2AETNSP45413G smart phone

Page 1 Specifications Size 132.0*65.0*8.25mm Volume TBD Main Display 4.5 inch FWVGA Touch screen/ Support SIM card Type* Miro-SIM card System Used* GSM/GPRS 850 GSM/GPRS 1900 WCDMA/HSDPA Band V WCDMA/HSDPA Band II BT3.0+EDR IEEE 802.11b/g/n(HT20) Phone ook ca pacity* SIM according to card’s type, 250 in the mobile Camera/ vidicon/ vebcam Supported Hands free Supported Page 2 WAP/GPRS * Supported MP3/Record Supported VibrationMotor/BSupported Call Supported Incoming number Display* Supported Call Cost/ Fixed dialing * Supported(Need network support) Alarm clock/Calendar/W orld Time Supported Phone Supported Auto Redialing * Not supported * USB Supported (T-flash card) File Browsing St Supported Page 3 MENU Messages [New message.]: Write new text /Multimedia message [Search]：Search the messages of SIM1 and SIM2。 [Export SMS]：Export all the text message to the sd card。 [Import SMS]：Import all the text message to the phone。.. [Delete message]:Delete message (Lets you delete messages from selected multimedia messages folders) [Wappush messages]:view the wappush messages [Message settings]:Message settings(Includes options for changing the settings for reading. Writing and sending messages ,and check the availability of the options from your service provider) Page 4 [Message settings]:Message settings(Includes options for changing the settings for reading. Writing and sending messages ,and check the availability of the options from your service provider) Call Center You can view your recent call information. 【Call history】 [Sim1/Sim2 Call history]  All calls：recorder all calls history  Dialled calls： shows the most recently dialer numbers.  Received calls：Shows the phone numbers of answered incoming calls, if available from the network.  Missed call：shows the phone numbers of unanswered incoming calls, if available from the network. Page 5 Phone Book 【Add a new contact】：Add a new contact record. 【groups】: Contacts can be added to the group. 【Phonebook settings】 【Memory status】：Check the storage capacity of the SIM card. 【Preferred Storage】：Choose the storage position for the phonebook records. 【Copy contacts】： Provide two ways of copying from SIM1/SIM2 card to mobile, and from mobile to SIM1/SIM2 card. 【Delete all contacts】：Delete all the records in the SIM1/SIM2 card or the mobile, or delete items one by one. User profiles Lets you choose how your phone behavers in different environments by selection and customizing and a Page 6 combination of phone settings. The phone offer 5 profiles, as General /Silenet/ Meeting/ Outdoor /My style. And the profile settings as behind:  Alert type：Set up the alert style of alert  Ring type: Set up the Ring type  SIM 1 incoming call: Set the tone when SIM1 incoming call  SIM2 incoming call: Set the tone when SIM2 incoming call  Ringtone volume : set the Ring volume  SIM1 Message: Set up the alert style of SIM1 new message  SIM2 Message: Set up the alert style of SIM2 new message  Message volume: Set the message volume Page 7  Keypad tone: Set up the keypad tone  Power on: Set the Power on tone  Power Off: Set the Power off tone  System alert: Set the System alert 【Video Recorder】：  Camcorder Setting：Set the related parameters for the video camera.  Restore Default：Restore the video camera setting to defaults.  Recorder video : Click on the video button on the video 【Image Viewer】：View or modify photos saved in the album.  View: View the selected images Page 8  Browse Style：Set the align mode of photos from list files and matrix mode.  Use as: You can set up the photos to wallpaper, screen saver, power on/off display  Send: You can send out the photos via Bluetooth  Delete: Delete the picture chosen  Delete all files: Delete the all pictures  Sort by：Sort photos according to various modes. Audio Profiles Lets you choose how your phone behavers in different environments by selection and customizing and a combination of phone settings. The phone offer 4 profiles, as General /Silent/ Meeting/ Outdoor and you can add new profiles. The profile Page 9 settings as behind:  Vibrate: Set up Vibrate devices for incoming calls.  Volumes: Set up Ringtone & notifications and Alarms ring volumes  Voice call ringtone: Set your default voice calls ringtone  Video call ringtone: Set your default video calls ringtone  Default notification sound: Set system default notification sound  Dial pad touch tone: Set up the Dial pad tone on/off  Touch sounds: Set up touch sounds on/off  Screen lock sound: Set up screen lock sound on/off  Vibrate on touch: Set up whether vibrate on touch  【Video player】：  Play: Play the current video files. Page 10  Send: You can send out the video file via Bluetooth.  Delete: delete the current video file  Detail: for video information details 【Sound Recorder】  Record：Start recording.  Play：Play a selected record.  Append：Make additional recording for the selected record in .amr format.  Rename：Rename a selected record.  Delete：Delete a selected record.  List：View all sound recorder files in list  Settings：Set the position and the file format to save records. Page 11 Send：You can send out the sound recorder files via Bluetooth. 【FM radio】: [Channel list]: Set up the channel list and frequency [Channel operation]: search the prev,next channel that has searched in the channel list [seekbar operation]:use the seekbar to search your target channel [Auto search and settings]: choose the menu “search” then auto searching the channels [Settings]: You can modify some settings (such as Backgroud play , Loundspeker and so on) [Record]:You can record the audio file from FM radio and play/stop the recordfile [Append] Append the file to the recordfile list [File list] You can view the record file in the record list Page 12 [File list operation] You can handle the record file,for example play,rename,delete File Manager 【Phone】：  Open: Open a selected folder.  New folder: Built up a new folder  copy: Copying the files …
