tolerance [dBm] Radar Front 76.00 – 78.00 GHz 10.00 Measurements of power levels and declared antenna gains details in this report and were taken from the following RF module test report(s). EUT test information such as test equipments used, data of actual test, environmental conditions, measurement uncertainty and the persion who performed the original tests are referenced in the listed test report(s). Type Test Report Radio Standard Issud by Band(s) [GHz] RF Output Power + Antenna Gain (average) [dBm] Radar CQC-IVTS-2023-00311 FCC Part 95M CQC-IVTS 76.00 – 78.00 8.04 *: declared by the applicant. Report No.: CQC-IVTS-2023-00312 Page 5 of 12 2.4. Test Conditions* Temperature, [°C] Voltage, [V] T nom +25.0 V nom DC 10.2 V T min -40.0 V min DC 12.0 V T max +85.0 V max DC 13.8 V *: declared by the applicant 2.5. Additional Information Test items differences None Additional application considerations to test a component or sub-assembly Laptop with test software 2.6. Test Location Location 1 Company: CQC Internet of Vehicles Technical Service (Shenzhen) Co., Ltd. Address: Building G5, TCL International E City, Xili Street, Nanshan District, Shenzhen, China Post code: 518112 Contact Person: Wenliang Li Telephone: +86-755-8618 9654 e-Mail: [email protected] 2.7. Abnormalities from Standard Con…

Text truncated - open the document above for the full version.

Antenna Specifications for Radar Sensor (For Millimeter wave corner Radar Sensor) 1. General Specifications Items Specifications Antenna Type Microstrip antenna Frequency Band VSWR 2.0 max Gain 15dBi max 2. Antenna Model 3. VSWR & Radiation Pattern S11 & VSWR 76 to 78GHz Huizhou Desay SV Automotive Co., Ltd. NO.103, Hechang 5th Road West, Zhongkai National Hi-tech Industrial Development Zone Axis of Radiation Pattern Radiation Pattern -3D Transmitting Antenna Receiving Antenna

Test Report Test Report No.: CQC-IVTS-2023-00311 Product Name Millimeter Wave Corner Radar Sensor Model Number SRD3523/18 Applicant Huizhou Desay SV Automotive Co., Ltd. Approval Types FCC ID: 2AEQT-DSRDT001 CQC Internet of Vehicles Technical Service (Shenzhen) Co., Ltd. National Quality Inspection and Testing Center for Internet of Vehicles Products Report No.: CQC-IVTS-2023-00311 Page 2 of 43 Contents 1. T E S T S T A N D A R D S ................................................................. 4 2. S U M M A R Y ............................................................................ 5 2.1. General Remarks 5 2.2. Product Description* 5 2.3. EUT Operation Mode* 5 2.4. Modifications 5 2.5. Test Item (Equipment Under Test) Description* 5 2.6. Auxiliary Equipment (AE) Description* 6 2.7. Test Item Set-ups Description 6 2.8. Test Conditions* 6 2.9. Additional Information 6 2.10. Test Location 6 2.11. Abnormalities from Standard Conditions 6 2.12. Possible verdicts of the results 6 2.13. Formula for Determination of Correction Values (E c ) 7 2.14. Reporting Statements of Conformity – Decision Rule 7 2.15. Radiated Emission Measurement Distance 7 2.16. Antenna Characteristics 8 3. T E S T E N V I R O N M E N T .............................................................. 9 3.1. Address of the test laboratory 9 3.2. Environmental conditions 9 3.3. Test Description 9 3.4. Statement of The Measurement Uncertainty 9 3.5. Equipments Used during the Test 10 4. T E S T C O N D I T I O N S A N D R E S U L T S ........................................... 11 4.1. RF Output Power [§2.1046 ＆ 95.3367] 11 4.1.1. LIMITS .......................................................................................................................... 11 4.1.2. TEST CONFIGURATION ............................................................................................. 11 4.1.3. TEST PROCEDURE .................................................................................................... 11 4.1.4. TEST RESULTS ........................................................................................................... 12 4.2. Modulation Characteristic [§2.1047 ＆ KDB 653005 D01 76 – 81 GHz Radars] 14 4.2.1. LIMITS .......................................................................................................................... 14 4.2.2. VERDICT ...................................................................................................................... 14 4.3. Occupied Bandwidth [§2.1049 ＆ §95.3379] 15 4.3.1. LIMITS .......................................................................................................................... 15 4.3.2. TEST CONFIGURATION ............................................................................................. 15 4.3.3. TEST PROCEDURE .................................................................................................... 15 4.3.4. TEST RESULTS ........................................................................................................... 16 4.4. Field Strength of Spurious Radiation [§2.1053 ＆ §95.3379] 19 4.4.1. LIMITS .......................................................................................................................... 19 4.4.2. TEST RESULTS ........................................................................................................... 20 4.4.3. TEST PROCEDURE .................................................................................................... 21 4.4.4. FIELD STRENGTH CALCULATION ............................................................................ 24 4.4.5. TEST RESULTS ........................................................................................................... 24 4.5. AC Conducted Emission 31 4.5.1. LIMITS OF DISTURBANCE ......................................................................................... 31 4.5.2. TEST CONFIGURATION ............................................................................................. 31 4.5.3. TEST PROCEDURE .................................................................................................... 31 4.5.4. DISTURBANCE CALCULATION ................................................................................. 31 4.5.5. TEST RESULTS ........................................................................................................... 32 4.6. Frequency Stability 33 4.6.1. LIMITS .......................................................................................................................... 33 Report No.: CQC-IVTS-2023-00311 Page 3 of 43 4.6.2. TEST CONFIGURATION ............................................................................................. 33 4.6.3. TEST PROCEDURE .................................................................................................... 33 4.6.4. TEST RESULTS ........................................................................................................... 34 5. T E S T S E T-UP P H O T O S O F T H E E U T ........................................ 35 6. E X T E R N A L A N D I N T E R N A L P H O T O S O F T H E E U T ...................... 37 Report No.: CQC-IVTS-2023-00311 Page 4 of 43 1. T E S T S T A N D A R D S The tests were performed according to following standards: The equipment under test (EUT) has been tested at CQC-IVTS’s (own or subcontracted) laboratories according to the leading reference documents giving table below: No Identify Document Title Version/Date 1 FCC Part 95M The 76 – 81 GHz Band Radar Service 07/13/2023 2 ANSI C63.4 American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz 2014 3 ANSI C63.10 American National Standard for Testing Unlicensed Wireless Devices 2013 4 ANSI C63.26 American National Standard for Compliance Testing of Transmitters Used in Lincensed Radio Services 2015 5 KDB 653005 D01,…

Text truncated - open the document above for the full version.

Report No.: CQC-IVTS-2023-00311 Page 35 of 43 5. T e s t Set-up P h o t o s o f t h e E U T Radiated Emission (30 MHz – 1 GHz) Radiated Emission (1 GHz – 18 GHz) Report No.: CQC-IVTS-2023-00311 Page 36 of 43 Radiated Emission (18 GHz – 42 GHz) Radiated Emission (Above 40 GHz)
