User's Guide for GPS tracker watch. User's Guide for GPS tracker watch ETK‐GPS001 User's Guide for GPS tracker watch. Dear Sir/Madam： Sincerely thank you for purchasing the Children Positioning Watch which features locating the child. The main functions of this type of watch are listed as below: Emergency calling: Child can call for help by pressing SOS button in case of emergency; Precise localization: Guardian can obtain the child’s accurate location at any moment; Remote voice monitoring: Guardian can listen to the surrounding voices around the child; Remote alarm clock: Alarm clock can be set to warn the child to do something in his/her power; Electronic fence: Fence can be set to alarm the Guardian whenever the child enters or leaves the fence; Bi‐directional calling: Child can call his/her friends while the Guardian can call the child at any time. In order to better use the watch, please read the following instructions carefully and operate the watch according to the following instructions and suggestions. User's Guide for GPS tracker watch. Safety Warning  Use only the original accessories recommended by the manufacturer. Different models may result in danger and lead this product with all relevant licenses invalid.  Do not attempt to repair it yourself, for the modification to the product will affect the security of the product, and be careful of danger.  Avoid using the watch in the following environment: places with excessive temperature fluctuations, places with the temperature higher than 60°C or lower than 0°C, places with high pressure, dust or electrostatic interference.  Avoid touching with corrosive cleaning agents and chemicals, please use a soft, dry cloth to clean the watch.  It is prohibited to use the watch at the gas stations, restricted chemical plants or near the oil depots, for the use of the watch in the above environment may raise the risk of explosion.  When you are travelling on the airplane, please take care to place the watch in the baggage, and try not to place it in the handbag while going through the checkpoint, and the manufacturer is not responsible for the damage caused by such radiation. User's Guide for GPS tracker watch. Instructions on batteries & handling batteries  Batteries are not allowed to be thrown into the trashcan. As a consumer, you are legally required to handle and collect the used batteries properly.  Note that the battery positive and negative direction, if opposite, it may cause damage to the device.  It is prohibited to try to open the batteries or throw batteries into fire.  The liquid flowing from the batteries is very dangerous, and one cannot touch it unless wearing suitable gloves.  Never place the battery in the hands of children.  Remove the battery from the device if you do not use it for a long time. User's Guide for GPS tracker watch. Product Details Speaker: Do not cover it when calling MIC: Do not cover it when calling Charging interface: Connect the watch with power input to charge it Reset button: The watch can be reset by pressing the pinhole with fine needle in case of a dead halt SOS dialing/answer: Press the button for 3 seconds to dial out an emergency number in case of emergency, and short press the button to answer the incoming call, while short press the button to hang up under the condition of normal conversation. Tips: The watch will not be shutdown unless the battery is removed from it. Speaker Reset button Charging interface SOS dialing/Answer MIC Display screen User's Guide for GPS tracker watch. Operation Guide Plug‐in card: Open the rear cover of the watch and place SIM/UIM card into the slot as per the direction shown in the slot and find the golden contact and place the battery into place, finally put on the rear cover. Power on: Press SOS button for 3 seconds to start up the watch. (The mobile phone will not read its IMEI/SN unless the card has been plugged into the watch) Install APP: Please install the watch APP on your mobile phone before using the watch.  Scan QR code with your mobile phone on the back of packing box to download the watch APP; you can also enter http://dl.vmall.com/c0317gptlf to obtain the watch APP.  After installation, please create a new account and enter basic information when prompted, and then you'll get into the sign in interface to enter the phone number and password that you have entered while registering, and finally click “sign in” to enter. User's Guide for GPS tracker watch. Add Devices Click “ ” on device interface or swipe left on the screen to enter management interface, and then click “Add” on the top right of the screen, finally scan the bar code or enter the device number to add the device (The bar code stays on the back of the packing box, while the number under the bar code is the device number). Click here to scan bar code Click here to enter device part number User's Guide for GPS tracker watch. Manage Devices Long press certain device on the management interface to delete the device; click device number to enter Modify interface on which basic information, emergency numbers, monitor numbers, friends numbers, alarm clock can be set and the password of the device can be altered. User's Guide for GPS tracker watch. Emergency numbers: Three emergency numbers can be set to which the child can call for help by pressing SOS button for 3 seconds in case of emergency, and the watch will dial these 3 numbers for twice (the watch will stop dialing automatically once the call has been connected). Monitor numbers: 2 monitor numbers can be set by which commands can be given from the phone to monitor the surrounding voices around the child. Friends numbers: 5 numbers of friends can be set to which the child can call: list of friends numbers will be displayed by short pressing SOS button on home interface, and press it again to select one number from the list, and then after selection, long press SOS button to dial out. Alarm clock: Set alarm clock for the …
