2AEXY107DPRXMINI QUADCOPTER FPV PLUS

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 SHENZHEN HUBSAN INTELLIGENT COMPANY LIMITED 2015/12/2 To: SIEMIC, Inc. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, _____ SHENZHEN HUBSAN INTELLIGENT COMPANY LIMITED_____hereby authorize SIEMIC, Inc. to act as Certification Body for certifying for the following project(s): (Product description: MINI QUADCOPTER FPV PLUS, model name: H107D+,H107D) FCC ID : 2AEXY107DPRX Sincerely, Client’s signature Client’s name / title ：Sam LEE/CEO Contact information / address : 3th Floor, Bldg 1C,Shenzhen Software Industry Base, Xuefu Road, Nanshan District,Shenzhen,China,518054

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template& Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (obsolete) 3.0 4.0 March-26-2015 Corrections to STC form. Added reference to KDB (current) 4.0 5.0 Nov 19 2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 5.0 SHENZHEN HUBSAN INTELLIGENT COMPANY LIMITED 2015/12/2 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AEXY107DPRX Pursuant to sections 0.457 and 0.459 of CFR 47, we respectfully request permanent confidential treatment of the following Exhibits accompanying this application as: - e.g. Block Diagram - e.g. Schematics - e.g. Operational Description - e.g.FCC SW SECURITY DESCRIPTION The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Client’s name & title : Sam LEE /CEO Contact information / address: 13th Floor, Bldg 1C,Shenzhen Software Industry Base, Xuefu Road, Nanshan District,Shenzhen,China,518054

SHENZHENHUBSANINTELLIGENTCOMPANYLIMITED To ： SIEMIC,775MontagueExpressway,Milpitas,CA95035,USA DeclarationLetter DearSir ， Forourbusinessissueandmarketingrequirement,wewouldliketolist2model numbersontheFCCcertificatesandreports,asfollowing: ModelNo.:H107D+,H107D Wedeclarethat,allthemodelPCB,AntennaandAppearanceshape,accessoriesare thesame.Thedifferenceoftheseislistedasbelow: MainModelNoSerialModelNoDifference H107D+H107DDifferentmodelname Thankyou! Printedname/title:SamLEE/CEO Address:13thFloor,Bldg1C,ShenzhenSoftwareIndustryBase,XuefuRoad,Nanshan District,Shenzhen,China.518054

Test Report 15070788-FCC-E Page 19 of 28 Annex B. EUT And Test Setup Photographs Annex B.i. Photograph: EUT External Photo Whole package - Top View EUT - Front View EUT - Rear View EUT - Top View Test Report 15070788-FCC-E Page 20 of 28 EUT - Bottom View EUT - Left View EUT - Right View

Lable location

Test Report 15070788-FCC-E Page 21 of 28 Annex B.ii. Photograph: EUT Internal Photo EUT – Uncover View 1 EUT – Uncover View 2 Mainboard- Front View Mainboard- Rear View Mini Mainboard- Front View Mini Mainboard - Rear View Test Report 15070788-FCC-E Page 22 of 28 Camera – Front View Camera – Rear View Battery – Front View Battery – Rear View Antenna View

RF EXPOSURE REPORT Report No.: 15070788-FCC-H2 Applicant SHENZHEN HUBSAN INTELLIGENT COMPANY LIMITED Product Name MINI QUADCOPTER FPV PLUS Model No. H107D+ Serial No. H107D Test Standard FCC 2.1091:2014 Test Date November 11 to November 27,2015 Issue Date December 17, 2015 Test Result Pass Fail Equipment complied with the specification Equipment did not comply with the specification Winnie Zhang Test Engineer David Huang Checked By This test report may be reproduced in full only Test result presented in this test report is applicable to the tested sample only Issued by: SIEMIC (SHENZHEN-CHINA) LABORATORIES Zone A, Floor 1, Building 2 Wan Ye Long Technology Park South Side of Zhoushi Road, Bao’an District, Shenzhen, Guangdong China 518108 Phone: +86 0755 2601 4629801 Email: [email protected] Test Report 15070788-FCC-H22 Page 2 of 8 Laboratories Introduction SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management throughout a project. Our extensive experience with China, Asia Pacific, North America, European, and International compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets. Accreditations for Conformity Assessment Country/Region Scope USA EMC, RF/Wireless, SAR, Telecom Canada EMC, RF/Wireless, SAR, Telecom Taiwan EMC, RF, Telecom, SAR, Safety Hong Kong RF/Wireless, SAR, Telecom Australia EMC, RF, Telecom, SAR, Safety Korea EMI, EMS, RF, SAR, Telecom, Safety Japan EMI, RF/Wireless, SAR, Telecom Singapore EMC, RF, SAR, Telecom Europe EMC, RF, SAR, Telecom, Safety Test Report 15070788-FCC-H22 Page 3 of 8 This page has been left blank intentionally. Test Report 15070788-FCC-H22 Page 4 of 8 CO CONTENTS 1. REPORT REVISION HISTORY ............................................................................................................................ 5 2. CUSTOMER INFORMATION ................................................................................................................................ 5 3. TEST SITE INFORMATION ................................................................................................................................... 5 4. EQUIPMENT UNDER TEST (EUT) INFORMATION ......................................................................................... 6 5. FCC §2.1091 - MAXIMUM PERMISSIBLE EXPOSURE (MPE) ...................................................................... 7 6.1 APPLICABLE STANDARD ....................................................................................................................................... 7 6.2 TEST RESULT ........................................................................................................................................................... 8 Test Report 15070788-FCC-H22 Page 5 of 8 1. Report Revision History Report No. Report Version Description Issue Date 15070788-FCC-H2 NONE Original November 27, 2015 15070788-FCC-H2 V1 Change the modulation mode December 16, 2015 15070788-FCC-H2 V2 Delete WIFI related information December 17, 2015 2. Customer information Applicant Name SHENZHEN HUBSAN INTELLIGENT COMPANY LIMITED Applicant Add 13th Floor, Bldg 1C,Shenzhen Software Industry Base, Xuefu Road, Nanshan District,Shenzhen,China,518054 Manufacturer DONGGUAN TENGSHENG INDUSTIAL CO., LTD Manufacturer Add A22# Luyi Street, Tianxin Village, Tangxia Town, Dong guan, China 3. Test site information Lab performing tests SIEMIC (Shenzhen-China) LABORATORIES Lab Address Zone A, Floor 1, Building 2 Wan Ye Long Technology Park South Side of Zhoushi Road, Bao’ an District, Shenzhen, Guangdong China 518108 FCC Test Site No. 718246 IC Test Site No. 4842E-1 Test Software Radiated Emission Program-To Shenzhen v2.0 Test Report 15070788-FCC-H22 Page 6 of 8 4. Equipment under Test (EUT) Information Description of EUT: MINI QUADCOPTER FPV PLUS Main Model: H107D+ Serial Model: H107D Date EUT received: November 27, 2015 Antenna Gain: 1.6 dBi Input Power: Battery Spec: 3.7V, 520mAh, 2.0Wh Trade Name : HUBSAN FCC ID: 2AEXY107DPRX Type of Modulation: GFSK RF Operating Frequency (ies): 5725-5850MHz Number of Channels: 24CH Port: Power Port Test Report 15070788-FCC-H22 Page 7 of 8 5. FCC §2.1091 - Maximum Permissible exposure (MPE) 6.1 Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’ s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. Limits for General Population/Uncontrolled Exposure Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f 2 ) 30 30-300 27.5 0.073 0.2 30 300-1500 / / f/1500 30 1500-100,000 / / 1.0 30 f = frequency in MHz * = Plane-wave equivalent power density Test Report 15070788-FCC-H22 Page 8 of 8 6.2 Test Result WIFI Mode: Type Test mode CH Freq (MHz) Conducted Power (dBm) Tune Up Power (dBm) Output power 802.11 Low 5730 8.43 7.5±1 Mid 5795 7.08 7.5±1 High 5845 7.00 7.5±1 Predication of MPE limit at a given distance Where: S = power density (in appropriate units, e.g. mW/cm 2 ) P = power input to the antenna (in appropriate units, e.g., mW). G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor, is normally numeric gain. R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) For the antenna manufacturer provide only used limited to ERP/…

Text truncated - open the document above for the full version.

SHENZHEN HUBSAN INTELLIGENT COMPANY LIMITED MINI QUADCOPTER FPV PLUS Main Model: H107D+ Serial Model: H107D December 17, 2015 Report No.: 15070788-FCC-R2 (This report supersedes none) Modifications made to the product : None This Test Report is Issued Under the Authority of: Winnie Zhang Compliance Engineer David Huang Technical Manager This test report may be reproduced in full only. Test result presented in this test report is applicable to the representative sample only. Title: RF Test Report for MINI QUADCOPTER FPV PLUS Main Model: H107D+ Serial Model: H107D To: FCC Part 15.407: 2014, ANSI C63.10: 2013 Report No.: 15070788-FCC-R2 Issue Date: November 27, 2015 Page: 2 of 54 www.siemic.com.cn Laboratory Introduction SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management through out a project. Our extensive experience with China, Asia Pacific, North America, European, and international compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets. SIEMIC (Shenzhen-China) Laboratories Accreditations for Conformity Assessment Country/Region Scope USA EMC , RF/Wireless , Telecom Canada EMC, RF/Wireless , Telecom Taiwan EMC, RF, Telecom , Safety Hong Kong RF/Wireless ,Telecom Australia EMC, RF, Telecom , Safety Korea EMI, EMS, RF , Telecom, Safety Japan EMI, RF/Wireless, Telecom Singapore EMC , RF , Telecom Europe EMC, RF, Telecom , Safety Title: RF Test Report for MINI QUADCOPTER FPV PLUS Main Model: H107D+ Serial Model: H107D To: FCC Part 15.407: 2014, ANSI C63.10: 2013 Report No.: 15070788-FCC-R2 Issue Date: November 27, 2015 Page: 3 of 54 www.siemic.com.cn This page has been left blank intentionally. Title: RF Test Report for MINI QUADCOPTER FPV PLUS Main Model: H107D+ Serial Model: H107D To: FCC Part 15.407: 2014, ANSI C63.10: 2013 Report No.: 15070788-FCC-R2 Issue Date: November 27, 2015 Page: 4 of 54 www.siemic.com.cn CONTENTS 1 EXECUTIVE SUMMARY & EUT INFORMATION .......................................................................................... 5 2 TECHNICAL DETAILS ......................................................................................................................................... 6 3 MODIFICATION ..................................................................................................................................................... 7 4 TEST SUMMARY .................................................................................................................................................... 8 5 MEASUREMENTS, EXAMINATION AND DERIVED RESULTS ................................................................ 10 ANNEX A. TEST INSTRUMENT & METHOD ........................................................................................................ 38 ANNEX B. EUT AND TEST SETUP PHOTOGRAPHS ........................................................................................... 43 ANNEX C. TEST SETUP AND SUPPORTING EQUIPMENT ................................................................................ 48 ANNEX D. USER MANUAL / BLOCK DIAGRAM / SCHEMATICS / PART LIST ............................................ 52 ANNEX E. DECLARATION OF SIMILARITY ........................................................................................................ 53 Title: RF Test Report for MINI QUADCOPTER FPV PLUS Main Model: H107D+ Serial Model: H107D To: FCC Part 15.407: 2014, ANSI C63.10: 2013 Report No.: 15070788-FCC-R2 Issue Date: November 27, 2015 Page: 5 of 54 www.siemic.com.cn 1 EXECUTIVE SUMMARY & EUT INFORMATION The purpose of this test programme was to demonstrate compliance of the SHENZHEN HUBSAN INTELLIGENT COMPANY LIMITED , MINI QUADCOPTER FPV PLUS and model: H107D+ against the current Stipulated Standards. The MINI QUADCOPTER FPV PLUS has demonstrated compliance with the FCC Part 15.407: 2014, ANSI C63.10: 2013. EUT Information EUT Description : MINI QUADCOPTER FPV PLUS Main Model : H107D+ Serial Model : H107D Antenna Gain : 5.8GHz: 1.6 dBi Input Power : Battery Spec: 3.7V, 520mAh, 2.0Wh Classification Per Stipulated Test Standard : FCC Part 15.407: 2014, ANSI C63.10: 2013 Title: RF Test Report for MINI QUADCOPTER FPV PLUS Main Model: H107D+ Serial Model: H107D To: FCC Part 15.407: 2014, ANSI C63.10: 2013 Report No.: 15070788-FCC-R2 Issue Date: November 27, 2015 Page: 6 of 54 www.siemic.com.cn 2 TECHNICAL DETAILS Purpose Compliance testing of MINI QUADCOPTER FPV PLUS with stipulated standard Applicant / Client SHENZHEN HUBSAN INTELLIGENT COMPANY LIMITED 13th Floor, Bldg 1C,Shenzhen Software Industry Base, Xuefu Road, Nanshan District,Shenzhen,China,518054 Manufacturer DONGGUAN TENGSHENG INDUSTIAL CO., LTD A22# Luyi Street, Tianxin Village, Tangxia Town, Dong guan, China Laboratory performing the tests SIEMIC (Shenzhen-China) Laboratories Zone A, Floor 1, Building 2, Wan Ye Long Technology Park, South Side of Zhoushi Road, Bao'an District, Shenzhen, Guangdong, China Tel: +86-0755-2601 4629 / 2601 4953 Fax: +86-0755-2601 4953-810 Email: [email protected] Test report reference number 15070788-FCC-R2 Date EUT received November 10, 2015 Standard applied FCC Part 15.407: 2014, ANSI C63.10: 2013 Dates of test (from – to) November 11 to November 27,2015 No of Units : #1 Equipment Category : Spread Spectrum System/Device Trade Name : HUBSAN RF Operating Frequency (ies) 5725-5850MHz Number of Channels 5.725-5.850G: 24CH Modulation GFSK FCC ID 2AEXY107DPRX Title: RF Test Report for MINI QUADCOPTER FPV PLUS Main Model: H107D+ Serial Model: H107D To: FCC Part 15.407: 2014, ANSI C63.10: 2013 Report No.: 15070788-FCC-R2 Issue Date: November 27, 2015 Page: 7 of 54 www.siemic.c…

Text truncated - open the document above for the full version.

Title: RF Test Report for MINI QUADCOPTER FPV PLUS Main Model: H107D+ Serial Model: H107D To: FCC Part 15.407: 2014, ANSI C63.10: 2013 Report No.: 15070788-FCC-R2 Issue Date: November 27, 2015 Page: 47 of 53 www.siemic.com.cn Annex B.iii. Photograph 3: Test Setup Photo Radiated Spurious Emissions Test Setup Below 1GHz - Front View Radiated Spurious Emissions Test Setup Above 1GHz –Front View
