1 USER’S MANUAL JT-1501 2 Table of Contents... Chapter 01 Introduction Chapter 02 Safety precaution Chapter 03 About device and OS 1 Charging the battery 2 Switching on/off 3 Unlocking the screen 4 Restarting the device 5 Factory reset 6 Home page 7 Function operations 8 Settings 9 Wireless Network 10 Bluetooth 11 USB connection 12 Installation of application 13 Uninstallation of application Chapter 04 Specifications Chapter 05 Troubleshooting 3 Chapter 01 Introduction Congratulations on the purchase of the Tablet ! This device is built-in high performance Wifi receiver module, G-sensor, also can bring you into the portable media Tablet world and fulfilled your entertainment needs. It can support picture, video, music, E-book, games, online chat and other functions, moreover, various settings will fully show your individuality. This manual contains important safety and operating information in order to prevent accidents, please read this manual thoroughly and keep it for future reference. Chapter 02 Safety precautions  To use this Tablet safely, please read and follow the instructions in this manual carefully before use.  Never use the Tablet while driving or when operating any vehicle, as this could cause an accident. It is also against the law in many areas. Take care when using the Tablet outdoors, especially when crossing the street.  Do not listen to music at very high volumes using the earphones as this can permanently damage your hearing.  Keep the Tablet clean and never store it next to a heat source or in dirty, humid or wet places. Keep it out of direct sunlight. 4  Do not put the Tablet in high temperature places (over 40 º C), especially not in a car with the windows closed in summer.  Keep the Tablet away from strong magnetic fields.  Please don‟t turn on the device in where the wireless equipment is forbidden or when the usage of the device will cause interference and danger.  Press the Tablet‟s buttons gently. Pressing them or the screen too hard can damage the Tablet.  Do not use the Tablet in an electronics-prohibited area, such as in an airplane.  Do not use the Tablet in an extremely dry environment, as this can lead to static discharge, which can damage the Tablet.  Do not subject the product to harsh impacts.  Do not drop the appliance. This may result in damage to the product.  Do not attempt to dismantle or repair this unit yourself, Repairs should only be performed by qualified personnel only.  We will not be responsible for any memory loss caused by product damage, repairs or other reasons.  Disconnect the appliance from the power source when cleaning.  In order to prevent program failure, never disconnect the Tablet suddenly from a PC during downloading, uploading or formatting to prevent program failure. 5  Use a slightly damp, lint-free cloth to clean this appliance. Do not dismantle the Tablet or use alcohol, thinner or benzene to clean the surface of the Tablet . Chapter 03 About device Below is the six view structure. 1. Headphone jack 2. Volume +/- key 3. Power Key 4. USB port slot 5. MicroSD card slot 6 6. MicroSIM card slot 7. Back Camera 1. Charging the battery Important: The battery must be charged for at about 3 hours before using it for the first time. 2. Switching on/off To switch on the Tablet PC, press and hold the "power" button. When startup window appears, release the button. The system initialization may take several minutes. Please wait patiently. To switch off the tablet PC, press and hold the "power" button, when "power off " message appears, release the button. Touch the message, then press OK. 7 3.Unlocking the screen If you do not use the screen during certain period of time, the screen will be locked. To unlock the screen, press the power button once and drag "Lock" image right. 4.Restarting the device If the screen does not response to key press or tap, keep power button for long time to restart your Tablet PC 5.Factory reset To delete all data and restore your Tablet PC to factory defaults, touch“Settings” ->“Backup&reset” ->“Factory data reset” ->“Reset tablet” 8 6.Home page The Home screen gives you an overview of the contents of your device and gives you access to all of it‟s available functions and applications. 1.Google Search 2.Notification bar 3. Back icon 4. Home icon 5. Recent Apps 9 7. Functions Operation Click the related program icons to enter corresponding functions. 7.1 Music Click „Music‟ icon to open the music application. This application is used to play and store MP3 audio files. 7.2 Photo/Video Click „Photo‟, you will see all photos in this application. Click the photo files and review it. 7.3 Browser Click „Browser‟ icon to open „web browser‟ application and freely browse the internet. (Before you enter into website, please check you connect the wifi) 7.4 Camera Click „Camera‟ icon to open camera application. You can take a photo or make the video recording. 7.5 Calculator Click „Calculator‟ icon to open the calculator 10 application. This calculator is used to perform advanced mathematical operations. Use the number pad to enter the numbers. 7.6 Calendar Click „Calendar‟ icon to open the calendar application. You can personalize and add your memorandum. 7.7 Clock Click „Clock‟ icon to open the Clock application. You can personalize and program several types of alarms. 7.8 Email Click „Email‟ icon to open the email application and go directly to your personal e-mail software. This application is compatible with most e-mail software and is used to easily read, send and receive e-mails. 7.9 File Manager Click „File Manager‟ icon to open your tablet‟s navigator and have access to the contents of your Micro SD or device‟s internal memory. 11 8.Setti ngs 12 8.1 Wifi Turn on the wifi and connect it. 8.2 Bluetooth Turn on the Bluetooth 8.3 Data usage Set data usage cycle. 8.4 Sound Set the volumes, system sounds 8.5 Display Set the brightness, wallpaper, screensaver etc. 8.6 Storage Show all storage and s…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2Rev 5.0 Jolla Ltd. 2015.7.20 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, Jolla Ltd. hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): (Product description, model name): Product description: Tablet computer model name: JT-1501 FCC ID: 2AEZWJT-1501 Sincerely, Client’s signature : Jari-Pekka Walden Client’s name / title: Test Manager Applicant company：Jolla Ltd. address： Kalevantie 2, Tampere, Finland

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 Jolla Ltd. 2015.7.20 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AEZWJT-1501 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Jari-Pekka Walden Client’s name & title : Test Manager Contact information / address: Jolla Ltd. / Kalevantie 2, Tampere, Finland

Project No: STS1506051 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Project No: STS1506051 Photo 3 Photo 4 Project No: STS1506051 Photo 5 Photo 6

Label Tablet computer Model name: JT-1501 FCC ID: 2AEZWJT-1501 IC: 20283-JT1501 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. label

Project No: STS1506051 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 BT/WIFIANTENNA GPS ANTENNA Project No: STS1506051 Photo 3 Photo 4 Project No: STS1506051 Photo 5 Photo 6 Project No: STS1506051 Photo 7

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC Part 15B TEST REPORT Report No: STS1506051E01 Issued for Jolla Ltd. Kalevantie 2, Tampere, Finland Product Name: Tablet computer Brand Name: Jolla Model No.: JT-1501 Series Model: N/A FCC ID: 2AEZWJT-1501 IC: 20283-JT1501 Test Standard: FCC Part 15B ICES-003 Issue 5 S T L A B S Page 2 of 23 Report No.: STS1506051E01 Testing Engineer : (Hakim Hou) Technical Manager : (Vita Li) Authorized Signatory : (Bovey Yang) TEST RESULT CERTIFICATION Applicant’s name ................. : Jolla Ltd. Address .................................. : Kalevantie 2, Tampere, Finland Manufacture's Name ............ : Borqs BeiJing Ltd. Address .................................. : Tower A, Building B23, Universal Business Park, No. 10 Jiuxianqiao Road, Chaoyang District Beijing, 100015 China Product description Product name ......................... : Tablet computer Band name ............................ : Jolla Model and/or type reference .. : JT-1501 Standards ............................. : FCC Part 15B ICES-003 Issue 5 Test procedure ........................... : ANSI C63.4-2014 This device described above has been tested by STS, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test .......................................... : Date of performance of tests ................ : 11 June. 2015 ~18 June. 2015 Date of Issue ........................................ : 19 June. 2015 Test Result ........................................... : Pass Page 3 of 23 Report No.: STS1506051E01 Table of Contents 1. SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2. GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST MODES 7 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 7 2.4 DESCRIPTION OF SUPPORT UNITS 8 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 9 3. EMC EMISSION TEST 10 3.1 CONDUCTED EMISSION MEASUREMENT 10 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 10 3.1.2 TEST PROCEDURE 11 3.1.3 DEVIATION FROM TEST STANDARD 11 3.1.4 TEST SETUP 11 3.1.5 EUT OPERATING CONDITIONS 11 3.1.6 TEST RESULTS 12 3.2 RADIATED EMISSION MEASUREMENT 14 3.2.1 RADIATED EMISSION LIMITS 14 3.2.2 TEST PROCEDURE 15 3.2.3 DEVIATION FROM TEST STANDARD 15 3.2.4 TEST SETUP 16 3.2.5 EUT OPERATING CONDITIONS 17 3.2.6 TEST RESULTS 18 4. PHOTOS OF TEST SETUP 22 Page 4 of 23 Report No.: STS1506051E01 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 19 June. 2015 STS1506051E01 ALL Initial Issue Page 5 of 23 Report No.: STS1506051E01 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: EMISSION Standard Item Result Remarks FCC 47 CFR Part 15 & ICES-003 Issue 5 Subpart B (10-1-05 Edition) Conducted Emission PASS Meet Class B limit Radiated Emission PASS Meet Class B limit NOTE: (1) ” N/A” denotes test is not applicable in this Test Report 1.1 TEST FACILITY Shenzhen STS Test Services Co., Ltd. Add.: 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China CNAS Registration No.: L7649; FCC Registration No.: 842334; IC Registration No.: 12108A-1 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission (9KHz-150KHz) ±2.88dB 2 Conducted Emission (150KHz-30MHz) ±2.67dB 3 RF power,conducted ±0.70dB 4 Spurious emissions,conducted ±1.19dB 5 All emissions,radiated(<1G) 30MHz-200MHz ±2.83dB 6 All emissions,radiated(<1G) 200MHz-1000MHz ±2.94dB 7 All emissions,radiated(>1G) ±3.03dB 8 Temperature ±0.5°C 9 Humidity ±2% Page 6 of 23 Report No.: STS1506051E01 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Tablet computer Trade Name Jolla Model Name JT-1501 Serial Model N/A Model Difference N/A Channel List Please refer to the Note 2. Power Rating Battery: Rated Voltage:3.8V Charge Limit: 4.35V capacity : 4450mA Hardware version number N/A Software versioning number N/A Connecting I/O Port(s) USB port*2/ Earphone *1 Note: For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. Page 7 of 23 Report No.: STS1506051E01 2.2 DESCRIPTION OF TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Description Mode 1 USB port do data communication with PC For Conducted Test Final Test Mode Description Mode 1 USB port do data communication with PC For Radiated Test Final Test Mode Description Mode 1 USB port do data communication with PC NOTE: 1.Due to the different configuration and test, in this list only some worse mode. The worst test data of the worse modeis reported by this report. 2.We have be tested for all avaiable U.S. voltage and frequencies(For 120V,50/60Hz and 240V, 50/60Hz) for which the device is capable of operation. 2.3 BLOCK DIGRA…
