2AF6ERC201Remote Controller for Smart Garden Light

⋹ᐎᐲ䠁ཚ䱣➗᰾、ᢰᴹ䲀ޜਨ GoldenSun Lighting Technology Co., Ltd. ⋹ᐎᐲই⧟䐟儈ᯠᢰᵟഝ४1303ਧ2ਧᾬ3ᾬ 3F, #2 Building, GoldenSun Park, 1303 Nanhuan Road, Quanzhou , China Technical Manual Electrical System Parameters 1. Work voltage：DC 3 V 2. Working current：3.5 mA 3. Harmonic suppression: >50dBc 4. Sensitivity：+8dBm 5. Working frequency：433 MHZ 6. Modulation mode：ASK 7. Antenna impedance：50Ω Federal Communication Commission Interference Statement: 1.This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits Class B digital device. Pursuant to part 15 of the FCC rules. This limits are designed to a provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, The user is encouraged to try to correct the interference by one or more the following measures: -Reorient or relocate the receiving antenna -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected -Consult the dealer on an experienced radio/TV technician for help

NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER AUTHORITY TO OPERATE THE EQUIPMENT

RC 301 RC 301 RC 201 RC 201

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: 2AF6ERC201 MADE IN CHINA This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: 2AF6ERC201 MADE IN CHINA 35mm 25mm Material : PET Adhesive : Propylene Material and adhesive choosed can provide good performance against corrosion or drop

RC 301 RC 301 RC 301 RC 201 RC 201 RC 201

FCC ID: 2AF6ERC201 Report No.: GLU-15SE0087VNTY-1 1 FCC TEST REPORT REPORT NO.: GLU-15SE0087VNTY-1 MODEL NO.: RC30x, RC20x Where x in the model can be any number from 1 to 9. RECEIVED: Oct. 14, 2015 ISSUED: Nov. 11, 2015 APPLICANT: GoldenSun Lighting Technology Co., Ltd. ADDRESS: 3F, #2 Building, GoldenSun Park, 1303 Nanhuan Road, Quanzhou , China MANUFACTURER: Quanzhou GoldenSun Solar Technic Co., Ltd. ADDRESS: 1303 Nanhuan Road, Jiangnan Electronics High-Tech Park, Quanzhou 362000, China ISSUED BY: BUREAU VERITAS ADT (Shanghai) Corporation ADDRESS: 2F, Building C, No.1618, Yishan rd., 201103, Shanghai, China This test report consists of 29 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by A2LA or any government agencies. The test results in the report only apply to the tested sample. The test results in this report are traceable to the national or international standards. This report contains data that were produced under Laboratory ADT (Shanghai) Corporation. FCC ID: 2AF6ERC201 Report No.: GLU-15SE0087VNTY-1 2 Table of Contents 1 CERTIFICATION .......................................................................................... 3 2 SUMMARY OF TEST RESULTS .................................................................. 4 2.1 MEASUREMENT UNCERTAINTY ............................................................... 4 3 GENERAL INFORMATION .......................................................................... 5 3.1 GENERAL DESCRIPTION OF EUT ............................................................ 5 3.2 DESCRIPTION OF TEST MODES .............................................................. 6 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS .............................. 7 3.4 DESCRIPTION OF SUPPORT UNITS ........................................................ 7 4 EMISSION TEST .......................................................................................... 8 4.1 CONDUCTED EMISSION MEASUREMENT............................................... 8 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ............................ 8 4.1.2 TEST RESULTS .......................................................................................... 8 4.2 DEACTIVATION TIME ................................................................................. 9 4.2.1 LIMITS OF DEACTIVATION TIME MEASUREMENT .................................. 9 4.2.2 TEST INSTRUMENTS ................................................................................. 9 4.2.3 TEST PROCEDURES ................................................................................. 9 4.2.4 DEVIATION FROM TEST STANDARD ........................................................ 9 4.2.5 TEST SETUP ............................................................................................... 9 4.2.6 TEST RESULTS ........................................................................................ 10 4.3 RADIATED EMISSION MEASUREMENT .................................................. 11 4.3.1 LIMITS OF RADIATED EMISSION MEASUREMENT ............................... 11 4.3.2 TEST INSTRUMENTS ............................................................................... 13 4.3.3 TEST PROCEDURE .................................................................................. 14 4.3.4 DEVIATION FROM TEST STANDARD ...................................................... 14 4.3.5 TEST SETUP ............................................................................................. 15 4.3.6 EUT OPERATING CONDITIONS .............................................................. 16 4.3.7 TEST RESULTS ........................................................................................ 17 4.4 20DB OCCUPIED BANDWIDTH MEASUREMENT .................................. 22 4.4.1 LIMITS OF BAND EDGES MEASUREMENT ............................................ 22 4.4.2 TEST INSTRUMENTS ............................................................................... 22 4.4.3 TEST PROCEDURES ............................................................................... 23 4.4.4 DEVIATION FROM TEST STANDARD ...................................................... 23 4.4.5 TEST SETUP ............................................................................................. 23 4.4.6 TEST RESULTS ........................................................................................ 24 5 PHOTOGRAPHS OF THE TEST CONFIGURATION ................................. 25 6 PHOTOGRAPHS OF THE EUT ................................................................. 27 7 APPENDIX - INFORMATION ON THE TESTING LABORATORY ............. 29 FCC ID: 2AF6ERC201 Report No.: GLU-15SE0087VNTY-1 3 1 CERTIFICATION PRODUCT: Smart Remote Controller MODEL NO.: RC30x, RC20x Where x in the model can be any number from 1 to 9. APPLICANT: GoldenSun Lighting Technology Co., Ltd. MANUFACTURER: Quanzhou GoldenSun Solar Technic Co., Ltd. TESTED: Oct. 14, 2015~ Nov. 11, 2015 STANDARDS: FCC Part 15: 2015, Subpart C (Section 15.209 and 15.231), ANSI C63.10-2013 We, BUREAU VERITAS ADT (Shanghai) Corporation, declare that the equipment above has been tested in our facility and found compliance with the requirement limits of applicable standards. The test record, data evaluation and Equipment Under Test (EUT) configurations represented herein are true and accurate under the standards herein specified. PREPARED BY : , DATE: Nov. 11, 2015 Alex DU Testing Engineer TECHNICAL ACCEPTANCE : , DATE: Nov. 11, 2015 Joy Zhu Testing Manager APPROVED BY : , DATE: Nov. 11, 2015 Zhaoqian YU Lab Manager FCC ID: 2AF6ERC201 Report No.: GLU-15SE0087VNTY-1 4 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C Standard Paragraph Test Type Resu…
