2AF79BHP-1501Bluetooth headphone

The latest V4.1 bluetooth protocol support multipoint connection, you can connect it to 2 devices at the same time to enable you not miss any call from your two phones: Turn on the headphone and connect it to Phone A. Then switch off the bluetooth on Phone A. Connect the headphone with Phone B. Switch on the bluetooth on Phone A and select the headphone on the bluetooth list to connect. After above steps, The headphone is successfully connected with the two phones, you can listen to music on the last connected phone, and the headphone will auto switch to the phone which there is an incoming call. You can connect your headphone to bluetooth devices by simply tapping your bluetooth device with the headphone’s NFC signal area. Tap again to disconnect Bluetooth connecting. Press and hold the Multifunction button for 3seconds to turn the headphone on. The LED- indicator will flash BLUE when power on. Press and hold the Multifunction button for 3seconds again to turn the headphone off. The LED indicator will off. Note: The headphone will auto power off to save energy when there is no any operation after powerd on for 5mins. When your headphone is low battery, You can charge it via the attached Micro USB cable and connect the headphone to your computer or compatible AC adapter. During charging, the red LED indicator will turn on, and it will auto turn off when the headphone is fully charged. Make sure your phone, computer or music device is turned on. Press and hold Multifuncti button for about 3 seconds until LED light starts to flash BLUE quickly. Activate the Bluetooth feature on your phone or device and set it to search for Bluetooth devices. Select “BHP-1501” from the list of found devices Once successfully paired, the LED light will keep on, or flash BLUE every 0.5 second when play music or FM. FM MAIN SPECIFICATIONS: Bluetooth Version: Bluetooth V3.0 Transmission Distance: 10m Speaker diameter: 40mm Battery: 600mAh Li-polymer battery Charge time: 3 hours Play time: 15 hours Talking time: 16 hours stand-by time: 660 days Frequency response: 20Hz ~ 20KHZ Speaker Sensitivity: 110±3dB @ 1KHz Microphone Sensitivity: -39±3dB @1KHz Signal Noise Ratio: 90dB Impedance: 32 Ohm±10% Distorsion: 1% @ 1KHz Net weight: Approx. 170g Press Multifunction button to start and pause Music. Press to back to previous track. Press and hold to decrease volume. Press to skip to next track. Press and hold down button to increase volume. Press button to switch to FM radio model. the LED light will keep flash BLUE every 0.5 second then. Press and hold button to auto scan available programs. Press to next program, press and hold to Volume up. Press to Previous program, Press and hold to volume down. Note: The FM radio saves detected radio stations, you need to auto scan to detect new and more programs in different environment everytime. press the Multifunction button to answer an incoming call. press the button again to end call. press and hold down button or button To decrease or increase the volume during the call. Double click the Multifunction button to redial lastest call. Bluetooth Headphone 1 32 You can use the headphones as a wired headphone to save battery. Simply connect one end of the 3.5mm cable to the 3.5mm audio port on your headphone and the other end to your phone or device. Note: the headphone must be powered off when Inserting an audio cable to make it wired version. While you listen to music with the headphone wirelessly, you can share the music to another wired headphone by connect anotehr headphone to the wireless headphone via 3.5mm audio cable. Power on / off Answer / End / Re-dial call Volume down Previous Track Volume - / Previous Volume up Next Track Volume + / Next FM FM FM switch / Auto scan Play BHP-1501 Bluetooth When the headphone is connected to Mobile phones, The battery remainning status will be displayed on IOS and Android operation system NFC FM FM ACCESSORIES: 1 x Micro USB charging cable 1 x 3.5mm audio cable 1 x User manual Micro USB charging port Microphone 3.5mm audio port LED indicator 9 NFC signal area 9 NFC Pause Bluetooth + NFC + FM FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Shenzhen Yideou Electronic Technology Co., Ltd 2015/10/17 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, Shenzhen Yideou Electronic Technology Co., Ltd hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product description: Bluetooth headphone model name: BHP-1501 BHP-1402, BHP-1501A, BHP-1502, BHP-1503, BHP-1601, BHP-1602, BHP-1603, BHP-1605, BSK-1501, BSK-1503, BSK-1601, BSK-1602, BSK-1603, BSK-1604, BSK-1606 Trademark: N/A FCC ID: 2AF79BHP-1501 Sincerely, Client’s signature Client’s name / title : Kenny Yan / Manager Contact informations: Unit A of 3F Block 3, No.17 Sanwei Industrial Road, Xixiang Town, Baoan District, Shenzhen, China.

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 Shenzhen Yideou Electronic Technology Co., Ltd 2015/10/18 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AF79BHP-1501 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Client’s name / title : Kenny Yan / Manager Contact informations: Unit A of 3F Block 3, No.17 Sanwei Industrial Road, Xixiang Town, Baoan District, Shenzhen, China.

Shenzhen Yideou Electronic Technology Co., Ltd Model Difference FCC ID: 2AF79BHP-1501 Product description: Bluetooth headphone Model : BHP-1501 BHP-1402, BHP-1501A, BHP-1502, BHP-1503, BHP-1601, BHP-1602, BHP-1603, BHP-1605, BSK- 1501, BSK-1503, BSK-1601, BSK-1602, BSK-1603, BSK-1604, BSK-1606 All the models are the same circuit and RF module, except the mode names and outlook color. Regards Sincerely Client’s signature Client’s name / title : Kenny Yan / Manager Contact informations: Unit A of 3F Block 3, No.17 Sanwei Industrial Road, Xixiang Town, Baoan District, Shenzhen, China.

M/N: BHP-1501 FCC ID: 2AF79BHP-1501 Shenzhen Yideou Electronic Technology Co., Ltd Label location

Antenna location

Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151012762 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 1 of 32 FCC Part 15C Test Report FCC ID: 2AF79BHP-1501 Product Name: Bluetooth headphone Trademark: N/A Model Name : BHP-1501, BHP-1402, BHP-1501A, BHP-1502, BHP-1503, BHP-1601, BHP-1602, BHP-1603, BHP-1605, BSK-1501, BSK-1503, BSK-1601, BSK-1602, BSK-1603, BSK-1604, BSK-1606 Prepared For : Shenzhen Yideou Electronic Technology Co., Ltd Address : Unit A of 3F Block 3, No.17 Sanwei Industrial Road, Xixiang Town, Baoan District, Shenzhen, China. Prepared By : Shenzhen BCTC Technology Co., Ltd. Address : No.101,Yousong Road,Longhua New District, Shenzhen,China Test Date: Oct. 14 – Oct. 17, 2015 Date of Report : Oct. 17, 2015 Report No.: BCTC-151012762 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151012762 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 2 of 32 VERIFICATION OF COMPLIANCE Applicant’s name ................. : Shenzhen Yideou Electronic Technology Co., Ltd Address .................................. : Unit A of 3F Block 3, No.17 Sanwei Industrial Road, Xixiang Town, Baoan District, Shenzhen, China. Manufacture's Name ............ : Shenzhen Yideou Electronic Technology Co., Ltd Address .................................. : Unit A of 3F Block 3, No.17 Sanwei Industrial Road, Xixiang Town, Baoan District, Shenzhen, China. Product description Product name ............................ : Bluetooth headphone Trademark: N/A Model Name: BHP-1501, BHP-1402, BHP-1501A, BHP-1502, BHP-1503, BHP-1601, BHP-1602, BHP-1603, BHP-1605, BSK-1501, BSK-1503, BSK-1601, BSK-1602, BSK-1603, BSK-1604, BSK-1606 Test procedure FCC Part15.249 Standards ANSI C63.10-2013 This device described above has been tested by BCTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Test Result ............................................... : Pass Testing Engineer : (Eric Yang) Technical Manager : (Sophia Lee) Authorized Signatory : (Carson. Zhang) Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151012762 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 3 of 32 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 TEST FACILITY 4 1.2 MEASUREMENT UNCERTAINTY 4 2 . GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 DESCRIPTION OF TEST MODES 6 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 7 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 7 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 8 3 . EMC EMISSION TEST 9 3.1 RADIATED EMISSION MEASUREMENT 13 3.1.1 RADIATED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 15 3.1.5 EUT OPERATING CONDITIONS 16 3.1.6 TEST RESULTS 17 4 . BANDWIDTH TEST 22 4.1 APPLIED PROCEDURES / LIMIT 22 4.1.1 TEST PROCEDURE 22 4.1.2 DEVIATION FROM STANDARD 22 4.1.3 TEST SETUP 22 4.1.4 EUT OPERATION CONDITIONS 22 4.1.5 TEST RESULTS 23 5 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 27 5.1 DEVIATION FROM STANDARD 28 5.2 TEST SETUP 28 5.3 EUT OPERATION CONDITIONS 28 5.4 TEST RESULTS 28 6 . ANTENNA REQUIREMENT 29 6.1 STANDARD REQUIREMENT 29 6.2 EUT ANTENNA 29 7 . EUT TEST PHOTO 30 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151012762 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 4 of 32 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.249) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.249 Fundamental &Radiated Spurious Emission Measurement PASS 15.249 Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 TEST FACILITY Shenzhen BCTC Technology Co., Ltd. Add.:No.101,Yousong Road,Longhua New District, Shenzhen,China FCC Registration No.:187086 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151012762 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 5 of 32 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Bluetooth headphone Trade Name N/A Model Name BHP-1501, BHP-1402, BHP-1501A, BHP-1502, BHP-1503, BHP-1601, BHP-1602, BHP-1603, BHP-1605, BSK-1501, BSK-1503, BSK-1601, BSK-1602, BSK-1603, BSK-1604, BSK-1606 Model Difference All the same, except the mode names and outlook color Product Description Operation Frequency: 2402~2480 MHz Modulation Type: GFSK,PI/4 DPSK,8DPSK Bit Rate of Transmitter 1M/2M/3Mbps Number Of Channel 79 CH Antenna Designation: Please see Note 3. Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Channel List Please refer to the Note 2. Power DC 3.7V DC 5V from adapter Connecting I/O Port(s) Please refer to the User's Manual hardware version -- Software version -- Serial number -- Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2. Channel List Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 00 2402 27 2429 54 2456 01 2403 28 2…

Text truncated - open the document above for the full version.

Radiated Emission Conducted Emission
