2AF8KRF1-1Remote control

1 3 5 7 9 KKOOLLI RCUU Use 2 4 6 8 10 er Ma PO S U S B M H R F P V 1 2 3 4 5 6 7 8 9 10 anua OWER: To sw ‘pow SEARCH : To l Sear and v UP, DOWN, L Menu Long p SELECT(OK) : and c a BACK : To ret MENU : To go App HOME : To re REWIND : Pre Lon FORWARD : P Lon PLAY/PAUSE VOUME KEY T o vo l witch into ‘st wer on” mode launch searc ch input bar virtual keybo LEFT & RIGHT u focusing : M press(pressin To select ite ategory urn to previ o o to Player an menu eturn to Hom ess : Skip 10s ng press : skip Press : Skip 1 ng press : skip : To switch p : Located on o increase or olume level andby’ or e h mode focusing oard active T Move ng) : moving em, function ous screen nd 3 rd party me screen sec (back) pping 10sec 10sec (forwa pping 10sec play or pause the right sid decrease au rd) e de udio FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

KOOLi Inc. Agent Authorization Letter 2015/11/13 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen BCTC Technology Co., Ltd to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s name / title : Changmo Ha / Assistant secretary Contact information / address: 10 Corporate Park,Suite 330 lrvine, California 92606,USA

KOOLi Inc. Long Term Confidentiality Request Letter 2015/11/13 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR EUT NAME: Remote control MODEL : JQH15ARF1-1, JQH15ARF1-2, JQH15ARF1-3 FCC ID: 2AF8KRF1-1 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description required to be submitted with this application be permanently withheld from public review. SPECIFY REASON FOR REQUEST (i.e. the above documents are company proprietary information that could never get into the possession of your competition). Please contact me if there is any information you may need. Sincerely, Client’s name / title : Changmo Ha / Assistant secretary Contact information / address: 10 Corporate Park,Suite 330 lrvine, California 92606,USA

KOOLi Inc. Model Difference FCC ID: 2AF8KRF1-1 Model : JQH15ARF1-1, JQH15ARF1-2, JQH15ARF1-3 All the models are the same circuit and RF module, except the model names and outlook color. Regards Sincerely Client’s signature Client’s name / title : Changmo Ha / Assistant secretary Contact information / address: 10 Corporate Park,Suite 330 lrvine, California 92606,USA

M/N: JQH15ARF1-1 FCC ID: 2AF8KRF1-1 Label location

Antenna location

Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151013503 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 1 of 25 FCC Part 15C Test Report FCC ID: 2AF8KRF1-1 Product Name: Remote control Trademark: N/A Model Name : JQH15ARF1-1, JQH15ARF1-2, JQH15ARF1-3 Prepared For : KOOLi Inc. Address : 10 Corporate Park,Suite 330 lrvine, California 92606,USA Prepared By : Shenzhen BCTC Technology Co., Ltd. Address : No.101,Yousong Road,Longhua New District, Shenzhen,China Test Date: Nov. 5 – Nov. 9, 2015 Date of Report : Nov. 10, 2015 Report No.: BCTC-151013503 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151013503 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 2 of 25 VERIFICATION OF COMPLIANCE Applicant’s name ................. : KOOLi Inc. Address ................................. : 10 Corporate Park,Suite 330 lrvine, California 92606,USA Manufacture's Name ............ : Shenzhen Jinquanhui Technologe Co., Ltd. Address ................................. : 5 floor, building D, Longda Industrial Area, Huating RD, Dalang, Longhua, Shenzhen Product description Product name ........................... : Remote control Trademark: Model Name: JQH15ARF1-1, JQH15ARF1-2, JQH15ARF1-3 Test procedure FCC Part15.249 Standards ANSI C63.10-2013 This device described above has been tested by BCTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Test Result ............................................... : Pass Testing Engineer : (Eric Yang) Technical Manager : (Sophia Lee) Authorized Signatory : (Carson. Zhang) Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151013503 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 3 of 25 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 TEST FACILITY 4 1.2 MEASUREMENT UNCERTAINTY 4 2 . GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 DESCRIPTION OF TEST MODES 6 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 6 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 6 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 7 3 . EMC EMISSION TEST 8 3.1 RADIATED EMISSION MEASUREMENT 10 3.1.1 RADIATED EMISSION LIMITS 10 3.1.2 TEST PROCEDURE 11 3.1.3 DEVIATION FROM TEST STANDARD 11 3.1.4 TEST SETUP 12 3.1.5 EUT OPERATING CONDITIONS 13 3.1.6 TEST RESULTS 14 4 . BANDWIDTH TEST 18 4.1 APPLIED PROCEDURES / LIMIT 18 4.1.1 TEST PROCEDURE 18 4.1.2 DEVIATION FROM STANDARD 18 4.1.3 TEST SETUP 18 4.1.4 EUT OPERATION CONDITIONS 18 4.1.5 TEST RESULTS 19 5 . BANDWIDTH OF FREQUENCY BAND EDGE 21 5.1 DEVIATION FROM STANDARD 21 5.2 TEST SETUP 21 5.3 EUT OPERATION CONDITIONS 21 5.4 TEST RESULTS 22 6 . ANTENNA REQUIREMENT 23 6.1 STANDARD REQUIREMENT 23 6.2 EUT ANTENNA 23 7 . EUT TEST PHOTO 24 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151013503 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 4 of 25 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.249) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A 15.249 Radiated Spurious Emission PASS 15.249 Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 TEST FACILITY Shenzhen BCTC Technology Co., Ltd. Add.:No.101,Yousong Road,Longhua New District, Shenzhen,China FCC Registration No.:187086 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151013503 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 5 of 25 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Remote control Trade Name N/A Model Name JQH15ARF1-1, JQH15ARF1-2, JQH15ARF1-3 Product Description Operation Frequency: 2405~2470 MHz Modulation Type: FSK Number Of Channel 14 CH Antenna Designation: Please see Note 3. Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Channel List Please refer to the Note 2. Adapter N/A Battery DC 3V Connecting I/O Port(s) Please refer to the User's Manual hardware version -- Software version -- Serial number -- Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2. Channel List Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 00 2405 07 2440 01 2410 08 2445 02 2415 09 2450 03 2420 10 2455 04 2425 11 2460 05 2430 12 2465 06 2435 13 2470 3. Table for Filed Antenna Ant. Brand Model Name Antenna Type Connector Gain (dBi) NOTE 1 N/A N/A PCB Antenna N/A 0 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151013503 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 6 of 25 2.2 DESCRIPTION OF TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Frequency …

Text truncated - open the document above for the full version.

Radiated Emission
