1 M98 manual Rechargeable and waterproof Training collar operating guide Please read this entire guide before beginning 2 Important safety information Warning Not for aggressive dogs. Do not use this product if your dog is aggressive, or if your dog is prone to aggressive behavior. Aggressive dogs can cause severe injury and even death to their owner and others. If you are unsure whether this product is appropriate for your dog, please consult your veterinarian of certified trainer. CAUSION Risk of skin damage. Please read and follow the instructions in this manual. Proper fitness of the collar is important .A collar worn for too long or made too tight on the pet’s neck may cause skin damage. Ranging from redness to pressure ulcers; this condition is commonly known as bed sores. •Avoid leaving the collar on the dog for more than 12 hours per day. •If possible reposition the pet’s neck every 1 to 2 hours. •Check the fitness to prevent excessive pressure; follow the instruction in this manual. •Never connect a lead to the electronic collar, it will cause excessive pressure on the contacts. •When using a separate collar for a lead, don’t put pressure on the electronic collar. •Wash the dog’s neck area and the contacts of the collar weekly with a damp cloth. •Examine the contact area daily for signs of a rash or a sore. •If a rash or sore is found, discontinue use of the collar until the skin has healed. •If the condition persists beyond 48 hours, see your veterinarian. These steps will help your pet safe and comfortable. Millions of pets are comfortable while they wear stainless steel contacts. Some pets are sensitive to contact pressure. You may find after some time that your pet is very tolerant of the collar. If so, you may relax some of these precautions. It is important to continue daily checks of the contact area. If redness or sores are found. discontinue use until the skin has fully healed. Thank you for choosing Pet trainer Rechargeable and Waterproof Training Collar. Our missing is to ensure your pet’s safety by providing you the tools and techniques to successfully train your pet. 3 Table of Contents Components---------------------------------------------------------------------------------------4 Key Definition-------------------------------------------------------------------------------------5 Features--------------------------------------------------------------------------------------------6 How the Pet trainer Rechargeable and Waterproof Training Collar Works---------------7 Operating Guide----------------------------------------------------------------------------------7 Prepare the Remote Transmitter--------------------------------------------------------------7 Prepare the Receiver Collar -------------------------------------------------------------------8 Encode between Remote Transmitter and Receiver Collar--------------------------------9 To Test Pet trainer Rechargeable and Waterproof Training Collar-----------------------10 Fit the Receiver Collar--------------------------------------------------------------------------12 Re--thread the Collar---------------------------------------------------------------------------13 Regular Maintenance-----------------------------------------------------------------------------13 Frequently Asked Questions---------------------------------------------------------------------14 Troubleshooting------------------------------------------------------------------------------------16 Find the Best Intensity Level for Your Pet------------------------------------------------------17 Common size of different dogs-------------------------------------------------------------------18 Common weight of dogs---------------------------------------------------------------------------18 WARNING Please charge before using the product! Of the transmitter and receiver collar don’t work for a long time, you should charge it fully before keeping it idle, and charging it every one month 4 Components M98 1 for 1 M98 1 for 2 5 Key Definition 1.antenna: transmit the signal to Receiver Collar 2.Led light :this light will be on when pressing LED light button 3.LED Indicator :this light will flash when transmitter works, or when charging, this light will be on. 4.LCD Screen: •Static mode: under this mode, press Y button, Receiver will shock; press UP/sown button, can adjust vibration level from 0 to 100 •Beep mode: under this mode, press Y button, the receiver collar can get a “beep” sound •Light mode: under this mode, press Y button, the green LED light in the receiver will flash every one second, it is convenient to let you know where your pet is. •Channel 1: select to encode between transmitter and one of receiver collar •Channel 2: select to encode between transmitter and 2 nd of receiver collar 5.Up/down button: Intensity level button for vibration and static shock. 6.Led light button: when pressing the LED light button, the led light in the transmitter will be on 6 7.Channel button: press this button, can select to encode between transmitter and one of receiver collar, or between transmitter and 2 nd of receiver collar. 8.Launch button: after you finish mode selecting, press this button for confirmation 9.Mode button: include 4 modes as static mode, vibration mode ,beep mode and led light mode 10.The sound function 11.Speaker hole A when charging the battery, the red LED light shows up and changes to green LED light after fully charged B in LED light mode, press the launch button, the green LED in the receiver collar will flash every one second C When standby, the receiver collar will flash green LED light every four seconds D After turn on the receiver collar, press and hold the On/Off/Encode button for 5 seconds to enter encoding period the green LED light will keep flashing for 10 seconds to indicate the encoding time. Features 1.Chargeable remote transmitter and receiver collar 2.Waterproof receiver collar your pet can swim in the water 3.100levels of…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Shenzhen Cuter Pet Supply Co., LTD. 5F Building One,FuFengDa Industrial District,BaiShiXia Village,Fuyong street,Baoan Distric,Shenzhen, China 2015/06/02 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, Shenzhen Cuter Pet Supply Co., LTD. hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product description: Rechargeable and Waterproof Training Collar model name: M98, M328,M368,M388,M39,M518,M613,M661,M688,M81,M850, M853,M86,M87,M88,M89,M90,M900,M91,M99,M998 Trademark: N/A FCC ID: 2AEYLM98 Sincerely, Client’s signature Client’s name / title : Michael Lee / Engineer Contact informations: 5F Building One,FuFengDa Industrial District,BaiShiXia Village,Fuyong street,Baoan Distric,Shenzhen, China.

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 Shenzhen Cuter Pet Supply Co., LTD. 5F Building One,FuFengDa Industrial District,BaiShiXia Village,Fuyong street,Baoan Distric,Shenzhen, China 2015/06/02 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AEYLM98 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Client’s name / title : Michael Lee / Engineer Contact informations: 5F Building One,FuFengDa Industrial District,BaiShiXia Village,Fuyong street,Baoan Distric,Shenzhen, China.

Shenzhen Cuter Pet Supply Co., LTD. 5F Building One,FuFengDa Industrial District,BaiShiXia Village,Fuyong street,Baoan Distric,Shenzhen, China Model Difference FCC ID: 2AEYLM98 Product description: Rechargeable and Waterproof Training Collar Model : M98, M328,M368,M388,M39,M518,M613,M661,M688,M81,M850, M853,M86,M87,M88,M89,M90,M900,M91,M99,M998 All the models are the same circuit and RF module, except the mode names. Regards Sincerely Client’s signature Client’s name / title : Michael Lee / Engineer Contact informations: 5F Building One,FuFengDa Industrial District,BaiShiXia Village,Fuyong street,Baoan Distric,Shenzhen, China.

M/N: M98 FCC ID: 2AEYLM98 Label location

Antenna location

Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15050059 FCC Part 15C Test Report FCC ID: 2AEYLM98 Product Name: Rechargeable and Waterproof Training Collar Trademark: N/A Model Name : M98, M328,M368,M388,M39,M518,M613,M661,M688,M81,M850, M853,M86,M87,M88,M89,M90,M900,M91,M99,M998 Prepared For : Shenzhen Cuter Pet Supply Co., LTD. Address : 5F Building One,FuFengDa Industrial District,BaiShiXia Village,Fuyong street,Baoan Distric,Shenzhen, China Prepared By : Shenzhen BCTC Technology Co., Ltd. Address : No.101,Yousong Road,Longhua New District, Shenzhen,China Test Date: May 25 – May 31, 2015 Date of Report : Jun. 3, 2015 Report No.: BCTC-15050059 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15020059 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 2 of 31 VERIFICATION OF COMPLIANCE Applicant’s name ................. : Shenzhen Cuter Pet Supply Co., LTD. Address ................................. : 5F Building One,FuFengDa Industrial District,BaiShiXia Village,Fuyong street,Baoan Distric,Shenzhen, China Manufacture's Name ............ : Shenzhen Cuter Pet Supply Co., LTD. Address ................................. : 5F Building One,FuFengDa Industrial District,BaiShiXia Village,Fuyong street,Baoan Distric,Shenzhen, China Product description Product name ........................... : Rechargeable and Waterproof Training Collar Trademark: N/A Model Name: M98, M328,M368,M388,M39,M518,M613,M661,M688,M81, M850,M853,M86,M87,M88,M89,M90,M900,M91,M99,M998 Test procedure FCC Part15.231 Standards ANSI C63.10-2013 This device described above has been tested by BCTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Test Result ............................................... : Pass Testing Engineer : (Eric Yang) Technical Manager : (Sophia Lee) Authorized Signatory : (Carson. Zhang) Table of Contents Page Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15020059 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 3 of 31 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 7 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 8 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 9 3 . EMC EMISSION TEST 10 3.1 CONDUCTED EMISSION MEASUREMENT 10 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 10 3.1.2 TEST PROCEDURE 11 3.1.3 DEVIATION FROM TEST STANDARD 11 3.1.4 TEST SETUP 11 3.1.5 EUT OPERATING CONDITIONS 11 3.1.6 TEST RESULTS 12 3.2 RADIATED EMISSION MEASUREMENT 14 3.2.1 RADIATED EMISSION LIMITS 14 3.2.2 TEST PROCEDURE 15 3.2.3 TEST SETUP 16 3.2.4 EUT OPERATING CONDITIONS 17 3.2.5 TEST RESULTS 18 4 . BANDWIDTH TEST 23 4.1 APPLIED PROCEDURES / LIMIT 23 4.1.1 TEST PROCEDURE 23 4.1.2 DEVIATION FROM STANDARD 23 4.1.3 TEST SETUP 23 4.1.4 EUT OPERATION CONDITIONS 23 4.1.5 TEST RESULTS 24 5 . CALCULATION OF AVERAGE FACTOR 25 6 . DWELL TIME 27 6.1 DEVIATION FROM STANDARD 27 6.2 TEST SETUP 27 6.3 EUT OPERATION CONDITIONS 27 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15020059 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 4 of 31 Table of Contents Page 6.4 TEST RESULTS 28 7 . ANTENNA REQUIREMENT 29 7.1 STANDARD REQUIREMENT 29 7.2 EUT ANTENNA 29 8 . EUT TEST PHOTO 30 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15020059 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 5 of 31 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.231) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.209,15.231b Radiated Emission Test PASS 15.231c 20dB Occupy Bandwidth PASS 15.231a Dwell time PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15020059 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 6 of 31 1.1 TEST FACILITY Shenzhen BCTC Technology Co., Ltd. Add.:No.101,Yousong Road,Longhua New District, Shenzhen,China FCC Registration No.:187086 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15020059 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 7 of 31 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Rechargeable and Waterproof Training Collar Trade Name N/A Model Name M98 Serial Model M328,M368,M388,M39,M518,M613,M661,M688,M81, M850,M853,M86,M87,M88,M89,M90,M900,M91,M99, M998 Model Difference All the same,Only model name is different. Product Description The EUT is a Rechargeable and Waterproof Training Collar Operation Frequency: 433.92MHz Modulation Type: ASK Antenna Designation: Integral Antenna Gain 3dBi Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Adapter N/A Battery DC 3.7V Connecting I/O Port(s) Please refer to the User's Manual Note: 1. For a more detailed f…
