2AF27-9317219Node B basestation

NOT PROTECTIVELY MARKED This is an unpublished work the copyright in which vests in Roke Manor Research Limited. All rights reserved. The information contained herein is the property of Roke Manor Research Limited and is supplied without liability for errors or omissions. No part may be reproduced, disclosed or used except as authorised by contract or other written permission. The copyright and the foregoing restriction on reproduction, disclosure and use extend to all media in which the information may be embodied. NOT PROTECTIVELY MARKED X72/HB/9317/219 Issue 00-002 SMARTLINK 3G BTS USER MANUAL (BAND 4 VARIANT) X72/HB/9317/219 NOT PROTECTIVELY MARKED Use, duplication or disclosure of data contained on this sheet is subject to the restrictions on the title page of this document. Page 2 of 102 NOT PROTECTIVELY MARKED Issue 00-002 DOCUMENT RELEASE Prepared by Pete Wilkinson Signature Function Technical Author Approved by David Sherry Signature Function Project Manager DOCUMENT HISTORY Issue No Date CN No Brief Description 00-001 01 Jun 15 - Created document 00-002 30 Oct 15 - Updated safe working distance to .32m. NOT PROTECTIVELY MARKED X72/HB/9317/219 Use, duplication or disclosure of data contained on this sheet is subject to the restrictions on the title page of this document. Issue 00-002 NOT PROTECTIVELY MARKED Page 3 of 102 CONTENTS 1 WARNINGS AND CAUTIONS ................................................................................. 7 1.1 WARNINGS .................................................................................................. 7 1.2 CAUTIONS ................................................................................................... 8 2 PURPOSE AND PLANNING INFORMATION ............................................................ 10 2.1 INTRODUCTION ............................................................................................ 10 2.2 EQUIPMENT IDENTITY .................................................................................... 10 2.3 WARNINGS AND CAUTIONS .............................................................................. 10 2.3.1 Warnings ......................................................................................... 10 2.3.2 Cautions .......................................................................................... 10 2.4 ROLE AND PURPOSE ...................................................................................... 11 2.5 PHYSICAL DATA ........................................................................................... 11 2.6 PERFORMANCE DATA ..................................................................................... 13 2.7 ENVIRONMENTAL DATA ................................................................................... 14 2.8 TRANSPORTATION DATA ................................................................................. 15 2.9 MANNING REQUIREMENTS ............................................................................... 15 2.10 MAINTENANCE POLICY ................................................................................... 15 3 UNPACKING AND DEPLOYING THE SMARTLINK BTS .............................................. 16 3.1 INTRODUCTION ............................................................................................ 16 3.1.1 Warnings and Cautions ...................................................................... 16 3.2 UNPACKING AND INSPECTION ........................................................................... 17 3.3 ASSEMBLY/INSTALLATION ............................................................................... 21 3.4 POWER UP AND FUNCTIONAL CHECKS ................................................................. 23 4 GETTING STARTED WITH A SMARTLINK BTS ....................................................... 24 4.1 INTRODUCTION ............................................................................................ 24 4.2 CONNECTING THE SMARTLINK BTS TO AN IP NETWORK ......................................... 24 4.3 STARTING UP THE SMARTLINK MANAGEMENT CONSOLE AND RESOLVING ANY ISSUES ....... 26 4.3.1 Logging In ....................................................................................... 26 4.3.2 Dashboard ....................................................................................... 27 4.4 CONFIGURING MOBILE PHONES FOR USE WITH THE SMARTLINK NETWORK ................. 28 4.4.1 Inserting USIM into Mobile Phone ....................................................... 28 4.4.2 USIM Final Configuration ................................................................... 28 4.4.3 SMS Configuration ............................................................................ 29 4.5 VERIFYING 3G CONNECTIVITY .......................................................................... 29 4.5.1 Mobile Phone Connection ................................................................... 29 4.5.2 Mobile User Admin on the SMARTLINK Management Console ................. 30 4.5.3 Making Calls and Sending Texts ......................................................... 31 4.5.4 Proving Data Connectivity .................................................................. 31 4.6 POWERING-OFF THE SMARTLINK BTS .............................................................. 32 4.7 BOOTING THE SMARTLINK BTS AFTER POWER-OFF ............................................... 32 4.7.1 Reconnecting Mobile Phones .............................................................. 32 5 SMARTLINK MANAGEMENT CONSOLE .................................................................. 33 X72/HB/9317/219 NOT PROTECTIVELY MARKED Use, duplication or disclosure of data contained on this sheet is subject to the restrictions on the title page of this document. Page 4 of 102 NOT PROTECTIVELY MARKED Issue 00-002 5.1 CONNECTING TO THE SMARTLINK MANAGEMENT CONSOLE ...................................... 33 5.2 SMARTLINK MANAGEMENT CONSOLE OVERVIEW ............…

Text truncated - open the document above for the full version.

Sulis Consultants Limited Mead House, Longwater Road, Eversley, Hampshire, RG27 0NW, UK Registered in England & Wales, number 05466247 http://www.sulisconsultants.com 09 October 2015 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: 2AF27-9317219 To whom it may concern Pursuant to sections 0.457(d) and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application:  Schematics  Bills of Materials  Block Diagram  Operational Description  Tune-up procedure Chemring Technology Solutions have spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Yours Sincerely Charlie Blackham Director

FCC ID: 2AF27-9317219 IC: 20630-9317219

Please note: these are four metal topped DC-DC conv ertors and not RF cans in this photo

EM Field exposure calculation calculation RF Exposure – USA and Canada FCC Maximum Permissible Exposure (MPE) limits for equipment operating in the frequency range 1500 – 100,000 MHz is 1.0 mW/cm 2 which equates to 10 W/m 2 . Industry Canada Maximum Permissible Exposure (MPE) limits for equipment operating in the frequency range 300 – 6000 MHz range is 0.02619ƒ 0.6834 W/m 2 which equates to 4.90 W/m 2 at 2110 MHz. For the purpose of calculating a safe distance, the lower permitted exposure level for Canada will be used The equation S= √ 퐸퐼푅푃 4πS can be written to find safe distance, r: r = √ (PG/4πS) P: power input to antenna(s) in mW G: numeric gain of antenna relative to isotropic radiator S: power density in = 4.9 W/m2 The safe distance from the smartlink antenna shall be the greater of: 20 cm or √ (PG/4πS) Which gives 20 cm or √ (1.9*3.2 / 4 * π * 4.9) cm. Smartlink is designed to be used with one of two standard antennas  External 2 dBi omni-directional antenna  External 5 dBi omni-directional antenna These give the following safe distances from the unit: Antenna gain Safe distance (cm) 2 dBi (1.6 dBd) 21.12 5 dBi (3.2 dBd) 31.25 The recommended safe distance is 0.32 m

Sulis Consultants Limited Mead House, Longwater Road, Eversley, Hampshire, RG27 0NW, UK Registered in England & Wales, number 05466247 http://www.sulisconsultants.com RF Test Report: Roke “Smartlink” FCC ID: 2AF27-9317219 IC: 20630-9317219 SC_TR_168_C Prepared for: Chemring Technology Solutions Old Salisbury Lane Romsey SO51 0ZN UK SC_TR_168_C Page 2 of 25 Contents 1 Revision History .............................................................................................. 4 2 Purpose .......................................................................................................... 4 3 Reference Documents ...................................................................................... 4 4 Test Information ............................................................................................. 5 4.1 Client and manufacturer .......................................................................... 5 4.2 Test Locations ........................................................................................ 5 4.3 Test sample ........................................................................................... 5 5 Product Description.......................................................................................... 6 6 Test Configuration ........................................................................................... 7 6.1 Test sample and Operating mode ............................................................. 7 6.2 Support equipment ................................................................................. 7 6.3 Equipment set-up ................................................................................... 8 6.4 Supported Antennas ........................................................................................ 8 7 Summary of Tests performed ............................................................................ 9 8 Transmit Power .............................................................................................. 10 8.1 Test method ......................................................................................... 10 8.2 Test results .......................................................................................... 10 9 Spectral Power Density ................................................................................... 12 9.1 Test method ......................................................................................... 12 9.2 Test results .......................................................................................... 12 10 Occupied Bandwidth ....................................................................................... 13 11 Conducted Spurious Emissions inc. Band Edge ................................................... 14 11.1 Requirement and test method ................................................................. 14 11.2 Band edge results ................................................................................. 15 11.3 Conducted spurious emissions ................................................................ 16 12 Radiated Spurious Emissions ............................................................................ 19 12.1 Requirement and test method ................................................................. 19 12.2 Results ................................................................................................ 19 12.3 Final pre-scans ..................................................................................... 20 12.4 Initial pre-scans .................................................................................... 21 13 Test equipment and measurement uncertainty ................................................... 25 SC_TR_168_C Page 3 of 25 Tables Table 1: Equipment under test ................................................................................. 7 Table 2: Support Equipment .................................................................................... 7 Table 3: EUT Antenna configurations ......................................................................... 8 Table 4: Summary of tests performed ....................................................................... 9 Table 5: Transmit power ....................................................................................... 10 Table 6: Transmit power spectral density ................................................................ 12 Table 7: Occupied Bandwidth test results ................................................................ 13 Table 8: Conducted spurious emissions (Band edge) ................................................. 15 Table 9: Conducted spurious emissions ................................................................... 16 Table 10: Test Equipment ...................................................................................... 25 Table 11: Measurement uncertainty ........................................................................ 25 Figures Figure 1: Configuration for test ................................................................................ 8 Figure 2: Peak to Average (PAR) plots for two supported modulations ......................... 10 Figure 3: Transmit Power and PAR plots .................................................................. 11 Figure 4: Transmit Power Spectral Density plots ....................................................... 12 Figure 5: Occupied Bandwidth plots – worst case ..................................................... 13 Figure 6: Conducted Spurious Emissions (band edge ................................................. 16 Figure 7: CSE plots: Ch 1587 QPSK ........................................................................ 17 Figure 8: CSE plots: Ch 1587: 16QAM ..................................................................... 18 Figure 9: RSE pre-scans : 30-1000 MHz .................................................................. 21 Figure 10: RSE pr…
