2AEZGVICTSINGBluetooth Speaker

The Speaker has a fever phenomenon when normally operated or charging, it’s normal. If you need to clean the speaker. Please turn off the speaker and disconnect it with all external devices before cleaning. Do not drop or trample the speaker. use alcohol, benzene and other chemicals to clean the the Speaker. put it close to the extreme cold or hot objects. Please use the accessories provided original. dismantle the speaker without authorization. The service time of the Speaker’s battery depends on the output volume of the matched mobile phone. Please turn down the volume of your cell phone to about 70% of the maximum volume, which can prolong the service time. The Protective Level of the speaker reaches IP65 , splash is ok , but it can not be submerged into the water . Do notDo notDo not Precaution USB Cord 1PCS Instruction Book/Warranty Car d 1PCS Operating Instruction : 1. Turn on the Speaker, the LED indicator light will flash, voice prompt s “power on” at the same time. 2. Turn on the Bluetooth function of your Smartphone. 3. Search for the Bluetooth devices and select "C6" from the list. 4. Click it and pair the speaker with your Smartphone. 5. Enter the code "0000" if needed. 6. After successfully paired, the speaker can play music of you r Smartphone. 7. For next time, you just need to press the“ON/OFF”button until you hear "power o n" and release it, then thespeaker will connect to your mobile device automatically. Pair it with your Bluetooth Device: USB charging : Connect the speaker with computer or mobile by USB charging cable. Red led light means charging the speaker. The led light indicator turning off means speaker be fully charged. This charging method i s a l ittle slow, it will take about 5-6 hours to full charge the speaker. It will be faster charging with mob ile power adapter (5V 1A), it is about 2-3 hours. Speaker can also work during charge. 1.The fashion designed bluetooth speaker can offer you endless enjoyment when you are travelling on the road. 2.It has bluetooth function and can wirelessly connect with other mobile devices, and it is attached with an Aluminum alloy hook. You can conveniently hang this Speaker on the mountaineering bag o r a bicycle with the hook. 3.It has built-in MIC Bluetooth speaker and hands-free function, so you can conveniently pick u p a call by this mini Speaker in car, bathroom, at home or office, anywhere when it is connected to your Smartphone. 4.The suction cup on the back of the Speaker can be easily attached on the wall or any flat surface and is great for shower, baths, swimming pools, and boats, etc. 5.After the speaker is suspended for 15 minutes, it will shut down automatically Product overview : In order to let you enjoy the service better, Please read following agreement: The validity period of product warranty starts from the date of sale (“three guarantees”). During the validity period of “three guarantees”, the malfunction of this product will be solved according to the provision o f “three guarantees”: repair, replacement or return. During validity period of product warranty, the Company provides free maintenance service (exceeds the range of warranty). And, during the “three guarantees” period, the company will implement the paid service for following cases: 1.Cannot show the original warranty and effective invoice 2.The malfunction and damage are caused by irresistible factors and other reasons 3.The damage and failure are caused by your error in operation (not in accordance with th e “manual” of normal operation) 4.The failure and damage are caused by the transportation 5.The failure and damage are caused by the fault disassembly and maintenance without prior authorization of company. As for fault repair, please return the warranty card and sale invoice, and you need to deliver the warranty card and sales invoice together to after-sales service center and afford the transportation fees by yourself. The key definitions : 1. Long press the “ ” button to increase the volume, and short press the button to play the next song. 2. Long press the “ ” button to decrease the volume, short press the button to play the previous song. 3. The button is used to control music (play/pause) and calls. During playing music, short press the button to stop playing music. And, when there is an incoming call, the Speaker will automatically stop playing music, at that moment, the ring of cell phone sounds. You just need to click the button to answer the incoming call and long press the button to refuse the incoming calls. After answering the incoming call, click this button again to hang up the call. Also click the button twice to automatically redial the last telephone number. “ ” Specification: Input voltage: DC-5V/600MA Output power: 5W TH D + N ≤10% (1Khz/0dB) Polymer battery: 3.7V/500mAh Speaker unit: Φ 45 mm 4ohm/5W Frequency Response: 120Hz-22 kHz S/N: ≥90DB Weight: 145g Size: 87mm (W ) x 45mm (D) x 95mm (H) Working time: 3-4.5 hours Stand by time: 2 weeks Warranty Agreement : This is a Waterproof indoor/outdoor Wireless A2DP Bluetooth 3.0 Speaker With Built-in Microphone. It supports most Bluetooth cell phones, PDA, tablet PC, iPad, Mac Air, MP3 players, PCs, laptops and any other electronic devices with Bluetooth function. And, it has double built-in MIC, so you can enjoy music without the hassle of long cable. You can use this item at home, office, car and of course in your bath room ! Great suction cup and it ’s 5W speaker will offer you a nice using experience, you will love it! Hook 1PCS This equipment has been tested and found to comply with the limits fo r a C lass B d igital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protect ion against harmful interference i n a r esidential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruct ions, may cause harmful interference to radio communicat…

Text truncated - open the document above for the full version.

SHENZHEN COMISO DIGITAL TECHNOLOGY LIMITED 12/F, XinLong Technology Park, SongGang Town, BaoAn District, ShenZhen City, China. DATE :2015-07-21 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Hank.Yan of Global United Technology Services Co., Ltd. 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District Shenzhen Guangdong to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with SHENZHEN COMISO DIGITAL TECHNOLOGY LIMITED and 12/F, XinLong Technology Park, SongGang Town, BaoAn District, ShenZhen City, China. Dated this / Day of 07/21/2015 / Agency agreement expiration date: 07/21/2016 By: Wei Chen Signature Printed Title: Manager On behalf of : SHENZHEN COMISO DIGITAL TECHNOLOGY LIMITED Telephone: 0755-27534600

Differences Declaration To whom concern, We company SHENZHEN COMISO DIGITAL TECHNOLOGY LIMITED hereby declares: The product model(s) Mpow Buckler, PA57, PA89, C6 is identical in the same PCB layout, interior structure and electrical circuits with the model VICTSING which tested in Global United Technology Services Co., Ltd., the only differences are the model name for commercial purpose. Authorized signature: Position: Manager Date: 2015-7-21

SHENZHEN COMISO DIGITAL TECHNOLOGY LIMITED 12/F, XinLong Technology Park, SongGang Town, BaoAn District, ShenZhen City, China. 2015-07-21 Equipment Authorization Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AEZGVICTSING Product Name: Bluetooth Speaker Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics  Block diagram  Operational Description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 07/21/2015 By: Wei Chen Signature Printed Title: Manager On behalf of : SHENZHEN COMISO DIGITAL TECHNOLOGY LIMITED Telephone: 0755-27534600

FCC ID: 2AEZGVICTSING This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Label Location Label location

FCC ID: 2AEZGVICTSING According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where --f(GHz) is the RF channel transmit frequency in GHz --Power and distance are rounded to the nearest mW and mm before calculation --The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m) --- 3m So pt = (EXd) 2 /30 x gt Field strength = 95.60dBuV/m @3m Ant gain =0dBi, so Ant numeric gain= 1 So pt={ [10 (95.60) /10 6 x 3] 2 /30x1 }x1000 mW = 1.089mW So (1.089mW /5mm)x √2.441 = 0.34<3 Then SAR evaluation is not required

Global United Technology Services Co., Ltd. Report No.: GTSE15070130601 FCC REPORT Applicant: SHENZHEN COMISO DIGITAL TECHNOLOGY LIMITED Address of Applicant: 12/F, XinLong Technology Park, SongGang Town, BaoAn District, ShenZhen City, China. Equipment Under Test (EUT) Product Name: Bluetooth Speaker Model No.: VICTSING, Mpow Buckler, PA57, PA89, C6 FCC ID: 2AEZGVICTSING Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.249:2014 Date of sample receipt: July 15, 2015 Date of Test: July 16-20, 2015 Date of report issued: July 21, 2015 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Authorized Signature: Robinson Lo Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the GTS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of GTS or testing done by GTS in connection with, distribution or use of the product described in this report must be approved by GTS in writing. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. Report No.: GTSE15070130601 2Version Version No.DateDescription 00July 21, 2015Original Prepared By: Date: July 21, 2015 Project Engineer Check By:Date: July 21, 2015 Reviewer Global United Technology Services Co., Ltd.Project No.: GTSE150701306RF Room 301-309, 3th Floor, Block A, Huafeng Jinyuan Business Building, No. 300 Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, China Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960Page 2 of 30 Tested By: Report No.: GTSE15070130601 3Contents Page 1 COVER PAGE............................................................................................................................................ 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 4.1 MEASUREMENT UNCERTAINTY............................................................................................................ 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 CLIENT INFORMATION......................................................................................................................... 5 5.2 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.3 TEST MODE........................................................................................................................................ 7 5.4 DESCRIPTION OF SUPPORT UNITS....................................................................................................... 7 5.5 TEST FACILITY.................................................................................................................................... 7 5.6 TEST LOCATION................................................................................................................................. 7 5.7 OTHER INFORMATION REQUESTED BY THE CUSTOMER......................................................................... 7 6 TEST INSTRUMENTS LIST ..................................................................................................................... 8 7 TEST RESULTS AND MEASUREMENT DATA...................................................................................... 9 7.1 ANTENNA REQUIREMENT..................................................................................................................... 9 7.2 CONDUCTED EMISSIONS................................................................................................................... 10 7.3 RADIATED EMISSION METHOD........................................................................................................... 13 7.3.1 Field Strength of The Fundamental Signal ................................................................................ 15 7.3.2 Spurious emissions.................................................................................................................... 16 7.3.3 Bandedge emissions.................................................................................................................. 20 7.4 20DBOCCUPY BANDWIDTH.............................................................................................................. 21 8 TEST SETUP PHOTO ............................................................................................................................ 23 9 EUT CONSTRUCTIONAL DETAILS .....................................................................................................25 Global United Technology Services Co., Ltd.Project No.: GTSE150701306RF Room 301-309, 3th Floor, Block A, Huafeng Jinyuan Business Building, N…

Text truncated - open the document above for the full version.

Global United Technology Services Co., Ltd. Report No.: GTSE15070130602 FCC REPORT Applicant: SHENZHEN COMISO DIGITAL TECHNOLOGY LIMITED Address of Applicant: 12/F, XinLong Technology Park, SongGang Town, BaoAn District, ShenZhen City, China. Equipment Under Test (EUT) Product Name:Bluetooth Speaker Model No.:VICTSING, Mpow Buckler, PA57, PA89, C6 FCC ID: 2AEZGVICTSING Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.249:2014 Date of sample receipt: July 15, 2015 Date of Test: July 16-20, 2015 Date of report issued: July 21, 2015 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Authorized Signature: Robinson Lo Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the GTS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of GTS or testing done by GTS in connection with, distribution or use of the product described in this report must be approved by GTS in writing. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. Report No.: GTSE15070130602 2Version Version No.DateDescription 00July 21, 2015Original Prepared By: Date: July 21, 2015 Project Engineer Check By:Date: July 21, 2015 Reviewer Pj tE i Global United Technology Services Co., Ltd.Project No.: GTSE150701306RF Room 301-309, 3th Floor, Block A, Huafeng Jinyuan Business Building, No. 300 Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, China Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960Page 2 of 24 Tested By: Report No.: GTSE15070130602 3Contents Page 1 COVER PAGE............................................................................................................................................ 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 4.1 MEASUREMENT UNCERTAINTY............................................................................................................ 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 CLIENT INFORMATION......................................................................................................................... 5 5.2 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.3 TEST MODE........................................................................................................................................ 7 5.4 DESCRIPTION OF SUPPORT UNITS....................................................................................................... 7 5.5 TEST FACILITY.................................................................................................................................... 7 5.6 TEST LOCATION................................................................................................................................. 7 5.7 DESCRIPTION OF SUPPORT UNITS....................................................................................................... 7 5.8 OTHER INFORMATION REQUESTED BY THE CUSTOMER......................................................................... 7 6 TEST INSTRUMENTS LIST ..................................................................................................................... 8 7 TEST RESULTS AND MEASUREMENT DATA...................................................................................... 9 7.1 ANTENNA REQUIREMENT..................................................................................................................... 9 7.2 CONDUCTED EMISSIONS................................................................................................................... 10 7.3 RADIATED EMISSION METHOD........................................................................................................... 13 7.3.1 Field Strength of The Fundamental Signal ................................................................................ 15 7.3.2 Spurious emissions.................................................................................................................... 16 7.3.3 Bandedge emissions.................................................................................................................. 20 7.4 20DBOCCUPY BANDWIDTH.............................................................................................................. 21 8 TEST SETUP PHOTO ............................................................................................................................ 23 9 EUT CONSTRUCTIONAL DETAILS .....................................................................................................2…

Text truncated - open the document above for the full version.

Radiated Emission Conducted Emission
