2AF9RWETEKAndroid tv box

Usual Manual Products Picture : Specification: Amlogic Quad‐core ARM Cortex A9，Processor Up to 2.0 GHz, GPU: Octo core mali 450, Ram: DDR3 2GB Nand Flash : 8GB OS: Android 5.1.1 or Andorid 4.4.2 WiFi: 802.11 b/g /n/ supports Bluetooth Ethernet: 10m/100m/1000m I/O Ports: 1*HDMI 1.4a; 4*USB HOST; 1* RJ45; 1* 1* AV port; 1*SD Card reader; 1*DC input 12V， Main Functions : Video Format supports : MKV,WMV/VC‐1 SP/MP/AP,MPG,MPEG,dat,avi,mov,iso,mp4,rm,H.264/H.265,realVideo 8/9/10, up to 1080P Audio Format: MP3,AAC,WMA,RM,FLAC,OGG Support language: Multi-Ianguage,Chinese, English, Germany, Japanese, Korea, etc Share center: MiracastDLNA; DLNAetc Appliactions: Browse,Kodi, Netflix, Hulu, Flixster, youtube, Play store, SKYPE, Twitter, Facebook etc FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This device is only used for indoor.

WeTek Electronics Limited Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: SUBJECT: FCC Application for (FCC ID: 2AF9RWETEK) To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite device. We understand that devices subject to the DoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to-government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm Select the "accredited" option to search for FCC recognized accredited test firms. Test facilities located in countries, where the U.S. does not have an operational Telcom MRA are not recognized by the FCC to test for the DoC procedure. Testing laboratory: The Hong Kong Standards and Testing Centre Ltd.( 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong FCC registration number: 607756 Name: Wilson Wong Tel: 852-2666-1888) Regards, Signatory Client’s name / title : Miralem Mehulj / manager Contact information / address: Level 10, Central Building, 1-3 Pedder Street, Central, Hong Kong.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 WeTek Electronics Limited 2015/10/23 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, WeTek Electronics Limited hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product description: Android tv box model n ame: Wetek Core, Wetek Core Light, Wetek Openelec, Wetek Core Openelec+, wetek play, wetek play plus, wetek play+, Wetek Pro, Wetek plus., Wetek Trademark: WETEK FCC ID: 2AF9RWETEK Sincerely, Client’s signature ‘ Client’s name / title : Miralem Mehulj / manager Contact information / address: Level 10, Central Building, 1-3 Pedder Street, Central, Hong Kong.

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 WeTek Electronics Limited 2015/10/23 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AF9RWETEK We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description - FCC SW SECURITY DESCRIPTION The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Client’s name / title : Miralem Mehulj / manager Contact information / address: Level 10, Central Building, 1-3 Pedder Street, Central, Hong Kong.

WeTek Electronics Limited Model Difference FCC ID: 2AF9RWETEK Product description: Android tv box Model : Wetek Core, Wetek Core Light, Wetek Openelec, Wetek Core Openelec+, wetek play, wetek play plus, wetek play+, Wetek Pro, Wetek plus., Wetek All the models are the same circuit and RF module, except the mode names and outlook color. Regards Sincerely Client’s signature Client’s name / title : Miralem Mehulj / manager Contact information / address: Level 10, Central Building, 1-3 Pedder Street, Central, Hong Kong.

WETEK M/N: Wetek Core FCC ID: 2AF9RWETEK This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Label location

Antenna location

FCC §15.247 (i), §2.1091 – RF Exposure FCC ID: 2AF9RWETEK Applied procedures / limit According to FCC §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Note: ƒ is frequency in MHz * = Power density limit is applicable at frequencies greater than 100 MHz Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz * = Plane-wave equivalent power density MPE PREDICTION Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna, R=0.2m TEST RESULTS Tune up Produce power Maximum peak output power (dBm) Output power to antenna (mW) Antenna Gain (numeric) Power Density (S) (mW/ cm2) Limit of Power Density (S) (mW/ cm2) Result WIFI 2.4G 802.11b 16±1 17 50.12 1.62(2.1dBi)0.01617 1 Pass WIFI 2.4G 802.11g 14±1 15 31.62 1.62(2.1dBi)0.01020 1 Pass WIFI 2.4G 802.11n(HT 20) 13±1 14 25.12 1.62(2.1dBi)0.00810 1 Pass 802.11n(HT 40) 12±1 13 19.95 1.62(2.1dBi)0.00644 1 Pass BT 2±1 3 2.00 1.62(2.1dBi)0.00064 1 Pass 5G WIFI 802.11a 15±1 16 39.81 2.24(3.5dBi)0.01773 1 Pass 5G WIFI 802.11n(HT 20) 13±1 14 25.12 2.24(3.5dBi)0.01119 1 Pass 5G WIFI 802.11n(HT 40) 12±1 13 19.95 2.24(3.5dBi)0.00889 1 Pass

Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151012610 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 1 of 58 FCC Part 15C Test Report FCC ID: 2AF9RWETEK Product Name: Android tv box Trademark: WETEK Model Name : Wetek Core, Wetek Core Light, Wetek Openelec, Wetek Core Openelec+, wetek play, wetek play plus, wetek play+, Wetek Pro, Wetek plus., Wetek Prepared For : WeTek Electronics Limited Address : Level 10, Central Building, 1-3 Pedder Street, Central, Hong Kong Prepared By : Shenzhen BCTC Technology Co., Ltd. Address : No.101,Yousong Road,Longhua New District, Shenzhen,China Test Date: Oct. 12 - Oct. 24, 2015 Date of Report : Oct. 25, 2015 Report No.: BCTC-151012610 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151012610 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 2 of 58 VERIFICATION OF COMPLIANCE Applicant’s name ........... WeTek Electronics Limited Address ............................ Level 10, Central Building, 1-3 Pedder Street, Central, Hong Kong Manufacture's Name ...... Videostrong Technology Co., Ltd Address ............................ 402A, Buliding B, Donglian Industrial 23rd District Bao'an, Shenzhen China Product description Product name .......................Android tv box Model Name: Wetek Core, Wetek Core Light, Wetek Openelec, Wetek Core Openelec+, wetek play, wetek play plus, wetek play+, Wetek Pro, Wetek plus., Wetek Test procedure FCC Part15.407 Standards ANSI C63.10-2013 KDB789033 D02 General UNII Test Procedures New Rules v01 This device described above has been tested by BCTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Test Result Pass Testing Engineer : (Eric Yang) Technical Manager : (Sophia Lee) Authorized Signatory : (Carson. Zhang) Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151012610 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 3 of 58 TABLE OF CONTENTS Test Report Declaration Page 1. TEST SUMMARY ............................................................................................................. 4 2. GENERAL PRODUCT INFORMATION ............................................................................ 5 2.1. Product Function .................................................................................................................... 5 2.2. Description of Device (EUT) .................................................................................................. 5 2.3. Test Supporting System ......................................................................................................... 7 2.4. Independent Operation Modes .............................................................................................. 7 2.5. Test Sites ............................................................................................................................... 7 2.6. List of Test and Measurement Instruments ............................................................................ 8 3. TEST SET-UP AND OPERATION MODES ...................................................................... 9 3.1. Principle of Configuration Selection ....................................................................................... 9 3.2. Block Diagram of Test Set-up ................................................................................................ 9 3.3. Test Operation Mode and Test Software ............................................................................... 9 3.4. Special Accessories and Auxiliary Equipment ....................................................................... 9 3.5. Countermeasures to Achieve EMC Compliance .................................................................... 9 4. EMISSION TEST RESULTS ........................................................................................... 10 4.1. Conducted Emission Measurement ..................................................................................... 10 4.2. Radiated Emission Measurement ........................................................................................ 14 5. BAND EDGE COMPLIANCE TEST ................................................................................ 25 5.1. Limits .................................................................................................................................... 25 5.2. Test setup ............................................................................................................................ 25 5.3. Test Data ............................................................................................................................. 25 6. 6DB AND 99% BANDWIDTH TEST ............................................................................... 27 6.1. Measurement Procedure ..................................................................................................... 27 7. OUTPUT POWER TEST ................................................................................................ 37 7.1. Limits .................................................................................................................................... 37 7.2. Test setup ............................................................................................................................ 37 7.3. Test result ............................................................................................................................ 38 8. PEAK POWER SPECTRAL DENSITY TEST ................................................................. 39 8.1. Limits .....................................................................…

Text truncated - open the document above for the full version.

Radiated Emission Conducted Emission
