Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|
| 2 | 15C | 2.42 GHz - 2.45 GHz | 570.00 mW |
Modular TypeSingle Modular ApprovalConfidentialityLong Term Grant NotesSingle Modular Approval. Power listed is maximum combined conducted output power. This module is restricted to installation in products for indoor use only in mobile and fixed applications. Device operates with specific antennas in MIMO configurations as described in this filing. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except as evaluated in this filing or in accordance with FCC multi-transmitter product procedures. The antenna(s) used for this transmitter must not exceed a maximum gain of 2.1dBi in 2.4GHz.. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. This device has 20MHz and 40MHz bandwidth modes.
